Operating Instructions
Type 6027
2/2-way solenoid valve

2
1 OPERATING INSTRUCTIONS
The operating instructions contain important information.
▶Read the operating instructions carefully and follow the safety instruc-
tions in particular, and also observe the operating conditions.
▶Operating instructions must be available to each user.
▶The liability and warranty for the device are void if the operating instruc-
tions are not followed.
1.1 Symbols
▶Designates an instruction to prevent risks.
→designates a procedure which you must carry out.
Warning of injuries:
DANGER!
Imminent danger. Serious or fatal injuries.
WARNING!
Potential danger. Serious or fatal injuries.
CAUTION!
Danger. Minor or moderately severe injuries.
Warns of damage to property:
NOTE!
2 INTENDED USE
Incorrect use of the solenoid valve Type 6027 can be dangerous to
people, nearby equipment and the environment.
▶The device is designed to control, shut o and meter neutral media
up to a viscosity of 21 mm2/s.
▶Provided the cable plug is connected and installed correctly, e.g.
Bürkert Type 2518, the device satises protection class IP65 in
accordance with DIN EN 60529 / IEC 60529.
▶Use according to the permitted data, operating conditions and
conditions of use specied in the contract documents and operating
instructions.
▶Correct transportation, correct storage and installation and care-
ful use and maintenance are essential for reliable and problem-free
operation.
▶Use the device only as intended.
2.1 Denition of term
In these operating instructions, the term “device” always refers to the
Type 6027.
english

3
Risk of short-circuit/escape of media through leaking screw joints.
▶Ensure seals are seated correctly.
▶Carefully screw valve and connection lines together.
General hazardous situations.
To prevent injury, ensure that:
▶Do not make any internal or external changes. Ensure that the sys-
tem cannot be activated unintentionally.
▶Installation and repair work may be carried out by authorized tech-
nicians only and with the appropriate tools.
▶After an interruption in the power supply or pneumatic supply,
ensure that the process is restarted in a dened or controlled
manner.
▶Do not put any loads on the body.
▶For models with ATEX or UL approval follow the safety instructions
in the ATEX manual or on the respective supplementary sheet.
▶The general rules of technology apply to application planning and
operation of the device.
3 BASIC SAFETY INSTRUCTIONS
These safety instructions do not make allowance for any contingencies
and events which may arise during installation, operation and maintenance.
Danger – high pressure.
▶Before loosening the lines and valves, turn o the pressure and vent
the lines.
Risk of electric shock.
▶Before reaching into the system, switch o the power supply and
secure to prevent reactivation.
▶Observe applicable accident prevention and safety regulations for
electrical equipment.
Risk of burns/Risk of re if used continuously through hot device
surface.
▶Keep the device away from highly ammable substances and media
and do not touch with bare hands.
Risk of injury due to malfunction of valves with alternating current
(AC).
Sticking core causes coil to overheat, resulting in a malfunction.
▶Monitor process to ensure function is in perfect working order.
english

4
3.1 Warranty
The warranty is only valid if the device is used as intended in accordance
with the specied application conditions.
3.2 Information on the internet
The operating instructions and data sheets for type 6027 can be found
on the internet at:
www.burkert.com Type 6027
4 TECHNICAL DATA
4.1 Operating conditions
The following values are indicated on the type label:
•Voltage (Tolerance ± 10 %) / Current type
•Coil power consumption (active power in W - at operating
temp.)
•Pressure range
•Body material: Brass (MS), Stainless steel (VA)
•Sealing material: EPDM, PTFE, FKM, PEEK, NBR
•Port connection
Circuit function 2/2-way valve:
A (NC) B (NO)
2(A)
1(P)
2(B)
1(P)
Protection class: IP65 in accordance with DIN EN 60529 / IEC
60529 with cable plug, e.g. Bürkert Type 2518
english

5
4.2 Application conditions
Ambient temperature: max. +55 °C
Permitted medium temperature depending on coil material and sealing
material:
Variant Coil material Seal material Medium temperatur
Standard Epoxid
(NA38)
FKM (FF) –10…+140 °C
EPDM (AA) –30…+120 °C
NBR (BB) –10…+80 °C
PTFE + FKM (EP) –10…+140 °C
PTFE + EPDM (EA) –30…+120 °C
PTFE + PEEK (EP) –40…+180 °C
Hochdruck
MX31 & MX32
PEEK + FKM (TF) –10…+80 °C
PEEK + EPDM (TA) –30…+80 °C
PEEK + PEEK (TT) –40…+80 °C
AC07 PUR + FKM (PC) –10…+100 °C
AC10 / AC07 Polyamid alle –10…+100 °C
HINWEIS!
•Important note for WWB (NO) devices with alternating voltage:
Maximum medium temperature +100°C.
Permitted medium temperature and ambient temperature depending on
sealing material:
Temperatures for valves with UL/UR approval
seal material
Ambient temperature
EPDM (AA)
PTFE + EPDM (EA)
PTFE + FKM (EF)
PTFE + PEEK (EP)
FKM (FF)
–10...+55°C
Medium temperature
EPDM (AA) –30...+120°C
PTFE + EPDM (EA)
PTFE + FKM (EF) –10...+140°C
PTFE + PEEK (EP) –40...+140°C
FKM (FF) –10...+140°C
Operating duration: Unless otherwise indicated on the type label,
the solenoid system is suitable for continuous
operation
Important information for functional reliability during con-
tinuous operation: If standstill for a long period at least 1-2 acti-
vations per day are recommended.
english

6
Medium: neutral gases and liquids which do not attack the
body material, the inner parts of the valves or the
sealing material. Check resistance in individual
cases (www.burkert.com)
4.3 Conformity
In accordance with the EC Declaration of conformity, Type 6027 is com-
pliant with the EC Directives.
4.4 Standards
The applied standards, which verify conformity with the EC Directives,
can be found on the EC-Type Examination Certicate and / or the EC
Declaration of Conformity.
4.5 Type label
Example:
Type
Circuit function
Orice
seal material
Body material
Id.-Number
Voltage, Frequency,
Power consumption
Port connection,
Operating pressure
6027 A 6,0 FKM MS
Made in Germany
00178308 W17MG
24 V 50 Hz 16 W
G1/4 P
N 0 - 6 bar
english

7
5 INSTALLATION
5.1 Safety instructions
DANGER!
Risk of injury from high pressure in the equipment.
▶Before loosening the pipes and valves, turn o the pressure and
vent the lines.
Risk of injury due to electrical shock.
▶Before reaching into the device or the equipment, switch o the
power supply and secure to prevent reactivation.
▶Observe applicable accident prevention and safety regulations for
electrical equipment.
WARNING!
Risk of injury from improper installation.
▶Installation may be carried out by authorised technicians only and
with the appropriate tools.
Risk of injury from unintentional activation of the system and an
uncontrolled restart.
▶Secure system from unintentional activation.
▶Following assembly, ensure a controlled restart.
5.2 Before installation
Installation position: any, actuator preferably upwards.
Procedure:
→Check pipelines for dirt and clean.
→Install a dirt lter before the valve inlet (≤ 0.3 mm).
WARNING!
Medium leaking through damaged connections.
▶Do not damage sealing surfaces of the body connections during
installation.
Danger due to unsuitable screw connections.
▶At high pressures and temperatures ensure that the thread length
(load-bearing thread turns) is adequate for each pairing of materials.
NOTE!
Caution risk of breakage.
•Do not use the coil as a lever arm.
english

8
5.3 Installation – body variant
Procedure:
→Hold the device with a open-end wrench on the body and screw into
the pipeline.
Valve body must not be installed under tension.
Sealing material must not get into the device.
→Observe direction of ow: from 1 →2 (from P → A),
or CF B from P →B.
5.4 Installation – ange variant
Procedure:
→Loosen nut and remove coil.
→Insert seal into body.
→Screw body onto connection plate.
→Install coil (see chapter „5.6“).
→Observe direction of ow:
from 1 →2 (from P → A),
or CF B from P →B.
5.5 Electrical connection of the cable plug
WARNING!
Risk of injury due to electrical shock.
▶Before reaching into the system, switch o the power supply and
secure to prevent reactivation.
▶Observe applicable accident prevention and safety regulations for
electrical equipment.
If the protective conductor is not connected, there is a risk of electric
shock.
▶Always connect protective conductor and check electrical
continuity.
Seal
50 – 60 Ncm
Approved cable plug,
e.g. Type 2518 or other suitable cable plug in
accordance with DIN EN 175301-803 Form A
english

9
→Tighten cable plug (for permitted types see data sheet), observing
max. torque 50-60 Ncm.
→Check that seal is tted correctly.
→Connect protective conductor and check electrical continuity.
5.6 Installation of coil
WARNING!
Risk of escape of media.
When a sticking nut is loosened, medium may escape.
▶Do not tighten sticking nut any further.
Risk of injury due to electrical shock.
If the protective conductor contact between the coil and body is
missing, there is danger of electrical shock.
▶During installation insert the twist lock (plastic ring) into the body
journal. The plastic ring must not project over the octagonal nipple.
▶Check protective conductor contact after installing the coil.
Overheating, risk of re.
If the coil is connected without a pre-installed valve, the coil will
overheat and be destroyed.
▶Connect the coil with a pre-installed valve only.
Twist lock
(plastic ring)
Nut
O-Ring
4 x 90°
Observe tightening torque
„Tab. 1“!
Fig. 1: Installation of coil
Solenoid type Solenoid sizes Tightening torque [Nm]
AC19 (Standard) K (42mm), L (65mm) max. 15 Nm
AC10 5 (32mm), 6 (40mm) max. 5 Nm
AC07 2 (20mm) max. 2.8 Nm
Tab. 1: Tightening torques, solenoid mounting, solenoid types
english

10
6 MAINTENANCE, TROUBLESHOOTING
6.1 Safety instructions
WARNING!
Risk of injury from improper maintenance.
▶Maintenance may be carried out by authorised technicians only and
with the appropriate tools.
Risk of injury from unintentional activation of the system and an
uncontrolled restart.
▶Secure system from unintentional activation.
▶Following maintenance, ensure a controlled restart.
6.2 Malfunctions
If malfunctions occur, check whether:
•the device has been installed according to the instructions,
•the electrical and uid connections are correct,
•the device is not damaged,
•all screws have been tightened,
•the voltage and pressure have been switched on,
•the pipelines are clean.
If the magnet is not attracting
Possible causes:
•Short circuit or coil interrupted,
•core or core area dirty.
english

11
7 SPARE PARTS
CAUTION!
Risk of injury and/or damage by the use of incorrect parts.
Incorrect accessories and unsuitable spare parts may cause injuries and
damage the device and the surrounding area.
▶Use only original accessories and original spare parts from Bürkert.
▶Do not open the uidic part of the device without the consent of the
manufacturer.
7.1 Ordering spare parts
Coil
Fitting
Wearing part set can be requested via
the sales oces by quoting the identi-
cation number of the device.
8 TRANSPORT, STORAGE, DISPOSAL
NOTE!
Transport damages.
Inadequately protected equipment may be damaged during transport.
•During transportation protect the device against wet and dirt in
shock-resistant packaging.
•Avoid exceeding or dropping below the allowable storage
temperature.
Incorrect storage may damage the device.
•Store the device in a dry and dust-free location.
•Storage temperature: -40...+80°C
Damage to the environment caused by device components contami-
nated with media.
•Dispose of the device and packaging in an environmentally friendly
manner.
•Observe applicable regulations on disposal and the environment.
english

www.burkert.com
International address
www.burkert.com
Manuals and data sheets on the Internet: www.burkert.com
Bedienungsanleitungen und Datenblätter im Internet: www.buerkert.de
Manuel d'utilisation et fiches techniques sur Internet : www.buerkert.fr
© Bürkert Werke GmbH & Co. KG, 2016 - 2019
Operating Instructions 1909/04_EU-ML_00805570 / Original DE
Bürkert Fluid Control Systems
Sales Center
Christian-Bürkert-Str. 13-17
D-74653 Ingelfingen
Tel. + 49 (0) 7940 - 10 91 111
Fax + 49 (0) 7940 - 10 91 448
E-mail: [email protected]
