Burkert 8045 User manual

8045
MAGNETIC INDUCTIVE
FLOW TRANSMITTER
INSTRUCTION MANUAL

28045
ENGLISH
INTRODUCTION
1 INTRODUCTION
1.1 Symbol used ..................................................................................................................................................... 3
1.2 General Safety Instructions .......................................................................................................................... 3
2 QUICKSTART
2.1 Installation ......................................................................................................................................................... 4
2.2 Programming .................................................................................................................................................... 5
2.3 Testing 6
3 INSTALLATION
3.1 Installation Guidelines .................................................................................................................................... 7
3.1.1 Mounting Positions ....................................................................................................................... 8-9
3.2 Installation ...................................................................................................................................................... 10
3.3 General Electrical Connection ................................................................................................................ 11
3.4 Electrical wiring for the 8045 flow transmitter ..................................................................................... 12
3.4.1 18-36 VDC without relay ............................................................................................................... 12
3.4.2 18-36 VDC with relays ................................................................................................................... 13
3.4.3 Switches settings ........................................................................................................................... 14
3.4.4 Connection of the Pulse Output ................................................................................................. 14
3.5 Connection Examples ................................................................................................................................. 16
with a Topcontrol 8630 .............................................................................................................................. 16
with a Positioner 1067, without relay ..................................................................................................... 16
with an On/Off Topcontrol 8631 ............................................................................................................. 17
4 PROGRAMMING AND OPERATION
4.1 Operating and Control Guide ................................................................................................................... 18
4.2 Menu Guide ................................................................................................................................................... 19
4.3 Main Menu ...................................................................................................................................................... 20
4.4 Calibration Menu .......................................................................................................................................... 21
4.4.1 Language .......................................................................................................................................... 22
4.4.2 Engineering Units............................................................................................................................ 22
4.4.3 K-Factor ...................................................................................................................................... 23-24
4.4.4 Output Current ................................................................................................................................ 25
4.4.5 Pulse Output .................................................................................................................................... 26
4.4.6 Relay (option) ................................................................................................................................... 27
4.4.7 Filter Function .................................................................................................................................. 28
4.4.8 Totalizer ............................................................................................................................................. 29
4.4.9 50/60 Hz Noise Rejection ............................................................................................................ 29
4.5 Test Menu ....................................................................................................................................................... 30
4.5.1 Offset adjustment ........................................................................................................................... 30
4.5.2 Span adjustment ............................................................................................................................. 31
4.5.3 Calibration of the «flow zero» point ............................................................................................ 31
4.5.4 Flow Simulation ............................................................................................................................... 32
4.5.5 Coefficients Fs and Kw ................................................................................................................. 32
4.6 8045 settings ................................................................................................................................................ 33
4.6.1 8045 Flow transmitter at delivery .............................................................................................. 33
4.6.2 8045 Flow transmitter user configuration ............................................................................... 33
5 MAINTENANCE
5.1 Storing and Cleaning of the Sensor .......................................................................................... 34
5.2 Trouble Shooting Guide......................................................................................................... 34-35
6 ANNEX
6.1 Specifications ........................................................................................................................... 36-37
6.2 Dimensions ....................................................................................................................................... 38
6.3 Design and Measuring Principle ................................................................................................. 39
6.4 Type specification ........................................................................................................................... 40
6.5 Standard Delivery ........................................................................................................................... 40
6.6 Label type.......................................................................................................................................... 40
6.7 Spare Parts ................................................................................................................................ 41-43
Flow diagrams ................................................................................................................................... 44

3
8045
ENGLISH
INTRODUCTION
1.1 SYMBOL USED
Indicates information which must be followed. Failure to follow the
information could endanger the user and affect the function of the
device.
1.2 GENERAL SAFETY INSTRUCTIONS
Before installing or using this product, please read this manual and any
other relevant documentation to ensure you fully benefit from all the
advantages the product can offer.
●Please verify that the product is complete and free from any damage.
●It is the customer's responsibility to select an appropriate transmitter for the
application, ensure the unit is installed correctly, and maintain all components.
●Always check the chemical compatibility of the materials the device is made of.
●This product should only be installed or repaired according to the standards and rules
in force in the country, by specialist staff using the correct tools.
●Please observe the relevant safety regulations throughout the operation, maintenance
and repair of the product.
●When dismounting the transmitter from the pipe, take all the necessary precautions
linked to the process.
●Always ensure that the power supply is switched off before working on the device /
system.
●This electronic device is sensitive to electrostatic discharge; To avoid any damage by
immediate electrostatic discharge, pay attention to the requirements of EN 100 015-1.
●Always protect the device from electromagnetic perturbations, ultraviolet radiations
and, when installed outside, from the effects of climatic conditions.
●If these instructions are ignored, no liability will be accepted and the guarantee on the
device and accessories will become invalid.

48045
ENGLISH
QUICKSTART
Unpacking
Verify
Order code
Install the fitting
on the piping
Unscrew the 4
screws and open
Connect power
supply cable
Connect output
cable
Re-assemble the unit
and install onto the
fitting
Connect the earth to
the earthing screw
Turn on the
power
Check
display is 0
with no flow
Enter the
K-Factor
Program the Transmitter
This section provides a comprehensive installation and operation guide which will assist
with the commissioning of the 8045 Flow Transmitter.
2.1 INSTALLATION
O.K
Yes
No
No
Verification of items received.
See section 6.4
Contact your local Bürkert
subsidiary
Ensure the power supply
is disconnected before
starting work.
Ensure that security provisions
are considered with the
power cable and relay circuit.
Pay attention to the max.
permitted load of
the output current
loop.
The sensor finger must be
immersed in fluid 24 hours
before calibration (section 4.5.3)
Immerse the transmitter
into the fluid and perform
a „flow zero“ point
calibration
See section 4.4.3
See section 6.4
See section 3.4
See the next page.
See
section 3.3.1
See section 3.1

5
8045
ENGLISH
QUICKSTART
To access the CALIBRATION MENU simultaneously press for 5 seconds.
●Ensure that the enter key is unlocked - section 3.4.1
●Reference can additionally be made to the menu guide - section 4.2.
2.2 PROGRAMMING
The actions which are highlighted in grey must be fully completed for accurate
measurement.
Choose the
desired language
Select the desired
units
Calculate the
K Factor
Select current
output range
Select the pulse
output parameters
Configure relays
1 & 2 (if available)
Choose the
desired filter
Reset the totalizer
Selection of the
AC Frequency
Measurement or Simulation (optional)
ENTER
See section 4.4.1
See section 4.4.2
See section 4.4.3
See section 4.4.4
See section 4.4.5
See section 4.4.6
See section 4.4.7
See section 4.4.8
See section 4.4.9
Ex. Select the units l/s with 1 decimal
point and select m3for the totalizer
display.
Ex. 4 mA = 0 l/s and
and 20 mA = 10 l/s.
Ex. 1 pulse corresponds to 100 l.
2 types of filter available each with 10
levels of damping.
To avoid resetting of the totalizer, set the
internal switch 2 into the locked position
(see § 3.4.1).
To cancel any noise generated
by the main AC frequency.
See the next page.

68045
ENGLISH
QUICKSTART
To access the TEST MENU simultaneously press for 5 seconds.
2.3 TESTING
See Section 4.5.1
See Section 4.5.2
See Section 4.5.3
See Section 4.5.4
See Section 4.5.4
The actions which are highlighted in grey must be fully completed for accurate
measurement.
ENTER
Control of 4 mA
Control of 20 mA
„Flow zero“ point
Calibration
Simulation of
the outputs
Enter Fs and Kw
The unit is now ready
The Offset mode fixes the output
current of 4mA.
The mode Span fixes the output of
20mA.
Put the displayed value at 0.00 in the
selected unit when the liquid in the
pipe is not moving.
This is optional although it is
recommended for commissioning large
systems.
These values enable the calculation of
the process K factor.

7
8045
ENGLISH
INSTALLATION
3.1 INSTALLATION GUIDELINES
●Pressure - Temperature Diagram
Please be aware of the fluid pressure-temperature dependence according to
the respective fitting+sensor material as shown in the diagram below.
8045 with a PVDF sensor
8045 with a stainless steel sensor
Ensure that the device is not located near any large machinery which may interfere with
the transmitter as this can have an effect on the measurement readings.
-40 -10 +20 +50 +80 +110
2
4
6
8
10
16
P medium (Bar)
T medium (°C)
PP (PN10)
PVC (PN10)
PVC + PP (PN10)
PVDF (PN10)
PVDF (PN10)
Metal
Application range
-40 -10 +20 +50 +80 +110
2
4
6
8
10
P Medium (Bar)
T Medium (°C)
PVDF
PVC + PP
PVC
PP
PVDF / Metal
Application range

88045
ENGLISH
INSTALLATION
In order to ensure a high precision of the measure and good stability of
the „flow zero“ point, the transmitter must be installed into the
processed medium at least 24 H before calibration (electrode
passivation).
Dismounting precautions:
All precautions must be taken before removing the transmitter
depending on the process used as the pipe may contain dangerous /
agressive hot fluids or fluids with high temperatures or pressures.
3.1.1 Mounting positions
The 8045 electromagnetic flow transmitter can be mounted in the following ways to obtain
an accurate flow measurement although the piping should be designed to ensure that the
pipe is maintained full at all times to avoid inaccurate measurement.
Mounting horizontally
Mounting vertically
●When mounting vertically ensure that the flow direction is in an
upward direction as indicated by the arrow.
●Always mount the transmitter upstream a possible injection point in
the pipe of a high-conductivity product (acid, base, saline,...).
It is advisable to mount the transmitter at a 45°angle
to the horizontal centre of the pipe as shown in the
diagram to avoid having deposits on the electrodes
and false measurements due to air bubbles.
45°
45°
Correct Incorrect
Correct Incorrect
Flow direction
Flow direction
Flow direction

9
8045
ENGLISH
INSTALLATION
3 x DN10 x DN
Mounting direction and flow measuring:
The flow value displayed by the transmitter is positive whatever the mounting direction of
the device, but the totalizer increases or decreases depending on several parameters,i.e.:
●8045 with a PVDF sensor:
The totalizer increases when the arrow on the side of the housing indicates the
flow direction, the lug shows the upstream direction and the marked coax cable
is connected according to fig. 3.3 or 3.4.
●8045 with a stainless steel sensor:
The totalizer increases when the arrow on the side of the housing indicates the
flow direction, the cable glands show the downstream direction and the marked
coax cable is connected according to fig. 3.3 or 3.4.
The minimum straight upstream (10 x DN) and downstream (3 x DN) distances must be
observed.
Please ensure that the pipe design does not allow the build up of air
bubbles or cavities within the medium as this will cause measuring
errors.
Lug of the transmitter
(PVDF sensor)
Flow direction
Flow direction
Flow direction
Correct Incorrect
Correct Incorrect

10 8045
ENGLISH
INSTALLATION
3.2 INSTALLATION
The 8045 flow transmitter can be installed into pipes using our specially designed fitting
system S020. DEUTSCH
The fitting 4must be installed into the pipe according to the installation specifications
within section 3.1.
●Insert the plastic nut 3onto the fitting 4 and snap the plastic ring 2into the
guide-bush 5.
●Insert the sensor into the fitting ensuring the arrow on the side of the housing
indicates the flow direction, and:
Version with a PVDF sensor: ensuring the sensor is sitting correctly, making
sure that the lug 6 is aligned correctly onto the fitting.
Version with a stainless steel sensor: ensuring the cable glands show the
downstream direction and the alignment of the electrodes is perpendicular to
the flow direction.
If the mounting is correct, the sensor housing 1cannot be rotated.
The plastic nut must only be tightened by hand!
Fig. 3.1 Installation of flow transmitter
1
2
3
5
4
6
Flow direction
(PVDF sensor only)

11
8045
ENGLISH
INSTALLATION
(*)(*)
+
-
(**)
18-36VDC
3.3 GENERAL ELECTRICAL CONNECTION
●Use cables with a temperature limit of 80°C minimum.
●For normal operating conditions the measuring signal can be transmitted by a
shielded cable of 0.75 mm2 cross section.
●The line must not be installed in combination with carrying lines with a higher
voltage or frequency.
●If a combined installation cannot be avoided, a minimum space of 30 cm (1 ft)
should be respected.
●The cable diameter must be between 6 and 12 mm;
If 2 cables are needed, use the supplied multiway seal and 4-mm diameter cables.
●The power supply must be filtered and regulated - section 6.1
●Ensure the equipotentiality of the installation (power supply - transmitter - fluid):
- The various earth spots in the installation have to be connected together to
eliminate the potential differences that may occur between different earthes.
- Observe faultless grounding of the shield at both ends of teh cable.
- Earth the negative terminal of the power supply to suppress the common
mode currents. If direct earthing is not possible insert a 100 nF-condensator
between the negative terminal and the earth.
Special attention has to be paid if the transmitter is installed on plastic pipes
because there is no direct earthing possible.
Proper earthing is performed by earthing together the metallic devices such as
pumps or valves, that are as close as possible to the magmeter. If no such devices
are present, insert metallic piping parts (earthing rings, not supplied) into the
plastic pipes before and after the magmeter and earth them together. The earthing
rings shown in the diagram below must be in contact with the fluid.
Metallic devices (valve, pump, etc)
For plastic pipe applications
(*) or metallic parts, not supplied, inserted inside the pipe.
(**) If direct earthing is impossible, connect a 100 nF-condensator between the negative terminal and the
earth.
Shielding
Inside of the housing: Connect the shielding to the earth.
Take care not to completely untighten the screw. Insert shielding.
Retighten screw

12 8045
ENGLISH
INSTALLATION
P+
300 mA
4-20 mA +
-
18-36 VDC
+
-
-
+
I
P-
POS A
6
5
4
3
21
(*)
●Do not open and wire the transmitter with the power supply
connected.
●It is advisable to put security devices on :
Power supply: Fuse (300 mA) and an interrupter
Relay: 3A max. fuse and circuit breaker (depending on
application).
●Do not apply both a dangerous voltage and a very low safety
voltage to the relays.
3.4 ELECTRICAL WIRING FOR THE 8045 FLOW TRANSMITTER
3.4.1 18-36 VDC without relays
Lift the transparent lid after having unfastened the screw. Remove the cover via the
screws on the front display and pull the cable through the cable glands and wire
according to one of the pin assignment diagrams below.
The electronics within the 8045 allows a PLC with a sourcing or sinking 4-20 mA entry to
be connected. Position A (Fig 3.3) provides a sourcing configuration and Position B
(Fig 3.4) a sinking configuration.
Seal the unused cable gland using the supplied obstructor to ensure the
tightness of the transmitter. Unscrew the cable gland nut, insert the
obstructor and screw the nut back on the cable gland.
Fuse
PLC /
Valve
Coax connections
Power
supply
LockUnlock
ENTER
Flat cable connection
Fig. 3.3 Sourcing configuration - Position A
Switch 2
Switch 1
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.

13
8045
ENGLISH
INSTALLATION
4-20 mA
18-36 VDC
+
-
REL 2
P+
-+
P-
REL 1
230 VAC
m
3 A
3 A
230 VAC
300 mA
654321
(*)
300 mA
4-20 mA
+
-
18-36 VDC
+
-
I
POS B
P+
-+
P-
654321
(*)
3.4.2 18-36 VDC with relays
Lift the transparent lid after having unfastened the screw. Remove the cover via the
screws on the front display and pull the cables through the cable glands and wire
according to pin assignment diagram below (Fig. 3.5).
Use the supplied cable clip to fasten the wires originating from the relay
module.
Fig. 3.5 Pin assignment for relays
The device can be easily connected to a PLC independently of the respective version.
Fuse
PLC /
Valve Power
supply
Power
supply
LockUnlock
ENTER
Coax connections
Flat cable connection
Switch 2
Coax connections
Flat cable connection
Fuse
Switch 2
Switch 1
Fig. 3.4 Sinking configuration - Position B
(*) If direct earthing is
impossible, connect a
100 nF / 50 V-condensator
between the negative terminal
and the earth.
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.

14 8045
ENGLISH
INSTALLATION
3.4.3 Switch Settings
Switch1: This switch allows a sinking or sourcing PLC to be connected (output
current). For further information see section 3.4.1.
Switch2 : ●This switch allows the ‘Enter‘ key to be locked to avoid accidental
or unauthorized access to the Programmation and Test menus.
●The Switch2 when set in the unlocked position allows the
parameter values to be changed (K-Factor, relays, current, ...)
and when in the locked position access to the programmation and
test menus is restricted.
3.4.4 Connection of the Pulse Output
The pulse output can be easily connected to a PLC or counter independently of the power
supply or version.
3.4.4.1 Connection of a PLC
Fig. 3.6 PLC with common - Fig. 3.7 PLC with common +
V+ 0V INPUT
P+
-+
P-
654321
P+
-+
P-
V+ 0V INPUT
654321
Current Current

15
8045
ENGLISH
INSTALLATION
3.4.4.2 Connection of a load
Fig. 3.8 Electromechanical counter Fig. 3.9 Electronic counter with
or relay powered input
In the figures above ensure that the current does not exceed 100 mA.
Example:
For calculation of the load the following equation can be used;
Load = V Example:
IV = 30V
I = 20mA
Load = 1500 Ω
V1GND1 V2GND2
P+
-+
P-
654321
P+
-+
P-
V+ 0V
654321
Load
Load
Current
Current

16 8045
ENGLISH
INSTALLATION
24 V=
R1
9
10
78
65
34 12
+-+- +-
Setpoint + Setpoint -
+
-
4-20 mA
P+
-+
P-
REL 1
300 mA
654321
(*)
4-20 mA
24 V=
-
+
-+ 24 V I/O4 I/O3 I/O2 I/O1 GND2 I2 I1
U1
GND1
24 VDC PE 4-20 mA
0/4-20 mA
0-10 V
P+
-+
P-
REL 1
300 mA
654321
(*)
Connection between the 8045 flow
transmitter 18-36VDC and the 1067
positioner mounted on a diaphragm
valve 2031.
CONTINUOUS PNEUMATIC FLOW CONTROL
PLC
POSITIONER 1067
3.5 CONNECTION EXAMPLES
Connection between the 8045 flow
transmitter 18-36VDC and the
8630 Top Control mounted on a
diaphragm valve 2031.
PLC
Jumper
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.

17
8045
ENGLISH
INSTALLATION
4-20 mA
V=
V
24 V=
+
-
9
8
7
6
5
4
3
2
1
P+
-+
P-
REL2
REL 1
300 mA
654321
24 V=
+
-
(*)
Pilot valve
Connection between the 8045 flow transmitter
18-36VDC and the 8631Top Control mounted on
a diaphragm valve 2031 and a pilot valve 6012.
ON/OFF FLOW CONTROL
PLC
Top Control
On/Off
(*) If direct earthing is impossible, connect a
100 nF / 50 V-condensator between the
negative terminal and the earth.

18 8045
ENGLISH
OPERATION
4.1 OPERATING AND CONTROL GUIDE
Display
Selection of parameters
and incrementation
of digits.
Keys Menu Mode Finding a value
Previous Menu Increase from the blinking digit
Next Menu Advance to the next digit
Activate the menu displayed Validate the displayed value
(If “END“ is displayed,
save the modified
parameters and return
to the main menu
+ Resetting of the daily totalizer*. Modification of the decimal point:
2 Seconds (only available within daily totalizer Know the K-Factor and impulse
option § - 4.3) volume
+ Access or return to the
CALIBRATION MENU*
5 Seconds
+ + Access or return to the TEST
5 Seconds MENU*
* Only available within the main menu.
The Key can be locked to avoid accidental or unauthorized access.
For further information see sections 3.4.1 & 3.4.3.
ENTER
ENTER
ENTER
ENTER
0......9
0......9
0......9
Selection and confirmation.
Indication of the state of
relays 1 and 2.
(LED on = closed contact )
Selection of parameters
and digits.

19
8045
ENGLISH
OPERATION
4.2 MENU GUIDE
The menu guide below will assist in quickly and easily finding a desired parameter and
programming the 8045 flow transmitter.
ENTER
0......9
ENTER
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
0......9
ENTER
5 s
5 s
+
++
ENTER
0......9
0......9
CALIBRATION MENU
TEST MENU
LANGUAGE
UNIT
K-FAKTOR
CURRENT
PULSE
RELAY
FILTER
TOTAL
FREQUENC
END
OFFSET
SPAN
CALIB 0
FLOW
K-SENSOR
END

20 8045
ENGLISH
MAIN MENU
4.3 MAIN MENU
The following information is displayed within the Main Menu:
Flowrate : This is displayed in the selected engineering units
(see calibration menu).
Output Signal : The output signal is 4-20mA and is
proportional to the flow according to the selected measuring
range.
Main Totalizer : This is displayed in the required engineering
units (see calibration menu). To reset this totalizer see section
4.4.8 in the next menu.
Daily Totalizer : This is displayed with the same engineering
units as the main totalizer. A point behind the unit differentiates
this totalizer from the main totalizer. To reset this value,
simultaneously press the keys for 2 seconds within
this menu.
0......9
12.6 L/S
16.45 mA
80529 L
6247 L .
0......9
