BWI Eagle AIR-EAGLE SR PLUS 36-1400-4B-DC Manual

PRODUCT INFORMATION
BULLETIN
238 Pillow Street
Butler, PA 16001
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®SR PLUS
2.4 GHz RF Transmitter
MODEL 36-1400-4B-DC – Rev.3
DESCRIPTION
The AIR-EAGLE SR PLUS, MODEL 36-1400-4BIs an R.F. transmitter
capable of sending up to four digital button commands to the Air-Eagle
SR Receiver, model 38-2000 or 38-8000 from up to 1200 feet away.
This unit is user-programmable for up to 128 digital addresses and
eight network frequencies to allow multiple transmitters and receivers
to operate simultaneously in the same area without interference.
INSTALLATION
1. Mount the AIR-EAGLE SR PLUS TRANSMITTER in a convenient
location where the operator willhave easyaccess to allbuttons.
2. Install antenna. The unit has an antenna connector located on the
rightside on the enclosure.Attach the supplied portable antenna to
this connector.
3. Connect DC power and control to the proper terminals in your control
circuit.
DIGITAL ADDRESS & FREQUENCY SET-UP
This transmitter is factory programmed to Frequency #1 and Digital
Address“0”. These settings can be changed by the user in any
combination but must matchthe receiver that is set upto
communicate with this transmitter.If using this transmitter with a
model 38-2000 4-relay receiver, the digital address must be kept at
the default of Digital Address “0”.
1) Remove top cover.
2) Selectdesiredaddress and/or network frequency
3) Move SW4 on SEL2 to the “CLOSED” position. The TXLED will
illuminate (no datais being transmitted during this programming)
4) Once LEDis illuminated, move SW4 on SEL2 back to the
“OPEN” position. The TX LED will extinguish.
5) Programming is now complete.Replace topcover.
Note – Selected address and frequency settings will be maintained, in
the internal flash memory, even if power is removed from unit. The
above procedure needs to be performed onlyif changing digital
address and/or network frequency)
SEL1 (ADDRESS) Seven dip switches for selectingdigital address of this
transmitter (Maximum of 128 combinations)
Network
Address SW1 SW2 SW3
1 OPEN OPEN OPEN
2 CLOSED OPEN OPEN
3 OPEN CLOSED OPEN
4 CLOSED CLOSED OPEN
5 OPEN OPEN CLOSED
6 CLOSED OPEN CLOSED
7 OPEN CLOSED CLOSED
SEL 2 (SW 1-3):
(NETWORK
FREQUENCY)
8 CLOSED CLOSED CLOSED
Normal Operation Programming
SEL2 (SW4) OPEN CLOSED
Dimensions (withmounting plate) 6.3” L x 4.8” W x 2.3” H
CONTROLS & INDICATORS
TX LED Illuminates continuously while any button is
depressed and unit is transmitting.
Pushbuttons 1 thru 4 Transmits individual button RF codes to the
receiver
APPROVALS
United States (FCC) OUR-XBEEPRO
Canada (IC) 4214A-XBEEPRO
Europe (CE) ETSI

AIR-EAGLE®SR PLUS
2.4 GHz RF Transmitter
MODEL 36-1400-4B-DC – Rev.3
SPECIFICATIONS
DC Input 9 - 36 VDC @ 10Watts
Four Dry Contact Inputs Pre-wired to included pushbuttons
Enclosure ABS Plastic NEMA 3, 3R, 4, 12 + 13
Transmit Frequency 2.4GHz Spread Spectrum
Transmitter Coding
128 Digital Addresses
(Available only when communicating with model
38-8000)
Transmitter Channels 8 Independent Network Frequencies
Antenna Connection TNC Female
RF Output Power 60 mW
Transmit Range Approximately 1200 Feet
Operating Temperature -40oF to +185oF
REPLACEMENT PARTS & ACCESSORIES
PC Board (Main) 36-1402-4B-DC
Standard Antenna (Included):
2.4GHz TNC Portable Antenna (For
distances up to 1200 feet*) 49-1201
Optional Antennas and Accessories –
Used to increase range in both non line of sight and line of sight
applications. - Contact BWI Eagle for recommendations
2.4GHz Thru-Hole Mount Mobile Antenna 49-2201
2.4GHz Magnetic Mount Mobile Antenna 49-2202
2.4GHz Omni Directional Antenna 49-3201
2.4GHz 13dB Yagi Antenna 49-3202
Flex Coax Cable w/Connectors – Connects
external antenna(s) to base unit(s). 49-4000-XX (XX = # of Feet)
Inline Lightening Arrestor 49-5002
* = Line of Sight
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial andworkmanship
for a period of 1 year after date of purchase. Said warrantyto include the
repair or replacement of defective equipment. This warrantydoes not
cover damage due to externalcauses, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair, improper installation, or improper
testing. This limited warranty, and any implied warranties thatmayexist
under state law, applyonlyto the original purchaser of the equipment,and
last only for as long as such purchaser continues to own the equipment.
This warrantyreplaces all other warranties, express or implied including,
but not limited to, the implied warranties or merchantability and fitness for
a particular purpose. BWIEagle makes no express warranties beyond
thosestated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allow the exclusionof implied warrantiesso this limitation maynot
apply to you. To obtain warrantyservice, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss during shipping and is
responsible for the shipping costsincurred.
DOCUMENT DATE: 18-Jul-07
