BWI Eagle AIR-EAGLE SR PLUS Manual

PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE® SR PLUS
2.4 G
Hz
RF
Transmitter
MODEL
3
6
-
1
0
1
00
-
DC
I
-
DC
DESCRIPTION
The AIR-EAGLE SR PLUS TX Is an R.F. transmitter capable of sending
a single 5-24VDC input command to an Air-Eagle SR Receiver located
up to 600 feet away. Any number of transmitters and receivers can be
combined to create a medium range radio frequency system that
operates hazardous or hard-to-reach electrical apparatus from safe,
convenient locations. Eight user-selectable frequencies allow multiple
systems to operate simultaneously in the same area without
interference.
APPROVALS
United States (FCC) OUR-XBEEPRO
Canada (IC) 4214A-XBEEPRO
Europe (CE) ETSI
INSTALLATION
DISCONNECT DC Power from all equipment before installation.
1. Mount the AIR-EAGLE SR TRANSMITTER in a convenient location.
2. Install wiring to input terminal strip
3. Install antenna. The unit has an antenna connector located on the
right side on the enclosure. Attach the supplied portable antenna to
this connector.
4. Connect DC power to the proper terminals in your control circuit.
TERMINAL STRIP WIRING
TER 3
VOLTAGE INPUT
TER 2
RELAY OUTPUT
TER 1
AC/DC POWER INPUT
1 DC common 1 Not Used 1 (-) 9-36VDC
2 +5-24VDC 2 Not Used 2 (+) 9-36VDC
3 Not Used 3 Not Used
GENERAL OPERATION
When 5-24VDC appears on the input the unit transmits to energize relay 1
(or another relay as selected by the channel code transmitted) in any
receiver within transmit range. The signal transmits continuously as long
5-24VDC is present and ceases when 5-24VDC is removed.
Dimensions (with mounting plate) 7.07L x 3.57W x 1.62H
CONTROLS AND INDICATORS
Power – LED1 Illuminates green when unit is powered
TX – LED2 Illuminates red when unit is transmitting
Relay – LED3 Not used on this model
RF1 RF module that sends data to the remote
receiver
SEL1 Seven dip switches for selecting options and
network
freq
uency
TER
3
Voltage
i
nput
TER2 Relay output
TER1
Power Input

AIR-EAGLE® SR PLUS
2.4 G
H
z
RF Transmitt
er
MODEL
3
6
-
1
0
1
00
-
D
C
I
-
DC
CHANNEL CODE & FREQUENCY SET-UP
The unit is shipped from the factory with all SEL1 switches in the open
positions. By default it is transmitting Channel #1 code and operating on
Frequency #1. If you wish to transmit a different channel code or and/or
change the frequency, follow the instructions on the table below.
1) Remove power from unit
2) Remove top cover.
3) Select desired channel code and/or frequency using table below.
4) Reattach cover and apply power.
5) Programming is now complete.
CHANNEL SELECT
ION
SET
-
UP
SEL1 (SW1-4)
Channel
Code To Be
Transmitted
SW1 SW2 SW3 SW4
1
(default)
OPEN
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
OPEN
3
O
PEN
CLOS
E
D
OPEN
OPE
N
4
CLOSED
CLOSED
OPEN
OPEN
5
O
PEN
OPEN
CLOSED
OPEN
6
CLOSED
OPEN
CLOSED
OPEN
7
OPEN
CLOSED
CLOSED
OPEN
8
CLOSED
CLOSED
CLOSED
OPEN
9
OPEN
OPEN
OPEN
CLOSED
10
CLOSED
OPEN
OPEN
CLOSED
1
1
OPEN
CLOSED
OPEN
CLOSED
1
2
CLOSED
CLOSED
O
PEN
CLOSED
1
3
OPEN
OPEN
CLOSED
CLOSED
1
4
CLOSED
OPEN
CLOSED
CLOSED
1
5
O
PEN
CLOSED
CLOSED
CLOSED
1
6
CLOSED
CLOSED
CLOSED
CLOSED
FREQUENCY SET
-
UP
SEL1
(SW5-7)
Network
Frequency
SW5 SW6 SW7
1
(default)
OPEN
OPEN
OPEN
2
CLOSED
OPEN
OPEN
3
OPE
N
CLOSED
OP
EN
4
CLOSED
CLOSED
OPEN
5
OP
EN
OPEN
CLOSED
6
CLOSED
OPEN
CLO
SED
7
OPEN
CLOSED
CLOSED
8
CLOSED
CLOSED
CLOSED
SPECIFICATIONS
D
C Input
9
–
36
VDC
, 5 W
Transmitter
Frequency
2.4 GHz Spread Spectrum
RF Output Power
60 mW
Transmit Range Approximately 600 Feet
Transmitter
Frequ
encies
8 Independent Net
work Fre
q
uenc
ies
Antenna Connection TNC Female Connector
Operating Temperature
-
40
o
F to +185
o
F
Enclosure
Polycarbonate NEMA 4, 12, 13 – IP66
Weight
Approx 2 lbs.
DIMENSIONS
REPLACEMENT PARTS & ACCESSORIES
PC Board (Ma
in)
36
-
1
0
1
02
-
D
C
Standard
Antenn
a (Incl
uded):
2.4GHz TNC Portable Antenna (For
d
ista
nces up to 6
00 feet*)
49
-
1201
Optional Antennas and Accessories –
Used to increase range in both non line of sight and line of sight
applications.
-
Contact BWI Eagle fo
r recommendations
2.4GHz Thru
-
H
ole Mou
nt Mobil
e
Ant
enna
4
9
-
2201
2.4GHz Magne
tic
Mou
nt Mobile Antenna
49
-
2202
2.4GHz Omni Directional Antenna
49
-
3201
2.4GHz 13dB Yagi Antenna
49
-
3202
Flex Coax Cable w/Connectors – Connects
external antenna(s) to base
unit(s).
49-4000-XX
(X
X = # o
f Feet)
2 Ft. Bulkhead Assembly (Used when
mo
unting receive inside another enclosure)
49
-
5004
-
2
-
ISO
* = Line of Sight
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants the Air-Eagle Remote Control System, if properly used and
installed, will be free from defects in material and workmanship for a period of 1 year
after date of purchase. Said warranty to include the repair or replacement of defective
equipment. This warranty does not cover damage due to external causes, including
accident, problems with electrical power, usage not in accordance with product
instructions, misuse, neglect, alteration, repair, improper installation, or improper
testing. This limited warranty, and any implied warranties that may exist under state
law, apply only to the original purchaser of the equipment, and last only for as long as
such purchaser continues to own the equipment. This warranty replaces all other
warranties, express or implied including, but not limited to, the implied warranties or
merchantability and fitness for a particular purpose. BWI Eagle makes no express
warranties beyond those stated here. BWI disclaims without limitation, implied
warranties of merchantability and fitness for a particular purpose. Some jurisdictions
do not allow the exclusion of implied warranties so this limitation may not apply to
you. To obtain warranty service, contact BWI Eagle for a return material
authorization. When returning equipment to BWI Eagle, the customer assumes the
risk of damage or loss during shipping and is responsible for the shipping costs
incurred.
DOCUMENT DATE: 07/30/19 / PRODUCT REV. 5
