BWI Eagle AIR-EAGLE XLT Manual

PRODUCT INFORMATION
BULLETIN
105 Bonnie Drive
Butler, PA 16002
724-283-4681
724-283-5939 (fax)
www.bwieagle.com
AIR-EAGLE®XLT
900MHz RF Transmitter
MODEL 44REB-1300
DESCRIPTION
The AIR-EAGLE XLT TX Is a handheld R.F. transmitter designed to send
a single STOP command to the Air-Eagle XLT Receiver, Model 44P-8-
ESTOP receiver from up to 2500 feet away. When powered on, this
transmitter begins sending a heartbeat “beacon” signal to the receiver
which keeps the relays in an energized state, thus providing a failsafe
link. When the STOP button is depressed, the relays in the receiver
de-energize. If the transmitter loses link to the receiver, the relays also
de-energize. To save battery life, this transmitter incorporates an
On/Off procedure. Seven user programmable frequencies allow
multiple systems to be used simultaneously in the same area.
INITIAL SET-UP
This transmitter comes ready to operate, with rechargeable batteries
installed, and factory programmed to Frequency #1. No setup is
necessary. The following steps must be followed to turn system on or off.
Turn System On:
Step #1 –Depress and hold Button 1/9 until the TX LEDturns GREEN –
approximately 3 seconds.
Step #2 –Release Button 1/9. The TX LED will extinguish momentarily,
then begin to provide the battery charge status (BATTERY CHARGE
STATUS chart).
Step #3 –Once battery chargestatus has concluded, the TX LED will
begin to blink RED a few times a second to show the operator the unit is
powered up and transmitting a beacon signal.
Turn System Off:
Step #1 –Depress Button 1/9 until the TX LED turns RED - approximately
three seconds.
Step #2 - Release Button 1/9. The TX LED will extinguishmomentarily,
then begin to provide the battery charge status (seechart).
Step #3 –Once battery chargestatus has concluded, the TX LED will
extinguish and the transmitter is now powered off.
BATTERY CHARGE STATUS
Full
TX LED gives 3 GREEN blinks
Good
TX LED gives 2 GREEN blinks
Low
TX LED gives 2 RED blinks
Charging Required
TX LED gives 10 rapid RED blinks
Dimensions –5.36” L x 2.92” W x .1.26/1/04’ D
(note: STOP button adds .73” to length)
CONTROLS & INDICATORS
TX LED
Illuminates RED continuously while E-Stop
button is depressed and unit is transmitting.
Also guides user through On/Off Procedure and
provides battery charge status (See INITIAL
SET-UP & BATTERY CHARGE STATUS
sections)
E-Stop Button
Transmits STOP command to the receiver
Pushbutton1/9
Powers TX On/Off –No other function
Pushbuttons 2/10
thru 8/16
Not used on this model
Pushbutton P/Shift
Puts TXin frequency programmingmode (See
PROGRAMMING section

AIR-EAGLE®XLT
900MHz RF Transmitter
MODEL 44REB-1300
OPERATION
Once powered on the transmitter begins sending a beacon signal which
keeps the relays in the corresponding receiver energized. Should
transmittergo out of range, or batteries die, the beacon signal stops and
the relays de-energize. When in range, and during normal operation,
pressing the latching E-Stop button will send a command to immediately
de-energize the relays in the receiver.
Once depressed, the E-Stop buttonlatches into place, continuously
transmitting a Stopcommand. To release button and stop transmission,
this button must be twisted clockwise approximately ¼ turn
PROGRAMMING
Please read through these instructions completely before beginning
programming procedure!
At any time, you can check the current frequency setting by depressing
the P/Shift button, for approximately 5 seconds, until the TX LED is
illuminated “RED”. Then release all buttons and watch until the TX LED
begins to blink. The TX LED will blink “RED”one, two,three or four times
for Frequencies 1 thru 4, or will blink “GREEN” one, two or three times
for Frequencies 5 thru 7 accordingly. See table below for clarification.
LED Flashes:
Indicates Unit is Operating On:
RED –one time
Frequency 1
RED –two times
Frequency 2
RED –three times
Frequency 3
RED –four times
Frequency 4
GREEN –one time
Frequency 5
GREEN –two times
Frequency 6
GREEN –three times
Frequency 7
To change the setting, follow these steps:
To select from Frequencies 1 thru 8:
1. Depress theP/Shift button until the TX LED is illuminated
“RED”. (Approximately 5 seconds)
2. Release the P/Shift button, then while the TX LED is still
illuminated “RED”, depress button #1 to select “Frequency 1” or
button #2 to select “Frequency 2” etc. If the transmit LED goes
out before you have selected a network, no settings will have
changed, and the LED will blink corresponding to the frequency
that the TX is currently set to. You must then begin again at
step 1 if you wish to change the current setting.
3. The TX LED will blink to confirm that your frequency selection
has been accepted, and then will go out. For instance, if you
have selected Frequency #1, the TX LED will blink “RED” once
to confirm. If you have selected Frequency #6, the TX LED
blinks “GREEN” two times to confirm.
Programming is now complete andthe transmitter is active for normal
operation.
You may repeat the above procedure if you wish to change the frequency
at any time. See note* in SPECIFICATIONS.
SPECIFICATIONS
Keypad
DurableSealed Membrane Keypad –
Eliminates Dust, Dirt and Moisture
Failures
Enclosure
ASA/Polycarb Blend –IP54 –Not
Water Proof!
Power Requirements
Charging Base to Recharge Internal
Batteries
Battery Type
Internal NIMH rechargeable battery
pack.
Battery Life
(Continuous Usage)
Approximately 1 Week
Battery Life
(While Powered OFF)
6-9 Months
Battery Recharge Time
Approximately 4 Hours (See Charger
Base Specs)
Transmit Frequency
900MHz Spread Spectrum
RF Output Power
250 mW
Transmit Range
Approximately 2500 Feet
Operating Temperature
-40oF to +185oF
APPROVALS
United States (FCC Part 15)
MCQ-XBPS3B
Canada (IC)
1846A-XBPS3B
LIMITED WARRANTY STATEMENT
BWI Eagle Inc. warrants theAir-Eagle Remote Control System, if properly
used and installed, will be free from defects inmaterial and workmanship
for a period of 1 year after date of purchase. Said warranty to includethe
repair or replacement of defective equipment. This warranty does not
cover damage due to external causes, including accident, problems with
electrical power, usage not in accordance with product instructions,
misuse, neglect, alteration, repair,improperinstallation, or improper
testing. This limitedwarranty, and any implied warranties that may exist
under state law, apply only to the original purchaser of the equipment, and
last only for as long as such purchaser continues to own the equipment.
This warranty replaces all other warranties, express or implied including,
but not limited to, the implied warranties or merchantability and fitnessfor
a particular purpose. BWI Eaglemakes no express warranties beyond
thosestated here. BWI disclaims without limitation, implied warranties of
merchantability and fitness for a particular purpose. Some jurisdictions do
not allowthe exclusion of implied warranties so this limitation may not
apply to you. To obtain warranty service, contact BWI Eagle for a return
material authorization. When returning equipment to BWI Eagle, the
customer assumes the risk of damage or loss duringshipping and is
responsible for the shipping costs incurred.
DOCUMENT DATE: 10/3/16 / PRODUCT REV.0
