CABINETS TO GO Findley & Myers AB124 User manual

ASSEMBLY INSTRUCTIONS
These assembly instructions are only applicable for all Angle Base Cabinets
ITEM# AB124
Page 1

►Items Quantity
Item Description Qty
A
Left Face Frame & Door 1
B
Right Face Frame & Door 1
C
Top & Bottom Panel s 2
D Left Back Panel
1
E Right Back Panel 1
F
Toe Kicks (Left & Right)
2
G
Hardware Box
1
Bumper 4pcs, Shelf Bracket 4pcs, 135deg brackets 4pcs, 1/2" Round Head Screws 8pcs,
► Required tools:
Page 2
►General Instructions:
Tools Required: Phillips Screwdriver Optional Tools: Electric Drill Optional Tools: Rubber Mallet
► Hardware Box:
a b
cd
Qty 4 Q ty 4 Qty 8Qty 4
ThankyouforpurchasingaCabinetsToGoproduct.Youarenowtheproudownerofahighqualityproductdesigned
tofacethetestofdaily useandguaranteeingyourenjoymentformanyyearstocome.
Carefullyreadtheinstructionsbeforestartingtheinstallation.
Duringassembly,pleasefollowallgenerallyacceptedsafetyprocedures.
FailuretoadheretothefollowinginstructionswillinvalidatethewarrantyandCabinetsToGowilldeclineany responsibilityforany
damagescaused.Anyinstallationwhichdoesnotcorrespondtotheinstructionsmayresultin defects,malfunctioningparts,significant
damageand/orinjury.
Beforetheassemblybegins,checkthatallappropriateandrequiredplumbingandelectricalconnectionsexist.
Beforedrilling,makeabsolutelysurethattherearenopipes(gas,water,electricity,heating,etc.)atthedrilling location.CabinetsToGowill
notbeheldresponsibleforfailuretofollowtheseinstructions.
PRIOR TO ASSEMBLY, PLEASE MAKE SURE YOU HAVE ONE FACE FRAME BOX AND ONE CARCASS BOX, WHICH HAVE ALL THE PARTS IN THE
QUANTITIES MENTIONED BELOW. IF YOU ARE MISSING ANY PARTS, PLEASE STOP AND CONTACT CUSTOMER CARE IMMEDIATELY AT 1-800-
CABINET.
The materials listing above are for the largest unit in this instruction set. Smaller units may require less hardware and materials;
therefore, your item may contain a smaller number of each.
Shelf

1
►Instructions:
C
C
Page 3
Assemble the Top and Bottom Panels (C)
onto Left Back Panel (D) by connecting the
male and female cam locks and using a
screwdriver to turn the lock clockwise.
(Figure 1) { NOTE: It may be easier to lay Panel D
on a flat smooth soft work surface to assemble. }
Figure 1
D
Assemble the Right Back Panel (E) to
the Left Back Panel (D) & the Top/
Bottom Panels (C) by connecting the
male and female cam locks and using
a screwdriver to turn the lock
clockwise. (Figure 2)
2
D
E
Figure 2
SoftSurface
Hard Surface
D
D

3
4
a X4
a
G
Install the shelf clips (a) in the location
of your choosing. (Figure 3)
Page 4
Figure 3
Figure 4
Install the Shelf (G) onto the shelf
clips installed in the previous
step. (Figure 4)

5
c
b
A
B
6
X2
X4
Page 5
Figure 5
Figure 6
Install the Left Face Frame Door (A)
and the Right Face Frame Door (B)
onto the assembled panels. (Figure 5)
Assemble the Left Face Frame to the
Right Face Frame using 135 degree
brackets (b) and 1/2" screws (c) in
the locations shown. (Figure 6)

7
8
F
F
F
F
c
X4
b
X2
Figure 7
Assemble the Left Toe Kick to the Right
Toe Kick using 135 degree brackets (b)
and 1/2" screws (c). (Figure 7)
Figure 8
Install the Toe Kicks to the
other assembled panels. (Figure 8)
Page 6

X4
d
9
d
► Maintenance
For daily cleaning, use a dry cloth and
a soft liquid cleaner.
Never use abrasive cleaners containing acetone, chlorine or strong bleach. Al so, do not use tools as scrapers,
metallic brushes, and othe
r products which can scratch or tarnish surfaces.
Under no circumstances should you use chrome cleaner on chrome-plated or brass trim, hinges, handles, sockets etc.
Good ventilation is essential for maintaining the quali ty and look of this furniture.
Warranty and Customer Care Information
For the most up to date warranty information for your product, please visit our website - www.cabinetstogo.com to get
the specific details. If you have any questions with warranties or to make a claim, please contact Customer Care by email
- [email protected] or call 1-800-CABINET.
Page 7
Figure 9
Install the bumpers (d) onto
the corners of the doors opposite
of the hinges. (Figure 9)
