Campania FT-193 User manual

F
T
-
193CaterinaFountain inBasin
Professionalinstallationis recommendedforthis fountain!
R
evised
July11, 2018
-WINTERCARE-
Fountainbowls/topsandotherfountaincomponents,whichcollect water, shouldnotbeleftoutsideinthewinter since anycomponent,
whichfillswithwater andfreezesmaycrack.Likewise, componentssuchaspedestals,whichremaininabasin,filledwithwater,
whichthenfreezes,mayalsocrackor crumble. Ideally, therefore, afountainshouldalwaysbestoredindoorsor inadryprotected
place suchasacoveredporchawayfromtheelements. However, ifafountainmustbeleftoutside:
(1) Removepump, rubber stoppers, drainpipes, finials,andother smallcomponentsfor storageindoors. Note that stoppersor
drainpipesareremovedtoallowdrainageintheeventwater accumulatesinanybasin.
(2) Raisefountainbasefromgroundwithwood stripssothat basewill notfreeze tothegroundsurface.
(3) Cover or wrapthefountainwithburlapor other absorbentmaterial (oldblanket or towel) andthencover securelywith
plastic,making surethat water will notaccumulate inthebasinor other fountaincomponentandfreeze;
(4) Checkfountainperiodicallytoensurethatplastic issecureandwater isnotaccumulating inanyfountaincomponent.
-GENERALFOUNTAINTIPS-
Install fountainsonalevel surface. Youwill needaproperlygrounded110-volt (AConly) GFCI protectedreceptaclenear the
fountainfor your pump. All pumpsaresubmersible andmustbecompletelyunderwater tofunctionproperly. Testall pumpsand
adjusttofull outputprior toassembly. Itisnotrecommendedthat fountainsbeplaceddirectlyongrass or dirt. Positionthechannel
opening at thebaseofeachfountaintoward theelectrical outlet tobeusedsince thepump
cord willbethreadedthroughthisopening.
CheckoutYouTubefor a“Howto”video.
For moreCampania product informationvisit www.campaniainternational.com
All of ourcaststone is proudly
Pump KitPartsList
PK800 pump (1)
#10 stopper(1)
Metalplug forhole in side of basin (1)
2”length of3/4”ClearVinyltubing (1)**
2”length of5/8”ClearVinyltubing (1)**
Approx.50”length of1/2”BlackNon-Kinktubing (1)**
7 ½”length of1 ½”PVCpipe – Standpipe (1)
Wedges(6)
Hose clamps(2)*
*Hoseclamps maybe used asflow restrictors
**Tubing is preassembled
FOUNTAININFORMATION:
Thisfountain holdsapproximately130 gallonsof water.
Thisfountain usesalarger fountain cover but doesnot
cover the basin.
(FTNCOV-LG)
Compatible withRefill #10 Device and LEDkit
(A different style stopper mayberequestedfor therefillkit.)
TOOLSREQUIRED:
Bubble Level
Tape Measure
PUMPINFORMATION:
OEMPP800 - 800GPH Pump
16 FTcord length

FT
-
193
CaterinaFountain
inBasin
Professionalinstallation isrecommended for thisfountain!Assemble your fountain on a levelsurface using crushed stone, gravel, or cementpad asthe base.
RevisedJuly11, 2018
FGB-2030 (130 lbs)
72”Wx11.75”H
FT-193F(91 lbs)
18”Wx11”H
FT-193E (96lbs)
15.25”Wx17”H
FT-192E (162lbs)
35.25”Wx8”H
FT-193C(35 lbs)
10”Wx16”H
1. Placethefiberglass basinwherethefountainistobe installed.
a. Be sure tocheckthateachpartislevel and centeredduringthe
assembly ofthisfountain.
2. Spreada thinamount ofsiliconeonboth pumpcordsapproximately3feet
fromthepumpsandfitthemintothe double holedstopper.
3. Feedthepumpcordsthroughtheholeinthebasin.
4. Toensurea level installation,makesurethatyourun theremainingcord
throughthechannel inthe bottomofthebasin.
5. Press stopperfirmlyand evenlyintotheholeofbasin.
6. Spreada thinbeadofsiliconearoundthe perimeterofthestopper, slitin
thestopper,andaroundthepumpcords.
7. Looselywrapcordsupinthecenterofthe basin.
8. Placethefountainbase(FT-193F)overthepumpsandthecords.
9. Placethelargepedestal(FT-193E)on topofthe base.
10. Position thelargebowl (FT-192E)on topofthelargepedestal(FT-193E).
11. Fit thestandpipeintothelargebowl (FT-192E).
12. Centerthesmall pedestal(FT-193C)insidethelargebowl (FT-192E).
FT-192B(34 lbs)
18.25”Wx5”H
FT-193A(13 lbs)
5.5”Wx13”H
FT-193G (6lbs)
7.5”Lx2.75”Wx5.5”H
FT-193H (228 lbseach)
40.25”Lx9”Wx15.25”H
FT-193H (228 lbseach)
40.25”Lx9”Wx15.25”H
13. Usingahoseclamp,connectthe1/2"non-kinktubingendofthe
assembledtubingtothe pipeprotrudingfromthebottomofthesmall bowl
(FT-192B).
14. Feedthetubingdownthrough thesmall bowl, largebowl, and large
pedestaltothepump.
15. Fit the 3/4"cleartubingoverthepumpoutlet.
16. Centerthesmall bowl(FT-192B)onthesmall pedestal(FT-193C)
17. Placethefinial(FT-193A)intothesmall bowl (FT-192B)byfittingthe
copperinthefinialoverthecopperinthe bowl.
18. Fit the pumpcoverdoor(FT-193G)intothepumpcover(FT-193F).
19. Position thecopingwiththe channel (FT-193H) about6inchesfromthe
basin(FGB-2030)onthesideofthefountainwherethepumpcordisto
comeout. a. NOTE:Only1ofthe6copingshasachannel
20. Position the5remainingcopings(FT-193H) inacircle about6inches
fromthebasin.
21. Carefullypusheachpieceoneattime towardthe basinandintothe notch
ofthecoping.
a. Fit eachpiecetothecopingnext toit.
22. Fill thebasinwithwater.
