Canon G4000 series User manual

Guía de inicio
Para Começar
Démarrage
Getting Started

1
2
Instalación de la impresora.............................................................página 1
Conexión con el ordenador y con el teléfono inteligente
o la tableta......................................................................................página 5
Este producto requiere un manejo con cuidado de la tinta. La tinta puede salpicar al verterla en los depósitos
de tinta para llenarlos. Si la tinta mancha la ropa o los objetos, puede que no se vaya.
Instalando a impressora .................................................................página 1
Conectando a um computador e smartphone/tablet ......................página 5
Este produto requer manuseio cauteloso da tinta. A tinta pode respingar quando os cartuchos de tinta estão
cheios. Se a tinta entrar em contato com roupas ou objetos, pode ser que ela não saia.
Installation de l'imprimante .................................................................page1
Connexion avec un ordinateur et un smartphone ou une tablette......page5
L'encre utilisée avec ce produit doit être manipulée avec précaution. L'encre risque de provoquer des
éclaboussures lorsque les cartouches d'encre sont remplies. Si de l'encre tache vos vêtements ou vos effets
personnels, vous risquez de ne plus pouvoir l'enlever.
Installing the Printer............................................................................page1
Connecting with Computer and Smartphone/Tablet...........................page5
This product requires careful handling of ink. Ink may splatter when the ink tanks are lled with ink. If ink gets
on your clothes or belongings, it may not come off.

1
ENGLISH
1. Installing the Printer
For the procedure with icon, you can watch the video
tutorials for installing the printer by accessing the following
URL or scanning the QR codes.
Video
Guides
Checking Included Items
CD-ROM for
computer
(Windows)
Manuals
Removing Packing Materials
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 Remove the packing materials (such as tape) from
outside the printer.
2 aRemove the orange tape.
bOpen the scanning unit / cover.
b
a
3 Remove the orange tape and the protective
material and discard them.
Installing the Cartridge
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 aGrab the knob on the cartridge locking cover.
bOpen the cartridge locking cover.
a
b
2 Take out the C (color) cartridge from the box and
remove the label.
3 Remove the protective tape.
4 Insert the C (color) cartridge on the left.

2
5 Repeat steps 2 to 4 to insert the B (black)
cartridge on the right.
6 Close the cartridge locking cover and push it
down.
7 Press down both joint buttons.
Pouring Ink
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 Open the left ink tank cover.
2 Grab and remove the tank cap of the ink tank, and
then place it on the upper tank cap holder.
3 aTake the BK (black) ink bottle out of its
package.
bHold the ink bottle upright and remove the
bottle cap.
b
a
4 Insert the nozzle of the ink bottle into the inlet and
stand the ink bottle upside down.
5 Pour all ink into the ink tank.
6 Close the tank cap.

3
ENGLISH
7 Close the ink tank cover.
8 aOpen the right ink tank cover.
bRepeat steps 2 to 6 to pour all ink into the
corresponding ink tanks on the right according
to the label.
cClose the ink tank cover.
b
a
c
9 Check that all ink in the bottles is poured into the
ink tanks.
10
Close the scanning unit / cover.
Turning on the Printer
You can watch the procedure on a movie by scanning
the QR codes.
Android iOS
1 Connect the power cord.
Do not connect any cables except the power
cord yet.
Back
2 Press the ON button.
If an error message appears, make sure the
cartridges are installed correctly.
3 Use the [or ]button to select a language, and
then press the OK button.
4 If the following screen appears, select your country
or region, and then press the OK button.
5 aWhen the following screen appears, make
sure the ink preparation is complete.
bSelect Yes, and then press the OK button.
a
b

4
Selecting a Printer Connection Method
The connection method varies depending on how you use the printer. Select a printer connection method according to the
table below. In the following description, smartphones and tablet devices are collectively described as smartphone.
Using the printer with your computer or smartphone connected Using the printer without
connecting any other devices
Wireless LAN USB Do not connect
Connecting the printer to your
computer or smartphone via a
wireless router
router
Connecting the printer to your
computer or smartphone directly
without a wireless router *
USB cable
Use the [or ]button to select
Do not connect on the connection
method selecting screen, and then
press the OK button. Follow the on-
screen instructions to proceed with
the setup. Wait for about 6 minutes
until the following screen appears.
The setup is now complete.
* You may not connect your smartphone to the Internet wirelessly during connecting
the printer to the smartphone directly. In that case, you may be charged depending
on the contract with your service provider.
* Up to 5 devices can be connected to the printer via wireless LAN connection
directly.
1 Select your printer connection method, and then
press the OK button.
Follow the on-screen instructions to proceed
with the setup.
Users who select USB:
Do not connect a USB cable until you are
instructed.
2 If the following screen appears, proceed to the
next page.
■If you select Wireless LAN:
■If you select USB:

5
ENGLISH
Connecting with Computer
You need connection setup for each computer. Proceed
with the setup from step 1 for each computer.
The following describes the procedures for Windows and
Mac OS.
If you use a computer except for Windows or Mac OS
such as Chrome OS, access "http://canon.com/ijsetup",
and then follow the instructions on the Canon website to
set up your computer.
1 Select one of the following steps or to start
up the setup le.
Accessing the Canon Website
aVisit the Canon website below and click Set Up.
Follow the on-screen instructions to proceed
with the setup.
bIf the following screen appears, click Download.
cStart up the downloaded le.
Using the Setup CD
aInsert the setup CD into your computer.
When using Windows 10, Windows 8.1 or Windows 8:
bClick or File Explorer on the taskbar.
cSelect This PC or Computer on the left side of the
opened window.
dDouble-click the CD-ROM icon on the right side
of the window.
* If the contents of the CD-ROM appear, double-click
MSETUP4.EXE.
2 Click Start Setup.
Follow the on-screen instructions to proceed
with the setup.
You can set up your smartphone in the middle
of the steps.
On the following screen, click Instructions to
proceed with setup of your smartphone.
* Depending on your settings, the screen above may
not appear. In that case, proceed to "Connecting with
Smartphone" on page 6 after nishing the connection
to your computer.
3 If the following screen appears, click Exit.
The connection with your computer
is now complete. You can print from
your computer.
2. Connecting with Computer and Smartphone/Tablet
If you connect the printer to both your computer and your smartphone, connect it to the
computer rst.
To connect the printer only to your smartphone, proceed to "Connecting with
Smartphone" on page 6.

6
Connecting with Smartphone
You need connection setup for each smartphone. Proceed with the setup from step 1 for each smartphone.
Preparation
• Turn on Wi-Fi on your smartphone.
• If you have a wireless router, connect your smartphone to the wireless router.
* For operations, refer to manuals of your smartphone and the wireless router or contact those manufacturers.
1 Install the application software Canon PRINT Inkjet/SELPHY in your smartphone.
: Search "Canon PRINT" in App Store.
: Search "Canon PRINT" in Google Play.
Or access the Canon website by scanning the QR code.
2 Check the display on the printer.
The screen turns off when no operation is made for 10 minutes. Press one of the buttons on the operation panel
(except for the ON button) to display the screen.
If appears, the printer can not communicate by
wireless LAN connection. For details, access "http://canon.
com/ijsetup" to see Frequently Asked Questions.
No (Proceed to .)
Yes
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
cMake sure that the following screen appears.
The connection with your smartphone is
now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading
Paper" on page 8.
aDoes the following screen appear?
bDoes (the printer is connected to the network) appear on the screen displayed by pressing the
COPY button?
No Yes (Proceed to .)

7
ENGLISH
Procedures below vary depending on iOS or Android. Select your operating system and proceed to its
procedure.
aTap Settings on the HOME screen, and then tap
Canon_ij_XXXX on the Wi-Fi settings.
If Canon_ij_XXXX does not appear on the list, see
"Preparation of the Printer" below to operate the
printer, and then repeat step a.
bTap the installed application software.
cFollow the on-screen instructions to register the
printer.
Follow the on-screen instructions to proceed
with the setup.
If you select Auto Select Conn. Method
(recommended) on the connection method
selecting screen, the appropriate connection
method is selected automatically depending on
your environment.
dMake sure that the following screen appears.
aTap the installed application software.
bFollow the on-screen instructions to register the
printer.
If a message saying "Printer is not registered.
Perform printer setup?" does not appear, see
"Preparation of the Printer" below to operate the
printer, and then wait for a while until a message
appears.
Follow the on-screen instructions to proceed
with the setup.
The appropriate connection method is selected
depending on your environment.
cMake sure that the following screen appears.
The connection with your smartphone is now complete. You can print from your
smartphone.
To print photos, load photo paper. Proceed to "Loading Paper" on page 8.
aPress the Setup button on the printer. bUse the [or ]button to select Wireless LAN
setup > Easy WL connect, and then press the
OK button.
cReturn to the operation of your smartphone.
Preparation of the Printer

8
1 Open the paper support and the paper support
extension.
2 Slide the right paper guide to the right end.
3 Insert several sheets of paper until it stops with
the print side facing up.
4 Slide the right paper guide to align it with the
side of the paper stack.
5 aPull out the paper output tray.
bOpen the output tray extension.
a
b
Loading Paper
Using Fax Function
Before using the fax function, refer to the following manual to set up the fax function of your printer.
■Setting Up the FAX on the Online Manual
aVisit the Canon website below and click Set Up.
Follow the on-screen instructions to proceed with the setup.
bClick Making Fax Ready for Use.
■Setting Up the FAX in the Basic Manual which is installed into your computer.
