imagePRESS C7000VP
Customer Expectations Document
Version 7
Systems & Technical Support Division
Imaging Systems Group, Canon U.S.A.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 2
Contents
1. Introduction.............................................................................................................4
2. Product Overview ...................................................................................................4
2.1 Summary of Functions ....................................................................................5
2.2 Offset Press vs. Digital imagePRESS.............................................................5
2.3 Image Stabilization Control .............................................................................5
3. Machine Dimensions and Space Requirements ..................................................6
3.1 Dimensions .....................................................................................................6
3.2 Weight.............................................................................................................7
3.3 Installation and Service Space........................................................................7
3.3.1 Dimensions Diagrams........................................................................8
3.3.2 Installation Space Diagrams..............................................................9
3.4 Recommended Floor Space Requirements ..................................................11
3.5 Floor Structure Requirements.......................................................................11
3.6 Delivery Pathway ..........................................................................................12
3.7 Network Connectivity ....................................................................................12
4. Power/Electrical Requirements ...........................................................................12
4.1 Power Requirements for the Main Unit and Optional Accessories................13
5. Environmental Factors and Requirements.........................................................15
5.1 Temperature and Humidity Conditions..........................................................15
5.2 Temperature Gradient...................................................................................15
5.3 Ventilation .....................................................................................................16
5.4 Elevation Limitations.....................................................................................16
5.5 Lighting .........................................................................................................16
5.6 Sunlight.........................................................................................................16
5.7 Ammonia.......................................................................................................16
6. Specifications .......................................................................................................17
6.1 Main Unit.......................................................................................................17
6.2 Color Image Reader-H1................................................................................19
6.3 Feeder (DADF-R1)........................................................................................20
6.4 POD Deck-A1/Secondary POD Deck-A1......................................................21
6.5 Paper Deck-AC1...........................................................................................21
6.6 Stack Bypass-A1...........................................................................................22
6.7 Tab Feeding Attachment-C1.........................................................................22
6.8 Professional Puncher-B1 and Professional Puncher Integration Unit-A1......22
6.9 Finisher-AB1 .................................................................................................23
6.10 Saddle Finisher-AB2.....................................................................................25
6.11 Puncher Unit-V1............................................................................................27
6.12 Document Insertion Unit-C1..........................................................................27
6.13 Card Reader-C1............................................................................................28
6.14 High Capacity Stacker-C1.............................................................................28
6.15 Perfect Binder-B1..........................................................................................29
6.16 Booklet Trimmer-C1......................................................................................29
6.17 Two-Knife Booklet Trimmer-A1.....................................................................30
7. System Options ....................................................................................................30
7.1 Color UFR II/PCL/PS Printer Kit-T1 ..............................................................30
7.2 imagePRESS Server A2100 V2....................................................................31
7.3 imagePRESS Server A3100 V2....................................................................31

Version 7 imagePRESS C7000VP Customer Expectations Document Page 3
7.4 Color Universal Send Kit-G1.........................................................................32
7.5 Universal Send PDF Security Feature Set-A1...............................................32
7.6 Universal Send PDF Advanced Feature Set-A1............................................32
7.7 Digital User Signature PDF Kit-A1 ................................................................32
7.8 Secure Watermark-A1...................................................................................32
7.9 HDD Data Encryption Kit-B3.........................................................................32
7.10 HDD Data Erase Kit-A1.................................................................................33
7.11 Web Access Software...................................................................................33
7.12 Encrypted Secure Print Software..................................................................33
7.13 Remote Operator's Software Kit-A2..............................................................33
7.14 Access Management System Kit...................................................................33
7.15 Authorized Send Kit ......................................................................................34
7.16 Removable Hard Disk Drive Kit.....................................................................34
7.17 Other imagePRESS C7000VP Main Unit Accessory Options.......................34
7.18 Notes on the Hard Disk.................................................................................34
8. Installation Review................................................................................................35
8.1 Installation Time............................................................................................35
8.2 Customer Responsibilities.............................................................................36
9. Customer Maintenance Program.........................................................................36
10. Consumable Items................................................................................................36
10.1 Usage Conditions..........................................................................................37
10.2 Consumable Parts.........................................................................................37
10.2.1 Consumables...................................................................................38
11. Toner Container and Hopper Unit Yields............................................................38
12. Waste Toner Yields...............................................................................................39
13. Estimated Performance Standards .....................................................................39
14. Machine Reliability and Productivity...................................................................40
14.1 Print Speed ...................................................................................................41
14.2 Two Hour Unattended Operation ..................................................................42
14.3 Paper, Toner, and Waste Toner Replacement..............................................42
15. Optimum Monthly Print/Copy Volume ................................................................42
16. Media Usage/Compatibility..................................................................................43
16.1 Media Characteristics by Media Library Parameters.....................................43
16.2 Paper Handling and Storage.........................................................................43
16.3 Selecting the Correct Media..........................................................................44
16.4 Paper Grain and Curl....................................................................................45
16.5 Note for Customers Who Cut Their Own Paper............................................46
16.6 Media Feed Locations...................................................................................46
16.7 Paper Sizes and Feed Location Chart ..........................................................49
17. Image Quality Capabilities...................................................................................50
17.1 Customer-Defined Image Quality Adjustments and Recommendations........51
17.1.1 Device Management Settings..........................................................52
17.1.2 Paper Type Management Settings ..................................................53
18. Responsibility Matrix............................................................................................54

Version 7 imagePRESS C7000VP Customer Expectations Document Page 4
IMPORTANT
The purpose of this Customer Expectations Document is to explain the
current features and capabilities of the imagePRESS C7000VP, and establish
the customer’s expectations before he/she purchases the machine.
The information included in this document has been pulled from various
sources, including product reference guides, service guides, user manuals,
as well as results from internal Canon testing. Specifications and other
information contained herein may vary slightly from actual device values or
those found in advertising and other printed matter. Part numbers, yield
information, and specifications are subject to change without notice;
however, this document will be revised as new information becomes
available. Canon authorized dealers can access the latest revision of this
document from the Download Center page in the e-Support Web site
(support.cusa.canon.com).
1. Introduction
The Canon imagePRESS C7000VP Customer Expectations Document contains
information about the features and capabilities of the Canon imagePRESS
C7000VP. This document should be used as part of the presale, and
preinstallation planning process to help clarify the requirements and responsibilities
associated with owning and operating the imagePRESS C7000VP. It is also
recommended that those interested in purchasing the imagePRESS C7000VP
have, and familiarize themselves with, the information in this document prior to
making their purchase.
2. Product Overview
The Canon imagePRESS C7000VP is designed to produce the highest color
image quality in the marketplace, and maintains high-durability, productivity, and
value. This high-quality digital press also upholds output printing and copying
speeds of 70 ppm for both color and black-and-white LTR size documents.
The imagePRESS C7000VP has full color image quality, various media support
with the largest image area and highest color consistency and durability. As a
printer, the machine is capable of printing up to 1200 x 1200 lpi and dpi. As a
copier, the imagePRESS C7000VP can enhance the digital resolution of your
document by scanning in up to 600 x 600 dpi, and outputting the image in up to
1200 x 1200 dpi interpolated resolution. This results in higher quality characters,
smoother corners, and cleaner gradient transitions. Text appears sharper and
graphics appear extremely clear and detailed.
The imagePRESS C7000VP is designed with new technologies, such as the
oil-less V toner, E drum, Twin Red Imaging Laser Beam scanner, Twin Sleeve
Developer Unit, and Real Time and Post Fusing calibration to achieve unparalleled
image quality, color consistency, and media versatility.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 5
2.1 Summary of Functions
Function imagePRESS C7000VP
Output Speed (Color) 70 ppm (LTR)
Output Speed (B&W) 70 ppm (LTR)
Engine Resolution 1,200 x 1,200 dpi
Gradations 256 levels
Max. Paper Size 13” x 19.2”
Max. Paper Weight 110 lb cover (300 g/m²)
Printer Memory 1.5 GB
Copy Yes (w/optional Reader)
Mail Box Yes
Network Yes
Remote UI Yes
MEAP Capability Yes
imagePRESS Server A3100 V2
imagePRESS Server A2100 V2
Controllers Color UFR II/PCL/PS Printer Kit-T1
Network Scanning Yes (w/optional Reader)
Send Optional (Universal Send)
2.2 Offset Press vs. Digital imagePRESS
Offset printing is a technique that transfers (or “offsets”) an inked image from a
plate to a rubber blanket, and then to the printing surface. This enables the offset
press to maintain a consistent and high image quality over long print runs because
the plate never touches the paper. The process requires a substantial investment
in equipment and setup time to achieve these results.
Adigital press uses an electrostatic process to produce “offset-like” image quality
at a fraction of the cost of an offset press. In the imagePRESS C7000VP digital
press, the drum is imaged; the toner is applied, and then transferred to the AITB
(Advanced Imaging Transfer Belt). The AITB then transfers all four toner colors to
the paper in one single pass. The small toner particle size captures a greater color
gamut space, closer to that of an offset press.
2.3 Image Stabilization Control
The quality of printed images is affected by changes in the environment, such as
temperature, humidity, etc. in which the machine is installed. It is also affected by
the deterioration of image formation parts through extended usage. The
imagePRESS C7000VP performs image stabilization control to ensure stable print
quality over an extended period of time.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 6
3. Machine Dimensions and Space Requirements
3.1 Dimensions
The following table includes the width, height, and depth dimensions (in inches and
millimeters) of the main unit and optional accessories.
Unit Width Depth Height
Main Unit*1 101.8” 2,586 mm 44.7” 1,135 mm 52.4” 1,330 mm
POD Deck-A1 38.6” 982 mm 31.2" 792 mm 43.1" 1,095 mm
POD Deck-A1 &
Secondary PODDeck-A1 70.6” 1793 mm 31.2" 792 mm 43.1" 1,095 mm
Paper Deck-AC1 23.7” 601 mm 24.4" 621 mm 22.4" 570 mm
Color Image Reader-H1 28.9" 732 mm 23.5" 595 mm 4.1" 105 mm
DADF-R1 25.5" 646 mm 22.4" 570 mm 5.6" 143 mm
Professional Puncher-B1
& Professional Puncher
Integration Unit-A1 22.0” 560 mm 31.2” 792 mm 40.9” 1,040 mm
Primary High Capacity
Stacker-C1 33.9” 860 mm 30.1” 765 mm 48.8” 1,240 mm
Secondary High
Capacity Stacker-C1 33.9” 860 mm 30.1” 765 mm 48.8” 1,240 mm
Saddle Finisher-AB2*3 41.6” 1,057 mm 31.2” 792 mm 46.5” 1,180 mm
Finisher-AB1*2 35.0” 890 mm 31.2” 792 mm 46.5” 1,180 mm
Puncher Unit-V1 Part of the Finisher-AB1 or Saddle Finisher-AB2
Booklet Trimmer-C1*2 &
Saddle Finisher-AB2*3 74.4" 1,890 mm 31.2" 792 mm 46.5" 1,180 mm
Booklet Trimmer-C1,
Two-Knife Booklet
Trimmer-A1, & Saddle
Finisher-AB2
95.7” 2,431 mm 31.8” 792 mm 46.5” 1,180 mm
Document Insertion
Unit-C1 24.6" 625 mm 26.3" 667 mm 8.4" 213 mm
Perfect Binder-B1*4 36.3” 922 mm 31.1” 791 mm 53.5” 1,360 mm
Stack Bypass-A1*5 15.7” 398 mm 21.4” 544 mm 13.4” 339 mm
*1 The Marking Engine, Fixing Unit, and Power Station Unit all make up what is hereinafter
referred to as the “Main Unit.”
*2 The expansion tray is attached.
*3 The auxiliary booklet tray is attached.
*4 The Insertion Unit is included.
*5 The auxiliary tray is extended.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 7
3.2 Weight
The weights of the main unit, feeding and finishing options (in pounds and
kilograms) are listed in the table below.
Unit Weight
Main Unit 2,645 lb 1,200 kg
POD Deck-A1 551 lb 250 kg
Secondary POD Deck-A1 507 lb 230 kg
Paper Deck-AC1 112 lb 51 kg
Color Image Reader-H1 38.5 lb 17.5 kg
DADF-R1 47.3 lb 21.5 kg
Professional Puncher-B1 176 lb 80 kg
Professional Puncher Integration
Unit-A1 88 lb 40 kg
Primary High Capacity Stacker-C1 440 lb 200 kg
Secondary High Capacity Stacker-
C1 440 lb 200 kg
Saddle Finisher-AB2 392 lb 178 kg
Finisher-AB1 278 lb 126 kg
Puncher Unit-V1 6 lb 3 kg
Booklet Trimmer-C1 335 lb 152 kg
Two-Knife Booklet Trimmer-A1 419 lb 190 kg
Document Insertion Unit-C1 37.5 lb 17 kg
Perfect Binder-B1 697 lb 316 kg
Stack Bypass-A1 11.9 lb 5.4 kg
3.3 Installation and Service Space
The site must provide enough space for unrestricted operation, maintenance work,
and proper ventilation. The machine dimensions are in diagrams on the next page.
Every attempt should be made to install the equipment in a room that is large
enough to allow for proper servicing and maintenance of the equipment, and
ensure that issues, such as ventilation, odors, and dust accumulation will not be a
concern.
IMPORTANT
•Keep the back of the machine at least 39 23/64” (1,000 mm) away from a wall.
•The floor must be level (with no bows) for the stabilization and support of the
machine.
•The minimum doorway opening that the machine passes through prior to
installation must be at least 36” wide.
•The minimum elevator depth used to transport the machine prior to installation
must be at least 56”.
•At least 44 3/4” (1,135 mm) in width is necessary to negotiate turns prior to
installation.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 8
3.3.1 Dimensions Diagrams
Approx.
95.7” Approx.
33.9” Approx. 33.9” Approx.
101.8” Approx.
70.6”
Approximately 394”
Approx.
44.7"
Provide at least 3 feet on each side of the
machine for unrestricted operation, including the
opening of the Stacker door (approx. 34 1/4").
Approx.
52.4"
Approx.
40.9"
Approx.
58.1"
Approx.
36.3” Approx.
22.0”

Version 7 imagePRESS C7000VP Customer Expectations Document Page 9
3.3.2 Installation Space Diagrams
The approximate installation space requirements will differ, depending on how
your machine is configured and the optional accessories attached.
There must be enough space around the machine. The following diagrams show the
minimum dimensions; whenever possible, be sure there will be more space than indicated.
The optional Saddle Finisher-AB2 is attached.
[1] Main Station [3] Power Unit Station
[2] Sub Station [4] Saddle Finisher-AB2
The optional High Capacity Stacker-C1 and Paper Deck-AC1 are attached.
[1] Main Station [4] Paper Deck-AC1
[2] Sub Station [5] High Capacity Stacker-C1
[3] Power Unit Station
39.4”
39.4” 75.8”
39.4” 39.37”
143.7”
39.4”
39.4” 172.20”
39.4”
39.4” 77.4”

Version 7 imagePRESS C7000VP Customer Expectations Document Page 10
Maximum Configuration
[1] Main Station [8] High Capacity Stacker-C1
[2] Sub Station [9] High Capacity Stacker-C1 (Secondary)
[3] Power Unit Station [10] Perfect Binder-B1
[4] POD Deck-A1 [11] Finisher-AB1/Saddle Finisher-AB2
[5] Secondary POD Deck-A1 [12] Booklet Trimmer-C1
[6] Professional Puncher-B1 [13] Two-Knife Booklet Trimmer-A1
[7] Professional Puncher Integration Unit-A1
IMPORTANT
•The maximum configuration (fully configured machine) includes 2-POD
Decks-A1, the Main Unit (1-Marking Engine, 1-Fixing Unit, 1-Power Station
Unit), 1-Professional Puncher-B1 and Professional Puncher Integration Unit-A1,
2-High Capacity Stackers-C1, Perfect Binder-B1, Saddle Finisher-AB2, Booklet
Trimmer-C1, and Two-Knife Booklet Trimmer-A1.
•The fully configured width of the machine includes opening space for the POD
Deck door and the extended tray of the Two-Knife Booklet Trimmer.
39.4” 39.4”
413.9”
39.4” 39.4”
77.7”

Version 7 imagePRESS C7000VP Customer Expectations Document Page 11
3.4 Recommended Floor Space Requirements
For a fully configured imagePRESS C7000VP (2-POD Decks-A1, 1-Main Unit,
2-High Capacity Stackers-C1, 1-Professional Puncher-B1 and Professional
Puncher Integration Unit-A1, Perfect Binder-B1, Saddle Finisher-AB2, Booklet
Trimmer-C1, Two-Knife Booklet Trimmer-A1, and imagePRESS Server A3100 V2
with stand), it is recommended that there be at least 43.6’ (W) x 13.2’ (D) of floor
space.
IMPORTANT
The imagePRESS C7000VP was created to be modular in design. Your floor
space, budget, monthly copy/print volume, and applications will determine which
configuration will work best for you. Any configuration of up to 2-POD Decks-A1
and 2-High Capacity Stackers-C1 may be connected at once. The Saddle
Finisher-AB2 or Finisher-AB1, and Booklet Trimmer-C1 may be connected at the
same time as well. Please note that the imagePRESS C7000VP will require
some type of finishing option (Saddle Finisher-AB2, Finisher-AB1, or High
Capacity Stacker-C1).
3.5 Floor Structure Requirements
The floor on which this machine is installed must have strength of at least
92.2 lb/ft2(450 kg/m2). If the floor does not have this level of strength, consult your
building contractor before installing the machine.
The weight of the machine is distributed on the floor through the adjusters and
wheels. Do not install the machine on an unstable floor or platform.
39.4” 39.4”
413.9”
39.4” 39.4”
77.7”
43.6’ (13.3 m)
13.2’ (4 m)

Version 7 imagePRESS C7000VP Customer Expectations Document Page 12
3.6 Delivery Pathway
The dimensions of the Main Unit (excluding the output tray) of the imagePRESS
C7000VP are:
52 3/8” (H) x 101 7/8” (W) x 44 3/4" (D)
(1,330 mm (H) x 2,586 mm (W) x 1,135 mm (D)). With these dimensions in mind,
make sure that there is enough space to deliver the machine, and to bring the
machine to its final installation site.
3.7 Network Connectivity
A standard 10/100Base-T Ethernet interface (RJ-45 jack) for device installation,
monitoring, and Mail Box access, via the Remote UI, ships standard with all
configurations.
A USB 2.0 High-Speed interface port ships standard with all configurations for
direct connection to centralized environments that want to drive all jobs through a
single host PC.
4. Power/Electrical Requirements
The imagePRESS C7000VP requires a NEMA L21-30 receptacle for the main unit
and proper operation.
NEMA L21-30 Rece
p
tacle

Version 7 imagePRESS C7000VP Customer Expectations Document Page 13
4.1 Power Requirements for the Main Unit and Optional Accessories
Part or Accessory Power Supply Power Supply Cord/Plug
Specifications Length of Power Cord
Main Unit 3 Phase 208 V/30 A
outlet Y Configuration NEMA L21-30 9’ 8” (3 m)
POD Deck-A1*1
1-208 V/6 A outlet
(regardless of the
number of POD Decks
connected)
NEMA 6-15
UL498, 2-pole, 3-wire,
grounding devices rated
250 V/15 A
6’ (1.8 m)
High Capacity
Stacker-C1*2
1-115 V/7 A outlet
(regardless of the
number of stackers
connected)
NEMA 5-15 6’ (1.8 m)
Professional
Puncher-B1 &
Professional
Puncher Integration
Unit-A1*3
1-115 V/15 A outlet NEMA 5-15 6’ (1.8 m)
Saddle Finisher-AB2 1-208 V/8 A outlet
NEMA 6-15
UL498, 2-pole, 3-wire,
grounding devices rated
250 V/15 A
6’ (1.8 m)
Finisher-AB1 1-208 V/8 A outlet
NEMA 6-15
UL498, 2-pole, 3-wire,
grounding devices rated
250 V/15 A
6’ (1.8 m)
Perfect Binder-B1 1-208 V/15 A outlet
NEMA 6-15
UL498, 2-pole, 3-wire,
grounding devices rated
250 V/15 A
9’ (3 m)
Two-Knife Booklet
Trimmer-A1 1-115 V/15 A outlet NEMA 5-15 6’ (1.8 m)
imagePRESS Server
A2100 V2 1-115 V/6 A outlet NEMA 5-15 6’ (1.8 m)
imagePRESS Server
A3100 V2 2-115 V/6 A outlets NEMA 5-15 6’ (1.8 m)
*1 The Secondary POD Deck-A1 draws power from the POD Deck-A1.
*2 If you connect a second High Capacity Stacker-C1, the second stacker draws power from
the first stacker.
*3 The Professional Puncher Integration Unit-A1 provides the Professional Puncher-B1 with
power.
IMPORTANT
•If the optional Integrated Interface & Stand is installed on the imagePRESS
Server A2100 V2 (standard equipment on the imagePRESS Server A3100 V2),
an additional 115 V/6 A (NEMA 5-15) is required.
•We recommend an additional standard 115 V/15 A outlet for service tools, such
as a laptop computer or vacuum that may be attached.
•Use only dedicated outlets for the main unit and each optional accessory. Do not
use extension cords.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 14
NOTE
The Puncher Unit-V1, Document Insertion Unit-C1, DADF-R1, Color Image
Reader-H1, Booklet Trimmer-C1, and Paper Deck-A1 do not require any
additional outlets.
The following illustration shows the relative position of the power outlets, voltage
requirements, and dimensions of each optional accessory item.
Back
Monitor
imagePRESS
Server
3 Phase
208V/30A
Y Configuration
NEMA L21-30
208V/15A
NEMA 6-15
208V
208V/15A
NEMA 6-15
208V
208V
115V/15A
NEMA 5-15
115V
POD Deck
Sec.
POD
Deck
Paper
Deck
Engine Stacker Add.
Stacker Saddle Finisher Trimmer
Reader
ADF
Front
Inserter
Main Sub
115V/15A
NEMA 5-15
Perfect
Binder
208V/15A
NEMA 6-15
Puncher-V1
Pro. Puncher-B1
Integration Unit-A1
115V/15A
NEMA 5-15
2-Knife
Trimmer
115V/15A
NEMA 5-15
Back
Monitor
imagePRESS
Server
3 Phase
208V/30A
Y Configuration
NEMA L21-30
208V/15A
NEMA 6-15
208V
208V/15A
NEMA 6-15
208V
208V
115V/15A
NEMA 5-15
115V
POD Deck
Sec.
POD
Deck
Paper
Deck
Engine Stacker Add.
Stacker Saddle Finisher Trimmer
Reader
ADF
Front
Inserter
Main Sub
115V/15A
NEMA 5-15
Perfect
Binder
208V/15A
NEMA 6-15
Puncher-V1
Pro. Puncher-B1
Integration Unit-A1
115V/15A
NEMA 5-15
2-Knife
Trimmer
115V/15A
NEMA 5-15
Monitor
imagePRESS
Server
Monitor
imagePRESS
Server
3 Phase
208V/30A
Y Configuration
NEMA L21-30
208V/15A
NEMA 6-15
208V
208V/15A
NEMA 6-15
208V
208V
115V/15A
NEMA 5-15
115V
POD Deck
Sec.
POD
Deck
Paper
Deck
Engine Stacker Add.
Stacker Saddle Finisher Trimmer
Reader
ADF
Front
Inserter
Main Sub
115V/15A
NEMA 5-15
Perfect
Binder
208V/15A
NEMA 6-15
Puncher-V1
Pro. Puncher-B1
Integration Unit-A1
115V/15A
NEMA 5-15
2-Knife
Trimmer
115V/15A
NEMA 5-15
IMPORTANT
•Canon USA strongly recommends that dedicated and properly grounded outlets
be provided for the devices mentioned above. The ground connection serves to
provide the internal electronics with a reference voltage. Faulty or poor ground
sources will cause this reference voltage to fall into a range that no longer serves
as a reliable reference voltage. The internal logic and programming of the
imagePRESS C7000VP will not perform reliably because there is an insufficient
difference between the internal operating signal voltages and the poor ground
reference signal. A qualified electrician can measure and provide the ground
source that the imagePRESS C7000VP or any computer controlled office
equipment requires.
•Before installation, confirm that a dedicated NEMA L21-30 receptacle is available
as needed.
(Note: Phase converters and step down
transformers are not supported.)

Version 7 imagePRESS C7000VP Customer Expectations Document Page 15
5. Environmental Factors and Requirements
Operating Temperature: Between 68°F (20°C) and 80.6°F (27°C)
Operating Humidity: Between 30% and 70%
Atmospheric Pressure: 810.6 to 1,013 hPa (0.8 to 1.0 atm)
Noise (sound level): Standby: 74 dB; Copying: 82 dB
Ozone Emissions: 0.01 ppm (parts per million) or less (initial startup)
0.035 ppm or less (after a short break-in period)
NOTE
It may be necessary to use a humidifier or dehumidifier to attain the proper
humidity levels for optimal machine performance.
5.1 Temperature and Humidity Conditions
During operation, the permissible humidity range is 30% to 70% RH (Relative
Humidity) with a room temperature of 68°F to 80.6°F (20°C to 27°C).
There is a risk that paper feeding and image quality may be affected if the machine
is used in a location that does not meet these specifications.
The machine should not be installed in locations with significant shifts in
temperature or humidity. Areas containing water, or equipment, such as a heater,
stove, or portable air conditioner should be avoided unless proper environmental
control is available.
The permissible humidity range for storing paper is 30% to 70% RH (Relative
Humidity) with a room temperature of 68°F to 80.6°F (20°C to 27°C). Storing paper
in a location that does not meet these specifications may affect paper feeding and
image quality. For example, if the humidity is too high, paper curling and paper
jams will increase. If the humidity is too low, paper may shrink, lose resistance, and
toner will not adhere to the paper as well.
5.2 Temperature Gradient
Using an air conditioner during the winter, or if a sudden temperature change
occurs, may have an adverse affect on image positioning. Sudden temperature
changes may cause the paper to bend or contract, and cause a machine
malfunction due to condensation. To avoid these issues, control the temperature
gradient so that it does not exceed 18°F/H (10°C/H).

Version 7 imagePRESS C7000VP Customer Expectations Document Page 16
5.3 Ventilation
Ensure that there is an air exchange rate of at least 1.5 times per hour, and at least
3,885 ft3(110 m3) of space in the location where the machine will be installed.
This machine generates a slight amount of ozone during normal use. Although
sensitivity to ozone may vary, this amount is not harmful. Ozone may be more
noticeable during extended use or long production runs, especially in poorly
ventilated rooms. It is recommended that the room be appropriately ventilated,
sufficient to maintain a comfortable working environment, in areas of machine
operation.
5.4 Elevation Limitations
Install this machine at an elevation below 13,123’ (4,000 m) and at an air pressure
of less than 607.8 hPa.
5.5 Lighting
We recommend installing the machine in a location with at least 500 lux
(29 1/2” (75 cm) above the floor) for normal operation and maintenance.
5.6 Sunlight
Avoid installing the machine in direct sunlight. If this is unavoidable, use curtains to
shade the machine. Be sure that the curtains do not block the machine’s ventilation
slots or louvers, or interfere with the electrical cord or power supply.
5.7 Ammonia
Avoid installing the machine where ammonia is emitted. In a sufficient amount,
ammonia will attack the surfaces of the machine’s paper feed and image quality
components, thereby shortening their useful life and increasing the need for
periodic and remedial maintenance.
A professional assessment of the air quality in the room in which the machine is to
be installed is recommended prior to its installation.

Version 7 imagePRESS C7000VP Customer Expectations Document Page 17
6. Specifications
6.1 Main Unit
Item Specifications
Name Canon imagePRESS C7000VP
Type Console
Drum Photosensitive OPC Drum x 4
Color Supported Full Color
Engine Resolution Up to 1,200 dpi x 1,200 dpi
Reading Resolution Up to 600 dpi x 600 dpi
Number of Gradations 256
Memory 1.5 GB (standard)
Hard Disk 80 GB x 2
Size: 13" x 19", 12.60" x 17.72", 12" x 18", 11" x 17", LGL, LTR, LTRR, EXEC,
and Irregular Size (7 1/8" x 7 1/8" to 13" x 19 13/64”
(182 mm x 182 mm to 330.2 mm x 487.7 mm))
Weight: 17 lb bond to 110 lb cover (64 to 300 g/m²)
Thickness: Fewer than 350 µm
Paper Size/Weight/Type
Type: Thin, Plain, Heavy, Recycled, Color, Pre-punched, Bond Paper,
Transparency, Labels, Tab Paper, Coated, Texture Paper, Vellum
Margin Top Margin: 1/8” (2.5 mm) Left and Right Margins: 1/8” (2.5 mm)
Bottom Margin: 1/8” (2.5 mm)
After Powering ON: Fewer than 7 minutes
Warm-Up Time Returning from the Sleep mode: Fewer than 7 minutes
Activation time may vary, depending on the conditions under which the
machine is being used. (In all cases, at a room temperature of 68°F.)
First Copy Time
Full Color: 29 seconds (without the Reader)
Black-and-White*: 29 seconds (without the Reader)
* When the Black mode is set

Version 7 imagePRESS C7000VP Customer Expectations Document Page 18
Main Unit Table Continued
Item Specifications
Direct (sheets/minute) in both the Full Color and Black modes
13" x 19" Approximately 31.3 sheets/minute
(17 lb bond to 110 lb cover (64 to 300 g/m2))
12.60” x 17.72” Approximately 33.6 sheets/minute
(17 lb bond to 110 lb cover (64 to 300 g/m2))
12" x 18" Approximately 33.1 sheets/minute
(17 lb bond to 110 lb cover (64 to 300 g/m2))
11" x 17" Approximately 35.0 sheets/minute
(17 lb bond to 110 lb cover (64 to 300 g/m2))
LGL
Approximately 41.8 sheets/minute
(17 to 28 lb bond (64 to 105 g/m2))
Approximately 33.3 sheets/minute
(28 lb bond to 63 lb cover (106 to 170 g/m2))
Approximately 25.1 sheets/minute
(63 to 110 lb cover (171 to 300 g/m2))
LTR Approximately 70.0 sheets/minute
(17 lb bond to 110 lb cover (64 to 300 g/m2))
LTRR
Approximately 53.2 sheets/minute
(17 to 28 lb bond (64 to 105 g/m2))
Approximately 42.4 sheets/minute
(28 lb bond to 63 lb cover (106 to 170 g/m2))
Approximately 31.9 sheets/minute
(63 to 110 lb cover (171 to 300 g/m2))
Print Speed (Except
when paper is fed from
the optional Stack
Bypass-A1)
EXEC
Approximately 70.0 sheets/minute
(17 lb bond to 63 lb cover (64 to 170 g/m2))
Approximately 61.1 sheets/minute
(63 to 110 lb cover (171 to 300 g/m2))
Paper Feeding System/
Capacity Up to 1,000 sheets x 2 paper decks (20 lb bond (80 g/m²))
Multiple Copies 1 to 9,999 sheets
Power Source 3-phase, 5-wire 208 V AC, 60 Hz, 30 A (one power cord)
Maximum Power
Consumption 8,500 W
Dimensions (H x W x D) 52 3/8" x 101 7/8" x 44 3/4" (1,330 mm x 2,586 mm x 1,135 mm)
Weight Approximately 2,645 lb (1,200 kg)
Installation Space
(W x D)
101 7/8" x 44 3/4" (2,586 mm x 1,135 mm) (main unit only, excluding the
output tray)
175 7/8" x 44 7/8" (4,468 mm x 1,141 mm) (when the optional POD Deck-A1
and Finisher-AB1 are attached)
111 1/4" x 73 1/8" (2,826 mm x 1,856 mm) (when clearing paper jams, main
unit only, excluding the output tray)
194 5/8" x 73 1/8" (4,942 mm x 1,856 mm) (when clearing paper jams, and
when the optional POD Deck-A1 and Finisher-AB1 are attached)
Altitude 13,123' (4,000 m (607.8 hPa)) maximum
Temperature while in
Use 68 to 80.6°F (20 to 27°C)
Humidity 30 to 70% RH

Version 7 imagePRESS C7000VP Customer Expectations Document Page 19
6.2 Color Image Reader-H1
Item Specifications
Type Flatbed
Image Sensor CCD
Resolution for Reading Up to 600 dpi x 600 dpi
Acceptable Originals Sheet, book, three dimensional objects (up to 4.4 lb (2 kg))
Paper Sizes 11" x 17", LGL, LTR, LTRR, STMT, STMTR, or EXEC
Magnification
Regular paper size: Same Ratio
1:1
Reduction
1:0.78 (LGL ➞LTR)
1:0.73 (11" x 17" ➞LGL, 11" x 15" ➞LTR)
1:0.64 (11" x 17" ➞LTR)
1:0.50 (11" x 17" ➞STMT)
1:0.25
Enlargement
1:1.21 (LGL ➞11" x 17")
1:1.29 (LTR ➞11" x 17")
1:2.00 (STMT ➞11" x 17")
1:4.00
Copy Ratio: 25 to 400% (in 1% increments)
Power Source/
Consumption From the main unit.
140 W maximum
Dimensions (H x W x D)/
Weight
4 1/8" x 28 7/8" x 23 1/2" (105 mm x 732 mm x 595 mm) (excluding the
document feeder)
Approximately 38.5 lb (17.5 kg) (excluding the document feeder)

Version 7 imagePRESS C7000VP Customer Expectations Document Page 20
6.3 Feeder (DADF-R1)
Item Specifications
Original Feeding
Mechanism Automatic Document Feeder
Size and Weight of
Originals
Original Supply Tray:
11" x 17", LGL, LTR, LTRR, or STMT (STMT originals cannot be placed
horizontally (STMTR).)
1-sided scanning: 13 to 57 lb bond (50 to 216 g/m2)
2-sided scanning: 13 to 57 lb bond (50 to 216 g/m2) for LTR, and
13 to 53 lb bond (50 to 200 g/m2) for 11" x 17", LGL, and
LTRR
SADF Tray:
11" x 17", LGL, LTR, LTRR, or STMT (STMT originals cannot be placed
horizontally (STMTR).)
10 to 57 lb bond (38 to 216 g/m2)
Original Tray Capacity
Original Supply Tray:
100 sheets (20 lb bond (80 g/m2))
SADF Tray:
1 sheet
Original Replacement
Speed
Copying: 50 sheets/minute (LTR in the Black-and-White and Full Color
modes)
Scanning: 80 sheets/minute*1 maximum (LTR in the Black-and-White and Full
Color modes at 300 dpi)
*1 The scanning speed may vary, depending on the scanning mode and
original type.
Power Source/
Consumption From the main unit.
100 W maximum
Dimensions
(H x W x D)/ Weight
5 5/8" x 25 1/2" x 22 3/8" (143 mm x 646 mm x 569.5 mm)
Approximately 47.3 lb (21.5 kg) (excluding the output tray)
