Canon PIXMA MX452 User manual

Setting Up Your MX452 In
Default Mode (Tel Priority Mode)
Without An Answering Machine
DSL/Cable Modem Connection
Next

Fax Easy Setup
NextPrevious
Click Next to step through this image-friendly version of Fax Easy Setup.
If you started Fax Easy Setup, on the fax machine’s operation panel, and
prefer to go through this image-friendly version…
Step 1
Press the FAX button at any screen
to go to fax standby mode.
Step 2
Click Next to proceed
through the setup.

Connecting The Phone Lines
NextPrevious

Fax to Phone Line Connection
NextPrevious 4
Before
HandSet
(Phone)
(ExistingPhone Cord)
Walljack
DSL/Cable
Modem P
C
(ExistingPhoneCord)
After
(ExistingPhoneCord)
(PhoneCordincludedwith
Canonprinter)
(ExistingPhone Cord)
Walljack DSL/Cable
Modem
P
C
HandSet
(Phone)

Fax to Phone Line Connection
NextPrevious 5
•PlugtheprovidedphonecordintotheDSL/CableModem.
(ExistingPhoneCord)
(PhoneCordincludedwith
Canonprinter)
(ExistingPhone Cord)
Walljack DSL/Cable
Modem
P
C
HandSet
(Phone)

Fax to Phone Line Connection
NextPrevious 6
•Plugtheprovidedphonecordintothe“LINE”jackontherearof
themultifunction.
(ExistingPhoneCord)
(PhoneCordincludedwith
Canonprinter)
(ExistingPhone Cord)
Walljack DSL/Cable
Modem
P
C
HandSet
(Phone)

Fax to Phone Line Connection
NextPrevious 7
•Removethewhiteplugfromtheupperjacklabeled“EXT.”
(ExistingPhoneCord)
(PhoneCordincludedwith
Canonprinter)
(ExistingPhone Cord)
Walljack DSL/Cable
Modem
P
C
HandSet
(Phone)

Fax to Phone Line Connection
NextPrevious 8
•Plugthesecondphonecordintothe“EXT.”jacklocatedontherearof
themultifunction.
(ExistingPhoneCord)
(PhoneCordincludedwith
Canonprinter)
(ExistingPhone Cord)
Walljack DSL/Cable
Modem
P
C
HandSet
(Phone)

Fax to Phone Line Connection
NextPrevious 9
•Plugtheexistingphonecordintothephone
(ExistingPhoneCord)
(PhoneCordincludedwith
Canonprinter)
(ExistingPhone Cord)
Walljack DSL/Cable
Modem
P
C
HandSet
(Phone)

Setting Up The Receive Mode
NextPrevious

Step 1
Turn on the MX452 by pressing the
ON button, if it is not powered on
already.
Step 2
Press the FAX button.
NextPrevious 11

Step 3
The fax standby screen will appear.
Step 4
Press the Menu button.
NextPrevious 12

Step 5
The FAX menu screen will appear.
Step 6
Use the LEFT or RIGHT button to
select “Receive mode set”.
NextPrevious 13

Step 7
Press the OK button.
Step 8
Use the LEFT or RIGHT button to
select “TEL priority mode”.
NextPrevious 14

Step 9
Press the OK button.
Step 10
Use the LEFT or RIGHT button to
select “Yes” at Make adv. settings
screen.
NextPrevious 15

Step 11
Press the OK button.
Step 12
Use the LEFT or RIGHT button to
select “User-friendly RX”.
NextPrevious 16

Step 13
Press the OK button.
Step 14
Use the LEFT or RIGHT button to
select “ON”.
NextPrevious 17

Step 15
Press the OK button.
Step 16
You will return to the “Fax standby
screen” and the receive mode will
appear on the screen.
NextPrevious 18

Receiving A Fax
To receive a fax:
• Pick up the handset on the phone connected to the MX452.
• Listen for fax tones.
• When the tones stop hang up the handset.
• The MX452 will receive the fax document.
IMPORTANT:In order to receive a fax, you must pick up the handset on a
phone that is connected to the multifunction.
Previous 19
