Canon PIXMA TS8300 Series User manual

Guía de inicio
Lea primero Información de seguridad e
información importante (apéndice).
Configuración en línea
Hay vídeos e instrucciones detalladas en
el sitio web de Canon.
Configurar un ordenador
Configurar un teléfono inteligente
Getting Started
Read Safety and Important Information
(addendum) first.
Online Setup
Detailed instructions and videos are
available on the Canon website.
Setup a Computer
Setup a Smartphone

Go
Instalación de la impresora ...............................................................................................página 1
Conexión con un ordenador, teléfono inteligente o tableta....................... página 4
Vídeos instructivos
Cómo sujetar la impresora
Installing the Printer................................................................................................................... page 1
Connecting to a Computer, Smartphone or Tablet...............................................page 4
Holding the Printer
Instructional Videos

1
ENGLISH
Setting Up the Printer
1. Box Contents
•
Ink tanks for setup •
Power cord
•
Setup CD-ROM for Windows
•
Safety and Important Information
•
Getting Started (this manual)
2. Removing Packing Materials
Important
When printing starts, the operation panel opens and the paper
output tray extends out automatically. Do not place anything in
front of the printer.
1 Remove and dispose of any packing materials
and orange tape.
• Using the printer with orange tape or packing
material still attached, may cause the printer to
malfunction.
2 Open the scanning unit / cover and remove the
orange tape.
b
a
3 Close the scanning unit / cover.
• Open the scanning unit / cover fully and then close it.
Caution
Watch your fingers.
a
b
3. Turning on the Printer
1 Connect the power cord.
Back
Important
At this time, do not connect any other cables.
2 Open the operation panel and press the ON
button.
a
b
3 Scroll and tap to select your language, and then
tap Yes .
4 Tap OK.
4. Installing the Ink Tanks
1 Open the scanning unit / cover.
Caution
Do not touch the print head holder until it stops moving.
Online Setup

2
Setting Up the Printer
2 Remove the tape and film on the ink tank.
ba
• Check that no tape is left over.
3 Slowly remove the orange cap.
Important
• Do not squeeze the ink tank with the
Y-shaped air hole blocked.
• Do not touch the areas shown in red.
4 Install the ink tank.
• Insert the ink tank into the print head and press down
until it clicks.
5 Check that the color of the ink tank you installed
appears on the screen.
Important
If the color is not displayed on the screen even though you
have installed the ink tank, the color of the ink tank may be
wrong or you may have installed an ink tank, such as one
with a different model number, that is not supported by this
printer. Either install an ink tank for the correct color or use the
provided ink tank for setup.
6 Repeat steps 2 through 5 to install all the ink
tanks.
• Check that all the colors appear.
7 Close the scanning unit / cover.
• The printer will start initializing.
Caution
Watch your fingers.
a
b
5. Loading Paper
Check!
Remove any orange tape.
1 Tap OK.
2 Remove the cassette from the printer and
remove the cassette cover.
a
b
Cassette cover

3
ENGLISH
3 Slide apart the paper guides.
• Slide the right paper guide to the right edge. Align
the front paper guide with the Letter or A4 mark.
4 Load paper.
• Load 2 or more sheets of Letter or A4 sized plain
paper with the print side facing down.
• Place the paper against the front paper guide, and
align the right paper guide to the width of the paper.
a b
5 Attach the cassette cover and replace the
cassette.
a
b
• Look at it from the side to
confirm it looks like the
diagram.
6 Tap OK.
7 Tap Next.
• Follow the on-screen instructions to continue setup.
This includes making selections related to sending
information.
Refer to "Sending Information To Canon" in Safety
and Important Information.
8 Tap Next.
9 Tap OK.
10 Check that the following screen appears.
If you will use the printer without connecting any other
devices, setup is now complete.

6-a
4
Setting Up the Printer
Computer Smartphone
Computer and
smartphone
Connecting to a Computer
If you are using multiple computers, perform these steps on each computer.
1 Access the Canon website from a
computer.
2 Select Set Up.
3 Enter your printer's model name and
click Go.
4 Click Start.
5 Click If you have already prepared
your printer, go to Connect.
Note
The following steps are for Windows (except
Windows 10 in S mode) and macOS users. For other
operating systems, continue setup by following the
on-screen instructions instead.
6 Click Download.
7 Run the downloaded file.
8 Click Start Setup.
9 Follow the on-screen instructions.
• These operations may take some time.
• To connect to a smartphone as well, see "6-b.
Connecting to a Smartphone" on page 5.
Using the Setup CD-ROM for Windows
Double click EasySetup.exe in the CD-ROM, and then continue from step 3. If you do not have an
internet connection, open the win folder in the CD-ROM and double click SETUP.exe. This will install
the printer driver.
What device are you connecting?
6-a.Connecting to a Computer

6-b
5
ENGLISH
1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.
• Scan the QR code shown on the right to access the Canon website, and then
download the app.
2 Open the installed app.
3 Follow the on-screen instructions in the app to add your printer.
Connecting to a Smartphone
If you are using multiple smartphones, perform these steps on each smartphone.
Prepare the following before starting.
aEnable the Wi-Fi setting on your smartphone.
bConnect your smartphone to the wireless router (if you have a wireless router).
Refer to your smartphone and wireless router manuals for more details.
6-b. Connecting to a Smartphone
Once you have added your printer, you can print from your smartphone.
To print photos, see "Loading Photo Paper" on page 6.

6
Loading Photo Paper
1 Open the rear tray cover and extend the paper
support.
2 Open the feed slot cover and slide the right-
hand side paper guide to the far right.
3 Load several sheets of photo paper with the
print side facing up and slide the side paper
guide against the edge of the paper stack.
a
b
4 Close the feed slot cover.
• Follow the on-screen instructions to set information
for the loaded paper.
Printing Photos Saved on a Memory Card
Photo paper can only be loaded in the rear tray.
1 Turn on the printer.
2 Load several sheets of photo paper.
3 Insert the memory card into the card slot.
4 Flick right and left through the photos and
select one.
5 Tap the Color button to start printing.

1
ESPAÑOL
Instalación de la impresora
1. Contenido de la caja
•
Depósitos de tinta para
configuración •
Cable de alimentación
•
CD-ROM de instalación para Windows
•
Información de seguridad
e información importante
•
Guía de inicio (este manual)
2. Retirar los materiales de
protección
Importante
Cuando comienza la impresión, se abre el panel de control y se
extrae la bandeja de salida del papel automáticamente. No coloque
nada delante de la impresora.
1 Retire y tire los materiales de protección y la
cinta naranja.
• El uso de la impresora con la cinta naranja o material
de protección todavía adherido podría provocar un
mal funcionamiento de la impresora.
2 Abra la cubierta/unidad de escaneado y elimine
la cinta naranja.
b
a
3 Cierre la cubierta/unidad de escaneado.
• Abra la cubierta/unidad de escaneado
completamente y luego ciérrela.
Precaución
Tenga cuidado con los dedos.
a
b
3. Encender la impresora
1 Conecte el cable de alimentación.
Atrás
Importante
En este momento, no conecte ningún otro cable.
2 Abra el panel de control y pulse el botón
ACTIVADO (ON).
a
b
3 Desplácese y puntee para seleccionar su idioma
y luego puntee Sí (Yes).
4 Puntee OK.
4. Instalación de los depósitos
de tinta
1 Abra la cubierta/unidad de escaneado.
Precaución
No toque el soporte del cabezal de impresión hasta que
deje de moverse.
Conguración en línea

2
Instalación de la impresora
2 Retire la cinta y la película del depósito de tinta.
ba
• Compruebe que la cinta se ha eliminado completamente.
3 Retire la tapa naranja despacio.
Importante
• No apriete el depósito de tinta si el
orificio de aire en forma de Y está
bloqueado.
• No toque las áreas rojas que se muestran
en rojo.
4 Instale el depósito de tinta.
• Inserte el depósito de tinta en el cabezal de impresión
y empújelo hacia abajo hasta que encaje en su sitio.
5 Compruebe si el color del depósito de tinta que
instaló aparece en pantalla.
Importante
Si no se muestra el color en pantalla a pesar de haber instalado
el depósito de tinta, es posible que el color del depósito de tinta
no sea correcto o que haya instalado un depósito de tinta, por
ejemplo con un número de modelo distinto que no sea compatible
con esta impresora. Instale un depósito de tinta para el color
correcto o utilice el depósito de tinta proporcionado para la
configuración.
6 Repita los pasos 2 a 5 para instalar todos los
otros depósitos de tinta.
• Compruebe que aparezcan todos los colores.
7 Cierre la cubierta/unidad de escaneado.
• La impresora comenzará a iniciarse.
Precaución
Tenga cuidado con los dedos.
a
b
5. Carga del papel
Comprobar!
Retire cualquier cinta naranja.
1 Puntee OK.
2 Retire el cassette de la impresora y retire la
cubierta del cassette.
a
b
Cubierta del cassette
