Canvas CV Camrose 088-2208 User manual

Production Number: xxxxxxxx
ASSEMBLY INSTRUCTIONS
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
CV Camrose 7 PC Fire Dining-Table
Product No. 088-2208
Model No. A201002701

WARNING: For Outdoor Use Only.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
odour
property
flammable vapours
odour.
3.
1 AA 1.5V battery required (not included)
Please dispose of or recycle the batteries
according to municipal requirements.
WARNING:
DANGER
CV Camrose 7 PC Fire Dining
.
Propane cylinder required (not included)

3MODEL NO. 088-2208 | PRODUCT NO. A201002701
TABLE OF CONTENTS
GENERAL INFORMATION
General information
Specifications
Important safety information and precautions
Expanded view
Parts list
Assembly
Location
Setup
Gas connection
Leak test
Lighting
Storage and maintenance
Troubleshooting
Limited warranty
3
4
4
6
7
11
12
11
12
13
10
8
10
10
IMPORTANT
Please take time to read these instructions thoroughly and follow each step carefully for safe and easy
operation. Keep this manual for installer and consumer future reference/use. We would like to hear from
you with any comments or suggestions.

Product name
Model No.
Rated Heat Output
Fuel
Gas Supply
Manifold Pressure
Orifice Size (diameter)
Gas Supply Pressure
CV Camrose 7 PC Fire Dining
4
SPECIFICATIONS
IMPROTANT SAFETY INFORMATION AND PRECAUTIONS
Propane—LP
20 lb (9 kg) LP-Gas cylinder
11" W.C.
1.9 mm
25 PSI (minimum) to 250 PSI (maximum)
The installation must comply with local codes, or in the absences of local codes with the
National Fuel Gas Code, ANSI Z223.1/NF-PA54; The international Fuel Gas Code, Natural Gas
and Propane Installation Code, CSA B149.1; or the Propane Storage and Handling Code, B149.2,
as applicable.
The LP gas supply cylinder to be used must be:
1-Constructed and marked in accordance with the U.S. Department of Transportation (D.O.T.)
Specifications for LP-Gas Cylinders, or the Standard for Cylinders, Spheres and Tubes for
trans portation of Dangerous Goods and Commission, CAN/CSA-B339 as applicable;
2-Provided with a listed overfilling prevention device;
3-Provided with a cylinder connection device compatible with the connection for the appliance.
Always place the appliance on a firm and level surface.
Solid fuels must not be burned in this gas appliance. When using decorative lava rocks, use
only lava rocks (INCLUDED).
The appliance must be used only outdoors in a well-ventilated space and shall not be used in a
building, garage or any other enclosed area.
When in use, keep the appliance area clear and at least 40" (101.6 cm) side, back and top
oD.sruopavdnadiuqilelbammalfrehtodnaenilosag,slairetamelbitsubmocmorfecnaraelc
not use the appliance under overhead combustible surfaces. Certain items or materials, when
stored under the appli
ance or nearby, will be subjected to radiant heat and could be damaged.
088-2208 A201002701
38,000 BTU/HR

5MODEL NO. 088-2208 | PRODUCT NO. A201002701
IMPROTANT SAFETY INFORMATION AND PRECAUTIONS
Open the door and inspect the hose assembly and burner prior to each use. If there is evidence of
excessive abrasion or wear or if the hose or burner is damaged, it must be replaced by an
appropriate part from the manufacturer.
Inspect the gas connections of the appliance prior to each use. Do not operate the unit if there is
a gas leak. Have the appliance inspected annually by a qualified service person.
The pressure regulator and hose assembly provided with the appliance must be used. The replace-
ment part must be the same as the part specified by manufacturer.
For instructions on how to connect the LP-Gas tank and check for leaks, please refer to the “Gas
Connection” on page 18 and “Leak Test” on page 19.
Children and adults should be alerted to the hazards of high surface temperatures and should stay
away to avoid burns and prevent clothing ignition.
Young children and pets should be carefully supervised when they are in the area of the appliance.
Any guard or other protective device removed for servicing the appliance must be replaced prior
to operation.
Clothing or other flammable materials should not be hung from the appliance or placed on or near
the appliance.
Do not use this appliance if any part has been under water. Immediately call a service technician to
inspect the appliance and to replace any part of the control system which has been under water.
LP-Gas supply cylinder to be used must be constructed and marked in accordance with the specifi-
cations for LP-Gas cylinders of the U.S. Department of Transportation (DOT).
The cylinder supplies system must be arranged for vapour withdrawal and the cylinder must include
a collar to protect the cylinder valve.
Use only 20 lb (9 kg) LP-Gas cylinders.
Do not burn wood or any other materials in this appliance.
The appliance must be isolated from the gas supply piping system by closing its individual manual
The appliance must be isolated from the gas supply piping system by closing its individual manual
shutoff valve during any pressure testing of the gas supply piping system at test pressure equal to
or less than 1/2psi (3.5kPa).
Other cylinders may be acceptable for use with the appliance provided they are compatible with
the appliance retention means and accompanied by illustration(s) depicting the cylinder mounted on
the appliance using the cylinder retention means and the point of contact between the cylinder and
the retention means.
Properly place the hose out of pathways where people may trip over it or
in areas where they may be subject to accidental damage.
The burner must be replaced prior to the appliance being put into
operation if it is clear that the burner is damaged. The replacement
burner must be the same as the part specified by the manufacturer.
To clean the appliance, including the burner, please refer to “Storage and
Maintenance” on page 20 .
18" (46 cm)
12 1/2" (32 cm)

6
EXPANDED VIEW
EXPANDED VIEW

PARTS LIST
MODEL NO. 088-2208 | PRODUCT NO. A201002701
7
Parts List
Label Part Number Description Qty Part Image
A P003100067 Lid
Top
Bowl
Back panel
Side panel
Panel
Cylinder rack
Lava rock (1KG)
Accessory for door
1
B P002100225 1
C P002500092 1
D P002400030 1
E P004100085 1
F P002400032 1
G P002400031 1
H P006700047 1
IP006600020 4

If you want to replace the parts listed, please contact Customer Service Centre: 1-888-670-6684
PARTS LIST
Hardware Pack
Label Part Number Description Qty Add Part Image
AA
H010020001 Bolt M6*15 32 3
BB
H090010002
Bolt M6*15 4 1
CC
H050010023
Flat washer M6 36 3
DD
H090010002 Wrench M6 1 0
J P00510010 Chain
Long foot tube
Short foot tube
Support
8 2
K1 P005700317 2
K2 P005700318 2
L P005000292 4
8

MODEL NO. 088-2208 | PRODUCT NO. A201002701
9
ASSEMBLY
1
1x
4x 4x
1x 1x

ASSEMBLY
28x
8x

ASSEMBLY
MODEL NO. 088-2208 | PRODUCT NO. A201002701
11
4x 4x
1x
1x
3

4
ASSEMBLY
1
2x
8x
2x
2x
11 of 17
8x

5
ASSEMBLY
MODEL NO. 088-2208 | PRODUCT NO. A201002701
13
8x 8x

6
ASSEMBLY
14
4x 4x

7
ASSEMBLY
15 MODEL NO. 088-2208 | PRODUCT NO. A201002701
1x

8
ASSEMBLY
16
1x

ASSEMBLY
MODEL NO. 088-2208 | PRODUCT NO. A201002701
17
2x
9

Your gas appliance must be installed on a flat, stable surface, away from any
combustiblematerials or construction.
1-Remove the appliance from container box and placeit on any level, outdoor,
non-combustible surface.
NOTE: Do not place this applianceon grass or dirt area. This may prevent proper
safety venting.
2-Open the gas door and put the cylinder inside.
1) Clean the valve and ensure the tank holder is situated in an appropriate location (Fig. 1).
2) Loosen the tank holder retainer bolt by turning counter-clockwise (Fig. 2). Place the
propane tank on the tank holder (Fig.3) and tighten the retainer bolt securing the tank to
the tank holder (Fig. 4).
3) Connect the regulator to the propane tank as shown (Fig. 5). Perform aleak test as
described on page 11.
4) Disconnect the regulator from the tank as shown (Fig. 6).
LOCATION
SETUP
Gas Connection
Your Gas appliance comes assembled, ready for a Gas connection.
3-Unscrew the battery box as shown in Fig 1.Insert the negative electrode side of the
battery into the bottom of battery box as shown in Fig 2. Then screw the battery box as
shown in Fig 3.
Fig. 1Fig. 2 Fig. 3
18
78

Do not use an open flame to check for leaks.
Do not smoke during testing.
Do not test indoors.
A leak test must be performed whenever the gas cylinder is replaced.
WARNING!!!
NOTE: While in use, the burner flame should be mainly blue in appearance with a small
amount of yellow. Theflame canbe identified by the following figure.
1. Make sure the control knob isin the “OFF” position.
2. Make sure the gas cylinder is correctly and securely connected to the pressure regulator,
without over-tightening.
3. Turn on the gas cylinder valve. Apply 50% soap and 50% water solution to the gas hose
and connections betweenthe control knob and gas cylinder.
4. If something is leaking, you will see bubbles form. In case of leaks, turn off the gas supply,
undo the leaking connection, re-connect it and try again. If the leak persists, consult
Customer ServiceCentre for assistance at 1-888-670-6684.
5. If the connection does not leak, continue to the next step.
1. Push in and turn control knob to LOW.
2.
If the burner is not lit, turn the knob back to "OFF" ait 5 minutes
3.
If burner is lit, continue to depress control knob for 1-2 minutes
.tohsielpuocomrehtehtlitnu
4. Release control knob and the burner should stay lit.
5. Turn control knob to desired heat setting: LOW – HIGH.
6.
LEAK TEST
MODEL NO. 088-2208 | PRODUCT NO. A201002701
19
LIGHTING
LEAK TEST
Turn controlknobto OFF to shut down. Turnoff gas supply at
cylinder. Allow a 5-minute complete shut off period before relighting
the appliance.
and repeat step 1.
Press andturn the control valve knob clockwise to OFF toshutdown the fire pit.
Close the gas cylinder valve when the fire pit isnot inuse.
(CAUTION: Do not kink flexible gas hose. Ifitis kinked, a gas leak could occur.)
7.
Warning: Lighting the fire tableimproperly could lead toan unsafe condition.
BLUE
BLUE
LOW
HIGH
YELLOW TIPS
LOW
Correct Flame
Incorrect Flame
OFF
HIGH
MAX
BAS
ARRET
LOW

To obtain the best performance from your fire table, you must perform the following
storage and maintenance activities on a regular basis:
Allow at least 35 minutes for the fire table to cool down after
use, before disconnecting and removing the gas cylinder.
Store the gas cylinder in a dry, well-ventilated and
sheltered area protected from inclement weather and dust,
out of the reach of children, and not in a building, garage or
any other closed area.
The fire table may be storedindoors only if the cylinder is
disconnected and removed.
Keep the fireplace area clear and free from combustible materials,
gasoline and other flammable vapours and liquids.
Installation and repair should be done by a qualified service person. The fire table
should be inspected before use and at least annually by a qualified service person.
More frequent cleaning may be required as necessary. It is imperative that the control
compartment, burner, and circulating air passageways of the fire table be kept clean.
If you disassemble the burnerwhen cleaning the fire table, please reassemble it
according tothe picture on the righttomake sure the burner induction tunnelis on
and exactly covers the orifice base. Itis imperative that the controlcompartment,
burner, and circulating air passageways of the fire table bekept clean. Itisrecommended
not to disassemble the burner.
Permanent installation and repair should bedone byaqualified service person. The
fire table should beinspected annually byaqualified service person.
20
STORAGE AND MAINTENANCETROUBLESHOOTING
PROBLEM OBSERVED POSSIBLE CAUSE CORRECTIVE MEASURES
G as odour G as l
Low gas pressure
Clogged or dirty burner
ports
Blocked orifice
Spent battery
Incorrect gas supply or
pressure
Blocked orifice
Clogged or dirty burner ports
eak
.
Check gas supply pressure.Delayed ignition
Clean burner ports—see manual
section.
Check orifice opening.
Replace battery.
Check gas supply pressure.Incorrect burner flame
Check and clean orifice opening.
Clean burner ports.
