Canvas HAVANA GAZEBO User manual

CANOPY FOR 88-0342
HAVANA GAZEBO
ASSEMBLY INSTRUCTIONS
Toll-free: 1-888-670-6684
IMPORTANT: Please read this manual carefully before beginning assembly of this product.
Keep this manual for future reference.
Production Number :xxxxxxxx
MODEL NO. 088-1044-2
PRODUCT NO. A111001300

IMPORTED FOR TRILEAF DISTRIBUTION TRIFEUIL TORONTO, CANADA M4S 2B8

3
TABLE OF CONTENTSIMPORTANT SAFETY INSTRUCTIONS
Table of Contents 3
Important Safety Instructions 3
Parts List 4
General Requirements 4
Assembly 5-12
Cleaning and Maintenance 13
Technical Data 13
Warranty 13
IMPORTANT: Retain for future reference, and read carefully.
Warning! Please read and understand the manual before proceeding
with assembly. To check and ensure all parts present without breakage.

4
PARTS LIST
MODEL NO. 088-1044-2 | PRODUCT NO. A111001300
1-888-670-6684
- 1
Large Canopy
3A P001100375
- 1Small Canopy
3D P001100376
Let us help you!
DO NOT RETURN YOUR PRODUCT TO THE STORE. CALL US FIRST!
If you have questions regarding your product, require warranty
assistance, or have damaged or missing parts, please call our
customer service toll-free helpline. Contact us for assistance;
we’rehere to help.
IMPORTANT: Please read and understand this manual before any assembly. Before beginning
the assembly of product, make sure all parts are available. Compare parts list with packaging
contents. If any part is missing, or if you have any questions, contact the service centre
at 1-888-670-6684 (toll-free).
Unpack and place all the parts from the packaging box in an open areaand position them on the
floor. Remove all packing materials and place them back into the box. Do not dispose of the
packing materials until assembly is complete. Read each step carefully before beginning anyassembly
and make sure you understand each step. If you are missing a part, please call our toll-free number
for assistance: 1-888-670-6684.
Needed for assembly: The following tooling not included in the package
Screwdriver Ladder 2 people
GENERAL REQUIREMENTS

5
ASSEMBLY
1

ASSEMBLY
6MODEL NO. 088-1044-2 | PRODUCT NO. A111001300
2

7
ASSEMBLY
3

8 MODEL NO. 088-1044-2 | PRODUCT NO. A111001300
ASSEMBLY
4

9
ASSEMBLY
1X
5

10 MODEL NO. 088-1044-2 | PRODUCT NO. A111001300
ASSEMBLY
1X
6

11
ASSEMBLY
7

12 MODEL NO. 088-1044-2 | PRODUCT NO. A111001300
ASSEMBLY
8

CAUTION!
Check all screws and nuts periodically for tightness; fasten them as
required.
Disassemble the gazebo in reverse order of the steps used to assemble.
Always disassemble the gazebo completely. A partially-disassembled
gazebo is not stable enough to resist wind and bad weather, and
therefore canbedamaged and/or cause damage.
CLEANING AND MAINTENANCE
WARRANTY TECHNICAL DATA
Dimensions (L x W x H) 127.75'' x 127.75'' x 35.82''
324.5 x 324.5 x 91 cm
Product weight 5.5 lbs
2.5 Kg
This product carries a one (1) year warranty against defects in workmanship and
materials.
Trileaf Distribution agrees to replace the defective product free of charge within
the stated warranty period, when returned by the original purchaser with proof of
purchase. This product is not guaranteed against wear or breakage due to misuse
and/or abuse.
