Canvas TRINITY SIDE C-TABLE 168-0069-0 User manual

TRINITY SIDE C-TABLE
MODEL NO. 168-0069-0
ASSEMBLY INSTRUCTIONS
HAVING TROUBLE?
TOLL-FREE:
1-888-670-6684

We believe the power of decor and how
it makes up the fabric of your home.
That’s why the CANVAS assortment gets
its inspiration from Canadians and the
way they live.
From on-trend furniture pieces, to
Holiday Decor and Outdoor Living,
CANVAS makes it easy to refresh your
space to reflect your unique style and
the way you live.
We welcome your thoughtful comments
and feedback so please visit our website
to tell us about your experience.
We would love to see how you bring
CANVAS to life. Please share your
photos using #mycanvasstyle.
Parts List/Exploded View 4
Step-by-Step Instructions 6
Warranty 10
Caring for your item 10
Hex KeyTo avoid damage, ensure screws are
hand tightened. DO NOT USE POWER
TOOLS TO ASSEMBLE YOUR UNIT.
2 people
TABLE OF CONTENTS
TOOLS REQUIRED
• This product is intended for domestic indoor use only.
• The product should be placed on a flat horizontal surface.
• Arrange necessary manpower when assembling or moving the product.
• Do not push furniture, especially on a carpeted floor. Have someone help
you lift heavy items and set it in place.
• Check all screws periodically for tightness. When required, tighten them again.
• Do not exceed maximum weight capacity of 44 lb (20 kg).
WARNING! TO REDUCE THE RISK OF SERIOUS INJURY,
READ THE FOLLOWING SAFETY INSTRUCTIONS BEFORE
ASSEMBLING AND USING THE SIDE TABLE.
TRINITY SIDE C-TABLE 3

4 5TRINITY SIDE C-TABLETRINITY SIDE C-TABLE
ITEM DESCRIPTION QUANTITY
A Tabletop 1
B Table legs 2
C Tabletop rungs 2
D Table leg rung 1
E Screws M6x35 mm 6
F Screws M6x25 mm 4
G Hex key 1
PARTS LIST EXPLODED VIEW
A
B
C
D
E
F
G

6 7TRINITY SIDE C-TABLETRINITY SIDE C-TABLE
100 %
100 %
STEP 1
REQUIRES B, C, E, G
Hand tighten the two TABLETOP RUNGS (C) to the TABLE LEGS (B) using two
SCREWS M6x35 mm (E) and HEX KEY (G).
STEP 2
REQUIRES D, E, G
Hand tighten the TABLE LEG RUNG (D) to the TABLE LEGS (B) using one SCREW
M6x35 mm (E) and HEX KEY (G).
X2 X1X1 X2 E
E
BC
C
E
E
GB C
G
2used
2used
1used
1used
1used
X1 X1X1 E G
G
D
D
STEP-BY-STEP INSTRUCTIONS STEP-BY-STEP INSTRUCTIONS

8 9TRINITY SIDE C-TABLETRINITY SIDE C-TABLE
100 %
100 %
STEP 3
REQUIRES B, E, G
Hand tighten the other TABLE LEG (B) to the TABLETOP RUNGS (C) and the TABLE
LEG RUNG (D) using three SCREWS M6x35 mm (E) and HEX KEY (G).
STEP 4
REQUIRES A, F, G
Note: Overturn the frame so that the side with the plastic foot pads is facing upwards.
Hand tighten the TABLETOP (A) to the frame using four SCREWS M6x25 mm (F) and
HEX KEY (G).
G
STEP-BY-STEP INSTRUCTIONS STEP-BY-STEP INSTRUCTIONS
X3 X1X1 E
E
E
E
G
G
B
B
3used
4used
1used
X4X1 X1
G
G
F
F
F
F
F
A
A

10 TRINITY SIDE C-TABLE
WARRANTY
CARING FOR YOUR ITEM
1. Avoid direct sunlight.
This product is intended
for indoor use only.
5. Do not exceed the
maximum load capacity
(20 kg, 44 lb).
3. Do not use unless all
bolts and screws are
firmly tightened.
2. Do not light any fires
on or near the product!
4. For cleaning, use
water or mild detergent;
do not use solvent-type
cleaning agents; if there
is solvent on the product,
clean with dry cloth and
water.
6. Do not stand or step
on the product.
1 2 3
4 5 6
This CANVAS™ product carries a one (1) year warranty against defects in workmanship and
materials. Trileaf Distribution agrees to replace the defective product free of charge within the
stated warranty period, when returned by the original purchaser with proof of purchase. This
product is not guaranteed against wear or breakage due to misuse and/or abuse.
Made in China
Imported by Trileaf Distribution Trifeuil Toronto, Canada M4S 2B8
MODEL NO. 168-0069-0
Exclusively at Canadian Tire
