CAS CBX User manual

2
CBX 앞표지

3
PRECAUTIONS

4

5
Other conventions used in this manual include:
Item Description
1) 2) 3)… Indicates the step number in a procedure or a sequence of changes in the
balance display.
Indicates the display change or action sequence performed by the balance
after an operation has been initiated.
Refer to the recommended sections for further information on a specific topic.
etc. Indicates the balance display status.
Underlined portions (_) indicate that the character is blinking.
mass display Indicates the balance is in the weighing mode and mass is displayed in one of
the weighing units.
These sections include information to make using the balance more
convenient.
Menu Map item
[1]
Indicates the Menu Map item to be selected.
The number inside the [ ] is the number of the item on the Menu Map.
See Section 2.3 "Menu Map."

6
1. BASIC OPERATION.........................................................................................10
1.1 Balance Components......................................................................................10
1.1.1 Operations of the Keys on the Main Unit................................................................. 12
1.1.2 Symbol Display............................................................................................................. 13
1.2 Installation .............................................................................................15
1.2.1 Choosing the Installation Site ................................................................................... 15
1.2.2 Balance Installation....................................................................................................... 15
1.3 Turning the Power ON ...................................................................................17
1.4 Adjusting the Built-in Clock ..........................................................................18
1.5 Span Calibration.............................................................................................18
1.6 Wegighin........................................................................................................18
1.6.1 Changing the Unit Display.......................................................................................... 19
1.6.2 Changing the Minimum Display Digit（／ ）............................. 19
1.7 Maintaining and Transporting the Balance.....................................................19
1.7.1 Cleaning the Balance ...................................................................................................... 19
1.7.2 Transporting the Balance................................................................................................ 19
1.8 Specifications .................................................................................................20
2. MEMU ITEM SELECTION.............................................................................21
2.1 Introduction ....................................................................................................21
2.2 Procedure of Menu Item Selection .................................................................21
2.3 Menu Map ......................................................................................................23
2.4 General Menu Operations...............................................................................31
2.4.1 Setting Numeric Values............................................................................................... 31
2.4.2 Setting a Decimal Point................................................................................................ 31
2.4.3 Menu Lock..................................................................................................................... 31
2.4.4 Last Menu Recall.......................................................................................................... 32
2.4.5 Returning to the Default Settings (menu reset)........................................................ 33
2.5 Calibration Execution Menu...........................................................................34
2.5.1 Calibration......................................................................................................................... 34
2.5.2 Span Calibration Using the Built-in Weight, ............. 35
2.5.3 Calibration Check Using the Built-in Weight ................ 35
2.5.4 Span Calibration Using External Weights ........................................ 36
2.5.5 Calibration Check Using External Weights ............................ 37
2.6 Calibration Setting Menu ...............................................................................38
2.6.1 Selecting the Standard Calibration Type ( -) ........................ 38
2.6.2 PCAL - Calibration of the Built-in Weight -.................... 38

7
2.7 Graphic Display Menu : ...............................................39
2.7.1 Overview.........................................................................................................................39
2.7.2 Full Scale Mode ...................................................................39
2.7.3 Target Mode .........................................................................39
2.7.4 Group Mode .........................................................................40
2.7.5 Level Mode ..........................................................................40
2.7.6 No Graphic Display ............................................................40
2.8 Environment Menu : ....................................................41
2.8.1 Overview.........................................................................................................................41
2.8.2 Averaging ................................................................................41
2.8.3 Stability Detection Band ........................................................41
2.8.4 Tracking ....................................................................................42
2.8.5 Pretaring Value ..................................................................42
2.8.6 Whole Lighting Mode .............................................................43
2.8.7 Taring/Printing .................................................43
2.9 Application Menu : .......................................................44
2.9.1 Overview.........................................................................................................................44
2.9.2 Zero Range .....................................................................................................................44
2.9.3 Auto Zero........................................................................................................................45
2.9.4 Auto Print........................................................................................................................45
2.9.5 Peak Hold........................................................................................................................46
2.9.6 Interval Timer.................................................................................................................47
2.9.7 Auto-Memory and Zeroing ...........................................................................................47
2.9.8 Animal Weighing..........................................................................................................48
2.10. Unit Registration Menu and Unit Change....................................................49
2.10.1 Unit Registration Menu................................................................................................49
2.10.2 % Conversion.................................................................................................................49
2.10.3 Piece Counting...............................................................................................................50
2.10.4 Solid Specific Gravity Measurement.........................................................................51
2.10.5 Liquid Specific Gravity Measurement......................................................................52
2.11 System Setting Menu : .............................................53
2.11.1 Date for the Built-in Clock...........................................................................................53
2.11.2 Time for the Built-in Clock ...................................................53
2.11.3 Display During Standby ........................................................53
2.11.4 Measurement Control System ................................................54

8
2.12 Communication Menu ( blinking) .......................55
2.12.1 Overview........................................................................................................................ 55
2.12.2 Handshaking - .................................................................... 55
2.12.3 Format ................................................................................ 55
2.12.4 Communication Speed .................................................. 56
2.12.5 Parity / Bit Length -.............................................................. 56
2.12.6 Stop Bit －............................................................................. 56
2.12.7 Delimiter ........................................................................... 56
3. CONNECTIONG PERIPHERAL INSTRUMENTS.........................57
3.1 EP-60A Electronic Printer..............................................................................57
3.2 Personal Computer - RS-232C -.....................................................................57
3.2.1 Connecting the Cable................................................................................................... 57
3.2.2 Data Format ................................................................................................................... 58
3.2.3 Using Command Codes.............................................................................................. 59
3.2.4 Windows® Direct Function ....................................................................................... 64
3.2.5 Multi-Connection Mode.............................................................................................. 67
3.3 Optional AKB-301 Application Keyboard.....................................................69
3.3.1 Basic Information.......................................................................................................... 70
3.3.2 Example of Use............................................................................................................. 71
3.4 Foot Switches .................................................................................................73
3.5 Hook for Below-Balance Weighing ...............................................................74
4. APPENDIX............................................................................................75
4.1 Part List ..........................................................................................................75
4.1.1 Standard Accessories and Maintenance Parts ......................................................... 75
4.1.2 Options............................................................................................................................ 75
4.2 Table of Unit Conversion Constants...............................................................76
4.3 Specifications for the RS-232C/AUX Connector ...........................................77
4.4 Error Display List...........................................................................................78
4.4.1 General Display............................................................................................................. 78
4.4.2 Error Display.................................................................................................................. 79

9
INTRODUCTION
Thank you for purchasing this medium-sized electronic balance, the CAS CBX-K/ CBW-K
series.
In addition to its ability to make rapid mass measurements, the CBX-K/ CBW-K series is also
well-equipped with a four-mode analog display, clock function, various application
measurement functions and a unit conversion function. Furthermore, it is a high performance,
multi-functional balance which can be used in a great variety of applications when connected
to peripherals. The CBW-K series features a built-in calibration weight which allows easy
sensitivity calibration wherever you are, making it even more convenient to use.
Before using the balance read this instruction manual carefully to ensure long and fruitful use
of the CBX-K/ CBW-K series.

10
1. BASIC OPERATION
1.1 Balance Components
Open the package and sure following items are included.
Balance body, pan, AC adaptor, Balance cover, adhesive tape,
Instruction manual, inspection certificate,
<CBW-K only>
Internal weight, Fix screw of the internal weight, cover of the internal weight
Fix of the screw of the internal cover
Name Appearance Notes
Balance unit
The serial number of the balance is
stated on this nameplate
Pan
Built-in calibration
mass
Check that the numerals on this
part are the same as the last 5
figures of the serial number on the
balance unit (CBWK series only)
Calibration
weight stopper
screw
(CBWK series only)
Calibration weight
cover (CBWK series only)
Calibration weight
cover setscrew (CBWK series only)
AC adaptor

11
Position of the calibration lever (CBW-K series only)
Regardless of whether the calibration lever is in the measurement or calibration position,
ensure that both the left and right levers have been turned until they come to a stop.
Calibration lever (2 places, on the left and on the right)
(CBW-K series only)
Level screws
Level
Dis
p
la
y
Pan
Balance unit
Ke
y
switch
KEY Connector
RS-232C
Connector
DATA I/O
Connector
DCIN
Connector
Measurement
position ···········································
Calibration
position ···········································
Rear of balance
Front of balance
