CB2 shelf User manual

2 - shelf support
panels
(1 - Labeled A,
1- Labeled B)
2 - side rail
support panels
AB
hex wrench (included)
shelf KING BED
Made in India - r06 Page 1 of 4
hardware
components
tools required
Customer Service 800.606.6252 | Latest instructions available at www.cb2.com
2 - bolts
Thank you for purchasing the Shelf King Bed. This page
lists all the contents included in the box. Please take the
time to identify the hardware as well as the individual
components to this product. As you unpack and prepare
for assembly, place the contents on a carpeted or
padded area to protect them from damage.
Note: 2 people are required to safely assemble this product.
8 - nuts 10 - washers 8 - pins
1- headboard
(Labeled A)
1 - footboard
(Labeled B)
1 - center rail
2 - side rails
(1 left, 1 right)
Missing hardware?
Please call 800.606.6387 for replacements.
1 - headboard
shelf (Labeled A)
1 - footboard
shelf (Labeled B)
2 - slat assemblies
A
B
A
B

STEP 1: With assistance of another adult, carefully fit notched end of shelf support panel A
into bottom of headboard shelf shown.
STEP 2: Fit threaded studs of headboard shelf into corresponding holes and slot of head-
board as shown. Make sure threaded stud is exposed on the other side of headboard.
headboard
headboard
shelf assembly
A
headboard
shelf
shelf
support
panel
A
STEP 1
STEP 2
shelf KING BED
2
MadeinIndia -r06 Page2of 4
CustomerService800.606.6252|Latestinstructionsavailableatwww.cb2.com
1
STEP 2
A
STEP 1
STEP 2
headboard
assembly
left side
rail
right side
rail
center
rail
bracket
STEP 1: With assistance of another adult, fit threaded
studs of headboard into corresponding brackets of
left and right side rails. Using a hex wrench, secure
each threaded stud with 1 hex nut and 1 washer as
shown.
STEP 2: Attach bracket of center rail to headboard
with 1 bolt and 1 washer as shown, using a hex
wrench.
B
STEP 1

A
STEP 2
STEP 3
STEP 2
STEP 3
headboard
left side
rail
right side
rail
bracket
center
rail
bracket
STEP 1 : Fit dowels of footboard shelf into correspond-
ing holes and slot of footboard as shown. Make sure
threaded stud is exposed on the other side of footboard.
STEP 2: Fit threaded studs of footboard into corre-
sponding brackets of left and right side rails. Using a
hex wrench, secure each threaded stud with 1 hex nut
and 1 washer as shown.
STEP 3: Attach bracket of center rail to footboard with
1 bolt and 1 washer as shown, using a hex wrench.
footboard
footboard
shelf
B
STEP 1
B
Carefully fit notched end of shelf support panel B into bottom of footboard shelf shown.
footboard
shelf
shelf
support
panel
shelf KING BED
3
MadeinIndia -r06 Page 3of4
CustomerService800.606.6252|Latestinstructionsavailableatwww.cb2.com
4

side rail
support
panel
Fit notched end of 1 side rail support into left and
right side rails as shown. Make sure side rails are
securely supported by side rail support panels.
With assistance of another adult, place
2 slat assemblies onto side and center
rails. Attach slat assembly with 8 pins
as shown.
Assembly is now complete.
6
5
cleaning & care
Clean surfaces with a dry soft cloth. Do not use abrasive cleaners.
