CEECO WPP-531-FD User manual

Issue 4.0
SERVICE MANUAL
FOR
MODEL WPP-531-FD
HANDS FREE WEATHERPROOF TELEPHONE
AND
MODEL SSP-531-FD
STAINLESS STEEL PANEL TELEPONE
EQUIPPED WITH SPK1.07 UNVL FIRMWARE
R
COMMUNICATION EQUIPMENT AND ENGINEERING COMPANY
519 W South Park Street Okeechobee, FL 34972
863-357-0798
Serving The Telephone Industry Since 1930.

Issue 4.0
IMPORTANT INFORMATION
FOR
CUSTOMER
Please fill in before you continue.
The following information is necessary when calling CEECO for assistance.
MODEL NUMBER MODEL SSP-FD OR WPP-531-FD
EQUIPPED WITH SPK1.07 FIRMWARE
SERIAL NUMBER
DATE MANUFACTURED
LOCATION INSTALLED
For us to better serve you, please have this information available when calling for technical support.
CEECO
Communication Equipment & Engineering Company
519 W South Park Street
Okeechobee, FL 34972
863-357-0798- telephone
863-357-0006- facsimile
[email protected]
www.ceeco.net

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
3
TABLE OF CONTENTS
SECTION PAGE
1.0 INTRODUCTION ............................................................................................................. 4
2.0 GENERAL......................................................................................................................... 4
3.0 PROGRAMMING:............................................................................................................ 5
4.0 PROGRAMMING TABLES............................................................................................. 9
5.0 OPERATION................................................................................................................... 11
6.0 RECOMMENDED TOOLS AND TEST EQUIPMENT:............................................... 12
7.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS: .............................. 12
8.0 TESTING: ....................................................................................................................... 13
9.0 SPECIFICATIONS: ........................................................................................................ 14
10.0 PARTS LIST: .................................................................................................................. 15
11.0 FCC NOTICE:................................................................................................................. 16
12.0 REPAIR AND RETURN INFORMATION: .................................................................. 17
13.0 WARRANTY POLICY:.................................................................................................. 18

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
4
1.0 INTRODUCTION
The practices in this manual provide installation and maintenance information for
the CEECO Model SSP 531-FD or Model WPP-531-FD Telephone with SPK1.07
Universal firmware.
The information in this manual is subject to change without notification.
For information not included in this manual, please call or write:
CEECO
Customer Service
519 W South Park Street
Okeechobee, FL 34972
863-357-0798- telephone
863-357-0006- facsimile
[email protected]
www.ceeco.net
2.0 GENERAL
2.01 The CEECO hands free telephone is a sturdy, vandal resistant, Stainless
Steel Panel Speakerphone, with optional ADA feature (RED/GREEN
LED). Instead of a hookswitch and handset, the telephone has a Press to
start/Press to stop button for initiation and termination of phone calls. The
Emergency Auto Dial button is also provided for one button dialing of a
preprogrammed number of up to 11 digits. Manual volume control is also
provided inside the telephone.
2.02 The microphone is muted during dial tone eliminating the use of hand held
dialers.
2.03 Incoming calls may be allowed or blocked depending on the
programming.
2.04 Programming is accomplished via the DTMF keypad.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
5
3.0 PROGRAMMING:
NOTE: It is recommended that you ground yourself to prevent ESD
damage to the PCB(s).
3.01 Connect the phone to a working telephone line or a DTMF test set before
programming.
3.02 Move the mini-jumpers (located on the CEECO-SPK Printed Circuit
Board) to the “ON” position, as depicted on the last page of this manual.
3.03 Press the CALL button and wait for dial tone before programming any
digits.
3.04 Each location is accessed by dialing the "#" sign and a two digit code. The
valid program locations are: #00, #01, #02, #18, #30, #69 (speed dial
locations), and #70-#89 (allowed call locations). The previous contents of
the location are automatically erased when the location code is accessed.
NOTE:Once the “#" (pound) key has been entered you may get an
operator recording or a fast busy, please disregard and continue
programming.
3.05 To clear all user programmable memory, with the phone on hook (no dial
tone) and the mini-jumpers in the "ON" position, press the CALL button
located on the front of the phone and dial #97#18#.
3.06 Location "00" is the phone option location. It is comprised of ten digits,
all of which must be filled to render the phone functional. By entering 0
or 1 into each of the 10 digits, the phone is customized to a particular
installation.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
6
PROGRAMMING CONTINUED…
LOCATION #00:(OPTION TABLE)
#00 __ __ __ __ 0 __ 1 0 __ __
Digit 1:
0 Call restrictions are in effect. (Default)
1 No call restrictions.
Digit 2:
0 No incoming calls allowed. (Default)
1 Incoming calls allowed.
Digit 3:
0 No Conversation Time-Out. (Default) For Emergency Button
1-9 Minutes Conversation Time-Out
Digit 4:
0 No Conversation Time-Out. (Default) For Call Button
1-9 Minutes Conversation Time-Out
Digit 5:
0 Always 0 for this model. (Default)
Digit 6:
0 No ADA Feature (Default) Always 0 for this model.
9 Activate ADA Feature
Digit 7:
0Always 0 for this model
Digit 8:
0 Do not dial PBX access number #l8 (Default)
1 Dial PBX access number stored in Location #18 For Call Button
Digit 9:
0 Do not dial PBX access number #02. (Default)
1 Dial PBX number stored in location #02. For Emergency Button
Digit 10:
0 No Wink Detect
l-9 Length of the Wink (l = 50ms incremental to 450ms – entering a 5 is
recommended)

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
7
PROGRAMMING CONTINUED…
EXAMPLE:
DIAL #00 0152000015
Phone will be set as follows:
DIGIT 1 .. CALL RESTRICTIONS IN EFFECT
DIGIT 2 .. INCOMING CALLS ALLOWED
DIGIT 3 .. 5 MINUTE TIME OUT FOR EMERGENCY CALLS
DIGIT 4 .. 2 MINUTE TIME OUT FOR BLACK CALL BUTTON
DIGIT 5 .. ALWAYS 0
DIGIT 6 .. ALWAYS 0
DIGIT 7 .. ALWAYS 0
DIGIT 8 .. DO NOT DIAL PBX NUMBER STORED IN LOCATION
#18
DIGIT 9 .. DIAL THE PBX ACCESS NUMBER FIRST FROM
LOCATION #02 (SHORT PAUSE THEN DIAL EMERGENCY
NUMBER).
DIGIT 10 . 250ms WINK
LOCATION #01:(EMERGENCY NUMBER)
#01 ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___
This location holds the Emergency number to be dialed. The number can be in
the range of 1 to 11 digits. Whenever a caller pushes the "EMER" (RED) button
the number in location #01 will be dialed. If caller wants to hang up then he or
she must push the "CALL " button. The automatic time out disconnect
features will begin to work after the number has been dialed. The call will also
disconnect when the called end hangs up, provided the PBX gives the proper
wink back on the line.
LOCATION #02:(PBX - EMERGENCY NUMBER)
#02 ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___
This location holds the PBX number to be dialed for “Emergency” Calls. The
number can be from 1 to 11 digits. Any number stored in location #02 will
automatically dial first, followed by a pause, then the phone will automatically the
number stored in location #01.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
8
PROGRAMMING CONTINUED…
LOCATION #18: (BLACK CALL BUTTON)
#18 ___ ___ ___ ___ ___ ___ ___ ___ ___ ___ ___
This location holds the number to be dialed for the “Call” button. The number
can be from 1 to 11digits. Any number stored in Location #18 will automatically
dial first when the black “Call” button is pressed.
LOCATION #30 - #69: (SPEED DIAL TABLE)
If Speed Dialing is desired, enter the Speed Dial numbers in any of these 40
locations. The numbers can range from 1 to 11 digits.
EXAMPLE:
Enter #3018005551212 in the programming sequence. When in normal
operating mode, the user dials #30 and the phone will Speed Dial 1 800
555 1212.
LOCATION #70 - #89: (CALL RESTRICTIONS OR “ALLOWED”
NUMBERS)
If the phone is intended to restrict certain calling patterns, then it must be
programmed to tell it specifically which calls to allow. Enter the allowed
numbers in any of these 20 locations. The numbers can range from 1 to 11 digits.
EXAMPLE:
NOTE: The * (Asterisk) symbol is defined as a wildcard. A wildcard allows any
digit (0-9) to be emitted from the keypad.
#70 0-***-***-**** Allows all 0 minus and 0 plus calls.
#71 1-555-1212 Allows 1-555-1212 information calls.
#72 911 Allows 911 emergency calls.
#73 1-800-***-**** Allows 1-800 calls.
3.07 When programming is finished, return the mini-jumpers to the
"OFF" position. Then return the phone to an “on hook” state (no dial
tone), by pressing the black "CALL " button.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
9
4.0 PROGRAMMING TABLES
4.01 OPTION TABLE
FUNCTION DESCRIPTION
#00 _ _ _ _ _ _ _
Digit 1 2 3 4 5 6 7
4.02 SPEED DIAL TABLE
LOCATION DESCRIPTION LOCATION DESCRIPTION
#30 _ - _ _ _ - _ _ _ - _ _ _ _ #38 _ - _ _ _ - _ _ _ - _ _ _ _
#31 _ - _ _ _ - _ _ _ - _ _ _ _ #39 _ - _ _ _ - _ _ _ - _ _ _ _
#32 _ - _ _ _ - _ _ _ - _ _ _ _ #40 _ - _ _ _ - _ _ _ - _ _ _ _
#33 _ - _ _ _ - _ _ _ - _ _ _ _ #41 _ - _ _ _ - _ _ _ - _ _ _ _
#34 _ - _ _ _ - _ _ _ - _ _ _ _ #42 _ - _ _ _ - _ _ _ - _ _ _ _
#35 _ - _ _ _ - _ _ _ - _ _ _ _ #43 _ - _ _ _ - _ _ _ - _ _ _ _
#36 _ - _ _ _ - _ _ _ - _ _ _ _ #44 _ - _ _ _ - _ _ _ - _ _ _ _
#37 _ - _ _ _ - _ _ _ - _ _ _ _ #45 _ - _ _ _ - _ _ _ - _ _ _ _
#46 _ - _ _ _ - _ _ _ - _ _ _ _ #53 _ - _ _ _ - _ _ _ - _ _ _ _
#47 _ - _ _ _ - _ _ _ - _ _ _ _ #54 _ - _ _ _ - _ _ _ - _ _ _ _
#48 _ - _ _ _ - _ _ _ - _ _ _ _ #55 _ - _ _ _ - _ _ _ - _ _ _ _
#49 _ - _ _ _ - _ _ _ - _ _ _ _ #56 _ - _ _ _ - _ _ _ - _ _ _ _
#50 _ - _ _ _ - _ _ _ - _ _ _ _ #57 _ - _ _ _ - _ _ _ - _ _ _ _
#51 _ - _ _ _ - _ _ _ - _ _ _ _ #58 _ - _ _ _ - _ _ _ - _ _ _ _
#52 _ - _ _ _ - _ _ _ - _ _ _ _ #59 _ - _ _ _ - _ _ _ - _ _ _ _

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
10
PROGRAMMING TABLES CONTINUED…
4.03 FREE CALL TABLE
LOCATION DESCRIPTION LOCATION DESCRIPTION
#70 _ - _ _ _ - _ _ _ - _ _ _ _ #80 _ - _ _ _ - _ _ _ - _ _ _ _
#71 _ - _ _ _ - _ _ _ - _ _ _ _ #81 _ - _ _ _ - _ _ _ - _ _ _ _
#72 _ - _ _ _ - _ _ _ - _ _ _ _ #82 _ - _ _ _ - _ _ _ - _ _ _ _
#73 _ - _ _ _ - _ _ _ - _ _ _ _ #83 _ - _ _ _ - _ _ _ - _ _ _ _
#74 _ - _ _ _ - _ _ _ - _ _ _ _ #84 _ - _ _ _ - _ _ _ - _ _ _ _
#75 _ - _ _ _ - _ _ _ - _ _ _ _ #85 _ - _ _ _ - _ _ _ - _ _ _ _
#76 _ - _ _ _ - _ _ _ - _ _ _ _ #86 _ - _ _ _ - _ _ _ - _ _ _ _
#77 _ - _ _ _ - _ _ _ - _ _ _ _ #87 _ - _ _ _ - _ _ _ - _ _ _ _
#78 _ - _ _ _ - _ _ _ - _ _ _ _ #88 _ - _ _ _ - _ _ _ - _ _ _ _
#79 _ - _ _ _ - _ _ _ - _ _ _ _ #89 _ - _ _ _ - _ _ _ - _ _ _ _
EXAMPLE:
#70 0 - * * * - * * * - * * * * #73 1 - 4 11 - _ _ _ - _ _ _ _
Allows all 0 minus and 0 plus Allows 1411 information calls.
phone calls.
#71 9 - 1 1 _ - _ _ _ - _ _ _ _ #74 0 - 8 0 0 - * * * - * * * *
Allows 911 emergency calls. Allows 0-800 calls if set in
theoptiontable
#72 1 - 8 0 0 - * * * - * * * * #75 _ - _ _ _ - _ _ _ - _ _ _ _
Allows 1-800 calls if set in option table.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
11
5.0 OPERATION
5.01 To make a call, press the black "CALL" button located on the front of the
phone. When dial tone is received, the transmitter is muted and the phone
waits for numbers to be dialed.
5.02 To make an Emergency call, press the red "EMER" button located on the
front of the phone. The preprogrammed number will dial out on the line.
5.03 After the call is complete, press the "CALL" button again to terminate the
call. If user does not press the "CALL" button when he or she is finished
using the phone, then the phone will hang-up after detecting a WINK
(momentary open) or when the timer times-out, if it was so programmed.
5.04 If digit 1 of Location #00 is "0", then call restrictions are in effect. The
numbers that may be dialed are restricted to the numbers entered into
Location #70-#79. If the number dialed is not in the Location #70-#79,
then the phone gives three tones and drops the line.
If digit 1 of Location #00 is "1" then there are no
restrictions and any number may be dialed.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
12
6.0 RECOMMENDED TOOLS AND TEST EQUIPMENT:
DTMF Test Set
Volt/Ohm Meter
3/8" Nut Driver
5/16" Nut Driver
Flat Blade Screw Driver
Security Tool, CEECO Part Number 301-064
7.0 INSTALLATION NOTES AND ASSEMBLY INSTRUCTIONS:
7.01 Using a 301-064 security tool (not supplied) to remove the four locking
screws.
7.02 The security tool is for a standard 5/32" button head screw generally used
on the framework of the phone booths.
7.03 Separate the cover assembly from the Weatherproof Housing.
7.04 Run the inside station wire through the Weatherproof Housing and
terminate on to the RJ11C terminal block on the Housing.
7.05 The use of a gas tube or carbon station protector is recommended. The
station ground should not exceed 50 ohms.
7.06 Plug the modular line cord from the SPK 660-000 PC board into the
RJ11C terminal block.
7.07 Dress the line cord away from the locking screws and seat the faceplate
into the enclosure.
7.08 Secure the cover assembly by tightening the security screw.
*****WARNING*****
A. Never install telephone wiring during a lightning storm.
B. Never install telephone jacks in wet locations unless the jack is
specifically designed for wet locations.
C. Never touch uninsultated telephone wires or terminals unless the
telephone line has been disconnected at the network interface.
D. Use caution when installing or modifying telephone lines.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
13
8.0 TESTING:
Assuming that the phone was programmed to automatically dial an emergency
number, and also allow use of the keypad for normal calls, without automatically
dialing a number when the black “CALL” button is pressed, the following should
apply:
Action: Connect the phone to a working phone line or DTMF test set.
Press the black "CALL" button.
Reaction: Dial tone.
Action: Dial a number.
Reaction: The called party answers.
A normal speakerphone conversation is allowed.
Action: Finish the conversation.
Press the "CALL" button, or wait until time-out occurs
(if programmed as such).
Reaction: The call is terminated.
Action: Press the "EMER" button.
Reaction: Preprogrammed number is automatically dialed (SEE SECTION 2,
LOCATION #01) and will not disconnect unless the black
“CALL” button is pushed, the called party hangs up and a wink
back is received, or a programmed time out disconnect occurs.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
14
9.0 SPECIFICATIONS:
INPUT POWER: C.O. LINE POWERED (48v-52v Loop)
LOOP CURRENT: 23ma. MIN. 80ma. MAX.
IMPEDANCE: 600 Ohms
SIGNALING: DTMF, 70ms tone, 50ms spacing
OUTPUT: -4.0 to -6.0dbm
ENVIRONMENTAL: Temperature 0°C to 50°C
Humidity 20%-90% non-condensating
PROGRAMMING: Via DTMF keypad.
DIMENSIONS: 12 5/8” High x 9 1/2” Wide x 8” Deep
including Door
MEMORY RETENTION: Lithium Battery - Long life
WEIGHT: 16 Pounds
FCC REGISTRATION: BW88T7-13716-TE-T
RINGER EQUIVALENCY: 0.4A
TYPE JACK: RJ11C
U.L. LISTED NO.: 6OF5

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
15
10.0 PARTS LIST:
QUANTITY PART NUMBER DESCRIPTION
4 331-006 Outer Cover Locking- Screw
1 301-018 Modular Line Cord
1 301-054 Modular Connector (RJ11C)
1 531-200 Service Manual
1 700-008 Keypad Cable
1 660-000 CEECO SPK Board
1 705-110 Connectorized Keypad
2 6020 Momentary Panel Switch
1 14024 Speaker
1 331-005 Weatherproof Housing
ACCESSORIES:
1 301-064 Security Tool

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
16
11.0 FCC NOTICE:
11.01 FCC REGISTRATION AND REPAIR INFORMATION
Your new telephone has been registered with the Federal Communication
Commission (FCC) in accordance with Part 68 of it's rules. The FCC
requires that you be advised of certain requirements involving the use of
this telephone.
11.02 CONNECTION WITH THE NATIONWIDE TELEPHONE
NETWORK
The FCC requires that you connect this telephone to the Nationwide
Telephone Network through a registered jack provided by the Telephone
Company in your area. This jack is a modular outlet, which you can order
from your local telephone company.
11.03 NOTIFICATION TO THE TELEPHONE COMPANY
Before connecting this telephone, the FCC requires that you notify your
local telephone company business office. The number is in the front of
your phone book.
Tell them:
The "line" to which you will connect the telephone (that is, your phone
number) and the telephone's FCC registration number and ringer
equivalence number. These numbers are listed in Section 11.00.
The FCC further requires that you notify your local telephone company
when permanently disconnecting this telephone.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
17
12.0 REPAIR AND RETURN INFORMATION:
12.01 WARRANTY REPAIR
Any device returned requiring warranty service, repair or credit must be
accompanied with a "Return Material Authorization" (RMA) FORM. It must
include return shipping instructions, original purchase order number and special
marking instruction. A description of the trouble observed must be attached to
the defective unit. This information must be inside the shipping container.
12.02 DIRECT ALL INQUIRES TO:
CEECO
Repair Department
863-357-0798- telephone
863-357-0006- facsimile
[email protected]
www.ceeco.net
12.03 NON-WARRANTY REPAIR
CEECO will repair equipment out of warranty for a set charge plus parts.
The customer must pay the shipping costs both directions.
12.04 RETURN FOR CREDIT
Material may be returned for credit only with prior approval. Material
authorized for return is subject to a 20% restocking charge based on the
manufacturer’s list price Return RMA must be requested no later than 30
days after original shipment.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
18
13.0 WARRANTY POLICY:
13.01 GENERAL
CEECO products are guaranteed to be free of defects in material and
workmanship for a period of 365 days from the date of original purchase.
CEECO's obligation under this warranty is limited to repair or
replacement of any part found to be defective by CEECO. Under no
circumstances shall CEECO be liable for loss, damage, cost of repair or
consequential damages of any kind, which have been caused by neglect,
abuse, act of God or improper operation of equipment. This warranty is
limited to the value of material only.
13.02 PRINTED CIRCUIT BOARDS
Printed circuit boards should not be repaired in the field. If a unit is found
to be faulty, replace it with another unit and return the faulty unit to
CEECO for repair. Modifications by any one other than CEECO will void
the warranty.

Issue 4.0
CEECO
Communication Equipment and Engineering Company
PROPRIETARY
19
When programming is
completed, move the mini
j
umpers to the OFF
p
osition.
NOTE:
Do not leave the mini jumpers in the ON position,
this will decrease battery life.
Move the mini jumpers to
the ON position BEFORE
going off-hook.
Locate the mini jumpers
on the corner of the PCB.
ON
OF
F
ON
OF
F
ON
OF
F
When programming is
completed, move the mini
j
umpers to the OFF
p
osition.
NOTE:
Do not leave the mini jumpers in the ON position,
this will decrease battery life.
Move the mini jumpers to
the ON position BEFORE
going off-hook.
Locate the mini jumpers
on the corner of the PCB.
ON
OF
F
ON
OF
F
ON
OF
F
