WM-200N
High Power 11n 300Mbps PoE
Wireless Access Point
Quick Installation Guide
V2.0

User’s Manual
Quick Installation Guide
2
Introduction
Overview
Aspiring to provide the best performance/price ratio for both SMB and industrial applications, CERIO
WM-200N is uniquely designed for Wall Mount with metal case and IP50 rating for a fast, robust, secure
and business class access point perfect for installation in factories, warehouses, hotels marinas,
hospitals, large homes, hotspot and more.
CERIO WM-200N is compliant to the latest wireless standards that are required in highly secured
enterprise networking environments. Its Wireless Distribution System (WDS) feature allows for flexible
extension of wireless coverage. It can be power via three alternative methods from either the Single
LAN port for Power over Ethernet (PoE), DC jack providing the ability to back up each other with fail-over
redundancy function, giving WM-200N reliable connectivity in mission critical situations. The antenna
diversity design enhances the connection reliability to improve data transmission capability. WM-200N
High Power AP Support to pure output power to 300mW and has two detachable 8dBi high-gain
antennas for optimal wireless coverage.
CERIO WM-200N is easy-to-use and install with web-based administrative interface making
configuration and client management simple and easy. In addition, management interfaces such as CLI
and SNMP are also supported by WM-200N
Support Multiple-SSID capability is to use just one AP to simultaneously emulate up to 8 APs with
different ESSIDs by separate their packets by using different VLAN IDs. Hence, using one AP is able to
act as if there are actually 8 different APs deployed in the same area. Client isolation is also supported by
WM-200N that clients under an AP are isolated with eachother.
Package Contents
WM-200N (main unit) x 1
PowerAdapter x1
8dBi Dipole SMA Omin Antenna x 2
Ground Cable x 1
RJ-45EthernetCable x1
Mounting Screw pack x 1
Rubber Gasket x 1
WarrantyCard x1
CD Manual x 1

User’s Manual
Quick Installation Guide
3
Features
Key Feature
300mW Pure Output Power for 11n Mode , Provide best WiFi coverage
Operation Modes : Access Point, WDS (Repeater)
Maxmum Security with 802.1x, WPA, and AES
Integragted IEEE 802.3af Power over Ethernet (PoE) Dual PoE Power redundancy
Include High Gain 8 dBi detachable antenna for optimal wireless coverage.
Support 8 Multiple-BSSIDs.
Enclosed in an IP50 compliant metal chassis .
Access Point Feature
Number of ESSID: 8.
Number of associated clients per ESSID: 32.
WDS Mode support to extend wireless coverage by connecting wirelessly to
another WDS capable AP up to 8 WDS links.
Beacon interval: adjustable to best adapt to the deployment environment.
IAPP: to facilitate faster roaming for the stations among different APs nearby.
Support Adjustable transmission power: 7 Levels.
Support Tag VLAN function.
Authentication/Encryption (Wireless Security)
WEP (64/128/152-bits) , WPA/WPA2 with TKIP or AES-CCMP,
IEEE802.1X,WPA-PSK, WPA-Enterprise.
Setting for TKIP/CCMP/AES key’s refreshing period
Hidden SSID broadcast support.
Access Control list (ACL) by MAC Address.
Support WEP and AES data encryption over WDS link.
Management
Support SNMP V2c, V3
Web-Based management interface.
Upgradeable firmware.
Software one-button-click to reset back to factory defaults.
Configuration backup & restore.
Support use Static IP and DHCP client.
Support Event log.

User’s Manual
Quick Installation Guide
4
Panel Function Description
There are several LED indicators and button on the front of the WM-200N. Please refer
to the definitons below :
Front Panel
Real Panel
LED Panel

User’s Manual
Quick Installation Guide
5
1. 12V DC Injector : Attach the power cable here.
2. Reset Button ( Reboot ) :Press and hold the Reset button for 2 seconds to restart
system. The LED except Power indicator ( this button only for quickly Reboot )
3. LAN1(PoE)/ LAN2/ LAN3 :The LAN1/LAN2 /LAN3 port are for connection to external
network or POE switch.
4. Console : The Serial RS-232 DB9 cable attaches here.
5. Scan Button :
→ Press and hold the Reset button for 3seconds and release to Scan New AP's
Channel. The STATUS LED will be FLASH
→ Press and hold the Reset button for more than 10 seconds to reset the system to
default configurations. The SYSTEM LED will be FLASH ( Reset factory default )
6. Antenna : WM-200N supports 1 RF Interface with 2 SMA connectors for Antenna
connection.
7. STATUS: LED ON indicates System up, OFF indicates down, FLASH indicates Scan
button activated.
8. SYSTEM: LED ON indicates Flash busy, OFF indicates Flash Idle
9. WLAN : Green LED FLASH indicates Wireless ON, and FLASH quickly indicates
Wireless Transmit quickly.
10.LAN1/LAN2 /LAN3: Green LED ON indicates connection, OFF indicates no connection,
and FLASH indicates The Port Transmit
11.PWR : Green LED ON indicates power on, and OFF indicates power off.

User’s Manual
Quick Installation Guide
6
First-Time Installation and Configuration
This chapter describes how to setup your WM-200N eXtreme PoE High-End Wireless Access
Point for wireless connectivity to your LAN.
Please Follow below setup
1. Place the WM-200N at a best location.
The best location for WM-200N is usually at the center of your wireless network.
2. Connect WM-200N to your external network device.
Connect one end of the Ethernet cable to the LAN1 port of WM-200N on the front
panel. On your environment, connect the other end of the cable to the external
Internet. The LAN1 LED indicator should be ON to indicate a proper connection.
3. Connect WM-200N to your network device.
Connect one end of the Ethernet cable the LAN2 port of WM-200N on the front panel.
Connect the other end of cable to a PC for configuring the system. The LAN2 LED
indicator should be ON to indicate a proper connection.
4. There are two ways to supply power over to WM-200N
I. Connect the DC power adapter to the WM-200N power socket one the front
panel.
Please only use the power adapter supplied with the WM-200N package. Using a different
Power adapter may damage this system
II.WM-200N is capable of transmitting DC current via its LAN PoE port. Connect an
IEEE802.3af-compliant PSE device, e.g. A PoE Switch, to the LAN1 port of
WM-200N with the Ethernet cable.
Now, the hardware installation is completed.
Software Configuration
WM-200N supports web-based configuration. Upon the completion of hardware
installation, WM-200N can be configured through a PC/NB by using its web browser such
as Internet Explorer 6.0 or later.
Default IP Address: 192.168.2.254
Default Subnet Mask: 255.255.255.0

User’s Manual
Quick Installation Guide
7
Default Username and Password for “root”: root / default
IP Segment Set-up for Administrator's PC/NB
Set the IP segment of the administrator's computer to be in the same range as
WM-200N for accessing the system. Do not duplicate the IP Address used here with
IP Address of WM-200N or any other device within the network.
Example of Segment: (Windows XP)
1. Click Start -> Settings -> Control Panel, and then “Control Panel” window
appears. Click on “Network Connections”, and then “Network Connections”
window appears.
2. Click right on “Local Area Connection”, and select Properties.
3. In “Local Area Connection Properties” window, select “Internet Protocol
(TCP/IP)” and click on Properties button.

User’s Manual
Quick Installation Guide
8
4. Select “Use the following IP address”, and type in
IP Address : 192.168.2.100
Subnet mask : 255.255.255.0
Launch Web Browser
Launch as web browser to access the web management interface of system by
entering the default IP Address, http://192.168.2.254, in the URL field, and then
press Enter.

User’s Manual
Quick Installation Guide
9
System Login
The system manager Login Page then appears.
Enter “root” as User name and “default” as Password, and then click OK to login to
the system.
System Overview page will appear after successful login.
Notice: WM-200N for the convenience of the administrator to change settings
without affecting the user connectivity. Please make sure all the changes in the
settings are completed and saved before restarting the WM-200N.
Quick Configuration
WM-200N is a two mode system which can be configured either as a access point or an
WDS as desired. This section provides a step-by-step configuration procedure for basic
installation on AP Mode and WDS Mode.

User’s Manual
Quick Installation Guide
10
AP Mode
Ensure the Operating Mode is currently at AP mode; the web management UI can be
viewed at the Status section under the System Overview page. (default operating mode is
in AP Mode)
Mode Confirmation
Ensure the Operating Mode is currently at AP mode; the web management UI can
be viewed at the Status section under the System Overview page.

User’s Manual
Quick Installation Guide
11
Change Password
1. Click System -> Management and then Admin Configuration page appears.
2. Enter a new password, and verify it again in the new password and check new
password field respectively.
3. By default, the password for “root” user is “default”, if you login as “root” user that
means you had granted an administrator privilege, an administrator has the right to
modify anything on WM-200N.
4. Click Save button, and process with steps followed.

User’s Manual
Quick Installation Guide
12
LAN Setup
1. Click System -> LAN, and then Network Setup page appears.
2. For the reason to management the WM-200N with an easy way, we recommend
you to use “Static IP” for WM-200N, you must assign an “IP address”, “IP
Netmask” and “IP Gateway” in the related fields, please notice that, if you enter a
wrong information in this page, the WM-200N will not work properly, please make
sure the whole IP information is suitable for your network.

User’s Manual
Quick Installation Guide
13
3. Enable “Static IP” and “Specify DNS Server IP” option, and enter the related
informations in the field. Click Save button to save the settings.

User’s Manual
Quick Installation Guide
14
Time Server Setup
1. Click System -> Time Server, and then Time Server Setup page appears.
2. Enable “Setup Time Use NTP”, and then enter the related information. Click Save
button to save the settings.

User’s Manual
Quick Installation Guide
15
ESSID Settings
1. Click Wireless -> Virtual AP Setup, and then VAP Setup page appears.
2. By default, the WM-200N will only enable one Virtual AP, click “Edit” and then
VAP0 Configuration page appears.
3. Setup the broadcasting ESSID for easily identifying the system when device is
trying to associate the service. Click Save button to save settings.

User’s Manual
Quick Installation Guide
16
Wireless Security Settings

User’s Manual
Quick Installation Guide
17
1. For the security reason, we recommend you use the “WPA2-PSK” to protect your
wireless network. In this page.
2. In VAP0 Configuration page, select “WPA2-PSK” in “Security Type“ pull down
menu. The WPA-PSK setting field will show up immediately.
3. The WPA2-PSK wireless security method is a very easy way to encrypted and
transfer your data through wireless, all you have to do is enter the WPA2 key
information required in the Pre-shared Key field, and the same information will
also be used to set up devices which will then be using WM-200N services.

User’s Manual
Quick Installation Guide
18
4. Click “Save” and “Reboot” to activate all settings configured so far.
Congratulation!
The AP mode is now successfully configured.
