Challenger Lifts CL10 Instruction manual

Rev. 12/04/18
Installation, Operation & Maintenance Manual
Versymmetric® Two Post
Surface Mounted Lift
MODEL CL10
10,000 LBS.CAPACITY
2500 LBS.PER ARM
2311 South Park Rd Louisville, Kentucky 40219
Email:[email protected] Web site:www.challengerlifts.com
Office 800-648-5438 /502-625-0700 Fax [phone]
IMPORTANT: READ THIS MANUAL COMPLETELY BEFORE
INSTALLING or OPERATING LIFT

Model CL10
Installation, Operation and Maintenance
Page 2
Rev 12/04/18
CL10-IOM-A.doc
GENERAL SPECIFICATIONS
See Figure 1 CL10 CL10-2 CL10-3
AColumn Height 11’- 8” 13’- 8” 14’- 8”
BFloor to Overhead Switch 11’- 2 1/2 ” 13’- 2 1/2” 14’- 2 1/2”
CRise Height (Screw Pads Highest Position) 74 1/8”
DCylinder Height (Full Stroke) 11’- 11”
EAdjustable Overall Width 11’- 11” / 11’ – 6 1/2"
FScrew Pad Height 3 7/8” to 6 1/8”
GInside of Columns 114 1/2” / 110”
Drive Thru Clearance 104 1/2" / 100”
Ceiling Height Required 11’- 11 ” 13’- 9” 14’- 9”
* Lifting Capacity
(Hydraulic Pressure at Cap.) 10,000 lbs. (2500 lbs. Per Arm)
(2750 psi)
** Lifting Time 38 Sec. (approximate)
Motor 2HP, Single Phase, 60Hz, 208/230
Optional – 2HP, Three Phase, 50/60Hz, for 208 or 230 or 460
* Lift capacity ratings are based on loads equally distributed on all four arms.
** Lifting and lowering speeds may vary depending on the weight of the vehicle.
Fig 1a - General Specifications Fig1b - Service Bay Layout

Model CL10
Installation, Operation and Maintenance
Page 3
Rev 12/04/18
CL10-IOM-A.doc
WARNING
VERTICAL CLEARANCE
Check the height of the area where the lift is to be
installed. Clearance should be calculated based on
the full raised height of the lift.
Failure by purchaser to
provide adequate clearance
could result in
unsatisfactory lift performance, property
damage, or personal injury.
FLOORING
Be certain you have the proper concrete floor to
properly handle the loaded lift. Floor should be in
generally good condition with no large cracks,
spalling or deterioration.
Minimum requirements for concrete are 4
inches minimum depth, with steel
reinforcement, 3500 psi, cured for 28 days
per local commercial practice. Floor should be
level within 3/8 inch over the installation area. No
anchors should be installed within 8 inches of any
crack, edge, or expansion joint. If these conditions
cannot be met, a pad may be poured to
accommodate the lift.
Check with local building inspectors and/or permits
office for any special instructions or approvals
required for your installation.
A qualified person should be consulted to address
seismic loads and other local or state requirements.
Failure by purchaser to
provide the recommended
mounting surface could
result in unsatisfactory lift performance,
property damage, or personal injury.
LOCATION
This lift has been evaluated for indoor use only with
an operating ambient temp. range of 5 – 40°C (41–
104°F)
ELECTRICAL REQUIREMENTS
For lift installation and operation it is necessary to
have a dedicated circuit with circuit breaker or time
delay fuse. Refer to wiring diagram for circuit
sizing.
SAFETY NOTICES AND DECALS
For your safety, and the safety of others, read and
understand all of the safety notices and decals
included here.
READ ENTIRE MANUAL BEFORE ASSEMBLING,
INSTALLING,OPERATING,OR SERVICING THIS
EQUIPMENT.
PROPER MAINTENANCE AND INSPECTION IS
NECESSARY FOR SAFE OPERATION.
DO NOT OPERATE A DAMAGED LIFT.
Safety decals similar to those shown here are found
on a properly installed lift. Be sure that all safety
decals have been correctly installed on the columns
as described in this installation manual. Verify that
all authorized operators know the location of these
decals and fully understand their meaning. Replace
worn, faded, or damaged
decals promptly.
Do not attempt to raise a
vehicle on the lift until the
lift has been correctly installed and adjusted as
described in this manual.
WARNING
WARNING

Model CL10
Installation, Operation and Maintenance
Page 4
Rev 12/04/18
CL10-IOM-A.doc
RECEIVING
The shipment should be thoroughly inspected as
soon as it is received. The signed bill of lading is
acknowledgement by the carrier of receipt in good
condition of shipment covered by our invoice.
If any of the goods called for on this bill of lading
are shorted or damaged, do not accept them until
the carrier makes a notation on the freight bill of the
shorted or damaged goods. Do this for your own
protection.
NOTIFY Challenger Lifts AT ONCE if any
hidden loss or damage is discovered after receipt.
IT IS DIFFICULT TO COLLECT FOR LOSS OR
DAMAGE AFTER YOU HAVE GIVEN THE
CARRIER A CLEAR RECEIPT.
File your claim with Challenger Lifts promptly.
Support your claim with copies of the bill of lading,
freight bill, and photographs, if available.
Component Packing List
PART # QTY/
LIFT DESCRIPTION
A2001-57-P1 Power Column Ass’y
A2001-57-I1 Idler Column Ass’y
A2060 1 Overhead Beam
CL10-HW-A 1 Hardware Box
B2202SD 1 3-Stage Arm Pack
B2302SD 1 2/3-Stage Arm Pack
A2055-57-*2 Column Extensions CL10-*
A2003 - *1 Sync Cable Pack CL10-*
36035 1 Overhead Shut-Off Bar Ass’y
12045 1 Overhead Limit Switch
AB-9367
AD-9367 1 Power Unit – 1 Phase
Power Unit – 3 Phase
CL10-LP-A 1 Literature Pack
ACCEPTED OILS –Do not use oils with detergents
Hydraulic fluid is not provided with the lift shipment
-10 wt. anti-foam, anti-rust hydraulic / biodegradable oil
-Dexron III ATF
INSTALLATION
SAFETY REQUIREMENTS FOR INSTALLATION
AND SERVICE
Refer to ANSI/ALI ALIS (current edition)
IMPORTANT:Always wear safety glasses while installing lift.
TOOLS (MINIMUM REQUIRED)
a. Tape measure, 16ft
b. Chalk line
c. 4ft level
d. 10” adjustable wrench
e. Standard open end wrenches 7/16”, 1/2",
(2) 9/16”, (2) 11/16”, 3/4", 15/16”
f. 5/16” allen wrench
g. Needle nose pliers
h. Hammer drill with 3/4” diameter carbide tipped
bits
i. 2lb hammer
j. Torque wrench: 150 foot pounds minimum with
1 1/8” socket
k. 12 ft. Step ladder
l. Anti-Seize lubricant (for arm pins and foot pad
screw threads and stop rings)
LAYOUT
1) Layout the service bay according to the
architect’s plans or owners instructions (see
Fig 1b). Failure to install in this orientation
can result in personal and property damage.
Be certain that the proper conditions exist, see
page 3.
2) Assemble column extension to column using
3/8-16 x 3/4" lg Hex flange head bolt. Repeat
for opposite column and extension.
3) Erect both column assemblies. Align the
notches in column base, with the installation
lines.
LOCKING PAWL
FOR LIFTS WITH OPTIONAL DUAL PENDANT
CONTROL, REFER INSTALLATION OF THE
LOCKING PAWL AND LOCK RELEASE CABLE TO
THE “DUAL PENDANT CONTROL INSTALLATION &
OPERATION MANUAL SUPPLEMENT”.
Fig 2 – Locking Pawl Assembly

Model CL10
Installation, Operation and Maintenance
Page 5
Rev 12/04/18
CL10-IOM-A.doc
4) Install Power Column locking pawl and lock
release clevis with 5/8” diameter x 1 1/2” lg
shoulder bolt and 1/2”-13 nylon lock nut, Fig. 2.
Attach 3/8” O.D. extension spring to upper hole
in locking pawl and other end to hole in bracket
welded to column.
5) Attach ½” O.D. extension spring to hole located
on bottom side of Idler Column lock pawl and
install using 5/8” shoulder bolt and lock nut, Fig
2. Attach 3/8” O.D. spring the same as Power
side.
ANCHORING
6) The anchor bolts must be installed at least 8”
from any crack, edge, or expansion joint.
7) Use a concrete hammer drill with a 3/4 inch
carbide bit. Tip diameter should conform to
ANSI Standard B94.12-1977 (.775 to .787). Do
not use excessively worn bits or bits which
have been incorrectly sharpened. A core bit
may be necessary if an obstruction is
encountered. Never substitute with shorter
anchor.
8) Recheck “Inside of Columns” dimension, Fig 1.
Drill the anchor holes using the base plate as a
template. Drill through the floor if possible or to
a depth of 4 inches minimum.
Complete steps 8 thru 11 for the five (5)
exposed anchors around each column, then
raise the carriages. Repeat steps 8 thru 11 for
the two (2) anchors under each carriage.
9) Vacuum dust from the hole for proper holding
power.
10) Shim both columns to plumb using the shims
provided as shown in Fig 3. DO NOT shim
more than 1/2" at any given point. Use a level
no less than 24” in length to plumb columns.
11) Assemble washer and nut to anchor with nut
just below impact section of bolt. Drive anchor
into hole until nut and washer contact base.
Fig 3 – Column Shimming
12) Tighten power column anchors and recheck
column for plumb. Reshim if necessary. Torque
to 150 foot pounds to set anchors.
OVERHEAD
13) Before raising overhead into position install 4
each (2 per column) hex flange bolts and nuts
in middle hole of column extension (see Fig 4
Installation Aid) for temporary support of
overhead. Lift overhead assembly up into
position and install with 8 each (4 per column)
3/8-16 x 3/4” lg hex flange bolts and hex flange
nuts per side as shown in Fig 4.
Fig 4 – Overhead Assembly
14) Check idler column shimming. Use additional
shims (see Fig. 3) to remove any gaps that
may have been created while installing
overhead beam. Tighten anchor bolts and re-
check column for plumb. Torque to 150 foot
pounds.
15) Install Overhead Limit Switch to the Overhead
Beam using the rear set of holes on the Power
Side of the lift. Fig. 4a.
Fig. 4a – Overhead Limit Switch Power Side
16) Install the Idler Bracket to the Overhead Beam
using the rear set of holes on the Idler Side of
the lift. Fig. 4b. Note the orientation of the

Model CL10
Installation, Operation and Maintenance
Page 6
Rev 12/04/18
CL10-IOM-A.doc
Idler Bracket. The narrow slot needs to be
facing towards the Power Column. Slide the
Shutoff Bar over the limit switch on the Power
Side. Pin the Shutoff Bar to the Idler Side
Bracket with the 10mm dia. x 55mm Lg. clevis
pin & hairpin cotter.
Fig. 4b – Overhead Bracket Idler Side
17) Assemble the sheaves and spacers onto the
sheave pin as shown in Fig 5. Set in cradle
with all assembly parts between the two plates.
Fig 5 – Sheave Assembly
SYNCHRONIZER CABLES
18) Attach one end of synchronizing cable to
carriage with the supplied nut and jam nut. See
Fig 6a &6b for proper attachment.
19) Route cable up and over sheave in overhead.
Follow across to other sheave on opposite
column. Route down through carriage to
sheave in bottom of column. Route under
sheave and up to cable attachment. Use Fig 6a
for proper attachment.
20) At the top of each column extension assemble
the cable trapping hardware with a 3/8-16 x
3”Lg bolt with (2) 3/8-16 flange nut at each
sheave location, Fig 5.
21) Repeat for opposite side.
22) Manually raise the carriages to a common lock
position, to gain access to the cable-tie-off tabs
located on the carriage ladder.
Insure that the top of the hydraulic cylinder
is out of the way but still retained in the
opening of the top plate of the carriage as
shown in Fig 6a.
Failure to follow previous
step could result in personal
injury.
IMPORTANT:
4 1/2" lg STAND-OFF
FOR 11'- 6 1/2" WIDTH
IMPORTANT:
4 1/2" lg STAND-OFF
FOR 11'- 6 1/2" WIDTH
IMPORTANT:
4 1/2" lg STAND-OFF
FOR 11'- 6 1/2" WIDTH
IMPORTANT:
4 1/2" lg STAND-OFF
FOR 11'- 6 1/2" WIDTH
HYDRAULIC
CYLINDER
HYDRAULIC
CYLINDER
HYDRAULIC
CYLINDER
HYDRAULIC
CYLINDER
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
NARROW SETTING ONLY
Fig 6a – Cable Assembly
IMPORTANT:
Stand-Offs to be used only on the 11’– 6 ½” Overall
Width Setting.
Fig 6b – Jam Nut
CA UT I ON

Model CL10
Installation, Operation and Maintenance
Page 7
Rev 12/04/18
CL10-IOM-A.doc
POWER UNIT &HYDRAULIC HOSES
POWER UNIT HOSE
'O' RING ELBOW
Fig 7 – Power Unit Mounting
IMPORTANT – To insure proper hose fitting seal
without damage to the fitting follow this
procedure for each hose connection: Screw
flared fitting on finger tight. Rotate flared fitting 1
1/2 hex flats (90 deg.). Back the flared fitting off one
full turn. Again tighten flared fitting finger tight, then
rotate flared fitting 1 1/2 hex flats (90 deg.).
23) Mount Power Unit to power column as shown
in Fig 7. The mounting hardware, (4) 5/16”-18
hex nuts, are pre-installed on power unit
mounting bracket.
24) Uncoil Idler side hose and route through the
Idler Side column extension as shown in Fig
8a. taking care to avoid the synchronizing
cables and hydraulic cylinder path. Remove
slack and tighten all 3 clamps. Route hose
across overhead avoiding the synchronizing
cables and down through the Power Side
column extension as seen in Fig 8b. Do Not
Tighten Clamps at this time.
Fig 8a – Hose Routing,
Idler Side Column Ext.
Fig 8b – Hose Routing,
Power Side Column Ext.
25) Loosely attach power column hose and idler
column hose using the tee fitting (in hardware box)
Attach Power Unit Hose to power side column
extension as seen in Fig 9a. Connect Power
unit hose to tee from Fig 8b and remove slack
from power column hose. Tighten loose fittings
and clamps from previous step. Serpentine
any extra hose length in overhead.
Fig 9 – Power Unit Hose
26) Thread 9/16-18 O-ring elbow (in hardware box)
into power unit. Attach free end of power unit
hose to elbow. See Fig 7. CAUTION do not
damage rubber O-ring.
27) BE CERTAIN ALL FITTINGS AND CONNECTIONS
ARE TIGHT. IT IS THE INSTALLERS RESPONSIBILITY
TO INSURE SYSTEM IS LEAK-FREE. Fill the Power
Unit with three gallons of clean 10wt anti-foam
anti-rust hydraulic / Biodegradable oil or
Dexron III ATF. DO NOT USE OILS WITH
DETERGENTS.
LOCK RELEASE
28) Attach Mechanical Lock Release Cable
Assembly to Power Column Lock Release
Clevis using the 3/16” diameter x 1/2" long pin
and (2) “C” clip retainers, Fig 10.

Model CL10
Installation, Operation and Maintenance
Page 8
Rev 12/04/18
CL10-IOM-A.doc
29) Insert threaded sleeve portion of cable
assembly in slot located on tab above locking
pawl, Fig 10. One jam nut should be located on
each side of tab. Position threaded sleeve with
½” of thread below tab as indicated in Fig 10
and tighten jam nuts.
Fig 10 – Power Column Lock Assembly
30) Route opposite end of cable assembly up
Power Column and into column through access
slot in bottom of Column Extension. Following
the path of the hydraulic line, route cable
assembly across overhead clear of moving
parts and back out through access slot in
bottom of idler side column extension. Attach
Cable Assembly to the hydraulic hose with
loosely fit wire ties.
NOTE: DO NOT kink cable assembly when routing.
Tighten and trim wire ties after final cable
adjustments have been made
31) Attach Adhesive-Backed Tab to Idler Column
left of the lock assembly (Fig 11). Route Lock
Release Cable down left side of Idler Column
and secure with loosely fit wire tie to Adhesive-
Backed Tab. Attach Cable clevis to 1/2" O.D.
Extension Spring.
CABLE CLEVIS
1/2" O.D. EXT.
SPRING
EXTEND LOOP WHEN
INSTALLING AT NARROW
OR LOWERED SETTING
EXTEND LOOP WHEN
INSTALLING AT NARROW
OR LOWERED SETTING
1/2" O.D. EXT.
SPRING
CABLE CLEVIS
EXTEND LOOP WHEN
INSTALLING AT NARROW
OR LOWERED SETTING
1/2" O.D. EXT.
SPRING
CABLE CLEVIS
EXTEND LOOP WHEN
INSTALLING AT NARROW
OR LOWERED SETTING
1/2" O.D. EXT.
SPRING
CABLE CLEVIS
Fig 11 – Idler Column Lock Assembly
32) Insert threaded sleeve portion of cable
assembly in slot located on tab below lock
pawl, Fig 11. With one jam nut located on each
side of tab, adjust the threaded sleeve to begin
to pull tension on the ½” O.D. spring. Snug jam
nuts by hand.
THE LOCK RELEASE CABLE ADJUSTMENT IS NOT
COMPLETE UNTIL THE LIFT HAS BEEN LOWERED AND
“FINAL ADJUSTMENTS”HAVE BEEN MADE.
ARM INSTALLATION
33) Grease the arm pin or carriage arm pin hole
with heavy viscous grease and install the arms.
Use the grease fittings during regular monthly
maintenance.
34) Slide the provided washer onto pin up against
the inner bevel gear.
35) Install the provided retaining ring onto the pin
with tool, Fig 12.
36) Arm restraints should disengage when lift is
fully lowered. To insure that the arm restraint
gears engage and disengage properly loosen
the bolts on the large gear on the arm. Allow
the small outer gear to align itself with the inner
large gear and tighten the bolts.
37) Extend the foot pad to both extents and apply
“anti-seize” to the three retaining rings and
where the double screw makes contact with the
base of the foot pad.

Model CL10
Installation, Operation and Maintenance
Page 9
Rev 12/04/18
CL10-IOM-A.doc
Fig 12 –Arm Pin Keeper Install
ELECTRICAL
38) Wire tie Limit Switch cord to column extension
hydraulic line and power unit line.
39) Connect the Overhead Limit Switch Cord to
Power Unit as shown in Fig 13.
40) Connect Power Unit to suitable electrical
source as shown in Fig 13.
41) IMPORTANT:AFTER WIRING HAS BEEN
COMPLETED,TEST OPERATION OF POWER UNIT &
OVERHEAD LIMIT SWITCH.WHILE RAISING LIFT,
OPERATE OVERHEAD SHUTOFF BAR.POWER UNIT
MOTOR SHOULD STOP WHEN SHUTOFF BAR IS
RAISED.
SAFETY DECALS
42) Clean surface of the rear column above the
power unit and install Safety Decals, Page 3
and Fig. 14.
43) If optional Book Holder for “Vehicle Lifting
Points” guide was purchased, install on front of
column.
Fig 14 – Safety Decal and
OPTIONAL Book Holder Placement
FINAL ADJUSTMENTS
HYDRAULICS
44) Lower the lift to the floor and raise the lift
approximately one foot.
45) Start with Idler side first. Slowly and carefully
loosen the bleed plug on top of the cylinder just
enough to allow the entrapped air to escape.
Repeat for power side.
46) Raise lift 6 inches. Repeat step 41 until no air
comes out of cylinder.
47) Pressure test hydraulic system. Energize
power unit, raise lift to full rise and continue to
run motor for additional 10 seconds. (NOTE:
pressure relief will make a high pitch squeal
sound for these 10 seconds.) Check hydraulic
system for leaks.
48) Energize power unit again for 10 seconds. With
a clean rag, wipe down both cylinder rods. (The
cylinders are shipped with a small amount of
clear anti-corosive lubricant that will be forced
out through the wiper when the lift reaches full
rise.) If lubricant is not wiped clean from the
cylinder rod, the cylinder will apear to be
leaking.
SYNCHRONIZING CABLES
49) Raise lift and insure carriages lower into same
lock position.
50) Adjust synchronizing cables so the tension is
equal in both cables and carriages are firmly
sitting on locks.
51) Cycle lift to insure that latches operate
simultaneously.
LOCK RELEASE CABLE
52) Lower lift to the floor and snap plastic cover
over Power Column lock assembly.
53) Pull and release Power Column lock release
handle while watching Idler Column lock.
Adjust lower threaded sleeve cable adjuster
jam nuts on Idler Column until Idler Column
lock disengages and engages fully. When
properly adjusted, the idler column lock should
just come to rest against the back of the
column when engaged and fully out against the
tab when disengaged. Tighten Idler Column
lower tab jam nuts.
IMPORTANT: IF IDLER SIDE LOCK PAWL DOES NOT
FULLY DISENGAGE,DAMAGE MAY RESULT TO IDLER
SIDE CARRIAGE AND OR CABLE SYNCHRONIZING
SYSTEM.
54) Tighten threaded sleeve cable adjuster jam
nuts and install lock release knob.
55) Tighten and trim wire ties.
56) Snap plastic cover over Idler lock assembly
(align release cable with notches in cover).

Model CL10
Installation, Operation and Maintenance
Page 10
Rev 12/04/18
CL10-IOM-A.doc
FEMALE ARM SHIM INSTALL
(3-STAGE ARMS ONLY)
57) Extend the arm fully and lift up on the male
portion, Fig 15.
58) Using a hammer to set, place the shim on the
mouth of the female arm. Use the provided self
locking set screw and 1/8” Allen wrench to
securely lock the shim in place.
Fig 15 – Arm Shim, 3-Stage
FINAL CHECKOUT PROCEDURE
59) Demonstrate the operation of the lift to the
owner/operator/employer using a typical
vehicle and review correct and safe lifting
procedures using the Lifting It Right booklet
as a guide.
60) Return all provided literature (including this
manual) to the literature pack envelope and
deliver the envelope to the
owner/operator/employer.
61) Complete the online warranty registration (refer
to the included warranty statement).

Model CL10
Installation, Operation and Maintenance
Page 11
Rev 12/04/18
CL10-IOM-A.doc
1
5
4
6
(Normally Open)
M
FIELD
CONECTIONS
FIELD
CONECTIONS
A2A1
T9
T5
T4
T6
M
T8
T3
T7
T2
T1
12
34
56
L3
L2
L1
T3
T2
T1
FACTORY WIRED FOR
208−240V
6
4
2
5
3
1
RECONNECTIONS FOR
440−480V
T3
T2
T1
T9
T6
T7
T4
T8
T5
FOR THREE PHASE
M
FOR SINGLE PHASE
Wiring Diagram
Fig 13 – Electrical Wiring Diagram

Model CL10
Installation, Operation and Maintenance
Page 12
Rev 12/04/18
CL10-IOM-A.doc
OPERATION PROCEDURE
SAFETY NOTICES AND DECALS
This product is furnished with graphic safety
warning labels, which are reproduced on page
3 of these instructions. Do not remove or
deface these warning labels, or allow them to
be removed or defaced. For your safety, and
the safety of others, read and understand all of
the safety notices and decals included.
OWNER/EMPLOYER RESPONSIBILITIES
This lift has been designed and constructed according to
ANSI/ALI ALCTV-2011 standard. The standard applies
to lift manufactures, as well as to owners and employers.
The owner/employer’s responsibilities as prescribed by
ANSI/ALI ALOIM-2008, are summarized below. For
exact wording refer to the actual standard provided with
this manual in the literature pack.
The Owner/Employer shall insure that lift
operators are qualified and that they are trained in
the safe use and operation of the lift using the
manufacturer’s operating instructions; ALI/SM 93 -
1, ALI Lifting it Right safety manual; ALI/ST-90 ALI
Safety Tips card; ANSI/ALI ALOIM-2008, American
National Standard for Automotive Lifts-Safety
Requirements for Operation, Inspection and
Maintenance; ALI/WL Series, ALI Uniform Warning
Label Decals/Placards; and in case of frame
engaging lifts, ALI/LP-GUIDE, Vehicle Lifting
Points/Quick Reference Guide for Frame Engaging
Lifts.
The Owner/Employer shall establish procedures
to periodically inspect the lift in accordance with
the lift manufacturer’s instructions or ANSI/ALI
ALOIM-2008, American National Standard for
Automotive Lifts-Safety Requirements for
Operation, Inspection and Maintenance; and the
employer shall insure that the lift inspectors are
qualified and that they are adequately trained in
the inspection of the lift.
The Owner/Employer shall establish procedures
to periodically maintain the lift in accordance with
the lift manufacturer’s instructions or ANSI/ALIOIM-
2008, American National Standard for Automotive
Lifts-Safety Requirements for Operation,
Inspection and Maintenance; and the employer
shall insure that the lift maintenance personnel are
qualified and that they are adequately trained in
the maintenance of the lift.
The Owner/Employer shall maintain the periodic
inspection and maintenance records
recommended by the manufacturer or ANSI/ALI
ALOIM-2008, American National Standard for
Automotive Lifts-Safety Requirements for
Operation, Inspection and Maintenance.
The Owner/Employer shall display the lift
manufacturer’s operating instructions; ALI/SM 93 -
1, ALI Lifting it Right safety manual; ALI/ST-90 ALI
Safety Tips card; ANSI/ALI ALOIM-2008, American
National Standard for Automotive Lifts-Safety
Requirements for Operation, Inspection and
Maintenance; and in the case of frame engaging
lift, ALI/LP-GUIDE, Vehicle Lifting Points/Quick
Reference Guide for Frame Engaging Lifts; in a
conspicuous location in the lift area convenient to
the operator.
IMPORTANT SAFETY INSTRUCTIONS
When using your garage equipment, basic safety
precautions should always be followed, including
the following:
1. Read all instructions.
2. Care must be taken as burns can occur from
touching hot parts.
3. To reduce the risk of fire, do not operate
equipment in the vicinity of open containers of
flammable liquids (gasoline).
4. Keep hair, loose clothing, fingers, and all
parts of body away from moving parts.
5. Use only as described in this manual. Use
only manufacturer’s recommended
attachments.
6. ALWAYS WEAR SAFETY GLASSES.
Everyday eyeglasses only have impact
resistant lenses, they are not safety glasses.
SAVE THESE INSTRUCTIONS

Model CL10
Installation, Operation and Maintenance
Page 13
Rev 12/04/18
CL10-IOM-A.doc
LIFTING A VEHICLE
1) Insure that the lifting arms are parked, out to full
drive thru position.
2) Center the vehicle between the columns in the
service bay and position the vehicle’s center of
gravity midpoint between the columns. NOTE:
the center of gravity is based on the weight
distribution and is not the same as the
center point of the vehicle.
DO NOT EXCEED 2500 POUNDS PER ARM.
DO NOT ATTEMPT TO LIFT THE VEHICLE WITH ONLY
TWO ARMS,AS THIS WILL VOID THE WARRANTY
INSURE THAT THE HIGHEST POINT ON THE VEHICLE
WILL CONTACT THE OVERHEAD LIMIT SWITCH BAR.
DO NOT PLACE THE VEHICLE IN THE SERVICE BAY
BACKWARDS.
REFER TO THE VEHICLE MANUFACTURERS SERVICE
MANUAL,TECHNICAL BULLETINS,“VEHICLE LIFTING
POINTS GUIDE”(ALI/LP-GUIDE)OR OTHER
PUBLICATIONS TO LOCATE THE RECOMMENDED LIFTING
POINTS.
3) Position the arms and adapters so all four pads
contact the vehicle simultaneously.
The vehicle should remain level during lifting.
4) Raise the lift until all four wheels are off the
ground. Test the stability of the vehicle by
attempting to rock the vehicle. Check adapters
for secure contact with vehicle lift points. If the
vehicle seems unstable, lower the lift and
readjust the arms. If the vehicle is stable, raise
the vehicle to a height a few inches above the
desired working height.
5) Lower the vehicle until the safety latches on
both columns engage. The vehicle should
remain level when both latches are engaged. If
one side engages and the other continues to
descend, stop lowering the vehicle, raise it
several inches, and try again to engage both
latches.
Always lower lift into locks before entering the
area beneath the vehicle.
Always use safety stands when removing or
installing heavy components.
LOWERING AVEHICLE
1) Insure that the area under the vehicle is clear of
personnel and tools.
2) Raise the vehicle until both latches are free.
3) Disengage the locks by pulling and hold the
lock release lever.
4) Lower the vehicle by depressing the lowering
valve handle.
5) Continue to lower the vehicle until the carriages
stop against the base plate. Retract the
extension arms, and park them.
LOSS OF POWER
If for any reason the lift will not raise off the locks
or the locks will not retract, consult factory
authorized personnel.
DO NOT OVERRIDE ANY SAFETY FEATURE IN
AN ATTEMPT TO LOWER THE LIFT.

Model CL10
Installation, Operation and Maintenance
Page 14
Rev 12/04/18
CL10-IOM-A.doc
MAINTENANCE
To avoid personal injury, permit only qualified
personnel to perform maintenance on this
equipment. Maintenance personnel should follow
lockout/ tagout instructions per ANSI Z244.1.
The following maintenance points are suggested
as the basis of a routine maintenance program.
The actual maintenance program should be
tailored to the installation. See ANSI/ALI ALOIM
booklet for periodic inspection checklist and
maintenance log sheet.
If lift stops short of full rise or chatters, check
fluid level and bleed both cylinders per
Installation Instructions.
Replace all Safety, Warning or Caution Labels if
missing or damaged (See Installation
instructions page 3.)
Daily
Keep lift components clean.
Check for loose or broken parts.
Check hydraulic system for fluid leaks.
Check adapters for damage or excessive wear.
Replace as required with genuine Challenger
Lifts parts.
Check lock release activation. When properly
adjusted, the idler column lock should rest firmly
against the back of the column when engaged
and against the spring mount tab when
disengaged.
Weekly
Check synchronizer cables and sheaves for
wear. Replace as required with genuine
Challenger Lifts parts.
Check synchronizer cable tension per Installation
Instructions. Adjust if necessary. If both threaded
ends of either cable have run out of adjustment,
then replace both cables. (Cables should always
be replaced in sets.)
Monthly
Torque concrete anchor bolts to 80 ft-lbs.
Visually inspect concrete floor for cracks and/or
spalls within 12” of base plate
Check overhead shutoff switch. While raising lift,
operate overhead shutoff bar. Power Unit motor
should stop when bar is raised.
Lubricate carriage slide tracks with heavy
viscous grease. (Grease all (4) corners of both
columns.)
Lubricate arm using the grease fittings.
If any problems are encountered, contact your
local service representative.

Model CL10
Installation, Operation and Maintenance
Page 15
Rev 12/04/18
CL10-IOM-A.doc
PARTS BREAKDOWN
Fig A. Column & Overhead
ITEM # PART # QTY/LIFT DESCRIPTION
1
A2010-P 1 POWER COLUMN WELD
A2010-I 1 IDLER COLUMN WELD
2
A2055-57-0
2 COLUMN EXTENSION WELD - CL10
A2055-57-2 COLUMN EXTENSION WELD - CL10-2
A2055-57-3 COLUMN EXTENSION WELD - CL10-3
3 A2060 1 OVERHEAD CHANNEL
4 A2067 1 SHUTOFF BAR
5 31129 1 SHUTOFF BAR CUSHION
6 B2064-01 1 LIMIT SWITCH PACKAGE
(INCLUDES SWITCH w/ CORD, BOTH BRACKETS, & ITEMS 7-10)
7 B2065-3 4
M6 x 14mm PHILLIPS PAN HEAD SCREW
8 B2065-4 4
M6 SERRATED FLANGE HEX NUT
9 B2065-5 1
CLEVIS PIN 10mm x 55 Lg.
10 GJY12-3 1
HAIRPIN COTTER
11 A1153 24 3/8-16NC HEX.FLG.HD.C.S X 3/4" Lg.
12 A1154 32 3/8-16NC HEX.FLG.NUT
13 A2159 4 3/8-16NC x 3”Lg HEX HEAD C.S. Gr.5
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. [phone] for the Parts Distributor in your area)

Model CL10
Installation, Operation and Maintenance
Page 16
Rev 12/04/18
CL10-IOM-A.doc
PARTS BREAKDOWN (continued)
Fig B. Lock
FOR LIFTS EQUIPPED WITH
DUAL PENDANT CONTROL
REFER TO SEPERATE
"DUAL PENDANT CONTROL
MANUAL SUPPLEMENT"
FOR LIFTS EQUIPPED WITH
DUAL PENDANT CONTROL
REFER TO SEPERATE
"DUAL PENDANT CONTROL
MANUAL SUPPLEMENT"
FOR LIFTS EQUIPPED WITH
DUAL PENDANT CONTROL
REFER TO SEPERATE
"DUAL PENDANT CONTROL
MANUAL SUPPLEMENT"
FOR LIFTS EQUIPPED WITH
DUAL PENDANT CONTROL
REFER TO SEPERATE
"DUAL PENDANT CONTROL
MANUAL SUPPLEMENT"
ITEM #
PART # QTY/LIFT DESCRIPTION
20
A2135-0
1
LOCK RELEASE CABLE ASSEMBLY - CL10
A2135-2 LOCK RELEASE CABLE ASSEMBLY - CL10-2
A2135-3 LOCK RELEASE CABLE ASSEMBLY - CL10-3
21 B1140 2 LOCK PAWL
22 A1133 2 LOCK COVER
23 30020 2 LOCK PIN (5/8 x 1 1/2" Lg. SHOULDER BOLT)
24 37013 2 LOCK PIN RETAINER (1/2-13NC HEX LOCK NUT)
25 37119 1 CLEVIS PIN KIT
26 A1131 2 LOCK SPRING (3/8" O.D.)
27 A1132 1 CABLE SPRING (1/2" O.D.) – Idler side ONLY
28 A1141 1 LOCK RELEASE CLEVIS ASSEMBLY – Power side ONLY
29 36096 1 BALL HANDLE – Power side ONLY
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. [phone] for the Parts Distributor in your area)

Model CL10
Installation, Operation and Maintenance
Page 17
Rev 12/04/18
CL10-IOM-A.doc
PARTS BREAKDOWN (continued)
Fig C. Hydraulics
ITEM #
PART # QTY/LIFT DESCRIPTION
32 AB-9367 1 POWER UNIT 1ph, 60 Hz, 208-230V
AD-9367 POWER UNIT 3ph, 60 Hz, 208-230/460V
33 16138R 2 CYLINDER (68" STROKE RAM)
34 16167 2 90 Degree ELBOW
35 A2127-I 1 IDLER HOSE
36 A1122-12 10 3/8” HOSE CLAMP
37 A1153 5 3/8-16 x ¾ HEX FLANGE HEAD BOLT
38 A1154 5 3/8-16 HEX FLANGE NUT
39 39103 1 37 Degree UNION TEE
40 A2127-57P 1 POWER HOSE
41 31025 1 3/8” LINE CLAMP
42 A2125 1 ¼-20 x ¾ HEX FLANGE HEAD BOLT
43 40085 1 ¼-20 HEX FLANGE NUT
44 12748 1 ¼ x ¼ NYLON SPACER
45 A2127-PU 1 POWER UNIT HOSE
46 16167 1 9/16-18 STRAIGHT THREAD ELBOW
47 A1069 2 5/16-18 x 1 HEX FLANGE HEAD BOLT
48 4100237 2 5/16 HEX FLANGE NUT
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. [phone] for the Parts Distributor in your area)

Model CL10
Installation, Operation and Maintenance
Page 18
Rev 12/04/18
CL10-IOM-A.doc
PARTS BREAKDOWN (continued)
Fig D. Synchronizer
ITEM #
PART # QTY/LIFT DESCRIPTION
50
A2115-0
2
SYNCHRONIZER CABLE - CL10
A2115-2 SYNCHRONIZER CABLE - CL10-2
A2115-3 SYNCHRONIZER CABLE - CL10-3
51 A2116 4 5/8-11NC HEX NUT
52 A2117 4 5/8-11NC HEX JAM NUT
53 A2118 2 CABLE SPACER (4 1/2" LONG)
54 36025 6 SHEAVE ASSEMBLY (5" DIA. X 5/16" GROOVE)
55 36024 2 SHEAVE PIN
56
A
1063-S 4 SHORT SHEAVE SPACER (LINE)
A
2063-S SHORT SHEAVE SPACER (HOSE)
57
A
1063-L10
2 LONG SHEAVE SPACER (LINE)
A
2063-L LONG SHEAVE SPACER (HOSE)
58 36013 10 1" I.D. SPACER WASHER
59 36014 2 1" EXT. RETAINING RING
60 A1153 2 3/8-16 x 3/4" LOCK. HEX FLG. HEAD, C.S
61 A2158 2 1/4 DIA. x 1 3/4" Lg CLEVIS PIN
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. [phone] for the Parts Distributor in your area)

Model CL10
Installation, Operation and Maintenance
Page 19
Rev 12/04/18
CL10-IOM-A.doc
PARTS BREAKDOWN (continued)
Fig E. Carriage & 3-Stage Arm Pack (B2202SD)
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. [phone] for the Parts Distributor in your area)

Model CL10
Installation, Operation and Maintenance
Page 20
Rev 12/04/18
CL10-IOM-A.doc
PARTS BREAKDOWN (continued)
ITEM # PART # QTY/LIFT DESCRIPTION
65 B2026-57 2 CARRIAGE WELD (57” LADDER)
66 31023 16 SLIDE BLOCK
67 B2026-2 2 RUBBER DOOR GUARD
68 X10-088 4 M8x1.25x30mm Lg. SHCS
69 X10-087 8 M8 WASHER
70
B2210-PB 1 FRONT FEMALE ARM WELD (POWER)
B2210-IB 1 FRONT FEMALE ARM WELD (IDLER)
71 CS1020020200C 2 FRONT INTERMEDIATE ARM WELD
72 B2218C 2 FRONT MALE ARM WELD
73
B2220B 2 REAR FEMALE ARM WELD
74 B2230C 2 REAR INTERMEDIATE ARM WELD
75
B2235C 2 REAR MALE ARM WELD
76 CS1020-05 4 STOP LOOP
77
B2270 4 FOOT PAD ASSEMBLY (items 78-83), 55mm STROKE
78 A1104-H 4 RUBBER INSERT
79
A1101-1H 4 FOOT PAD WELD
80 B17256 4 2 x 30mm ROUND WIRE RETAINING RING
81
B2261 4 THREADED SLEEVE
82 B17257 8 3 x 45mm ROUND WIRE RETAINING RING
83
B17276-1 4 THREADED INSERT
84 B2211 4 ROLL PIN, 6mm DIA x 30mm Lg.
85
B2202-02 4 ROLL PIN, 12mm DIA x 80mm Lg.
86 CS1020-03-01 4 FEMALE ARM SHIM
87 CS1020-03-02 4 M6 x 1 x 6mm Lg. SELF-LOCKING SET SCREW
88 17350 8 M8 x 10mm Lg. FLAT HEAD BOLT
89 CS1020-04 4 STOP BLOCK
90 B2202-01 4 ROLL PIN, 12mm DIA x 60mm Lg.
91 B1078 4 ARM PIN WELD
92 A1070TC 4 INNER GEAR, BEVELED
93 B1068 12 M10x1.5x25mm Lg. HEX FLANGE HEAD BOLT
94 A1075 4 PULL RING
95 A1073C 4 ARM RESTRAINT SHAFT
96 31109 4 COMPRESSION SPRING (RESTRAINT SHAFT)
97 A1072TC 4 OUTER GEAR, BEVELED
98 36014 4 1” EXTERNAL RETAINING RING
99 A1077TC 4 ARM RESTRAINT SHAFT ASSEMBLY (items 93-98)
100 B2203S-01D 4 39mm ID, 51mm OD WASHER
101 B1083 4 38mm EXTERNAL RETAINING RING
B2202SD 1 ARM PACK, CL10, 3-STAGE
B2203S-PD 1 FRONT ARM ASSEMBLY (POWER) Items: 70, 71, 72, 76-93,100,101
B2203S-ID 1 FRONT ARM ASSEMBLY (IDLER) Items: 70, 71, 72, 76-93,100,101
B2204SD 2 REAR ARM ASSY. Items: 73-93,100,101
Replace all worn, damaged, or broken parts with parts approved by Challenger Lifts Inc.
or with parts meeting Challenger Lifts Inc. specifications.
Contact your local Challenger Lifts Parts Distributor for pricing and availability.
(Call Challenger Lifts Inc. [phone] for the Parts Distributor in your area)
