Charder R230 User manual

0 IN-1457[17001B] 201806
Bakery Dough Scale
R230
User’s Manual
www.charder.com
Please read this manual carefully before operating your set and retain it for future reference.

R230 Series
1 IN-1457[17001B] 201806
CONTENTS
CONTENTS ...................................................................................................................... 1
INTRODUCTION .............................................................................................................. 2
Safety Precautions ...................................................................................................................... 2
INSTALLATION ................................................................................................................ 2
Package Contents ....................................................................................................................... 2
Parts Description ........................................................................................................................ 3
Selecting the Location ................................................................................................................ 3
Power ......................................................................................................................................... 3
Battery Power ............................................................................................................................. 3
OPERATION .................................................................................................................... 4
eypad and Display Description ................................................................................................. 4
Status Indicators ......................................................................................................................... 4
LED Indications ........................................................................................................................... 4
eypad Description .................................................................................................................... 4
Turning Scale On/Off .................................................................................................................. 5
Zero Operation & Setting ........................................................................................................... 5
Changing Units of Measure ........................................................................................................ 5
Checkweighing Mode ................................................................................................................. 5
Checkweighing Annunciators ..................................................................................................... 6
Backlight Setting ......................................................................................................................... 6
MAINTENANCE ............................................................................................................... 6
Cleaning ...................................................................................................................................... 6
Troubleshooting ......................................................................................................................... 7
Service Information .................................................................................................................... 7
TECHNICAL DATA ............................................................................................................ 7
Specifications ............................................................................................................................. 7
Disposal ...................................................................................................................................... 8
ERROR AND STATUS MESSAGE ........................................................................................ 8
Error Message ............................................................................................................................ 8
WARRANTY .................................................................................................................... 8

R230 Series
2 IN-1457[17001B] 201806
INTRODUCTION
This manual rovides detailed instructions for the installation work, o eration and maintenance instructions of the
CHARDER R230 Scale, lease read this manual com letely before installing and o erating scale.
Safety Precautions
Please follow these safety recautions:
• Verify AC Ada ter in ut voltage matches the local AC ower su ly.
• Do not insert liquids or foreign object.
• Do not o erate the scale in hostile environments.
• Do not dro loads or leave ermanent load on the latform. This may damage the measuring system.
• Do not lace the scale u side down on the an.
• Do not o en the scale. Never attem t to make re airs yourself because this could be dangerous. The warranty is
void if this sti ulation is ignored. The scale may only be o ened by authorized ersonnel.
• Always disconnect the device from the ower su ly before installing, servicing, cleaning or erforming
maintenance.
• Check the ower cable regularly for damage. If it is damaged, immediately disconnect the device from the ower
su ly.
INSTALLATION
Package Contents
• R230 Scale
• AC Power Ada tor
• User’s Manual
R230 Scale
User’s Manual
AC Power Ada tor

R230 Series
3 IN-1457[17001B] 201806
Parts Description
Selecting the Location
Select a firm, vibration-free and horizontal location for the scale. Avoid locations with direct sunlight, excessive air
current, heat sources, or ra id tem erature fluctuations.
Power
Connect the AC Ada tor to the AC mains su ly. Connect the lug to the AC jack on the bottom of the scale as shown
in the illustration below. The ower outlet should be close to the scale and easily accessible.
Battery Power
Build-in Rechargeable-battery. Only Charder rechargeable battery ack can ower and charge for R230 scale.
The scale will automatically switch to battery o eration if there is a ower failure or the ower cord is removed to
rovide uninterru ted scale o eration. The scale can be o erated while batteries are recharging, and the battery is
rotected against overcharging. During charging, the battery indicator dis lays the charge level, the batteries should
be com letely charged when the battery indicator turns solid green.
Note: When low battery is dis layed, the scale will shut off after 30 seconds.
CAUTION:
Risk of ex losion can occur if re laced with the wrong ty e or connected im ro erly.
Do not use the battery for any ur ose other than those described in this manual.
Do not disassemble, re air or otherwise mani ulate the battery ack.
Obey the local laws and regulations on dis osing the battery.
Stainless Steel Pan
LCD Dis lay
Key Pad
Adjustable Feet

R230 Series
4 IN-1457[17001B] 201806
OPERATION
eypad and Display Description
Status Indicators
ICON Description
Stability dis lay
→ 0 ←
Zero setting activated
Negative sign
NET
Dis lay net weight
Hold
Dis lay hold function
Condition of battery
Power su ly connected
Steady green light re resents the battery is fully charged.
g / lb / lb:oz / oz Currently chosen weight unit
LED Indications
LED status Description
Eternal on Battery full charge 100%
Blinking Battery is charging
Blink twice in 1 second When connect ower ada tor
Blink once and turn off for 1 second No battery or battery defective
Blink twice and turn off for 1 second Abnormality with the charging system
Blink 3 times and turn off for 1 second Abnormal battery voltage
Blink 4 times and turn off for 1 second Battery voltage in an overload condition
eypad Description
KEY DESCRIPTION FUNCTION
ON/OFF Switch -Turn on and off dis lay
Unit Switch /  -Change the weighing units to alternate units of
measurement
Hold / Target / OK -Call u hold function
-Setting target weight in checkweighing mode
Tare / Backlight / ▲
▲▲
▲ -Tarring
-Dis lay backlight

R230 Series
5 IN-1457[17001B] 201806
Turning Scale On/Off
To turn the scale on, ress the [ON/OFF button. Scale will dis lay and then enters the active weighing
mode.
To turn the scale off, ress the [ON/OFF button.
Zero Operation & Setting
When ower on the scale and if the weight on the scale is within the initial zero tolerance, the scale will dis lay zero
automatically.
Although there is nothing on the an and the dis lay is not zero, ress [TARE button to set zero to the scale.
Changing Units of Measure
In weighing mode, use [UNIT to dis lay the next available measuring unit. Re eat rocess to scroll through all units.
Checkweighing Mode
This mode sets low and high weight limits for ortion control rocesses.
Enter checkwighing mode
Press and hold [HOLD/TARGET button to enter checkweighing mode.
Setting target weight values
LOWER LIMIT SETTING The first digit is dis layed flashing.
A triangle a ears next to the Under.
And the LCD turns no backlight.
Re eatedly ress [TARE ▲
▲▲
▲ until the desired number
a ears.
Press [UNIT  to acce t and move to the next digit.
Re eat until all the digits are correct.
And ress [HOLD/TARGET/OK to confirm the setting of
lower limit and then enter to high limit setting.
HIGH LIMIT SETTING The first digit is dis layed flashing.
A triangle indicator will a ears next to the Over and
the LCD light u in red.
Re eatedly ress [TARE ▲
▲▲
▲ until the desired number
a ears. Press [UNIT  to acce t and move to the next
digit.
Re eat until all the digits are correct.
And ress [HOLD/TARGET/OK to confirm setting.
Ready for Checkweighing
If required, lace an em ty container on the an and ress [TARE .
Return to Weighing mode
Press and hold [HOLD/TARGET button to return weighing mode.

R230 Series
6 IN-1457[17001B] 201806
Checkweighing Annunciators
The OVER, ACCEPT, and UNDER annunciators are to the right of the dis lay and the features as below.
WITHIN TARGET RANGE The LCD light u in green and a triangle a ears next to
“Accept”, and you will hear 2 short bee s.
UNDER TARGET RANGE The LCD light off and a triangle a ears next to “Under”
and no bee sound effect.
OVER TARGET RANGE The LCD light u in red and a triangle a ears next to
“Over”, and you will hear continuous short bee s.
If the dis lay shows Err, this means weight exceeds
overload limit.
SETTINGS
Backlight Setting
Press [TARE and hold for 2 seconds to turn ON the backlight manually.
Press [TARE and hold for 2 seconds to turn OFF the backlight manually.
Tare Setting
Place an em ty container on the scale and ress [TARE . The dis lay will show a net value of “0”.
To clear the Tare value, ress [TARE with the an em ty.
Auto off Setting
Press and hold [UNIT for 6 seconds until the dis lay show
And dis lay will show A_OFF, ress [UNIT to select auto turn off time or off this function. And ress [ZERO and ress
[UNIT to see End to confirm setting.
MAINTENANCE
Cleaning
Before cleaning, disconnect the ower lug from ower outlet and remove batteries from the a liance to ower off
the unit.
• Clean with a dam cloth and a mild soa or similar agents if necessary, and buffed dry with.
• Do not use any acids, alkalis or strong active solvents to clean the housing or control anels.

R230 Series
7 IN-1457[17001B] 201806
Troubleshooting
SYMPTOM POSSIBLE CAUSE REMEDY
Scale will not turn on
Battery discharged Check the batteries or ada ter and
recharge the battery.
Power cord not lugged in ro erly Check ower cord connection and
lugged in ro erly into the ower
outlet.
Other failure Have the scale serviced by Charder
authorized service center.
Battery fails to charge fully Battery is defective Have battery re laced by Charder
authorized service center.
Scale flashes Battery Battery discharged Connect the ower and recharge the
battery.
Service Information
If the troubleshooting section above does not resolve or describe your issue, contact your authorized Charder service
agent for further assistance or Charder Customer Su ort at [phone] or email to info_ce[email protected]
TECHNICAL DATA
Specifications
MODEL R230
Ca acity 1.5 kg / 3 lb 3 kg / 6 lb 6 kg / 12 lb
Graduation 0.2 g / 0.0005 lb 0.5 g / 0.001 lb 1 g / 0.002 lb
Power Requirements 100 V - 240 V DC 15V / 0.3A AC ada ter
Built-in rechargeable battery
Weighing Units lb:oz, oz, g, lb
Dis lay 0.8 in LCD with Red and Green backlight
5-digit 6-Segment, Character height 21 mm/0.83 in
Key Function 4 Keys
On / Off, Unit, Target / Hold, Tare / Backlight
O erating
Tem erature and
Humidity
5°C to 35° C / 41°F to 95°F
15% - 85% RH
A lication Mode Weighing, Checkweighing
Construction 304 Stainless Steel housing and latform
ABS bottom
Platform Size 175 x 165 mm / 7" x 6 1/2"
Assembled
Dimensions
235 x 175 x 62 mm / 9 1/4" x 7" x 2 7/16"
Weight 1.82 kg / 4 lb

R230 Series
8 IN-1457[17001B] 201806
Disposal
In conformance with the Euro ean Directive 2002/96 EC on Waste Electrical and Electronic Equi ment
(WEEE), this device may not be dis osed of with domestic waste. This also a lies to countries outside
the EU, according to their s ecific requirements.
Please dis ose of this roduct in accordance with local regulations at the collecting oint s ecified for
electrical and electronic equi ment. For more detailed information about recycling this roduct, lease contact the
local distributor from which you urchased this device.
ERROR AND STATUS MESSAGE
Error Message
ERROR MESSAGE DESCRIPTION REMEDY
Low battery indication Connect the ower and recharge
the battery.
Counting value is higher than the
high limit value
The scale has detected a failure
with load cell or wiring. Have the
scale serviced by Charder
authorized service center.
Counting value is lower higher than
the low limit value
The scale has detected a roblem
with load cell or wiring. Have the
scale serviced by Charder
authorized service center.
Zero value is too high when ower
on
Em ty load late before ower u .
Recalibrate the scale.
Zero value is too low when ower on Check if scale is laced correctly.
Recalibrate the scale.
Overload Remove excess weight and use
scale within its limits.
Zero value is too low Increase the load. If this roblem
remains unresolved, contact
Charder authorized service center.
WARRANTY
Charder scales are warranted against defects in material and workmanshi for a eriod of 1(one) year from the date
of urchase. Please retain your recei t as roof of urchase. Warranty ex iration on roducts returned without roof
of urchase will be determined from the manufacturing date code or the date of shi ment to the authorized dealer.
Coverage may be invalidated as this date is revious to urchase date. No other ex ress or im lied warranty is given
by Charder.
Freight damage on returns is not covered under warranty.
This warranty does not a ly for following reasons, the roduct has been damaged by accident or misuse, arts and
roducts of a consumable nature, ex osed to radioactive or corrosive materials, has foreign material enetrating to
the inside of the roduct, or as a result of service or modification by other than Charder.

R230 Series
9 IN-1457[17001B] 201806
Charder Electronic Co., Ltd.
No.103, Guozhong Rd.,
Dali Dist., Taichung City
41262 Taiwan (R.O.C.)
Tel: [phone]
Fax: [phone]
htt ://www.charder.com
IN-1457[17001B] © 2017 Charder Electronic Co., Ltd., All rights reserved
