Chauvin Arnoux AEMC 1035 User manual

Megohmmeters
Models 1035 & 1039
User Manual
ENGLISH
DIGITAL ANALOG MEGOHMMETERS
WITH AEMC
®
INSTRUMENTS

Copyright©Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments. All rights reserved.
No part of this documentation may be reproduced in any form or by any means (including electronic
storage and retrieval or translation into any other language) without prior agreement and written consent
from Chauvin Arnoux®, Inc., as governed by United States and International copyright laws.
Chauvin Arnoux®, Inc. d.b.a. AEMC®Instruments
15 Faraday Drive • Dover, NH 03820 USA
Tel: [phone] or [phone] • Fax: [phone]
This documentation is provided “as is,” without warranty of any kind, express, implied, or otherwise. Chauvin Arnoux®,
Inc. has made every reasonable e󰀨ort to ensure that this documentation is accurate; but does not warrant the accuracy or
completeness of the text, graphics, or other information contained in this documentation. Chauvin Arnoux®, Inc. shall not
be liable for any damages, special, indirect, incidental, or inconsequential; including (but not limited to) physical, emotional
or monetary damages due to lost revenues or lost prots that may result from the use of this documentation, whether or
not the user of the documentation has been advised of the possibility of such damages.

Statement of Compliance
Chauvin Arnoux®, Inc. d.b.a. AEMC® Instruments
certies that this instrument has been calibrated
using standards and instruments traceable to
international standards.
We guarantee that at the time of shipping your
instrument has met its published specications.
An NIST traceable certicate may be requested
at the time of purchase, or obtained by returning
the instrument to our repair and calibration
facility, for a nominal charge.
The recommended calibration interval for this
instrument is 12 months and begins on the date of
receipt by the customer. For recalibration, please
use our calibration services. Refer to our repair and
calibration section at www.aemc.com.
Serial #:
Catalog #: 2116.90 / 2116.91
Model #: 1035 / 1039
Please ll in the appropriate date as indicated:
Date Received:
Date Calibration Due:
Chauvin Arnoux®, Inc.
d.b.a AEMC®Instruments
www.aemc.com

Contents
INTRODUCTION .......................................................................... 6
1.1 International Electrical Symbols................................................7
1.2 Denition of Measurement Categories (CAT) ...........................7
1.3 Receiving Your Shipment..........................................................7
1.4 Ordering Information.................................................................8
1.4.1 Accessories and Replacement Parts............................8
PRODUCT FEATURES ................................................................ 9
2.1 Description................................................................................9
2.2 Model 1035 Control Features .................................................10
2.3 Model 1039 Control Features ................................................. 11
2.4 LCD Display Symbols .............................................................12
2.4.1 Digital Display Symbols ..............................................12
2.4.2 Analog Bargraph.........................................................12
2.5 Button Functions.....................................................................13
2.5.1 Yellow Push Button .....................................................13
2.5.2 ALARM Button ............................................................13
2.5.3 Cursor Button..............................................................13
2.5.4 Scroll Cursor Button....................................................14
2.5.5 Backlight Button ...................................................14
2.5.6 REL Button...............................................................14
2.6 Measurement Functions .........................................................15
2.6.1 AC/DC Voltage Measurement - Safety Check ............15
2.6.2 Insulation Resistance Testing .....................................15
2.6.3 Resistance ..................................................................16
2.6.4 Capacitance (1039) ....................................................17
2.6.5 AC/DC Current (1039) ................................................18
2.6.6 AC Voltage (1039) ......................................................18
2.7 Special Functions ...................................................................18
2.7.1 Battery Life Indication .................................................18
2.7.2 Auto-O󰀨.......................................................................18
2.7.3 Battery Auto Test.........................................................19
2.7.4 Fuse (1039) ................................................................19
2.7.5 Buzzer.........................................................................19

2.7.6 Alarm Setpoints ..........................................................20
2.7.7 Relative Measurements ( REL) ...............................22
2.7.8 Programming the Capacitance per Unit Length (1039)......22
SPECIFICATIONS ...................................................................... 23
3.1 Electrical Specications ..........................................................23
3.1.1 Voltage........................................................................23
3.1.2 Insulation ....................................................................24
3.1.3 Resistance ..................................................................24
3.1.4 Capacitance (1039) ....................................................25
3.1.5 Distance (1039) ..........................................................25
3.1.6 AC/DC Current (1039) ................................................25
3.1.7 AC Voltage (1039) ......................................................25
3.1.8 Power Supply..............................................................26
3.2 Mechanical Specications ......................................................26
3.3 Environmental Conditions.......................................................26
3.4 Safety Specications .........................................................27
OPERATION .............................................................................. 28
4.1 Operation ................................................................................28
4.2 AC/DC Voltage and Insulation Measurement .........................28
4.3 Resistance Measurement .......................................................29
4.4 Capacitance Measurement (1039) .........................................29
4.5 AC/DC Current Measurement (1039) .....................................30
4.6 AC Voltage Measurement (1039) ...........................................30
4.7 Application Examples .............................................................31
4.7.1 Insulation Measurements on Installations...................31
4.7.2 Insulation Measurements on Cables ..........................31
4.7.3 Insulation Measurements on Motors...........................32
MAINTENANCE ......................................................................... 33
5.1 Battery Replacement ..............................................................33
5.2 Fuse Replacement (1039) ......................................................33
5.3 Cleaning..................................................................................33
5.4 Storage ...................................................................................33
5.5 Repair and Calibration ..............................................................34
5.6 Technical and Sales Assistance................................................34
5.7 Limited Warranty .......................................................................35

Digital Analog Megohmmeter Models 1035/1039 6
CHAPTER 1
INTRODUCTION
Warning
These safety warnings are provided to ensure the safety of
personnel and proper operation of the instrument.
• Read the instruction manual completely and follow all safety
information before operating this instrument.
• Safety is the responsibility of the operator!
• Tests are to be carried out only on non-energized
circuits! Check for live circuits before making resistance
measurements (safety check).
• The Megohmmeter Models 1035 and 1039 are sources
of high voltage, as is the sample connected to them. All
persons performing or assisting in the tests must employ all
safety precautions to prevent electrical shock to themselves
and to others.
• Use personal protective equipment where appropriate.
• When testing capacitance samples, make sure that they
have been properly discharged and that they are safe
to touch. Dielectric insulation samples should be short-
circuited for at least ve times the amount of time they were
energized.
• Megohmmeters should never be used in an explosive
environment.
• Use the leads supplied with the megohmmeters. If they are
defective or worn, replace before testing.
• NEVER use the megohmmeters on electrical conductors
rated above 600 V in overvoltage category III (CAT III).

7 Digital Analog Megohmmeter Models 1035/1039
1.1 International Electrical Symbols
This symbol signies that the instrument is protected by
double or reinforced insulation.
This symbol on the instrument indicates a WARNING and that
the operator must refer to the user manual for instructions
before operating the instrument. In this manual, the symbol
preceding instructions indicates that if the instructions are not
followed, bodily injury, installation/sample and product damage
may result.
Risk of electric shock. The voltage at the parts marked with this
symbol may be dangerous.
In conformity with WEEE 2002/96/EC
1.2 Denition of Measurement Categories (CAT)
CAT IV corresponds to measurements performed at the primary electrical
supply (< 1000 V).
Example: primary overcurrent protection devices, ripple control units, and
meters.
CAT III corresponds to measurements performed in the building installation
at the distribution level.
Example: hardwired equipment in xed installation and circuit breakers.
CAT II corresponds to measurements performed on circuits directly
connected to the electrical distribution system.
Example: measurements on household appliances and portable tools.
1.3 Receiving Your Shipment
Upon receiving your shipment, make sure that the contents are
consistent with the packing list. Notify your distributor of any missing
items. If the equipment appears to be damaged, le a claim immediately
with the carrier and notify your distributor at once, giving a detailed
description of any damage. Save the damaged packing container to
substantiate your claim. Do not use an instrument that appears to be
damaged.

Digital Analog Megohmmeter Models 1035/1039 8
1.4 Ordering Information
Model 1035 (Discontinued - No longer available) ....................... Cat. #2116.90
Includes soft carrying case, 3 color-coded leads, 1 black test probe, 3 alligator
clips, 2 grip probes, batteries and user manual.
Model 1039 (Discontinued - No longer available) ....................... Cat. #2116.91
Includes soft carrying case, 2 color-coded leads, 1 black test probe, 2 alligator
clips, 2 grip probes, batteries and user manual.
Model 1035 Field Kit.......................................................... Cat. #2115.42
Includes meter, eld case, 3 color-coded leads, black test probe, 3 alligator clips,
2 grip probes, remote test probe, batteries and user manual.
Model 1039 Field Kit.......................................................... Cat. #2115.43
Includes meter, eld case, 2 color-coded leads, black test probe, 2 alligator clips,
2 grip probes, remote test probe, AC current probe, batteries and user manual.
1.4.1 Accessories and Replacement Parts
AC Current Probe MN211 (Lead - 1mA/A - 240A max) ....... Cat. #2115.73
Remote Test Probe.............................................................. Cat. #2118.97
Field Case (Waterproof) ...................................................... Cat. #2118.98
Hands Free Carrying Case.................................................. Cat. #2118.99
Soft Carrying Pouch ............................................................ Cat. #2119.02
Lead- Replacement ............................................................. Cat. #2119.40
(Includes Set of 2, 5 ft Color Safety Leads, 4 mm Straight Plug, 4mm Right-angle
Plug, 2 color-coded Alligator Clips, 2 Color-coded “hook” Grip Probe, 1 Black Test
Probes) for Model 1039.
Lead- Replacement ............................................................. Cat. #2119.41
(Includes Set of 2, 5 A Color Safety Leads, 4 mm Straight Plug, 4 mm Right-
angle Plug, 3 color-coded Alligator Clips, 2 Color-coded “hook” Grip Probe, 1 Black
Shielded Cable) for Model 1035.
Set of 5 Fuses, 600 V, 0.63 A, ¼ x 1¼ in (6 x 32 mm) ........ Cat. #2970.78
Order Accessories and Replacement Parts Directly Online
Check our Storefront at www.aemc.com/store for availability

9 Digital Analog Megohmmeter Models 1035/1039
CHAPTER 2
PRODUCT FEATURES
2.1 Description
These portable megohmmeters function with batteries. They can be used
to check insulation and voltages, and to measure resistances. The
Model 1039 can also be used for:
• measurement of the capacitance of a telephone line
• current measurement
• measurement of the pure alternating component of a DC
voltage
These megohmmeters help to ensure the safety of electrical and
telephone installations. The acquisition, processing and display of the
measurements are managed by a microprocessor. They o󰀨er a wide
range of advantages such as:
• automatic detection of the presence of a dangerous voltage
on the terminals in MΩ ranges (all insulation measurement
blocked if V > 25 V)
• protection of the instrument against external voltage surges
• operator safety by means of automatic discharge of the high
voltage on the equipment tested
• display of the di󰀨erence compared to a measurement value
in memory
• measurement of the length of a telephone line according to
its capacitance per km unit length (1039)
• automatic shutdown of the instrument to save the batteries
and indication of the battery charge
• fuse testing by periodic checks during current measurement
(1039)
• a large backlit LCD screen with a wide range of indicators
making it very easy for the user to read

Digital Analog Megohmmeter Models 1035/1039 10
2.2 Model 1035 Control Features
Figure 1
1. Safety terminals - Ø 4 mm (marked “+” and “G”) and a 3-Point socket
for connecting the remote control
2. Backlight liquid crystal display
3. Buttons: Yellow (to activate insulation measurement)
ALARM, ,, and ΔREL (see § 2.7)
4. 6-position switch:
OFF, MΩ- 50 V, MΩ- 100 V, MΩ- 250 V, MΩ- 500 V, 400 kΩ
5. Battery compartment and stand (not shown in drawing)

11 Digital Analog Megohmmeter Models 1035/1039
2.3 Model 1039 Control Features
Figure 2
1. Safety terminals - Ø 4 mm (marked “mA”, “+” and “-”). Next to the “-”
terminal, there are two additional contacts for connecting the remote
control probe (3-Point connector).
2. Backlight liquid crystal display
3. Buttons: Yellow (to activate insulation measurement)
ALARM,
,, and ΔREL (see § 2.7)
4. 7-position switch:
OFF, MΩ- 50 V, MΩ- 100 V, 40 kΩ, 4000 nF, 400 mA, 400 V~
5. Battery compartment and stand (not shown in the drawing)

Digital Analog Megohmmeter Models 1035/1039 12
2.4 LCD Display Symbols
2.4.1 Digital Display Symbols
Timer On
ALARM Alarm On
>High Limit Trigger
<Low Limit Trigger
Test Voltage On
– Negative Value
Refer to User Manual
FUS Fuse Open
>25V Measured Voltage >25 V
Lead, Resistance Zeroing
Active Buzzer
Permanent Run –
Auto-O󰀨 Disabled
Low Battery
nF nanoFarad
Km Kilometers
REL Relative Position
BAT Batteries low – must be replaced
OL Over Range - Over Load
- - - Insulation < 10 kΩ at 50 V, < 20 kΩ at 100 V,
< 50 kΩ at 250 V, < 100 kΩ at 500 V
2.4.2 Analog Bargraph
Insulation > 1.1 GΩ
Insulation < 70 kΩ

13 Digital Analog Megohmmeter Models 1035/1039
2.5 Button Functions
2.5.1 Yellow Push Button
The yellow button is used to initiate the test voltage when measuring
insulation resistance. In any function setting (except OFF), the
megohmmeter is in the voltage mode and works as a voltmeter to detect
if any voltage is present on the tested sample. If a voltage greater than
25 V is detected, the yellow test button is disabled and insulation testing
is not possible.
2.5.2 ALARM Button
The ALARM button can be used to activate/deactivate the alarm
thresholds during insulation and resistance measurements.
It is also used with the ► and ▲ selection cursor buttons to adjust the
alarm set points.
2.5.3 Cursor Button
When programming the alarm setpoints, the ► cursor button makes the
following symbols ash as follows:
- the measurement unit (if applicable),
- the thousands digit,
- the hundreds digit,
- the tens digit,
- the units digit,
- the decimal point,
- the alarm trigger (above or below the setting)
- and it then returns to the measurement units.
The capacitance per unit length in nF/km (with the button on the
1039). By pressing the ► button, you can make the following elements
ash successively:
- the tens digit,
- the units digit,
- and it then returns to the tens digit.

Digital Analog Megohmmeter Models 1035/1039 14
2.5.4 Scroll Cursor Button
When programming the alarm setpoints, the ▲ button is used to scroll
through the possible values for each parameter, which ashes:
- MΩor GΩfor insulation, kΩor Ωfor resistance, for the
measurement units,
- 1,2, 3 or _ for the thousands digit,
- 0, 1, 2, 3, 4, 5, 6, 7, 8 and 9 for the hundreds, tens and units,
- “-.- - -” or “- -.- -” or “- - -.-” or “- - - -” for the decimal separator,
- > or < for above or below threshold trigger.
- When programming the capacitance per unit length in nF/km, the
▲ button can be used to change the values of the ashing digits
to 0, 1, 2, 3, 4, 5, 6, 7, 8 or 9.
2.5.5 Backlight Button
1035 and 1039: When this button is pressed, the backlighting of the
display comes on. It will be turned o󰀨 automatically one minute later.
When it is lit, you can turn the backlighting o󰀨 by pressing this button
again.
1039: When the switch is on 4000 nF, a long press on this button
enables you to program the unit length value (see § 2.7.8).
2.5.6 REL Button
A long press on this button enables you to memorize a value. The
measurements that follow will be the positive or negative deviation
compared with the value memorized (does not function for voltage on the
MΩpositions).

15 Digital Analog Megohmmeter Models 1035/1039
2.6 Measurement Functions
2.6.1 AC/DC Voltage Measurement - Safety Check
As soon as the switch is set to one of the MΩpositions, the instrument
measures the voltage between its + and - terminals. The value of this
voltage is displayed (0 to 600 VAC/DC max).
If the voltage present is less than 25 V, the insulation can be
tested, but the lower the test voltage the greater the possibility of
error.
If the voltage is greater than 25 V, and >25 V are displayed.
Pressing the yellow button will only cause the buzzer to turn on
and the symbol to ash until the button is released.
These warnings only end if the voltage falls below 25 V (disconnection of
the leads or removal of the voltage) or if the yellow button is released or,
naturally, if you turn o󰀨 the instrument by returning the switch to the OFF
position.
WARNING: If the voltage detected is above 600 V (outside mea-
surement range), OL will appear on the digital display.
2.6.2 Insulation Resistance Testing
If there is not a dangerous voltage (see above), the user can then
measure the insulation by pressing the yellow button. The high voltage
is then generated between the terminals (marked + and -). The value
of the measurement is shown on the logarithmic scale of the bargraph
and on the digital display, with the corresponding MΩor GΩsymbol. As
soon as the yellow button is released, the instrument returns to voltage
measurement mode.
WARNING: If the voltage generated may be dangerous, is
displayed.

Digital Analog Megohmmeter Models 1035/1039 16
The instrument indicates if the value measured is outside its
measurement range. If the measured insulation resistance is greater
than 400MΩ(1039), 2 or 20 GΩ (1035), the OL symbol is displayed on
the digital display instead of a value. When the measurement is greater
than 1.1 GΩ, the ► symbol lights up on the right-hand side of the
bargraph. Similarly the digital measurement display indicates “- - -” if the
insulation resistance is less than:
Model 1039: 10 kΩ at 50 V; 20 kΩat 100 V
Model 1035: 10 kΩ at 50 V; 20 kΩ at 100 V; 50 kΩ at 250 V;
100 kΩat 500 V
When the measurement is less than 70 kΩ, only the ◄ symbol lights up
on the left-hand side of the bargraph.
To measure high insulation values, you are advised to use the “G” guard
terminal to remove the inuence of supercial leak currents and “hand
capacitance”.
2.6.3 Resistance
Resistance measurement corresponds to the 40 kΩposition of the switch
on the 1039 and the 400 kΩposition on the 1035. The measurement is
indicated on the digital measurement display, accompanied by the Ωor
kΩsymbol if necessary. The instrument indicates if the value measured
is outside its measurement range. If the resistance is greater than 40 kΩ
or 400 kΩ, depending on the instrument, the OL symbol is displayed on
the digital measurement display. A programmed threshold may trigger
an alarm (see pg 18).

17 Digital Analog Megohmmeter Models 1035/1039
2.6.4 Capacitance (1039)
Capacitance measurement corresponds to the 4000 nF position of the
switch. The measurement is shown on the display accompanied by the nF
symbol. The length of the telephone line measured is indicated in km on
the digital threshold display, according to the programmed capacitance
per unit length.
If the leads are set up in a short circuit, the instrument indications
OL on the digital measurement display and the distance is - - - km.
If the capacitance measurement is greater than 4000 nF, the
OL symbol is displayed on the digital measurement display.
If the distance measurement is greater than 80 km, the OL
symbol is displayed on the digital measurement display.
If the leads are not connected, the digital measurement display
indicates 0.00.

Digital Analog Megohmmeter Models 1035/1039 18
2.6.5 AC/DC Current (1039)
Current measurement corresponds to the 400 mA position of the switch.
The measurement is shown on the display accompanied by the mA
symbol. The fuse is checked periodically.
If the current measurement is greater than 400 mAAC/DC, the
OL symbol is displayed on the display. The MN211 Current Probe
may be used to extend the measurement range to 200AAC.
2.6.6 AC Voltage (1039)
AC voltage measurement corresponds to the V~ position of the switch. The
measurement is shown on the display accompanied by the VAC symbol. In
this function, the DC component is not measured.
If the voltage measurement is greater than 400 VAC, the OL
symbol is displayed on the digital measurement display.
2.7 Special Functions
2.7.1 Battery Life Indication
When you move the switch from the OFF position to one of the function
positions, the battery voltage is applied to the circuit. All the display seg-
ments light up at the same time for 1 second. Then all the segments go out
(for 2 seconds) except the and the ◄ and ► symbols which delimit
the size of the bargraph.
The bargraph indicates the battery charge life and the digital measure-
ment display indicates the charge life available (0.00 to 1.00 = 0 to 100 %).
The instrument can be turned o󰀨 at any time by turning the rotary switch
to OFF.
2.7.2 Auto-O󰀨
After 5 minutes without any activity, the instrument automatically shuts o󰀨.
To start up the instrument again, press any one of the buttons, turn the
switch, or press the yellow test button on the remote control test probe.

19 Digital Analog Megohmmeter Models 1035/1039
DISABLING/ENABLING THE AUTO-OFF
• To disable the Auto-O󰀨, keep the button pressed down when
turning ON the instrument. The symbol is then displayed, indi-
cating that the Auto-O󰀨 function has been disabled.
• To enable the Auto-o󰀨 function, turn the instrument OFF and then
turn it back ON again. Auto-O󰀨 is the default mode.
2.7.3 Battery Auto Test
The battery supply voltage is measured automatically every second. The
battery voltage range for correct operation is 7 V to 10 V. There are four
possible cases:
• The voltage is correct: Nothing is displayed.
• The voltage is < 7.1 V: the symbol ashes. Remaining bat-
tery life is limited.
• The voltage is < 6.9 V: the symbol remains lit. Measurement
accuracy is no longer assured. Replace the batteries.
• The voltage is close to 6.7 V: the digital display indicates BAT and
then, after 5 seconds, the shutdown buzzer sounds, and the Auto
OFF function is activated. The instrument shuts down.
2.7.4 Fuse (1039)
The fuse is tested automatically when the instrument is started up and
then checked periodically during current measurement.
2.7.5 Buzzer
DISABLING/ENABLING THE BUZZER
Keep the ALARM button pressed down when you start up the instrument
by turning the switch. The symbol is no longer displayed.
To reactivate the buzzer, switch the instrument OFF and then back ON
again.

Digital Analog Megohmmeter Models 1035/1039 20
THE DIFFERENT SOUNDS
When the symbol is displayed, the buzzer is active. It gives out di󰀨erent
sounds, depending on the operation or warning.
• Short buzz (65 ms at 2 kHz):
- push on a button
- auto OFF
• Continuous buzz (at 2 kHz):
- measurement is lower than the minimum setpoint
- measurement is higher than the maximum setpoint
• Short, higher buzz (65ms at 4 kHz):
- when a disabled (inactive) button is pressed
(except the yellow test button)
• Repeated high buzzes (at 4 kHz):
- the detected voltage (safety check) at the sample is
greater than 25 V and the yellow button is pushed
2.7.6 Alarm Setpoints
Alarm setpoints can only be programmed for insulation and resistance
measurement. The setpoints can be upper or lower thresholds. They can
be active or inactive and will be stored in the memory even after the
instrument has been turned o󰀨.
PROGRAMMING OF THE ALARM SETPOINTS
To program the setpoint press the ALARM button until the ALARM symbol
is displayed and beeps a second time (the setpoint unit will blink, e.g. MΩ).
The value of the setpoint corresponding to the selected range is indicated
on the small digital display.
If no value was previously programmed, the display indicates a default
setpoints:
• On the 1039: > 0.050 MΩfor the MΩ- 50 V position
> 0.100 MΩfor the MΩ- 100 V position
< 20.00 kΩfor the 40 kΩposition
• On the 1035: > 0.05 MΩfor the MΩ- 50 V position
> 0.10 MΩ for the MΩ - 100 V position
> 0.25 MΩ for the MΩ - 250 V position
> 0.50 MΩ for the MΩ - 500 V position
< 20.00 kΩ for the 400 kΩ position
