Chroma 19071 User manual

i
HIPOT Tester
19071/19072/19073
Quick Start Guide

HIPOT Tester
19071/19072/19073
Quick Start Guide
Version 1.2
December 2010
P/N A11 001298
i

ii
Legal Notices
The information in this document is subject to change without notice.
Chroma ATE INC. makes no warranty of any kind with regard to this
manual, including, but not limited to, the implied warranties of
merchantability and fitness for a particular purpose. Chroma ATE INC. shall
not be held liable for errors contained herein or direct, indirect, special,
incidental or consequential damages in connection with the furnishing,
performance, or use of this material.
CHROMA ATE INC.
No. 66 Hwa-Ya 1st Rd., Hwa-Ya Technical Park, Kuei-Shan 33383,
Taoyuan County, Taiwan
Copyright Notices. Copyright 2009 - 2010 Chroma ATE INC., all rights
reserved. Reproduction, adaptation, or translation of this document without
prior written permission is prohibited, except as allowed under the copyright
laws.

iii
Warranty
All Chroma instruments are warranted against defects in material and
workmanship for a period of one year after date of shipment. Chroma
agrees to repair or replace any assembly or component found to be
defective, under normal use during this period. Chroma's obligation under
this warranty is limited solely to repairing any such instrument, which in
Chroma's sole opinion proves to be defective within the scope of the
warranty when returned to the factory or to an authorized service center.
Transportation to the factory or service center is to be prepaid by purchaser.
Shipment should not be made without prior authorization by Chroma.
This warranty does not apply to any products repaired or altered by
persons not authorized by Chroma, or not in accordance with instructions
furnished by Chroma. If the instrument is defective as a result of misuse,
improper repair, or abnormal conditions or operations, repairs will be billed
at cost.
Chroma assumes no responsibility for its product being used in a
hazardous or dangerous manner either alone or in conjunction with other
equipment. High voltage used in some instruments may be dangerous if
misused. Special disclaimers apply to these instruments. Chroma
assumes no liability for secondary charges or consequential damages and
in any event, Chroma's liability for breach of warranty under any contract or
otherwise, shall not exceed the purchase price of the specific instrument
shipped and against which a claim is made.
Any recommendations made by Chroma for use of its products are based
upon tests believed to be reliable, but Chroma makes no warranty of the
results to be obtained. This warranty is in lieu of all other warranties,
expressed or implied, and no representative or person is authorized to
represent or assume for Chroma any liability in connection with the sale of
our products other than set forth herein.
CHROMA ATE INC.
No. 66 Hwa-Ya 1st Rd, Hwa-Ya Technical Park,
Kuei-Shan 33383, Taoyuan County, Taiwan
Tel: [phone]
Fax: [phone]
http://www.chromaate.com

Material Contents Declaration
The recycling label shown on the product indicates the Hazardous
Substances contained in the product as the table listed below.
: See <Table 1>.
: See <Table 2>.
<Table 1> Hazardous Substances
Lead Mercury Cadmium Hexavalent
Chromium Polybrominated Biphenyls Polybromodiphenyl Ethers
Part Name
Pb Hg Cd Cr6+ PBB PBDE
PCBA O O O O O O
CHASSIS O O O O O O
ACCESSORY O O O O O O
PACKAGE O O O O O O
“O” indicates that the level of the specified chemical substance is less than the
threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC.
“°” indicates that the level of the specified chemical substance exceeds the
threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC.
Disposal
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities. Contact your local government for information regarding the
collection systems available. If electrical appliances are disposed of in landfills or
dumps, hazardous substances can leak into the groundwater and get into the food
chain, damaging your health and well-being. When replacing old appliances with
new one, the retailer is legally obligated to take back your old appliances for
disposal at least for free of charge.
iv

<Table 2> Hazardous Substances
Lead Mercury Cadmium Hexavalent
Chromium Polybrominated Biphenyls Polybromodiphenyl Ethers
Part Name
Pb Hg Cd Cr6+ PBB PBDE
PCBA °O O O O O
CHASSIS °O O O O O
ACCESSORY °O O O O O
PACKAGE O O O O O O
“O” indicates that the level of the specified chemical substance is less than the
threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC.
“°” indicates that the level of the specified chemical substance exceeds the
threshold level specified in the standards of SJ/T-11363-2006 and EU 2005/618/EC.
1. Chroma is not fully transitioned to lead-free solder assembly at this moment;
however, most of the components used are RoHS compliant.
2. The environment-friendly usage period of the product is assumed under the
operating environment specified in each product’s specification.
Disposal
Do not dispose of electrical appliances as unsorted municipal waste, use
separate collection facilities. Contact your local government for information
regarding the collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances can leak into the
groundwater and get into the food chain, damaging your health and well-
being. When replacing old appliances with new one, the retailer is legally
obligated to take back your old appliances for disposal at least for free of
charge.
v

Safety Summary
The following general safety precautions must be observed during all
phases of operation, service, and repair of this instrument. Failure to
comply with these precautions or specific WARNINGS given elsewhere in
this manual will violate safety standards of design, manufacture, and
intended use of the instrument. Chroma assumes no liability for the
customer’s failure to comply with these requirements.
BEFORE APPLYING POWER
Verify that the power is set to match the rated input of
this power supply.
PROTECTIVE GROUNDING
Make sure to connect the protective grounding to
prevent an electric shock before turning on the
power.
NECESSITY OF PROTECTIVE GROUNDING
Never cut off the internal or external protective
grounding wire, or disconnect the wiring of protective
grounding terminal. Doing so will cause a potential
shock hazard that may bring injury to a person.
FUSES
Only fuses with the required rated current, voltage,
and specified type (normal blow, time delay, etc.)
should be used. Do not use repaired fuses or short-
circuited fuse holders. To do so could cause a
shock or fire hazard.
DO NOT OPERATE INAN EXPLOSIVE ATMOSPHERE
Do not operate the instrument in the presence of
flammable gases or fumes. The instrument should
be used in an environment of good ventilation.
DO NOT REMOVE THE COVER OF THE INSTRUMENT
Operating personnel must not remove the cover of
the instrument. Component replacement and
internal adjustment can be done only by qualified
service personnel.
vi

Safety Symbols
DANGER – High voltage.
Explanation: To avoid injury, death of personnel, or
damage to the instrument, the operator must refer to
an explanation in the instruction manual.
Protective grounding terminal: To protect against
electrical shock in case of a fault. This symbol
indicates that the terminal must be connected to
ground before operation of equipment.
WARNING
The WARNING sign denotes a hazard. It calls
attention to a procedure, practice, or the like, which,
if not correctly performed or adhered to, could result
in personal injury. Do not proceed beyond a
WARNING sign until the indicated conditions are
fully understood and met.
CAUTION
The CAUTION sign denotes a hazard. It may
result in personal injury or death if not noticed
timely. It calls attention to procedures, practices
and conditions.
This indicates important information or tips for the
procedures and applications, etc. The contents
should be read carefully.
vii

viii
The Danger of Operating
1. When the instrument is under output voltage, please don’t touch test
area or you may shock hazard and result in death.
Please obey the following items.
•Make sure the grounding cable is connected correctly and using the
standard power cord.
•Don’t touch the output terminal.
•Don’t touch test cable of connecting test termination.
•Don’t touch test termination object.
•Don’t touch any charge component of connecting output terminal.
•As the instrument end the test or turn off output, please don’t touch
test unit immediately.
2. The shock accidents are usually occurred on the following conditions.
•The grounding terminal of the instrument doesn’t connect correctly.
•No use insulation glove for testing.
•After test is completed to touch test unit immediately.
3. Remote control for the instrument: This instrument provided with
remote control, normally using the external signal to control high
voltage output. For safety reasons and prevent from hazards, please
exactly follow instructions below while using remote control.
•Unexpected high voltage output may exist. Make sure if this
instrument is under testing/remote controlling before access to the
probes.
•When the instrument is under testing/operating, any access to DUT,
test cable and probe output terminal are prohibited, both for the
operator/service personnel.
•Normally remote control of this instrument is controlled by the high
voltage test bar. However, using of other control circuit is also
possible. For safety reasons and prevent from hazards, please
notice that unintentional access to the control test bar or bridging the
control circuit to high voltage terminal and test cables may cause
hazards. Please keep this terminal/control from unintentional
bridging/access to avoid danger.

WARNING Don't tie HV cable, RS232, Handler, GPIB control
cable and other low voltage cable together. Or it
may cause product damaged or PC crashed.
ix

x
Storage, Freight, Maintenance & Cleaning
Storage
When don’t use the device, please pack it properly and store under a good
environment.
(The packing is no needed when the device under appropriate
environment.)
Freight
Please use the original packing material when move the device. If the
packing material is missing, please use the equivalent buffer material to
pack and mark it fragile and waterproof etc to avoid the device damage
during movement. The device belongs to precise equipment, please uses
qualified transportation as possible. And avoid heavy hitting etc to
damage the device.
Maintenance
There is no maintenance operation for the general user. (Except for the
note in the manual.) Please contact our company or agent when the device
occurred the user judgment abnormal. Don’t maintain by yourself to avoid
occurred unnecessary danger and serious damage to the device.
Cleaning
Remove all connected wires and cables on the instrument before cleaning.
Use a brush gently to clean the dust on it. For internal cleaning, use a
low-pressure air gun to vacuum the dust inside or send it back to the
distributors or agents of Chroma for cleaning.

xi
Table of Contents
1. Introduction................................................................................1
1.1 An Overview of Function ..........................................................1
1.2 Specification (18ºC ∼28ºC RH ≤70%).....................................2
1.3 Standard Accessory..................................................................4
1.4 Optional Accessory...................................................................5
1.5 Initial Inspection........................................................................5
2. Operation and Setting...............................................................6
2.1 Front Panel ...............................................................................6
2.1.1 Display Area .......................................................................... 6
2.1.2 Button Area............................................................................ 7
2.1.3 Terminal Area ........................................................................8
2.2 Rear Panel................................................................................8
2.3 How to Perform Tests .............................................................12
3. Installation and Maintenance .................................................18
3.1 Notices for Installation ............................................................18
3.1.1 Charging During DC HiPot/Insulation Resistance Test .......20
3.1.2 Emergency Events ..............................................................21
3.1.3 Solving Problems ................................................................21
3.2 Notices for Maintenance.........................................................24
3.3 Troubleshooting ......................................................................24

HIPOT Tester 19071/19072/19073 Quick Start Guide
1
1. Introduction
1.1 An Overview of Function
■ This high quality automatic HiPot test instrument is designed to test the
withstanding leakage current and insulation resistance for electric
machinery and electronic devices.
■ For withstanding test, its output power is AC: 100VA (5kV, 20mA), DC:
30VA (6KV, 5mA), which is applicable to electronic, electric machinery
and components for withstanding and insulation tests.
■ For insulation resistance, its test range is from 0.1MΩ~50GΩ, and test
voltage is 0.050kV ~1kV definable.
■ For ground continue, its test range is from 0Ω∼5Ω.
■ For short/open detection, before testing high voltage test if the
capacitance is short or open circuit in advance. For ensure the DUT is
good contact then to perform high voltage test.
■ All settings for state, time, current, voltage and resistance can be seen
clearly on the display. There is no need to memorize the parameter
state of any items.
■ It is equipped with devices for Pass/Fail judgment, test results and
remote control.
■ It can perform high efficiency and accurate tests for electric machinery,
electronic devices and components.

HIPOT Tester 19071/19072/19073 Quick Start Guide
2
1.2 Specification (18ºC ∼28ºC RH ≤70%)
Withstanding Voltage Test
Test Voltage AC: 0.05∼5kV / DC: 0.05~6kV Constant
Voltage (19072, 19073 only)
Voltage Regulation ≤1%+5V, Rated Load
V-display Accuracy ± (1% of reading + 5 counts), 2V resolution
Cutoff Current
(Note1)
AC: 0.1mA ~ 20mA, DC: 0.01mA ~ 5mA
(Note1), 0.1uAdc resolution
± (1.5% of reading + 5 counts) (Note2)
WDC only
I-display Accuracy
0.1uA-299.9uA
0.3mA-2.999mA
3mA-20mA(5mAdc) ± (1.5% of reading + 5 counts) (Note2)
Output Frequency 50Hz, 60Hz
Test Time 0.1 ~ 999 Sec, continue (Note3)
Dwell Time 0.1 ~ 999 Sec, off
Ramp Time 0.1 ~ 999 Sec, off (0.1sec approx.)
Fall Time 0.1 ~ 999 Sec, off
Arc Detection
Setting Mode Programmable Setting
Detection Current AC: 1mA ~ 20mA, DC:1mA ~ 5mA
Min. pulse width 10us approx.
GOOD/NO-GO Judgment Function
Judgment System •Window comparator
•A NO-GO judgment is made when a
current greater than the high limit value
or smaller than the low limit value is
detected.
•When a NO-GO judgment is made, the
output voltage is cut out and a NO-GO
alarm signal is delivered.
•If no abnormal state is detected during
the test time a GOOD.
Judgment is made and a GOOD signal
is delivered.
Insulation Resistance Test (19073 only)
Test Voltage DC: 0.05kV ~ 1kV, Constant Voltage

HIPOT Tester 19071/19072/19073 Quick Start Guide
3
V-display Accuracy ± (5% of reading + 5 counts) (open voltage),
2V resolution
Resistance Range 0.1 MΩ∼50 GΩ(Note 4)
Measuring Accuracy ≥500V: 1MΩ∼1000MΩ: ± 4% + 5 counts
1GΩ∼10GΩ: ± 7% + 5 counts
10GΩ∼50GΩ: ± 12% + 5 counts
< 500V: 0.1 MΩ∼1000MΩ: ± 7% + 5 counts
< 100V: 0.1 MΩ∼1000MΩ: ± 10% + 5
counts
Secure Protection Function
Fast Output Cut-off Approx. 0.4mS, after NG happen
Fast Discharge Approx. 0.2S, Typical
Ground Fault Interrupt 0.5mA±0.25mAac(ON), OFF
Continuity Check 0.1Ω~5.0Ω± 0.2Ω, GC MODE
Panel Operation Lock YES
Memory Storage
Memories, Steps 10 steps or 60 groups for total 60 memory
location
GO/NG Judgment Window
Indication, Alarm GO: (Short Sound)
NG: W-Arc, W-Hi, W-Lo, IR-Lo, IR-Hi, GFI
(Long Sound)
Remote Connector
Rear Panel 9 Pin
D-type Connector
Input: Start, Stop, Interrupt
Output: Under test, Pass, Fail
TEST/RESET Control Low – active control, (24V open voltage
typical).
Input requirements
•Input time duration: 20msec. Approx.
The above input circuits are not
isolated from other internal circuits.
Options
RS-232 Interface Baud rate: 4800 ~ 19200, data bits: 8, stop
bit: 1
RS-485 Interface A maximum of 32 devices connected to
each bus.
Ambient Temperature and Relative Humidity
Specifications range 18 to 28°C (64 to 82°F), ≤70% RH.

HIPOT Tester 19071/19072/19073 Quick Start Guide
4
Operable range Maximum relative humidity 80% for
temperature up to 31°C (88°F).
Decreasing linearly to 50% relative
humidity at 40°C (104°F)
Altitude up to 2000m
Indoor use only.
Pollution degree 2
Storage range -10 to 60°C (-14 to 140°F), ≤80% RH.
Installation Category CAT II
Power Requirement
Line Voltage AC 100V, 120V, 220V ± 10%, 240V +5 -
10%
Frequency 50 or 60 Hz
Power No load: < 60W
Consumption With rated load: 300W max.
General
Dimension 270(W) x 105(H) x 350(D) mm
Weight Approx 12kg
Safety
Ground Bond Less than 100mΩat 25Amp, 3sec
Hipot Less than 10mA at 1.5kVac, 3sec
Insulation Resistance Over 100MΩat 500V 3sec
Line leakage current Less than 3.5mA at 127V, 3sec, normal,
reverse
Note 1: AC set over 75VA, DC set over 22.5VA the maximum operating time
is 60 seconds, and the same as rest time.
The period of rest time is 1/2 duty of operating time. For full rating
output, the line input range is +10% ∼-0%.
Note 2: Only refer to 1.2kV resistance load.
Note 3: IR test time is 0.3 sec ~ 999 sec.
Note 4: Display resistance range is up to 60GΩ.
1.3 Standard Accessory
Item Q’ty Description
USA-type power
cord 1 90°elbow USA-type power cord, length 1.8m

HIPOT Tester 19071/19072/19073 Quick Start Guide
5
Power adapter 1 USA-type power cord 3P – 2P adapter
HV terminal used
test cable 1 Alligator clip – cross HV head, red HV test cable, wire length 1m
LOW terminal used
test cable 1 Alligator clip – banana plug, black HV test cable, wire length 1.2m
Test cable of
grounding continue 1 Wire used in GC test, length 1.2m
3.15A fuse 2 For 3.15A SLOW 110VAC used
1.6A fuse 2 For 1.6A SLOW 240VAC used
Quick Start Guide 2 One English version and one Traditional
Chinese version.
User’s manual CD 1 CD for user’s manuals in English and
Traditional Chinese
1.4 Optional Accessory
Item Q’ty Description
RJ-45 twin head link cable 1 L: 450mm
RJ-45 twin head link cable 1 L: 1000mm
RJ-45 twin head link cable 1 L: 2000mm
RJ-45 twin head link cable 1 L: 4000mm
DB-9F single head link cable 1 L: 7000mm
Across HV head + HV cable 1 L: 2000mm
Black banana head + HV cable 1 L: 2000mm
Remark: Optional accessory is for link test model of 19073 + RS485.
1.5 Initial Inspection
Before shipment, this instrument was inspected and found to be free of
mechanical and electrical defects. As soon as the instrument is unpacked,
inspect for any damage that may have occurred in transit. Save all
packing materials in case that the instrument has to be returned. If
damage is found, please file claim with carrier immediately. Do not return
the instrument to Chroma without prior approval.

HIPOT Tester 19071/19072/19073 Quick Start Guide
2. Operation and Setting
2.1 Front Panel
The front panel is divided into several function areas. This section
explains each control and the information displays on LCD.
Button Area Button Area
Stop Button Display Area unction Key Display Area Function Keys
6
Power Switch Status Line Pass Indicator Test Status Indicator
Start Button Calibration Switch Fail Indicator Common Test Terminal
High Voltage Output Terminal
Terminal Area
2.1.1 Display Area
Function Key Display Area: Different function text appears in different
menu. The mapping function keys (F1-F4) are located at right. The
function key is invalid if the text is blank.
Status Line: This line shows the setting mode, value range, and test
results.
