Classic Exhibits SYMPHONY SYM-406B Manual

© 2023
Order #XXXXX
Locked layer contains
placeholder marks.
12
Counter Top Attachment
*
Align hole with pin. Rotate pin. Spring
will push pin into hole.
Back Panel Hole Placement
When assembled
When assembling counter, align holes
of back panel to vertical extrusion of
backwall frame.
Counter should be centered on backwall
frame when installed.
Holes on back panel of Counter are
off-center to attach to backwall vertical.
Back panel of
counter may be
rotated for either
left- or right-frame
configuration.
Backwall
vertical
Counter
Counter
Backwall
vertical
SYM-406B Backwall Counter
Steps:
1) Use screw caps to secure side panels to front & back panels. Ensure holes of back panel
are correctly aligned for backwall attachment.
2) Connect shelf supports with Velcro inside of panels, then place shelf on top of supports.
3) Attach Counter Top to assembled pedestal base. See Counter Top Attachment detail.
Back Panel
(with holes
for backwall
attachment)
EXAMPLE OF
VERTICAL WITH
LEFT OFSET
EXAMPLE OF
VERTICAL WITH
RIGHT OFSET
back
panel
back
panel
SYM-406B
back
panel Pedestal Top Attachment
Counter Top
**
Pedestal Base Assembly
Screw
Cap Screw
Cap
Side Panel
Shelf
Shelf Support
Shelf Support
Shelf Support
Shelf Support
Floor
Side Panel
NOTE: Remove pins for floor
from side panels when packing.
Front Panel
(with Door)
SYM-406B Portable Backwall Counter
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2023
Case 1 of 1
Order #XXXXX
Locked layer contains
placeholder marks.
Top View of Each Level
Level 1
(Bottom level)
Level 2 Level 3
Back Panel Front Panel
Floor
Shelf
Left &
Right
Side
Panels
Level 4 Level 5
Shelf
Supports
Standoffs
& Key
SYM-406B SYM-406B
Counter Top
Case Packing
