Classic Exhibits visionary DESIGNS MOD-1519 Manual

© 2023
Order #XXXXX
Locked layer contains
placeholder marks.
Completed Assembly
Item
1
2,3
2A,3A
4
5
Qty.
1
1,1
1,1
1
1
Description
Base Plate
36” Q914 Vertical Extrusion
36” Q914 Vertical Extrusion w/ Caps
28.835” Z45 Horizontal Extrusion
Mount Plate
Steps:
1) Attach base plate [1] to verticals [2] and [3], using bolts.
2) Attach verticals [2A] to [2] and [3A] to [3], using connector.
See Extrusion Connector detail.
3) Attach horizontal [4] between verticals [2A] and [3A].
4) Attach mount plate [5] and monitor mount. See
Monitor Mount Attachment detail.
5) Route monitor cord through conduit then attach to verticals
[2] and [2A]. See Cord Management detail.
2
1
Bolt
Bolt
3
5
4
2A
Monitor
Mount
3A
*
**Cord Management
Route cord through conduit.
Attach conduit by pinching
the opening and inserting
into the groove of extrusion.
pinch
Cord
Conduit
V15
Connector
Extrusion Connector
Slide upper extrusion
over connector and
rest on lower extrusion.
Secure with set screws.
*
To prevent product loss,
keep all screws attached
to connector after
disassembling.
Set Screw
*Monitor Mount Attachment
Attach mount plate to verticals. Attach monitor mount to
mounting plate, using bolts and wing nuts.
Mount Plate Wing
Nut
Bolt
Monitor Mount
MOD-1519 Monitor Stand
If you would like to tell us about your experience with your setup instructions please email us at [email protected]
SETUP INSTRUCTIONS

© 2023
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all set screws
and locks during disassembly.
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information

© 2023
Case 1 of 1
Order #XXXXX
Locked layer contains
placeholder marks.
Top View of Each Level
Setup Hardware
Level 1
(Bottom level)
Level 2 Level 3 Level 4
Monitor
Mount
1 2 2A 33A
4PR635
Case Packing
