CODELOCKS CL4500 User manual

Find more online at www.codelockssupport.com
Page 1
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
4.
5.
6.
CL4500 Getting Started Guide
About CL4500
This range of locks can be operated and managed directly via the
keypad or via a compatible smartphone by downloading the K3
Connect App. This guide contains the commonGetting Started
functions to enable you to quickly program your lock.
For detailed instructions, refer to the Programming & Operating
atInstructions www.codelockssupport.com.
The Basics
Master Code
The factory set Master Code is 12345678. This should be changed#
immediately after installation (Program 01). The Master Code (and
Sub-Master Code if set) always start with the button. This puts the#
lock in Programming Mode.
Access Methods
The lock supports a maximum of 350 Clients (users): User Codes
(100), User Cards (150) and User Compatible Phones (100).
Keypad
The lock has a 12 button, back-lit keypad which includes and butt* #
ons. The button is only used for programming. The * button is used#
in some Programs and with NetCodes.
Code Free
Code Free can be configured via Program 04 (refer to the Programmi
) or via by changing theng & Operating Instructions Key-in-Lever
cylinder tailpiece (refer to Installation Instructions).
Remote Release
The lock has two sets of terminals within the front housing for remote
release, labelled and . is intended forREM1 REM2 REM1
push-button release where the lock will open for the normal set time.
is intended for use where the lock needs to be released for aREM2
longer period. When a switch or relay connected to is closed,REM2
the lock will open for a period of 30 minutes after which the lock will
revert to normal operation.
Refer to for further information.Installation Instructions
The App
Manage with the K3 Connect App
The lock can be managed with the K3 Connect App by any Bluetooth
compatible smartphone.
The App is available on:
Apple App Store for Apple devices or Google Play™ for Android™
devices by searching for .K3 Connect
Install the K3 Connect App on your device.
Once installed, open K3 Connect and select Create
Account.
The account creation process includes email confirmation.
Once the account has been created, sign-in to the App.
To add a new lock, touch the icon on the screen.+ Locks
Enter the lock DIN and enter a name for your lock (we
recommend that you choose a meaningful name).
For this lock range the DIN is: CL4510.
The lock DIN is case-sensitive. The same DINNote:
(CL4510) to be used for all CL4500 variants i.e. CL4510 and
CL4520.
In the App, touch and then immediately, on the lock,
enter the following Program:
Master Code 00 1#• • ••
12345678 00 1Example: # • • ••
If you have changed your Master Code, substitute theNote:
code used in the example with your own code.
The lock will now pair with your phone.
For detailed instructions, refer to the Programming & Operating
atInstructions www.codelockssupport.com.
Factory Reset
The lock can be reset to its original factory settings. You may need to
do this if the Master Code is no longer known or you no longer have
management access via a smartphone. To reset the lock, you must
have access to the battery compartment in the rear of the lock.
Remove a battery.
Press and hold the button.0
Replace the battery whilst continuing to hold the button.0
After the double beep, release the button.0
Press the button three times.0
If successful the Blue LED's will burn for 7 seconds.
REGULATORY COMPLIANCE
The device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference, and This(1) (2)
device must accept any interference received, including interference
that may cause undesired operation.
This equipment has been tested and found to comply with the limits
for a Class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against
harmful interference in a residential installation.

Find more online at www.codelockssupport.com
Page 2
This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and
receiver.
Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for
help.
Apple, the Apple logo, and iPhone are trademarks of Apple Inc.,
registered in the U.S. and other countries. App Store is a service
mark of Apple Inc.
Android, Google Play and the Google Play logo are trademarks of
Google Inc.
Basic Programs
01 Change the Master Code
Note: The Master Code is 8 digits in length
Master Code 01 New Master Code New Master Code#• • • ••
12345678 01 87654321 87654321Example: # • • • ••
The Master Code has been changed to 87654321Result:
02 Change the Sub-Master Code
Note: The Sub-Master Code is 8 digits in length
Master Code 02 New Sub-Master Code New Sub-Master Code#• • •
•• 12345678 02 44556677 44556677Example: # • • • ••
The Sub-Master Code has been changed to 44556677Result:
03 Delete the Sub-Master Code
#Master Code 03• ••
12345678 03Example: # • ••
The Sub-Master Code has been deletedResult:
15.1 Lock-Down
Prevent the lock from being unlocked by any method except via
Master Code and Sub-Master Code:
#Master Code 15 1• • ••
12345678 15 1Example: # • • ••
Lock-Down is enabled. Only the Master and Sub-MasterResult:
Codes can be used to open the lock.
15.2 Cancel Lock-Down
Master Code 15 2#• • ••
12345678 15 2 Example: # • • ••
Lock-Down is cancelled.Result:
Clients (Users)
20.1 Add a Code Client
#Master Code 20 1 Code• • • ••
12345678 20 1 3366Example: # • • • ••
The Code 3366 can now be used to unlock the lock.Result:
20.2 Add a One-Time Code Client
#Master Code 20 2 Code• • • ••
12345678 20 2 7788Example: # • • • ••
The Code 7788 can be used to unlock the lock once only.Result:
20.3 Add a Smart Card Client
Note: After entering the program below, the lock will wait for a
MIFARE based smart card to be placed over the keypad.
Master Code 20 3#• • •• present MIFARE card
12345678 20 3Example: # • • •• present MIFARE card
The smart card will be able to unlock the lock.Result:
Up to 150 cards can be registered.Note:
21 Suspend a Code Client
#Master Code 21 Code• • ••
12345678 21 1199Example: # • • ••
The Code 1199 has been suspended.Result:
22 Restore a Code Client
#Master Code 22 Code• • ••
12345678 22 1199Example: # • • ••
The Code 1199 has been restored.Result:
Troubleshooting
Incorrect Code/Card
If 3 incorrect access attempts are made, the lock will suspend activity for 30 seconds.
Programming Error
If a programming mistake is made, the keypad will flash red and the lock will revert to normal operation.
Battery Failure
If the battery fails, the key-override should be used to open the lock. Batteries can be replaced by opening the battery cover on the rear of the
lock. Always use high-quality AA batteries and ensure that the batteries are inserted correctly. Please refer to local authority recommendations for
the disposal of old batteries.
