CommScope CMOD User manual

TECP-90-717 Rev C
© 2019 CommScope, Inc. Page 1 of 4
TECP-90-717
Rev C, August 2019
commscope.com
Installation
Instructions
Install the module on the rear of the universal chassis. Follow the numbered steps within the illustrations
below.
1. Pull out access tray handle.
2. Snap module down in five locations shown.
25208-B
ACCESS
TRAY
HANDLE
M
N
R
P
Q
U
V
T
O
3
1
2
5
W
X
4
M
N
O
P
Q
U
V
W
X
P
R
T
25209-A
END OF
ARM
GUIDE
CROSS
FRAME
TROUGH
INNER TRAY
CABLE GUIDE
3. Route fiber cable through inner tray cable
guide and end of arm guide.
4. Close the access tray.
Infrared radiation is
invisible and can seriously
damage the retina of the
eye. Do not look into the
ends of any optical fiber.
Do not look directly into
the optical adapters
of the adapter packs.
Danger:
!
NOTE: DO NOT INSTALL ADDITIONAL LABELS TO TOP OF MODULE.
INTERFERENCE MAY RESULT WITH ADJACENT TRAYS.
R
T
Q
U
V
P
R
T
R
T
NG4access ODF Platform Cabled Module (CMOD)

Page 2 of 4 © 2019 CommScope, Inc.
TECP-90-717
25210-A
UPPER
TRUMPET
FLARE
RADIUS
LIMITER
END OF
ARM
CABLE
GUIDE
REAR VIEW
(SOME SHEET
METAL REMOVED
FOR CLARITY)
5. If connecting on left side,
route as shown here.
CROSS
FRAME
TROUGH
ROUTE
UP OR
DOWN
OUTER
TRAY
CABLE
GUIDE
M
O
N
V
M
P
Q
R
T
U
w
X
J
H
I
K
L
A
C
B
D
E
F
G
25211-A
REAR VIEW
(SOME SHEET
METAL REMOVED
FOR CLARITY)
6. If connecting on
right side,
route as shown here.
OUTER
TRAY
CABLE
GUIDE
END OF
ARM
CABLE
GUIDE
X
W
V
U
T
S
R
Q
P
L
K
J
I
H
G
F
E
A
B
C
M
N
O
ROUTE
UP OR
DOWN
LOWER
TRUMPET
FLARE

TECP-90-717
© 2019 CommScope, Inc. Page 3 of 4
25216-A
8. If installing a C-MOD
with microcable routed
overhead, tie off
as shown using lance
points.
Start at inner most
points as shown.
Allow a drip loop
to form per
examples at right.
7. If installing a C-MOD with IFC, install a cable clamp as shown on the
cable clamp bracket. Start with the inner most positions and grow
outward. Assemble the clamp on cable and bracket in order shown.
Allow drip loop to form per
examples at right.
LANCE
POINTS
FORM
DRIP
LOOP
CABLE
CLAMP
COMPONENTS
(STACK IN
ORDER SHOWN)
CABLE
BRACKET
REAR VIEW
(SOME SHEET
METAL REMOVED
FOR CLARITY)
NOTE: FOR DRIP LOOP
ROUTING, REFER TO
LAMINATED CARDS
HANGING ON FRAME.
FORM
DRIP
LOOP

Page 4 of 4 © 2019 CommScope, Inc.
TECP-90-717
Technical Assistance
https://www.comscope.com/Support Center
SPLICE
CHASSIS
C-MOD
PIGTAILS
26969-A
9. If C-MOD has pigtails to be routed to the Splice Chassis, route as shown on the left below.
Refer also to TECP-90-704.
10. If C-MOD has IFC cable to be routed to underfloor clamp, route as shown on the right
below. Refer also to TECP-90-708.
11. For correct C-MOD cable routing with 120-inch and 76-inch breakouts from overhead, refe
r
to TECP-90-723 for the NG4-FR1000C1 frame or TECP-90-706 for the NG4-FR1000A1
frame.
PIGTAIL C-MODS TO SPLICE CHASSIS C-MODS WITH IFC TO UNDERFLOOR CLAMP
C-MOD
IFC
OSP
CABLE
C-MOD
IFC
