CommScope NG4access ODF Platform Value-Added Module User manual

300100105359 Rev D Page 1
This product is covered by one or more U.S.patents or their foreign equivalents. © 2019 CommScope.
For patents, see https://www.commscope.com/ProductPatent/ProductPatent.aspx All Rights Reserved.
Installation
Instructions
Installing a Single Height VAM
Install the module from the rear of the universal chassis (“left” module on left side, “right”
module on right side). Use the following procedure, referring to the illustration below.
1. Pull out the access tray handle.
2. Snap the module down in locations 1, 2, and 3, as shown in Figure 1, then squeeze the
module and access tray crossbar at location 4 and 5, as shown, until the module snaps in.
3. Slide in the access tray handle to close the access tray.
4. Connect cables to the module front ports and route the cables on the front of the frame per
instructions on laminated cards hanging on front of the frame (TECP-90-705).
Figure 1. Installing a Single Height VAM
Installing a Double or Triple Height VAM
Install the module from the rear of the universal chassis (“left” module on left side, “right”
module on right side). Use the following procedure, referring to the illustration below.
1. Identify the two or three trays where the double or triple high VAM is to be installed.
2. Remove the top one or two trays (see instruction video: https://youtu.be/xRx4xUo2fkA).
25239-A
1
4
ACCESS
TRAY
HANDLE
5
M
N
R
P
Q
U
V
W
X
T
O
3
2
TECP-90-720 •Rev D •December 2019
NG4access ODF Platform Value-Added Module (VAM)
All Front Access

TECP-90-720 • Rev D • December 2019
Page 2 Technical Support or Product Information
http://www.commscope.com/SupportCenter
3. Install clips between access tray doors referring to Figure 2.
Figure 2. Installing a Clip on an Access Tray Door
4. Snap the module down in locations 1, 2, and 3, as shown in Figure 3, then squeeze the
module and access tray crossbar at location 4 and 5, as shown, until the module snaps in.
5. Slide in the access tray handle to close the access tray.
6. Connect cables to the module front ports and route the cables on the front of the frame per
instructions on laminated cards hanging on front of the frame (TECP-90-705).
Figure 3. Installing a Double or Triple Height VAM
25614-A
ACCESS
TRAY
HANDLE
PRESS CLIP ON ACCESS
TRAY DOOR IN
ORIENTATION SHOWN
25612-A
1
4
ACCESS
TRAY
HANDLE
5
M
N
P
Q
U
V
W
X
T
O
3
2
A
F
G
I
J
K
L
H
E
