CommScope SYSTIMAX 360 iPatch 360-iP-1100-E-GS3-1U-24 User manual

SYSTIMAX®Solutions www.commscope.com
Instruction Sheet 860536390
Issue 3, November 2012
SYSTIMAX 360™iPatch®Panels Installation Instructions
© 2012 CommScope, Inc. All rights reserved
For RoHS Inquiries:
CommScope Inc.
Corke Abbey, Bray
Co. Dublin, Ireland
Attn: Legal Department
Page 1 of 3
General
These instructions describe how to install iPatch®SYSTIMAX 360™ PATCHMAX®panels, SYSTIMAX 360
Evolve modular panels (both flat and angled), and InstaPATCH QUATTRO panels to the iPatch panel bus. They
also describe how to connect these panels for use with the iPatch manager. The iPatch panels are SYSTIMAX®
approved products. The panels can be used in an iPatch System for both EIA-T568A and EIA-T568B wiring
applications.
Refer to the following instruction sheets for installing and cabling the specific panels:
•SYSTIMAX 360 PATCHMAX Panel Installation Instructions (860488808).
•SYSTIMAX 360 1100GS3 & 1100GS6 Evolve Modular Panel Instructions (860509967)
•SYSTIMAX 360 FTP Evolve Panel Instructions (860509975)
•SYSTIMAX InstaPATCH QUATTRO Modular Panel Instructions (860514066)
Ordering information is listed below:
Material ID Part No. Description
760152355 360-iP-1100-E-GS3-1U-24 360 iPatch 1100GS3 Evolve patch panel, 24-port
760152363 360-iP-1100-E-GS6-1U-24 360 iPatch 1100GS6 Evolve patch panel, 24-port
760152330 360-iP-1100-E-GS3-2U-48 360 iPatch 1100GS3 Evolve patch panel, 48-port
760152348 360-iP-1100-E-GS6-2U-48 360 iPatch 1100GS6 Evolve patch panel, 48-port
760152371 360-iP-M-E-HD6B-1U-24 360 iPatch FTP Evolve patch panel, 24-port
760152389 360-iP-M-E-HD6B-2U-48 360 iPatch FTP Evolve patch panel, 48-port
760158626 360-iP-1100A-E-GS3-1U-24 360 iPatch 1100GS3 Evolve angled patch panel, 24-port
760158634 360-iP-1100A-E-GS3-2U-48 360 iPatch 1100GS3 Evolve angled patch panel, 48-port
760158642 360-iP-1100A-E-GS6-1U-24 360 iPatch 1100GS6 Evolve angled patch panel, 24-port
760158659 360-iP-1100A-E-GS6-2U-48 360 iPatch 1100GS6 Evolve angled patch panel, 48-port
760158667 360-iP-MFTPA-E-HD6B-1U-24 360 iPatch FTP Evolve angled patch panel, 24-port
760158675 360-iP-MFTPA-E-HD6B-2U-48 360 iPatch FTP Evolve angled patch panel, 48-port
760123489 360-iP-PMAX-GS3-24 360 iPatch PATCHMAX GS3 panel, 24-port
760130393 360-iP-PMAX-GS6-24 360 iPatch PATCHMAX GS6 panel, 24-port
760123497 360-iP-PMAX-GS3-48 360 iPatch PATCHMAX GS3 panel, 48-port
760130401 360-iP-PMAX-GS6-48 360 iPatch PATCHMAX GS6 panel, 48-port
760161000 360-iP-INSTA-QTRO-24P 360 iPatch InstaPATCH QUATTRO panel, 24-port

860536390
Instruction Sheet www.commscope.com
Page 2 of 3
How to Contact Us
•To find out more about CommScope® products, visit us on the web at http://www.commscope.com/
•For technical assistance:
- Within the United States, contact your local account representative or technical support at
1-800-344-0223. Outside the United States, contact your local account representative or
Authorized Business Partner.
- Within the United States, report any missing/damaged parts or any other issues to
CommScope Customer Claims at 1-866-539-2795. Outside the United States, contact your
local account representative or Authorized Business Partner.
WARNING – Important Safety Instructions
•To reduce the risk of fire, electric shock, and injury to persons, read, understand, and adhere to the
following instructions as well as any warnings marked on the product.
•Remote risk of electric shock. Never install the product in wet locations or during lightning storms. Never
touch uninsulated communication wires or terminals.
•All wiring that connects to this equipment must meet applicable local and national building codes and
network wiring standards for communication cable.
•iPatch upgrade modules use infrared sensing technology and should be installed where they are not
exposed to direct sunlight or other infrared sources.
Save these instructions.
Overview
To prepare panels for use with an iPatch System, you must perform the following steps:
Step 1 – Mount a panel bus for the rack.
Step 2– Install an iPatch manager to supervise the rack.
Step 3– Connect each panel to the panel bus.
Step 4– Program the order of the panels in the rack.
Step 1 – Mount the Panel Bus
A panel bus must be installed on each rack where you plan to iPatch install panels. The panel bus allows
the iPatch Manager and iPatch panels to communicate. Also, the iPatch Manager supplies power to the
iPatch panels through the panel bus.
The panel bus must be installed to the left on the rack (viewed from the front). The preferred location is the
back corner of the rack’s left rail. The area where the panel bus will be mounted must be free of protrusions,
such as threaded inserts, nuts, and bolts.
To mount the panel bus on a rack other than a 7-foot (2.1m) rack or on a rack with a hole pattern other than
the universal hole pattern, contact your local account representative.
For instructions to install the panel bus for the rack, see the SYSTIMAX® iPatch System Panel Manager Guide
(860442573).

www.commscope.com
860536390
Issue 3, November 2012
Page 3 of 3
Step 2 – Install the iPatch Manager
An iPatch manager must be installed on each rack where you plan to install panels. The iPatch manager
supervises the iPatch panels in the rack and communicates with the iPatch System.
CommScope recommends mounting the panel manager in the 34th 1U slot up from the bottom of the rack so
that the top of the unit is about 65 inches (1.6m) above the floor. For instructions to install and configure the
panel manager, see the SYSTIMAX iPatch System Panel Manager Guide (860442573)
Step 3 – Connect Panels to the Panel Bus
To connect each panel to the panel bus, perform the following steps:
1. Position a cable retainer on the panel bus jumper
as shown (Figure 1) and remove the adhesive
backing from the cable retainer.
2. Connect the panel bus jumper to the nearest
connector on the panel bus, folding the jumper
as shown (Figure 2). Press the cable retainer
against the rack.
Note: The connector is keyed. The polarized tab
on the jumper connector fits into the
opening in the header connector on the
panel bus.
Important: For 48-port panels, connect both
panel bus jumpers.
Step 4 – Program the Order of Panels
To complete the installation, restore power to the panel manager for the rack and program the order of the
panels. For instructions, see the SYSTIMAX iPatch System Panel Manager Guide (860442573).
Figure 2.
Figure 1.
