CONVECTAIR SOPRANO Installation guide

Installation,
Operating Instructions &
Warranty Registration
( IMPORTANT : To be read and kept by the user )
SOPRANO
7808
421AA2273

1 - SPECIFICATIONS...............................................................
2 - PLANNING THE INSTALLATION..........................................
3 - INSTALLATION..................................................................
4 - WIRING............................................................................
5 - OPERATION......................................................................
6- MAINTENANCE.................................................................
7- PREVENTION.....................................................................
8 - THERMAL SAFETY CUT-OUT...............................................
9 - IF YOUR SOPRANO DOES NOT WORK..............................
10 - WARRANTY.....................................................................
Page 4
Page 4
Page 5
Page 5
Page 6
Page 6
Page 7
Page 7
Page 7
Page 9
SummarySummary

4
SpecificationsSpecifications
11
The Soprano is a compact, discreet and efficient unit that may be used in any room in
the house. During the installation, the Soprano allows you to select a wattage, either
750W or 1500W. It is also available in two models to suit your requirements: 120V or
240V. The Soprano’s control (sold separately) can, be a timer, a thermostat or even a
wall switch.
The unit must be connected to a 240V or 120V circuit, 60Hz depending on the model.
Disconnect the power supply before making the wiring conncetions.
CONVECTAIR recommendes that the Soprano be installed by a qualified electrician,
in accordance with national codes, local authority having jurisdiction.
- Determine the location where the Soprano is to be installed, ensure there are no
restrictions fot the minimum clearance permitted (Fig. 1).
- The eletrical connexion for the Soprano shall be made in a rec tangular box that has
been pre-installed in the wall. The junction box shall be of appropriate dimensions to
3/4” 1/2”
accomodate the cables and the supplied cover 2 x 4 (7cm x 11.5cm).
The unit must be connected to a 240V or 120V circuit, 60Hz depending on the model.
Disconnect the power supply before making the wiring conncetions.
CONVECTAIR recommendes that the Soprano be installed by a qualified electrician,
in accordance with national codes, local authority having jurisdiction.
CAUTION : DO NOT INSTALL BOTTOM AT LESS THAN 72” (180 cm) FROM THE
FLOOR, SIDES AT LESS THAN 4” (10cm) FROM ANY SURFACES MAINTAIN A 20”
(50 cm) FRONT CLEARANCE.
CAUTION : DO NOT INSTALL BOTTOM AT LESS THAN 72” (180 cm) FROM THE
FLOOR, SIDES AT LESS THAN 4” (10cm) FROM ANY SURFACES MAINTAIN A 20”
(50 cm) FRONT CLEARANCE.
WE THANK YOU FOR YOUR PURCHASE OF THIS EXCELLENT CONVECTAIR PRODUCT. WE THANK YOU FOR YOUR PURCHASE OF THIS EXCELLENT CONVECTAIR PRODUCT.
Planning the installationPlanning the installation
22

20/5 cm
” 0
3012”/ cm
”/cm8
20
”
72 / 180cm
4”
01cm
A
ab tteT le
Rep. 1
B
C
73.2”/ 183 cm minimum
Figure 1
A = 4.96”/12,4cm
B = 3.92” / 9,8cm
C = 4.84”/12,1cm
33
InstallationInstallation
- Free mounting bracket by pressing
ans pulling both locking brackets.
- Relocate the mounting bracket to
match the marks with the holes for
the bottom fasteners.
- Check horizontality of the mounting
bracket then mark and pierce the 4
holes for fastening.
- Replace mounting bracket and
fasten it with screws and anchors if
appropriate.
44 WiringWiring
- Two wattage configurations are possible for the Soprano.
Layout 750W :
- From the junction box connect the ground wire (copper) to the unit’s green wire, use
wire connectors (not included).
- Wire the unit following the recommandations as shown on the wiring diagrams
below :
- Carefully place wires in the junction box and screw on the cover.
- Place the Soprano against the wall and lock in position. Secure to wall bracket
before using.
Layout 750W :
CAUTION : DO NOT INSTALL HEATHER OVER A BATHTUB OR OTHER
CONTAINER. DO NOT USE IN AREAS WHERE GASOLINE, PAINT, OR FLAMMABLE
LIQUIDS ARE USED OR STORED.
CAUTION : DO NOT INSTALL HEATHER OVER A BATHTUB OR OTHER
CONTAINER. DO NOT USE IN AREAS WHERE GASOLINE, PAINT, OR FLAMMABLE
LIQUIDS ARE USED OR STORED.
APPAREIL APPAREIL APPAREIL
R R R
P = PURPLE R = RED B = BLACK G = GREEN C = COPPER W = WHITE
W R W
P P P
BBB
120 V CANADA / USA
BBB
GGG
C C C
MUR MUR MUR
240 V CANADA ONLY 240 V USA ONLY
5

Layout 1500W :
- From the junction box connect the ground wire (copper) to the unit’s green wire, use
wire connectors (not included).
- Wire the unit following the recommandations as shown on the wiring diagrams
below :
- Carefully place wires in the junction box and screw on the cover.
- Place the Soprano against the wall and lock in position. Secure to wall bracket
before using.
Layout 1500W :
APPAREIL APPAREIL APPAREIL
R R R
P = PURPLE R = RED B = BLACK G = GREEN C = CUIVRE W = WHITE
W R W
P P P
BBB
120 V CANADA / USA
BBB
G G G
C C C
MUR MUR MUR
240 V CANADA ONLY 240 V USA ONLY
OperationOperation
55
The operation could vary depending on the type of controls used. Plaese consult the
control operation manual for complete details.
To keep your unit clean, regular maintenance is suggested. To remove dust, use a soft
cloth. To remove a stain, use a damp cloth. Never use abrasive products which could
damage the finish.
Warning : in certains cases, the grille may become yellow after a while. This pheno-
mene is not due to a manufacturing defect. It is caused by smoke or suspende parti-
cles present in the surrounding air, heated and blown out through the grille. This colo-
ration can be reduced by cleaning the grille on a weekly basis.
MaintenanceMaintenance
66
CAUTION : ALWAYS DISCONNECT POWER TO THE UNIT BEFORE OPENING.CAUTION : ALWAYS DISCONNECT POWER TO THE UNIT BEFORE OPENING.
6

PreventionPrevention
77
It is recommended to frequently clean the air intake at the rear of the unit espacially in
areas where smoke and dust are present. Never use this heater during contruction or
other activities that generate high amounts of dust particles.
During the first time operation of the unit, it is possible that a slight odour and smoke
are expelled from your Soprano. This phenomen is normal and shall cease after a few
minutes of use.
- The Soprano is equipped with a safety cut-out which shuts off the fan and the hea-
ting element in case of overheating. To reset the safety cut out :
1- Shut the power of the heater off.
2- Check the heater for blockage, covering or dust and correct.
3- Wait 5 minutes; turn the power on and start the heater to check that it operates
propertly.
CAUTION : THIS HEATER IS HOT WHEN IN USE. TO AVOID BURNS, DO NOT
LET BRAKE SKIN TOUCH HOT SURFACES.
CAUTION : THIS HEATER IS HOT WHEN IN USE. TO AVOID BURNS, DO NOT
LET BRAKE SKIN TOUCH HOT SURFACES.
Thermal safety cut-outThermal safety cut-out
88
If your Soprano does not workIf your Soprano does not work
99
Prior to calling an electrician, please perform the following tests :
1- Ensure that the circuit breaher (in the main circuit box) is in the “ON” position.
2- Make sure that your timer, thermostat oer switch (not included) are in the “ON”
position.
3- Adjust the thermostat (not included) to the maximum power level.
4- If after all these tests, the unit does not work, shut power “OFF” and wait 5 minutes,
then repeat steps 1 to 3. If the unit is still non-functional, contact your eletrician or
CONVECTAIR.
After a while, the unit may shut off even if the heater is not clogged up. In such case,
the unit may require internal cleaning. Please contact one of our repair centers or call
CONVECTAIR.
7

REPAIR CENTERS : To find your nearest repair center please call CONVECTAIR.
Montréal : ( 450 ) 433-5701
Toll-free from Canade and USA : 1-800-463-6478
Fax : [phone]
Email : [e-mail]
Web : www.convecteair.ca
REPAIR CENTERS :
Montréal :
Toll-free from Canade and USA :
Fax :
Email :
Web :
30, Carré Sicard, Sainte-Thérèse (Québec) CANADA J7E 3X6
Phone: [phone] Fax : [phone]
Email : [e-mail] Web : http://www.convectair.ca
WarrantyWarranty
1010
2 YEARS against all defects / 5 YEARS on heating elements.
All CONVECTAIR units are subject to a double warranty : 2 years on all parts and
manufacturing defects and 5 years on the heating elements themselves.
Warranty is applicable from date of purchase by the customer and under certain
specific conditions.
All details furnished with each unit. Please keep your invoice (purchase or installation).
2 YEARS against all defects / 5 YEARS on heating elements.
