Converters.TV View 2000 EX User manual

PC VGA to TV Video Converter -
View 2000 EX ID# 518
Operation Manual

Introduction
PC VGA to TV Video Converter - View 2000 EX is a hand sized
universal VGA to TV converter box. t is ideal for viewing PC games,
PC DVD, or the internet on any standard TV. t supports Resolutions up
to 1024x768 (XGA), and also allows you to record PC images on
VCR/CD/DVD.
t is powered from the USB port of your computer, and is very easy to
use. The PC VGA to TV Video Converter - View 2000 EX features a set
of 5 switches used to select the TV (Video) system output. This allows
the correct video standard to be output to your TV.
Features
1. Plug and Display Hardware design. No software required.
2. OSD menu for PC control and operation.
3. Switchable NTSC, PAL and Secam video s stem.
4. Supports Composite Video, S-Video RGB/Y.Cb.Cr output.
5. Supports all Interlace Formats of Y/Cb/Cr, YUV & Y/Pb/Pr
6. Supports Zoom, Size and Menu control buttons.
7. Menu supports H & V scale, Brightness, Contrast, Hue, Saturation,
Sharpness and OSD Background.
8. Simultaneous displa to PC monitor and Standard TV.
9. Independent Hor. & Vert. Size adjustment plus programmable 2D
scaling.
10. 24 bit True Color digitiser.
esolutions
Supported
•VGA Mode: 640x480 (VHz=60,72,75,85); 800x600
(VHz=56,60,72,75,85); 1024x768 (VHz=60,70,72,75).
•VGA Mode ZOOM: 640x480 (VHz=60,72,75,85); 800x600
(VHz=56,60,72,75); 1024x768 (VHz=60).
•VGA Mode SIZE (NTSC, NTSC-EIAJ, PAL-M): 640x480
(VHz=60,72,75,85); 800x600 (VHz=56,60,72,75); 1024x768
(VHz=60,70,72,75).
•VGA Mode SIZE (PAL, PAL-N, PAL-Combination-N &
SECAM): 800x600 (VHz=56,60,72,75); 1024x768
(VHz=60,70,72,75).
•MAC Display Mode: 640x480 (VHz=66); 832x624 (VHz=75).

Connectors
VIDEO OUT : Connects PC VGA to TV Video Converter - View 2000 EX
to the VIDEO
input of TV/VCR or Video Projector.
S-VIDEO OUT: Connects PC VGA to TV Video Converter - View 2000 EX
to your TV/VCR /Video Projector supporting the S-VIDEO input.
RGB/Y.Cb.Cr OUT: Connects PC VGA to TV Video Converter - View
2000 EX to the VIDEO input of TV/VCR or Video Projector.
SCAN CNVTR: Connects H c ble to PC, PC VGA to TV Video Converter
- View 2000 EX nd monitor.
DC IN : Plug with power c ble (USB or PS/2 type).
Buttons &
Switches
•SIZE: Switch between UNDERSCAN nd OVERSCAN.
•ZOOM:Toggle between Zoom nd Norm l displ y.
•MENU: Press button to c clicall activate the functions. The functions
are HSCALE,VSCALE, BRIGHTNESS, CONTRAST, HUE,
SATURATION,SHARPNESS & OSD BACKGROUND.
•↓: Press the MENU button then press “↓” to select the function in
the menu.
•↑: Press the MENU button then press “↑” to select the function in
the menu.
•← : Select the function then press “←” to decrease the level.
•→ : Select the function then press “→” to increase the level.
• TV system switch Selects the desired video standard output.

Installation
The PC VGA to TV Video Converter - View 2000 EX is a "Plug and Displa "
video converter. The onl requirement to get the output of the computer on
the TV is to make the proper connections & ensure that our computer displa
is set within the supported parameters. Please read the following sections
carefull for the installation of the hardware. Please refer to the image below and
overview of the process.

IMPORTANT We highly recommend you to comply with the steps of
installation otherwise it will cause you much inconvenience.
1. M ke sure your computer's (l ptop, notebook or desktop PC) power is
turned Off.
2. Connect PC VGA to TV Video Converter - View 2000 EX to your TV -
VCR or Video Projector supporting the Video Input.
Note : PC VGA to TV Video Converter - View 2000 EX also supports high
qualit S-OUT connector and RGB OUT connector. If our TV or VCR
support S-VIDEO IN or RGB VIDEO IN, we highl recommended ou to use
it to get the best TV picture.
3. Connect H c ble to PC, PC VGA to TV Video Converter - View 2000
EX nd monitor.
3. Power on your PC.
4. Connect the USB or PS/2 power c ble to "DC IN" of the converter.
5. Turn on your TV/VCR/Projector or Monitor to get the picture on them.
Specifications:
•Video Type: NTSC, PAL & SECAM (via RGB out)
•Video Outputs: Composite Video, S-Video and RGB/Y.Cb.Cr
•Video Output Connections: Composite RCA socket (female), S-
Video 4 pin mini-din (female), RGB/Y.Cb.Cr 15 pin D-sub
(female).
•PC Input: 15 pin D-sub (female)
•Power Supply: PC USB port 5vDC suppl .
•Dimensions: 10cm (w), 6cm (d), 2.8cm (h)
•Weight: 0.085gms
