Copernicus RC200 User manual

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
1
Premium Royal® Reading Writing Center
Basic Reading Writing Center
RC200
RC201
Assembly Guide
Check out our other products online at www.copernicused.com
For assistance, please contact us by telephone at 1-800-267-8494 or email at [e-mail].
Have your packing slip ready for reference.
Basic Reading Writing Center
(RC201)
®
Premium Royal Reading Writing Center
(RC200)
Frame Box 1 (RC200-0) x1
Tub Pack (RC200-CB) x1
Frame Box 1 (RC200-0) x1
Frame Box 2 (RC200-1) x1
Tub Pack (RC200-CB) x2
Please Recycle

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
2
We do not inherit the earth
from our ancestors, we
borrow it from our children.
- NATIVE AMERICAN PROVERB
Change is the end result of all
true learning.
- LEO BUSCAGLIA
What you leave behind is not
what is engraved in stone
monuments, but what is
woven into the lives of others.
- PERICLES
Education is the most
powerful weapon which you
can use to change the world.
- NELSON MANDELA
Need Support?
Have a Question?
Email Customer Service www.copernicused.com
Check out some of our
other great products!
For missing parts and other issues regarding your product:
Please contact Customer Service, where we will be happy to help.
Telephone: [phone], Monday - Friday 8:00am - 4:30 pm EST
Email: [e-mail]
Register your Product
Registering your warranty ensures we have all the information we need to make any future warranty claims quick
and easy. Please visit and complete the form within 10 business days from product www.copernicused.com/warranty
assembly. By registering your product, you will be entered into a draw to win Copernicus product.
Make a Warranty Claim
We offer a Lifetime Warranty on almost everything we make. Please call or email 1-800-267-8494
[email protected]om to start your warranty claim. Proof of purchase will be required upon warranty claim (i.e.
copy of invoice).
Replace your Whiteboard
Have a well-used whiteboard that needs replacing? Our whiteboards carry a five-year warranty and replacement
parts program after the warranty period. Please call 1-800-267-8494 or email [email protected]om to get a new
whiteboard for your Copernicus product!
Lifetime
Frame & Tub
Warranty
Customer Service & Warranty Information
Dear Educator,
Thank you for purchasing the . We hope it meets your expectations and you and your students Reading Writing Center
enjoy using it at your school.
Every day we see and hear stories of teachers going above and beyond to help students thrive. Thank you so much for all
you do – you are awesome, and you make a difference.
Thank you for inspiring us.
If you have any questions, concerns or ideas on how we can improve please let us know by contacting our Customer
Solutions Ninjas at 1-800-267-8494 or [email protected].
Happy teaching,
Kaylyn Belcourt, President
[e-mail]
5 Year
Whiteboard
Warranty

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
3
Tips for Assembly
Before You Begin:
ŸLay out and identify all of the included parts.
Ÿaccording to step.The hardware has been packed
ŸRead the assembly guide over once to familiarize yourself with them.
As You Assemble the Unit:
ŸFollow the steps in sequence.
ŸBefore beginning each step, find the part(s) that you need for that step.
ŸThe title of each step states what you will be doing. Review the text and
the pictures as you build the unit.
Please read the warnings below for important safety information regarding your product. Failure to read these
warnings or to follow the instructions below could result in personal injury or damage to your product that could
void your warranty.
Indoor Use
Only
This product is intended for indoor comercial use only. To reduce the risk of fire or electric
shock, do not expose this product to rain or moisture. The internal components are not
sealed from the environment.
In its unassembled state, this product contains parts that can be hazardous to small children.
This product should be assembled by an adult.
Small Parts
This product is to be used under the supervision of an adult.
Adult
Supervision
Do not climb on, hang from or suspend objects from any components of your product
unless otherwise specified.
Climb
Hazard
Important Information! Warning!
The symbol denotes a
step needing extra
attention to ensure it is
done correctly.
Watch for These Helpful Symbols:
For safety, please have
someone help you when
working on steps
displaying this symbol.
2-Person Task

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
4
RC200-0
Before beginning, you should have:
Additional tools required:
Parts for RC201
RC201
3” Twin Wheel
Locking Caster
4x
Long Stretcher
(718mm)
4x
Ultra Safe Book Ledge
1x
Short Stretcher
(635mm)
2x
Magnetic Marker
Holder
1x
Tub Rack
2x
Chart Paper Peg Hook
2x
Chart Paper Loop
Hook
2x
Whiteboard Frame
1x
Top Tube
2x
Wire Tub Channel
4x
Bottom Frame
(Left)
2x
Bottom Frame
(Right)
2x
Inside
Frame Riser
2x
RC200-CB
Chart Paper Hang
Tags
20x
Open Tub
3x
(CC4068)
Small Tub
2x
(CC4070)
5 lbs Weight Limit10 lbs Weight Limit
Hardware
Actual Size
Tools
(Not to Scale)
M6 x 40mm Screw
12x
A
7mm
Hex Wrench
1x
4mm Allen Key
1x
3mm Allen Key
1x
M4 x 19mm Shoulder Bolt
4x
M6 Lock
Washer
12x
M4 Lock
Nut
4x
Fast Lead Screw 15mm
8x
M6 Barrel Nut
8x
M8 Lock
Washer
8x
C
D
EF
G
B
Adjustable Wrench 1x Rubber Mallet 1x
+
OR 10mm Wrench 1x

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
5
Before beginning, you should have:
Parts for RC200
RC200
RC200-0
Additional tools required:
RC200-CB
Chart Paper Hang
Tags
20x
Open Tub
3x
(CC4068)
Small Tub
2x
(CC4070)
5 lbs Weight Limit10 lbs Weight Limit
3” Twin Wheel
Locking Caster
4x
Long Stretcher
(718mm)
4x
Ultra Safe Book Ledge
1x
Short Stretcher
(635mm)
2x
Magnetic Marker
Holder
1x
Tub Rack
2x
Chart Paper Peg Hook
2x
Chart Paper Loop
Hook
2x
Whiteboard Frame
1x
Top Tube
2x
Wire Tub Channel
4x
Bottom Frame
(Left)
2x
Bottom Frame
(Right)
2x
Inside
Frame Riser
2x
RC200-1
RC200-CB
Chart Paper Hang
Tags
20x
Open Tub
3x
(CC4068)
Small Tub
2x
(CC4070)
5 lbs Weight Limit10 lbs Weight Limit
Shelf Assembly
1x
Book Folder
(Small)
2x
Back Wire Rods
4x
Tiny Tub
6x
Tub Rack
2x
Magnetic Marker
Holder
1x
Book Folder
(Large)
1x
Inside
Hardware
Actual Size
M6 x 30mm Screw
4x
M4 Lock
Nut
4x
M6 Lock
Nut
4x
M4 x19mm Shoulder
Bolt
4x
Hardware
Actual Size
Tools
(Not to Scale)
M6 x 40mm Screw
12x
A
M4 x 19mm Shoulder Bolt
4x
M6 Lock
Washer
12x
M4 Lock
Nut
4x
Fast Lead Screw 15mm
8x
M6 Barrel Nut
8x
M8 Lock
Washer
8x
C
D
EF
G
B
H
C
I G
Adjustable Wrench 1x Rubber Mallet 1x
+
OR 10mm Wrench 1x
7mm
Hex Wrench
1x
4mm Allen Key
1x
3mm Allen Key
1x

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
6
In case your wedge nut becomes dislodged from the connector, follow these steps to reinstall.
To help keep the wedge nut in place, do not remove the paper cover until you are ready to
assemble the connector.
1 2
1
You will need: (Not to Scale)
Actual Size:
Build Two Bottom Frames
Bottom Frame
(Left)
2x
Bottom Frame
(Right)
2x
4x
A
4x
Long Stretcher
(718mm)
2x
F
(Left)
(Right)
A
F
A
F
F
A
F
A
Screws face
toward stretchers
Connectors
face inward
Side View
4mm Allen Key
1x

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
7
2
You will need: (Not to Scale)
Actual Size:
Attach Wire Tub Channels
Wire Tub Channels
4x
8x 8x
E
E
E
E
E
E
E
E
DE
D
D
D
D
D
D
D
D
3
You will need: (Not to Scale)
Actual Size:
Install Short Stretchers
A A
AA
Short Stretcher (635mm)
2x
4x
A
4x
F
F
F
F
F
Connectors
face inward
4mm Allen Key
1x
4mm Allen Key
1x
Connectors
face inward

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
8
4
You will need: (Not to Scale)
Actual Size:
Whiteboard Frame
1x
Frame Riser
2x
1Attach Whiteboard Frame 2Attach Frame Risers
4x
Holes
face
inward
B
BB
BB
Remove paper
wrap from these
connectors (4x)
Use Hardware From
Step #5 Hardware Bag
4mm Allen Key
1x
Install Back Wire Rods
5
Back Wire Rods
4x
1
2
3
4
You will need: (Not to Scale)
Gently move apart
to fit wire rods inside
RC200
Only
For easier installation
start with bottom hole
and go upward
Rubber Mallet
1x
ATTENTION:
Wedge nuts move
when tapping in
the frame
!

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
9
You will need: (Not to Scale)
Attach Top Tubes
Top Tube
2x
B
BB
B
Check for wedge
nut inside all
connectors
See page #6 for details
6
Actual Size:
4x
B
These holes
face inward
4mm Allen Key
1x
Rubber Mallet
1x
Remove paper
wrap from these
connectors (4x)
7
You will need: (Not to Scale)
Actual Size:
Install Long Stretchers
Long Stretcher
2x
4x
A
4x
A
A
A
A
F
FF
F
F
4mm Allen Key
1x
Use Hardware From
Step #8 Hardware Bag

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
10
9
You will need: (Not to Scale)
Actual Size:
Attach Shelf Assembly
Shelf Assembly
1x
4x
4x
2-Person Task
RC200
Only
H I
H
I
H
I I
H
I
H
4mm Allen Key
1x
Adjustable Wrench
(or 10mm Wrench)
1x
3” Twin Wheel Locking Caster
4x
Install Casters
8
You will need: (Not to Scale)
Make sure the casters are
locked before standing unit up
!
If you cannot push the casters in
by hand, try placing an adjustable
wrench between caster wheels and
then tapping with a rubber mallet.
!

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
11
Install Book Folders
10
You will need: (Not to Scale)
Book Folder
(Largel)
1x
1
2
3
Book Folder
(Large) Book Folder
(Small)
Book Folder
(Small)
Install in the following order:
RC200
Only
11
You will need: (Not to Scale)
Actual Size:
Install Tub Racks
Middle wire faces down
OR
OR
4x 4x
Tub Rack
2x
CG
Stagger tub stop hardware like
shown above
C
G
C
G
C
G G
C
!Do not over tighten
Hardware or Tub Racks
will not slide easily
Book Folder
(Small)
2x
3mm Allen Key
1x
7mm Hex Wrench
1x

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
12
12
You will need: (Not to Scale)
Actual Size:
Installing Additional Tub Racks
(RC200 Only)
Middle wire faces down
RC200
Only
Stagger tub stop hardware like
shown above
C
G
C
G
C
G G
C
4x 4x
CG
Tub Rack
2x !Do not over tighten
Hardware or Tub Racks
will not slide easily
3mm Allen Key
1x
7mm Hex Wrench
1x
Install Tubs
13
You will need: (Not to Scale)
Small Tub
2x 5 lbs Weight Limit
Open Tub
3x 10 lbs Weight Limit
Small Tub
4x 5 lbs Weight Limit
Open Tub
6x 10 lbs Weight Limit
OR
RC201 RC200
RC201 RC200

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
13
Install Magnetic Tub Holder
14
You will need: (Not to Scale)
OR
RC201 RC200
RC201 RC200
Magnetic Marker
Holder
1x
Magnetic Marker
Holder
2x
15
You will need: (Not to Scale)
Ultra Safe Book Ledge
1x
Install Book Ledge
Pull out spring loaded
hooks to install into hole

RC200, RC201 - Version B - Released October 6, 2022 - Copernicus Educational Products Inc.
14
Install Chart Paper Hooks
16
You will need: (Not to Scale)
Chart Paper Peg
Hook
2x
Chart Paper Loop
Hook
2x
17
You will need: (Not to Scale)
Installs Chart Paper Hang Tags
Chart Paper Hang
Tags
20x
OR
RC201 RC200
Chart Paper Hang
Tags
40x
Remove Backing From Hang Tags
1Press Hang Tags on Chart Paper (not included)
2
Use First Completed Chart Paper
as Positioning Template For the Rest
3Hang Chart Paper on Chart Paper Peg Hooks
4
Make sure the hang tags are spaced
evenly from center of chart paper.
