COUGAR MX410-T Guide

FEATURES
Assembly Drawing
Power button / RGB control button
AG2.5" HDD/SSD drive bay
USB 3.0 / USB 2.0 / HD audio ports
BHAir filter for top panel
CFront panel IAir filter for bottom panel
DTempered Glass side panel 3 x 120mm fans for front panel (optional)
J
ERight side panel K2 x 120mm fans for top panel (optional)
Specifications might vary depending on the country or region of sale.
*Please choose either of front or top to install a 240mm radiator.
Installing the Front I/O Connectors
Stylish Dual RGB Strips
MX410-T integrates RGB lighting strips and air vents at the front panel. It brings you more
stylish design and more RGB lighting effects.
Elegant Design with Massive Tempered Glass Left Panel
With the full-length PSU cover hides cables and a massive tempered glass left panel presents
a clean and tidy build, you can easily build a pro-level system.
Wider but More Compact and Powerful
MX410-Tʼs 210mm width allows much larger interior space with better cooling performance
and cable management. However, its compact exterior dimension takes up less desktop space.
MX410-T can surely fit a full-sized ATX Motherboard, 300mm-length Graphic card, three
2.5” SSDs, and two 3.5”HDDs, which allow you to achieve the extreme operation and abundant
storage space.
Strong Cooling Performance
MX410-Tʼs interior space supports up to 165mm height CPU air cooler, a 240mm water cooling
radiator, and high-end cooling components. It helps you to protect critical components from
overheating.
MX410-T
F3.5" HDD cage L120mm fan for rear panel (1 RGB fan pre-installed)
• Dual RGB strips at the front panel with variant RGB lighting modes
• Elegant design with massive tempered glass left panel
• Support for up to six fans and a 240mm radiator
• Support for up to 300mm long graphics cards
• Support for two 3.5" HDDs and three 2.5" SSDs
ENGLISH
• Zwei RGB-Streifen an der Vorderseite mit verschiedenen
RGB-Beleuchtungsmodi
• Elegantes Design mit linker Abdeckung aus massivem gehärtetem Glas
• Unterstützt bis zu sechs Lüfter und einen 240-mm-Kühlkörper
• Unterstützt Grafikkarten mit einer Länge von bis zu 300 mm
• Unterstützt zwei 3,5 Zoll-Festplatten und drei 2,5 Zoll-SSDs
DEUTSCH
• Tiras RGB dobles en el panel frontal con varios modos de iluminación RGB
• Diseño elegante con panel izquierdo de vidrio templado
• Soporta hasta seis ventiladores y un radiador de 240mm
• Soporte para tarjetas gráficas de hasta 300mm de largo
• Soporte para dos HDD de 3.5" y tres SSD de 2.5"
ESPAÑOL
• Podwójne paski RGB na panelu przednim z różnymi trybami
oświetlenia RGB
• Elegancki wygląd dzięki lewej pokrywie z litego szkła hartowanego
• Obsługa maksymalnie 6 wentylatorów i radiatora do 240 mm
• Możliwość montażu kart graficznych o długości do 300 mm
• Obsługa dwóch dysków twardych 3,5" i trzy SSD 2,5"
POLISH
• Duas barras de LED RGB no painel frontal
• Design elegante com painel lateral esquerdo em vidro temperado
• Suporta até 6 ventoinhas e radiador de 240mm
• Suporta placas gráficas de até 300mm
• Suporta até 2 HDDs de 3.5" e 3 SSDs de 2.5"
PORTUGUÊS
РУССКИЙ
• Двойные полосы RGB на передней панели с различными
режимами подсветки RGB
• Элегантный дизайн с массивной левой панелью из закаленного
стекла
• Поддержка до шести вентиляторов и 240-мм радиатора
• Поддержка видеокарт длиной до 300 мм
• Поддержка двух 3.5-дюймовых жестких дисков и трех
2.5-дюймовых SSD
• Deux bandes RVB sur le panneau avant avec différents modes d'éclairage
RVB
• Conception élégante avec un capot gauche en verre trempé massif
• Prend en charge jusqu'à 6 ventilateurs et un radiateur de 240 mm
• Prend en charge les cartes graphiques jusqu'à 300 mm de longueur
• Prise en charge de deux disques durs 3,5" et trois SSD 2,5"
FRANÇAIS
• 前面板双RGB灯条预设多种灯效模式
• 高雅设计与全透钢化玻璃左侧盖
• 最高可支援6个风扇与240mm的水冷散热器
• 支援长达300mm的显示卡
• 支持2个3.5" HDD硬盘与3个2.5" SSD硬盘
中 文
• フロントパネルに多種類のRGBモードを備えたデュアルRGB LEDストリップ機能を
装着しています
• 強化ガラスウィンドウでPCの内部が見えるので内部のパーツを引き立てます
• 6個のファンと240ｍｍの水冷ラジエーターを装着でき、優れた放熱効果を確保します
• 最大300mmグラフィックカードに対応できます
• 2つの3.5"のHDDと3つの2.5" SSDを搭載可能です
日本語
• 다양한 RGB 조명 모드가있는 전면 패널의 듀얼 RGB 스트립
• 강력한 강화 유리 좌측 덮개가 있는 우아한 디자인
• 최대 6 개의 팬 및 240mm 라디에이터 지원
• 최대 300mm의 긴 그래픽 카드를 지원
• 3.5" HDD 2개와 2.5" SSD 3개
한국어
GLOBAL WARRANTY POLICY
WARRANTY PERIODS OF COUGAR GAMING DEVICES
Product : COUGAR MX410-T
Warranty : 1 Year
● This warranty gives you specific legal rights. You may also have other rights granted under local law.
These rights may vary.
● Only for electrical components.
год и месяц изготовления продукции указаны в серийном номере продукта.
(существует 2 способа определения даты изготовления, оба способа описаны ниже)
После S/N: первые две цифры означают год, вторые две – месяц изготовления.
Например, S/N: H1702000001 означает, что товар был произведен в феврале 2017 года.
После S/N: если указаны буквы, то две буквы представляют цифры из таблицы ниже, и означают год,
последующие две цифры – месяц изготовления.
Например, S/N: DAG02REVI000001 означает, что товар был произведен в феврале 2017 года.
●
Например,
AG = 17 = 2017 год
ДАТА ИЗГОТОВЛЕНИЯ ПРОДУКЦИИ
A B C D E F G H I J
12345678 9 0
A
B
Case Form Factor
Dimension
Motherboard Type
I/O Panel
Case Drive Bays
Expansion Slots
Model Name
Cooling Fan Support
Water Cooling Radiator Support
Maximum Number of Fans
Max. Graphics Card Length
Max. CPU Cooler Height
Max. PSU Length
300 (mm) / 11.8 (in) (Only fans at the front panel)
270 (mm) / 10.6 (in) (Radiator with fans at the front panel)
165mm / 6.5inch
160mm / 6.3inch
Transparent Left Panel 4mm Tempered Glass
MX410-T
Model No. CGR-5VM6B-T
Mid Tower
210 (W) x 455 (H) x 380 (D) mm / 8.3 (W) x 17.9 (H) x 15 (D) inch
7
Mini ITX / Micro ATX / ATX
USB 3.0 x 2 , USB 2.0 x 2 , Mic x 1, Audio x 1 , RGB Control Button
3.5" : 2 max.
2.5" : 3 max.
Front : 120mm x 3
Rear : 120mm
Top : 240mm
*
/ 120mm ( Max. Component Height on Motherboard is 40mm )
Front : 240mm
*
/ 120mm
6 Max.
Top : 120mm x 2
Rear : 120mm x 1 (RGB fan x 1 pre-installed)
MX410-T sports an attractive and compact design with dual RGB strips at the front panel.
With a massive tempered glass left panel, MX410-T showcases a clean and tidy build.
It has wider but more compact and powerful design, which allows you to have
high-performance and abundant storage space. ACCESSORY KIT
X 8Fan screws
X 17
Motherboard screws and 2.5" SSD screws
X 12Power supply screws
X 3Stand-off
3.5" HDD screws X 8
Cable ties X 6
B
A
C
D
E
F
G
H
IJ
K
L
HD AUDIO
HD AUDIO
POWER SW
POWER SW
POWER POWER LED
POWER LED + POWER LED
-
USB 3.0
USB3.0
USB 2.0
USB
H.D.D LED
H.D.D LED
- +

120
*240
*240
120
(Top)
1
(Rear)
3
120 120
120120
(Front)
2
Installing water cooling radiators & cooling fans
* Please choose either of front or top to install a 240mm radiator.
* Max. component height on motherboard is 40mm.
1
1
23
2
3
Installing the internal 2.5"SSDs
RIGHT
1
2
RIGHT
LEFT
RIGHT
Removing side panels
2
1
2
1
2
1
LEFT
1
2
Installing the internal 3.5"HDDs
RIGHT
Installing PCI-E cards
Support for graphics card up to 300mm-long
RIGHT
RIGHT
2
1
RIGHT
3
4
For more information, please visit
Compucase Enterprise Co.,Ltd.
All rights reserved.
www.cougargaming.com
Made in China
Compucase Enterprise Co.,Ltd.
No. 225, Lane 54, An Ho Road Sec. 2 Tainan, Taiwan, R.O.C
Tel:[phone]
Service E-Mail:[email protected]
COUGAR USA Technical Service
Tel: [phone]
Mail: [email protected]
https://cougargaming.com/support/contact/upload/
* 300 (mm) / 11.8 (in) (Only fans at the front panel)
* 270 (mm) / 10.6 (in) (Radiator with fans at the front panel)
3
