Courtyard Creations RTS855A User manual

RTS855A-WM
1
2
3
4
5
64
1
4
1
1
18
9
10
11
12
13 1
1
1
4
4
1
RTS855A-CS01
RTS855A-CS02
RFS8821-CS04
17C03A0814041Y2
17C01A0712002Y4
17FA08060601-Y4 17KAB1101----Y4
17KAA0201----Y4
1800337002
1800319004
17D03A040401-Y4
17FA05100701-Y4 WASHER d6.5*D30*2.0
JAM NUT M8*1.25
BOLT CAP M8
BOLT CAP M6
HEX.KEY WRENCH 6MM
NUT WRENCH 10&13MM
SEATASSEMBLY
BASE ASSEMBLY
SEAT POST
BOLT M8*40
BOLT M6*35
WASHER d8.5*D17*1.6
Step 1:
Place the seat assembly (#1) onto a non-abrasive surface,
such as a carpet, with the underside facing upwards.
Fasten the seat post (#3) to the brace of the seat
assembly (#1) by using bolts (#4), washers (#6 and #8)
and jam nuts (#9). See Figure 1.
Attention:
Make sure that each bolt needed for all steps match the
corresponding figure to ensure proper assembly.
FIGURE 1
#4 BOLT M8*40
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
PARTS LIST
PART
NO. MATERIAL CODE PART Q’TY
PAGE 1 OF 2 COURTYARD CREATIONS INC.
31
40
7
4
17FC08030801-Y2 WASHER d8.5*D12*2.1
Do not discard any of the packaging until you have checked that you have all the parts and pack of fittings.
Keep children away during assembly. This item contains small parts which can be swallowed by children.
Children should always be under direct adult supervision while using the product.
Retain the assembly instructions for future reference.
Please quote following FQC NO. when contacting service center.
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
!
!
!
!
STOP DON’T RETURN TO STORE!
6
6
8
8
9
9
10
10
4
4
31

Step 2:
Insert the seat post (#3) into the hole located in the center
of the base assembly (#2). Fasten them together by using
bolt (#5) and washer (#7). See Figure 2.
Note:
For ease with installation, we recommend that the seat
post (#3) be slightly oiled or waxed before fastening it to
the base assembly (#2).
Step 3:
See Full Assembly.
CAUTION:
To ensure one’s safety during use of this swivel chair,
examine all of the bolts to make sure that they are securely
fastened. This is a chair with swivel ability; therefore use by
young children should be adult supervised.
FIGURE 2
FULLASSEMBLY
#5 BOLT M6*35
PAGE 2 OF 2
3
2
5
7
11 35
Cleaning and Maintenance
• Wash frame and fabric parts with mild soap and water,
rinse thoroughly, and dry frame completely. Do not use
bleach, acid, or other solvents on the frame parts.
• We recommend the use of furniture covers when not in
use.
• Please inspect and tighten all bolts or fasteners on a
regular basis to ensure proper performance and safety
of your swivel chair.
• In order to prolong the life and beauty of your swivel
chair, we recommend that it be stored in a dry and
protected area during off season periods.
Make sure that all of the bolts have been tightened
completely and cover them with bolt caps (#10 and #11).
STOP DON’T RETURN TO STORE!
Missing A Part?
No Need To Go Back To
TheStore!
The store where you made your purchase
does not stock parts for this item
if you need parts,
whether they are missing or damaged.
Call Toll Free
TEL: [phone]
FAX: [phone]
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
PLEASE READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
PLEASE SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
SHOULD YOU NOTLOCATE ALL OF THE ABOVE PARTS, PLEASE INSPECTALL
PACKING MATERIAL FOR ANY SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED IN SHIPMENT.
SHOULDYOU EXPERIENCEANYDIFFICULTYDURING ASSEMBLYOR IF ANY
PARTIS MISSING OR DAMAGED,PLEASE CALL THE HELP LINE 1-877-539-7436
BEFORERETURNING THE ITEM TO THESTORE.
PLEASE PROVIDE THEFOLLOWING INFORMATION:
1- MODEL NUMBER OF THEPRODUCT.
2- PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS LIST
SHOWN ON ASSEMBLY INSTRUCTIONS.
MOST PROBLEMSCAN BERESOLVED WITHOUT RETURNING THIS PRODUCT
TO THERETAILER.
The store where you made your purchase
does not stock parts for this item
if you need parts,
whether they are missing or damaged.
STOP!
MissingA Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free
TEL: [phone]
FAX: [phone]
