Courtyard Creations RLS409W User manual

ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
PAGE 1 OF 6
V-3
RLS409W
COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. When contacting the service center.
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
!
!
!
!
!

A. Read these instructions thoroughly and acquaint yourself with the parts and
the illustrations to ensure safe and proper assembly.
B. You will need the following tools:
- Phillips Screwdriver
- Nut Wrench (See Part #27)
- Hex. Key Wrench (See Part #25 and #26)
C. Lay out all of the parts and match them with the table below.
PAGE 2 OF 6
PARTS LIST
PART
NO.
1
2
3
5
6
7
8
9
10
11
12
13
14
1
16
17
18
19
20
21
22
23
24
25
26
27
28
1
1
1
2
2
4
10
4
6
2
4
16
1
1
2
2
2
2
2
2
4
4
1
RLS409W-CS09-8
17C40A0714001YX
17C01A0812001YX
17C17A1306001YX
17C01A0823071YX
17FA08060601-YX
17FA05050401-YX
18000C06001
18000C23001
18000615004
18000018001
17KAA0201----Y4
17KAB1201----Y4
61R409WD00001BA
WASHER d6.5*D16*1.2
BOLT M6*40
BOLT M8*35
SCREW ST4.2*16
BOLT M8*70
CANOPY/FRAME CONNECTOR
PLASTIC SCREW
HEX.KEY WRENCH 6MM
NUT WRENCH 13&17MM
CANOPY
62RUS459FH102
47LA06310
4 1
47LA06309
62RLS409WN101
62RLS409WN102
RLS409W-CS01-1
RLS409W-CS11-1
62RLS409WM101
62RLS409AI101
62RLS409WH102
17GA20405201-Y3
TOP CROSS BEAM W/ADJUSTABLE TEETH
REAR CROSS BRACE
RIGHT LATERAL CROSS BRACE
LEFT LATERAL CROSS BRACE
FRONT UPRIGHT SUPPORT
REAR UPRIGHT SUPPORT
SWING ARM
SEAT ASSEMBLY
SWING ARM TUBE
FRONT/REAR CANOPY BRACE
SIDE CANOPY BRACE
SUSPENSION SPRING
PLASTIC NUT M6*P1.0
PLASTIC NUT M8*P1.25
WASHER d8.5*D17*1.6
MATERIAL
CODE PART Q’TY PART NO.
MATERIAL
CODE PART Q’TY
1
17KAA0101----Y4
HEX.KEY WRENCH 4MM
STOP DON’T RETURN TO STORE!
4
28000221024
LEG CAP
15 6
17C40A0705001YX
BOLT M6*15
V-3

PAGE 3 OF 6
Fig. A
Note:
When fastening with bolts and nuts, always use
a washer (#19 and #20) between the tube and
the bolt and the tube and the nut.
Step A - 1
Step A - 2
Step A - 4
Step A - 5
Do not tighten the bolts
after Step 1. Fasten all
bolts after Fig A.
Step A - 1 :
Fasten the front and rear upright supports (#5
and #6) at the top by using bolts (#14), washers
(#19), and plastic nuts (#21). Do the same
procedure for both sides. Keep the bolts loose.
Step A - 2 :
At both ends, insert the assembled upright
supports (#5 and #6) into the top cross beam
w/adjustable teeth (#1). Tighten all of the plastic
nuts and bolts.
Step A - 3 :
Fasten the lateral cross braces (#3 and #4) to the
upright supports (#5 and #6) by using bolts (#15)
and washers (#20). Do the same procedure for
both sides.
Step A - 4 :
Fasten the rear cross brace (#2) to the rear
upright supports (#6) by using bolts (#16),
washers (#20), and plastic nuts (#22). Tighten all
of the plastic nuts and bolts.
14
14
19
19 19
21
21
19
Step A - 3
STOP DON’T RETURN TO STORE!
1
5
6
5
55
5
6
6
6
26
6
3
4
6
15
15
20
20
16
22
12
12
12
12
20
20
Note :
1. Do not fasten the lower rear holes of them yet.
2. To ensure proper assembly, the label marked
“L” and “R” on the lateral cross brace (#3 and
#4) should coincide with the label marked “L”
and “R” on the front upright supports (#5).
R
L
L
R
V-3
Step A - 5 :
Insert the leg caps (#12) into all of the base feet.

PAGE 4 OF 6
Fig. B
Fig. C
Fig. D
Step C :
Hook the suspension spring (#13) into the top of both
swing arm tubes (#9). Do the same procedure for
both sides.
Step D :
Hang the other side of the suspension spring (#13)
into the hole located on the angled brace on the top
cross beam w/adjustable teeth (#1). Do the same
procedure for both sides.
Warning :
Make sure that both ends of the suspension springs
(#13) go completely through the holes in the angled
braces on the top cross beam w/adjustable teeth (#1)
and the swing arm tubes (#9).
STOP DON’T RETURN TO STORE!
1
99
9
9
7
8
7
99
9 9
13
13
13 13
13
13
13
13
Step B :
Open the seat assembly and fasten a swing arm
tube (#9) and a swing arm (#7) to the seat
assembly (#8) by using bolt (#16) and washers
(#20). Do the same procedure for both sides. Fasten
another swing arm tube (#9) to the swing arm (#7)
at the front bend by using bolt (#16), washers (#20),
and plastic nut (#22). Do the same procedure for
both sides. Fasten the other end of the swing arm
(#7) to the seat assembly (#8) by using bolt (#17)
and washers (#19). Do the same procedure for both
sides. 16
17
16
22
20 20
19
20
V-3

PAGE 5 OF 6
Fig. F
Step F :
Fasten the canopy/frame connectors (#23) on
the canopy assembly to the adjustable teeth
on both sides of the top cross beam (#1) by
using plastic screws (#24).
Fig. E
Step 1
Step 3
Step 2
Step 4
Step 5
STOP DON’T RETURN TO STORE!
11
11
11
11
10
10
10
1
10
28
28
28
28
24 23
23
18
18
Step E - 1 and Step E - 2 :
Slide the canopy/frame connectors (#23) onto
the side canopy braces (#10) and fasten into
position by using screws (#18). Make sure that
the teeth of the canopy connectors are facing
towards the inside of the swing.
Step E - 3 :
Insert the front and rear canopy braces (#11)
into the sleeves of the canopy (#28).
Step E - 4 :
Insert the tube ends of the side canopy braces
(#10) into the front and rear canopy braces
(#11).
Step E - 5 :
Insert the corners of the front and rear canopy
braces (#11) into the pockets of the canopy
(#28).
24
23
V-3

Fig. G
Cleaning and Maintenance
• Wash frame and fabric parts with mild
soap and water, rinse thoroughly, and dry
completely. Do not use bleach, acid, or
other solvents on the frame or fabric.
• The cushions and canopy may be surface washed with mild soap and water if necessary. Commercial foaming
upholstery cleaner may also be used. Rinse well and hang to dry. Do not machine wash or dry.
• We recommend the use of furniture covers to protect your swing when not in use.
• Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and safety of
your swing.
• In order to prolong the life and beauty of your swing, we recommend that the cushions and fabric parts be
stored in a dry and protected area during off season periods (i.e. overnight or on rainy days).
Special Warnings
1. The user of this swing should always inspect it before each use.
2. It is essential to place this swing on level ground and not less than 6 feet from any obstruction; such as fences,
garages, houses, overhanging branches,laundry lines, or electrical wires.
3. Check the tightness of all of the nuts and bolts on a regular basis.
4. Make sure that the suspension springs are properly secured before each use.
5. Always remove the canopy in heavy wind conditions; otherwise the canopy may tip over and cause damage to
its parts.
6. The manufacturer will not accept responsibility for unauthorized repairs or modifications to the swing or its parts.
7. Oil all of the metal parts that move regularly.
8. Weight limit is 750 lbs.
STOP DON’T RETURN TO STORE!
PAGE 6 OF 6
Step G :
To assure stability, double check that all of
the bolts have been completely tightened.
Warning :
To avoid danger of suffocation, always keep
plastic bags or small parts away from babies
and children.
Warranty
• This product is covered by Courtyard Creations Inc.'s. one–year limited warranty.
• Proof of purchase (dated register receipt) is required for warranty claims.
• It remains the customer’s responsibility for freight and packing charges to and from the service center.
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
For further assistance,
please visit us at
[email protected]
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL OF THE PARTS,MAKING SURE THAT
YOUHAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THE STORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMS CAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
V-3
