Courtyard Creations TLS25CD-WM User manual

16
#4 BOLT M6*16
ASSEMBLY INSTRUCTIONS
ATTENTION: THIS PRODUCT IS NOT FOR COMMERCIAL USE
INTENDED FOR RESIDENTIAL USE ONLY.
TLS25CD-WM
PAGE 1 OF 2 COURTYARD CREATIONS INC.
STOP DON’T RETURN TO STORE!
PARTS LIST
PART
NO. MATERIAL CODE PART Q’TY
1 1
2
3
4
5
6
7
8
9
4
12
4
8
1
8
1
4
47LA66074
TLS25CD-CS01
62TLS23CDY101
17C33A0706001Y4
17C01A0706001Y4
17FA05040301-Y4
18000337001
17KAA0101----Y4
TABLE TOP
LEG
CENTER CONNECTOR
WASHER d6.5*D13*1.0
BOLT CAP M6
HEX.KEY WRENCH 4MM
FIGURE 1
1
22
2
2
BOLT M6*16
Attention:
Make sure that each bolt needed for all steps
matches the corresponding figure to ensure proper
assembly.
Step 1:
Place the table top (#1) onto a non-abrasive surface,
such as a carpet, with its underside facing upwards.
Fasten the legs (#2) to the underside of the table top
(#1) rim by using bolts (#4) and washers (#6). Keep
the bolts loose. See Figure 1.
7
6
4
Use the correct bolts as indicated. Do not tighten any of the bolts until is completely assembled.
Do not sit or stand on this table.
Do not discard of any of the packaging until you have checked that you have all of the parts and
fittings required.
Keep children away during assembly. This item contains small parts that can be swallowed by
children. Children should always be under direct adult supervision while using this product.
Retain these assembly instructions for future reference.
Quote the following FQC NO. when contacting the service center.
!
!
!
!
!
!
SERVICE CENTER TOLL FREE NO.
TEL: [phone]
FAX: [phone]
BOLT M6*16
18000337004
BOLT CAP

PAGE 2 OF 2
STOP DON’T RETURN TO STORE!
FIGURE 2 FIGURE 3
5
8
6
5
8
6
2
2
2
2
3
Step 2:
Fasten the center connector (#3) to the middle of
the legs (#2) by using bolts (#5) and washers (#6).
Make sure that all of the bolts have been tightened
completely and cover them with bolt caps (#7 and #8).
See Figure 2.
Step 3:
Turn the table to its upright position. See Figure 3.
Cleaning and Maintenance
• Wash frame parts with mild soap and water, rinse thoroughly, and dry completely. Do not use bleach,
acid, or other solvents on the frame parts.
• Inspect and tighten all bolts and fasteners on a regular basis to ensure the proper performance and
safety of your table.
• When moving the table, lift. Do not drag this table.
• We recommend the use of furniture covers when not in use.
• In order to prolong the life and beauty of your table, we recommend that it be stored in a dry and
protected area during off season periods.
#5 BOLT M6*16
16
The store where you made your purchase
does not stock parts for this item.
If you need parts,
whether they are missing or damaged,
STOP!
Missing A Part?
No Need To Go Back To
The Store
Call us between 9:00 AM and 4:30 PM
Eastern Time Monday through Friday
Call Toll Free:
TEL: [phone]
FAX: [phone]
READ THESE INSTRUCTIONS COMPLETELY BEFORE STARTING ASSEMBLY
SEPARATE AND IDENTIFY ALL PARTS, MAKING SURE THAT YOU
HAVE ALL OF THEPARTSLISTED.
IF YOU DO NOTLOCATE ALL OF THE PARTS LISTED, INSPECT THE
PACKING MATERIAL FOR SMALL PARTSTHAT MAYHAVEBECOME
SEPARATED DURING SHIPMENT.
IF YOU EXPERIENCEANY DIFFICULTY DURING ASSEMBLYOR IF ANY
PARTS ARE MISSING OR DAMAGED,CALL THE HELP LINE AT
1-877-539-7436 BEFORERETURNING THIS ITEM TO THE STORE.
PROVIDE THEFOLLOWING INFORMATION WHEN CALLING:
1-MODEL NUMBER OF THEPRODUCT.
2-PARTNUMBER AND MATERIAL CODE OF THE PARTFROM THE PARTS
LIST.
MOST PROBLEMS CAN BERESOLVED WITHOUT RETURNING THIS
PRODUCT TO THERETAILER.
