Coway P-07FR User manual

0000000
User、s ManualUser、s Manual
This Water Filtration System is for domestic use. It can not be used in
overseas where the power rate is different.
For the right operation of Coway Water Filtration System read this manual.
Water Filtration System
The Letter of Guarantee is enclosed here with this Coway product
realizing "Quality is the best policy".
P-07FR/RV/U/UV

2
3
4
5
02
The electric filter change indicator
reminds user when to change the filter.
If the system is in use for an extended period
of time, the filter can be protected by the auto
flushing feature.
Coway invented a tankless water filtration
system which is very space-efficient.
The risk of water leakage is diminished by
using an electronic valve.
Self Filter Check
Auto Flushing(Only P-07FR/RV)
Innovative Tankless Water Filtration System
Safer Structure
6
Due to the tankless system, secondary-
source pollution, which sometimes occurs
inside of tanks, is eliminated.
Preventing Secondary Pollution
7
Users can get the purified water by Ultra
Violet.
UV Lamp Filter(Only P-07FRV/UV)
03
C
O
W
A
Y
FEATURES DEAR CUSTOMERS
User can get the purified water by just
opening the faucet.
Undersink type
1
>> Coway Water Filtration System has differentiated function.
Features
First of all, we would like to thank you very much for purchasing this Coway water
filtration system. This product is superior to the ones in the past in function and we believe
that it will provide you with cleaner and healthier water. We would like to recommend
you to read this User's Manual carefully for proper operation and maintenance and keep
this manual well together with the warranty. This user's manual could solve your problem
so that you can easily fix by yourself in just a few minutes.
This system (P-07FR/RV) conforms to NSF/ANSI 58 for the reduction of Pentavalent
Arsenic, Barium, Cadmium, Mercury, Selenium, Radium 226/228, Trivalent chromium,
Hexavalent chromium, Lead, Nitrate/Nitrite as verified and substantiated by test data. This
system (P-07FR/RV/U/UV) conforms to NSF/ANSI 42, 53 for the reduction of Chlorine and
VOC as verified and substantiated by test data. This system is acceptable for treatment for
influent concentrations of no more than 27mg/L nitrate and 3mg/L nitrite in combination
measured as N and is certified for nitrate/ nitrite reduction only for water supplies with a
pressure of 280kPa(40psig) or greater.
 
‐ Electricity Safety
‐ Installation Safety
For information
Safety Information
04
04
06
‐ Operation Safety
07
‐ Others
08
Names of Each Part
09
Water Filtration Process
10
How to use
Please Keep in Mind
Preparations
Operation Part/Indication Part
Contents
How to Operate
‐ To drink room water
Installation and cleaning
Installing Method
18
Filter Replacement And Daily Check
20
Filter Replacement Method
22
Others
Before Asking A/S
25
Specification
26
Water Flow Diagram
27
Warranty Information
29
12
13
14
17
17

04 05
SAFETY INFORMATION
If not observed, serious
injury or even death
could occur.
Danger
If not observed, serious
injury or property damage
could occur.
Warning
If not observed, slight
injury or property damage
could occur.
Caution
Electricity Safety
Safety Information Electricity Safety
-
For Information
Do not use a damaged power
cord or plug, and loose outlet.
Electrical shock or fire may occur
as a result.
Do not unplug by pulling the cord
or handle the plug with wet hands.
Electrical shock or fire may occur
as a result.
Do not plug into an outlet or
power strip that is being used
by several other appliances.
Use a separate outlet for the unit.
Fire may occur as a result.
Close the main water supply
valve and unplug the power cord
when not using for a long time.
Electrical shock or fire may occur
as a result.
Do not attempt to repair the
power cord.
Electrical shock or fire may occur
as a result.
Unplug the unit before repair,
inspection, or replacement.
Electrical shock may occur as
a result.
Do not run the power cord under
a heavy object to prevent it from
being damaged.
Electrical shock or fire may occur
as a result.
If the cord or plug is wet, unplug
the unit and let it completely
dry before subsequent use.
Electrical shock or fire may occur
as a result.
Be careful to keep this safety information.
Please read this information to prevent property loss and ensure your safety.

06 05
SAFETY INFORMATION
07
Danger Warning Caution
Safety Information Electricity Safety Installation Safety Operation Safety
For Information
Do not repeatedly plug and unplug
the unit from the electrical outlet.
Electrical shock or fire may occur
as a result.
Do not use if the cord appears to
be damaged. Please ask Customer
Service to replace the cord.
Electrical shock or fire may occur
as a result.
Remove any dust or water if it’s
on the plug.
Never use Benzene or gasoline
to clean the plug.
Electrical shock or fire may occur
as a result.
Installation Safety
Do not install the unit near
heaters.
Electrical shock or fire may occur
as a result.
Use or place the unit on a level area
and do not apply force to the unit.
Injury to the user or damage to
the unit could result.
Operation Safety
Do not put a candle, cigarette or
any other flammable object on it.
Fire may occur as a result.
Close the main weter supply valve
and plug out, then call to A/S
center in the case of any water
leakage from the product.
Electrical shock may occur as a result.
Immediately unplug and call the
Customer Service center if the unit
makes a strange noise or odd smell.
Fire may occur as a result.
Do not place dishes or containers
of water, drugs, food, or small
metal objects on top of the product.
Danger of electric shock, fire, or
product damage if water or alien
substances get into the product.
-
-
-
Please read this information to prevent property loss and ensure your safety.
Electricity Safety
Black
Particles
When moving the product or replacing
the fine post-carbon filter there may be
black residue particles under the tank
bottom stored water may get
contaminated.
Certain level of fine dust may be introduced
to silver coated activated carbon that is
used to the fine post-carbon filter to
enhance the taste of water; thus, it is
harmless to human body.

08 09
SAFETY INFORMATION
Safety Information Operation Safety Others Names of Each Part
/
-
-
For Information
Others
Do not carry the unit by its power cord.
Electrical shock or fire may
occur as a result.
Do not spray water or wipe them
with benzene when cleaning .
Electrical shock or fire may occur as a result.
Do not repair, disassemble, or
modify.
Electrical shock or fire may occur as a result.
Do not use filtered water for the water
exchange of an aquarium or a fishbowl.
Certain fish may die as a result.
The filtration system installation shall
comply with state and local laws and
regulations. Do not use with water
that is microbiologically unsafe or of
unknown quality without adequate
disinfection before or after the system.
Please read this information to prevent property loss and ensure your safety.
NAMES OF EACH PART
Front /Rear
Front /Rear
Restart Button
▶
Indication Part
▶
Outlet
(Blue Color)¼
▶
Inlet
(Orange Color)⅜
▶
Power Cord
▶
Extraction
(Orange Color)¼
▶
Indication Part
▶
Extraction
(Orange Color)¼
▶
Inlet
(Orange Color)¼
▶
Power Cord
▶
※Check fitting and tubings are the parts that can be replaced.
▶P-07FR/RV
▶P-07FU/UV
Operation Safety
Periodical filter replacement is
prerequisite for getting clean water.
In case filters are overused, the
performance of filters is deteriorate.

10 11
WATER FILTRATION PROCESS
Water Filtration Process
For Information
Disposed
Water Outlet
NEO-SENSE
FILTER
FINE POST-
CARBON FILTER
MEMBRANE
FILTER(RO)
UV LAMP FILTER
(Only P-07FRV)
PLUS-SEDIMENT FILTER
Using a step-by-step filtration method per pore, this filter effectively reduces various
foreign bodies that come from the supplying water pipe such as bits of rust. The Plus-
Sediment filter vastly reduces dirt, sand, rust particles, and other sediments.
PRE-CARBON FILTER
POST-CARBON FILTER
The activated carbon filter reduces chlorine, fluoride, odor, tri-halo methane, gas additive
MTBE, and organic pollutants such as pesticides, EDB, PCB, benzene, and TCE.
Made using coconut, this filter reduces unpleasant smell from water and enhances water
flavor.
UF Membrane filter reduces the foreign materials and water bornes microorganisms.
 The water filtering system (P-07FU/UV)
PLUS-SEDIMENT
FILTER
POST-CARBON
FILTER
PRE-CARBON
FILTER
MEMBRANE
FILTER(UF)
UV LAMP FILTER
(Only P-07FUV)
MEMBRANE FILTER(UF)
Reduces e.coli, coliform and other bacteria as well as viruses, yeasts, cryptosporidium,
and giardia.
UV LAMP FILTER(Only P-07FUV)
The Ultra Filtration phenomenon has been applied to Coway filtration system,
where a UF filter with pores of 0.01
㎛ is used to filter water. The components
of our water filtration system are as followed:
WARNING
NEO-SENSE FILTER
Reduces various foreign bodies that come from the feed water pipe such as dirt, sand,
rust particles, VOCs and chlorine.
MEMBRANE FILTER(RO)
FINE POST-CARBON FILTER
The RO(Reverse Osmosis) Membrane filter reduces Pentavalent Arsenic, Barium, Cadmium,
Mercury, Selenium, Radium 226/228, Trivalent chromium, Hexavalent chromium, Lead,
Nitrate/Nitrite. The influent water to the system shall include the following characteristics.
∙No organic solvents ∙Chlorine : < 2 ppm ∙pH : 7-8 ∙Temperature : 41-95 ℉(5-35 ℃)
∙Iron : < 2 ppm ∙Turbidity : < 1 NTU ∙Hardness : < 1000 mg/L
It is a composite filter. The post-carbon filter removes odor of water and improve water
taste. And the filter sensor eliminates the dust particles in the post-carbon filter.
Reduces e.coli, coliform and other bacteria as well as viruses, yeasts, cryptosporidium,
and giardia.
 The water filtering system (P-07FR/RV)
UV LAMP FILTER(Only P-07FRV)
The disposed water shall be used for cleaning a toilet, a house, dishes, and as
water for sundry uses. However, please do not use it for potable water or
cooking water.
WARNING
This system conforms to NSF/ANSI 58 for the reduction of Pentavalent Arsenic,
Barium, Cadmium, Mercury, Selenium, Radium 226/228, Trivalent chromium,
Hexavalent chromium, Lead, Nitrate/Nitrite as verified and substantiated by test data.

12 13
PLEASE KEEP IN MIND
Please Keep In Mind Preparations
How to Use
 The summary for the proper installation of the water filtration system.
1
Wind the teflon tape on the
adaptor and fit it to the pipe.
Then, connect the faucet with
the adaptor.
2
Connect orange tubing with
the connector on the adaptor.
3
Connect the orange colored
inlet tubing for the feed water
with the cold water pipe.
Extend the blue color outlet
tubing to where the drain is.
4
Connect the extraction fitting
to the faucet with a tube.
5
PREPARATIONS
Shall install the adaptor with connector
on the cold water pipe.
Flush water through each filter at
least 5 minutes before connection.
 Please check before use
Then, open the feed valve to supply water to the filtration system.
Connect the power to the voltage rating that matches it on
the rating plate.
When the lamp on the
indication parts are turned out
When the lamp on the indication
parts are turned out please check the
reason for break of electric supply in
case of electricity failure or other
conditions.
■
Regular filter change
The regular filter change is very
important to have clean water. The
filter after life is ended may degrade
the performance. Thus, do not miss
the time for the filter change.
■
Check the
Lamps!!
When not using for a long time please lock the main water supply
valve and plug out the power cord.
1
2
5
4
/
Connect it to voltage rating
that matches it on the rating
plate. Then, open the feed
valve to supply water to the
filtration system.
6
Make a hole on the drain pipe
and install the drain clamp
on the hole.
3
Outlet tubing
Inlet tubing

14 15
OPERATION PART
/INDICATION PART
Operation Part/Indication Part
 Operation Part/Indication Part (P-07FR/RV)
How to Use
Restart Button
1
▶
RO Membrane
filter replacement
Indicator
3
▶
Water Shortage
Indicator
5
▶
Neo Sense filter
replacement Indicator
2
▶
Post Carbon Block
filter replacement
Indicator
4
▶
Auto Flushing
Indicator
6
▶
The light lights up when
a Membrane(RO) filter
replacement is needed.
Change the filter when
the time of incoming
signal on .
RO Membrane filter
replacement Indicator
3
The light lights up when a
Post Carbon Block filter
replacement is needed.
Change the filter when the
time of incoming signal on .
Post Carbon Block filter
replacement Indicator
4
In case of water shortage,
the water shortage LED
lights up. Check the water
supply valve.
Water Shortage Indicator
5
When starting auto flushing
the indicator lamps on.
Auto Flushing Indicator
6
TheWater Shortage IndicatorandWashlights up when a UV Lamp filter replacement
is needed. Change the filter when the time of incoming signal on.
For normal operation
mode, push the Restart
Button.
Restart Button
1
The Filter lights up when a
Neo Sense filter
replacement is needed.
Change the filter when the
time of incoming signal on.
Neo Sense filter
replacement Indicator
2

16 17
OPERATION PART
/INDICATION PART
HOW TO OPERATE
Operation Part / Indication Part How to Operate
How to Use
 Operation Part/Indication Part (P-07FU/UV)
Plus Sediment
filter(A) + Pre carbon
filter(B) replacement
Indicator
1
▶
UF Membrane
filter replacement
Indicator
3
▶
Post carbon filter
replacement Indicator
2
▶
Water Shortage
Indicator
4
▶
The light lights up when Plus
Sediment filter and Pre carbon
filter replacement are needed.
Change the filter when the
time of incoming signal on.
Plus Sediment filter(A)
+ Pre carbon filter(B)
replacement Indicator
1
The light lights up when a
Post carbon filter
replacement is needed.
Change the filter when the
time of incoming signal on.
Post carbon filter
replacement Indicator
2
The light lights up when a
UF Membrane filter
replacement is needed.
Change the filter when the
time of incoming signal on.
UF Membrane filter
replacement Indicator
3
In case of water shortage,
the water shortage LED
lights up.
Water Shortage Indicator
4
 To drink room water
Put the extraction pipe in the desired position
and place the cup under the extraction faucet
to collect the water.
Turn the faucet on and off depending on
desired use of filtered water.
1
2
Water extraction automatically stops after
eight minutes to prevent too much use of
water or overflowing around the product
caused by user’s carelessness.
After repeating for four cycles, this device
will auto flush and then shut off.
(Only P-07FR/RV)
3
If the system does not work when the
faucet is opened, push the restart button
for one seconds to restart extraction.
(Only P-07FR/RV)
4
�
/
The influent water should not include any organic solvents because they may
damage RO membrane polymer and may decrease the performance of RO
membrane.
TheWater Shortage Indicatorlights up when a UV Lamp filter replacement is needed.
Change the filter when the time of incoming signal on.

18 19
INSTALLING METHOD
Installing Method
Installation and Cleaning
 Follow the instruction for installation (P-07FR/RV)
Extraction tubing
(Orange Color)
Connect the blue color outlet tubing 
to the drain clamp. Connect the inlet
tubing to the tap water supplying
pipe. Connect the
Extraction tubing 
to the faucet.
Inlet tubing
(Orange Color)



 Follow the instruction for installation(P-07FU/UV)
Extraction tubing (Orange Color)
Inlet tubing (Orange)
Connect the orange color Extraction
tubing to the faucet. Connect the
Inlet tubing to the tap water
supplying pipe.


Outlet tubing (Blue Color)

20 21
FILTER REPLACEMENT
AND DAILY CHECK
Filter Replacement And Daily Check
Installation and Cleaning
 Filter Replacement
Filter
The vitality of product is the filter. The fraudulent
filters or missing time for filter change may
degrade the performance and so interrupt the
filtration.
If the filter is not regularly replaced, it may degrade the water quality from the product. The filter
change cycle may vary within the range of expected replacement cycle depending on the feed
water quality.
 The period for the filter exchange is made based on 10ℓuse in a day for house use (4 people based) and
20ℓuse for business.
■
Estimated Time of Filter Replacement
■
Estimated Time of Filter Replacement
The filter change cycle described above is not the filter quality
warranty period but the expected cycle that the filter shows its
original performance. (based on the tap water.)
 The filter change cycle may be reduced for the areas with poor water
quality or more applications.
■
Part No.
Names of Filter Usable Period
Neo-Sense Filter
Membrane Filter(RO)
Fine Post-Carbon Filter
6 months
24 months
12 months
Part No.
Names of Filter Usable Period
Plus-Sediment Filter
Pre-Carbon Filter
Post-Carbon Filter
Membrane Filter(UF)
6 months
6 months
12 months
8 months
The product water should be tested every 6 months to ensure
that the contaminants are being reduced effectively.
Please contact your local dealer or Coway to initiate this service.

P-07FR/RV

P-07FU/UV
 Regular Check
Power
- Does the indication part repeat ON and OFF when you touch the power cord When the
power is connected?
- Is a part of power cord hotter than usual?
- Is a part of power cord distorted, discolored or damaged?
■
Indication Part
- Does any lamp on the indication part abnormally flicker?
■
For safe operation, we recommend the frequent check on the product.
Keep the optimum status of the product by frequent check for the following
items.
For any event above, immediately stop the operation and contact
your nearest Coway Customer Service Center.
For the abnormal flickering of lamp, immediately Contact your nearest
Coway Customer Service Center.
∙This reverse osmosis system contains a replacement component
critical to the efficiency of the system. Replacement of the reverse
osmosis component should be one with identical specifications,
as defined by the manufacturer, to assure the same efficiency
and contaminant reduction performance.
∙This reverse osmosis system contains a replacement treatment
component critical for the effective reduction of total dissolved
solids, and that the product water shall be tested periodically to
verify that the system is performing properly.

22 23
FILTER REPLACEMENT METHOD
Filter Replacement Method
Installation and Cleaning
 Please replace filter
Filter replacement time is indicated
when the corresponding LED of filter
flickers in window display.
Each of A, B and C respectively represents
Neo-sense filter, Membrane filter(RO),
Fine Post-carbon filter.(P-07FR/RV)
Each of A+B, C and D respectively
Represents Plus-sediment filter+ Pre
carbon Filter, Post carbon filter and UF
Membrane filter.
1
2
Close water lead-in valve and pull
out plug.
3
P-07FR/RV P-07FU/UV
P-07FR/RV P-07FU/UV
Remove fitting from filter as shown in diagram.
Replace filters as required. Take caution for
safety at all times.
Initialize filter setting by pressing the
corresponding button(for 3 sec) of filter
among the filter reset
buttons located at
the back of the front
panel.
5
6
�
�
Unfasten screws. Then, hold both side covers
at the bottom and force them upwards as if
pushing up to remove
them from the
main body.
4
�
P-07FR/RV P-07FU/UV

24 25
FILTER REPLACEMENT METHOD
■When LED to indicate filter replacement is turned on, users must not
attempt a replacing filters on their own. Make sure to inquire A/S
center.
■When the filter is used up to 80% of its capacity, corresponding LED
blinks. When the filter is completely used up, its LED lights up and the
alarm rings.
■If you push the Reset button for 1 second, the relative filter LED lights
off and the buzzer goes off.
Other Cautions for Safety
Check for normal operation of filter
replacement parts in window display.
8
Insert both side covers and fasten screws.
7
P-07FR/RV P-07FU/UV
Filter Replacement Method Before Asking A/S
BEFORE ASKING A/S
 Check the followings before asking A/S.
The product may not properly work due to the reasons except the breakdown because
you are not accustomed to how to operate or any negligible reasons. In those cases,
check the followings, and you can solve the simple troubles without the help from the
customer service center. If the trouble continues after you check the followings, contact
your nearest Customer Service Center.
A/S Phone No : 213-480-1600
The water
tastes weird
The water is
flowing
slower.
Check Items Solutions
Did you use the filter system for
too long?

Request filter change.
Request filter change.
Is it about time to change the filter?

Is it about time to change the filter?

Request filter change.
Did you lock the water supply valve?

Open the water supply valve.
Did the temperature of the water
drop suddenly?

When the temperature drops, the
amount of water filtered decreases.
Problem







Water does
not come
out, or the
fixed
quantity has
changed
All functions
suddenly
stop during
operation. Is room water overflowing or
leaking?
Is the power turned on?
Is the water being supplied properly?
Is the water inlet hose too long?
Is the hose bent?
Is the water supply valve closed,
or the water supply cut?
Is it about time to change the filter?
Request filter change.
Open the water supply valve.
Straighten the hose.
Shorten the water inlet hose
to 5m or less.
Check the water supply valve.
Connect the power to the
voltage rating that matches it
on the rating plate.
Request A/S.
/
 Please replace filter

26
SPECIFICATION WATER FLOW DIAGRAM
27
Other Cautions for Safety
Specification Water Flow Diagram
▶P-07FR
Plus-Sediment
Pre-Carbon
Post-Carbon
Membrane(UF)
LPS
Purified Water
HPS
Stem Elbow
Bulk Head
(1/4)
Feed Water
Regulator
Bulk Head
(1/4)
▶P-07FU
Neo-Sense
Membrane(Ro)
Fine Post-carbon
Feed Water
Disposed Water
HPS_F
Booster
Pump
Feed V/V
Feed V/V
Check
Fitting
(3/8)
Bulk Head
(3/8)
Stem Elbow
LPS
Bulk Head
(1/4)
HPS_E
Reducer
(1/4+3/8)
Bulk Head(1/4)
Purified Water
/
※Without any prior notice, all or parts of the product are subject to change for the purpose of
improving the performance of the product.
※Efficiency rating means the percentage of the influent water to the system that is available to the
user as reverse osmosis treated water under operating conditions that approximate typical daily
usage.
※Recovery rating means the percentage of the influent water to the membrane portion of the
system that is available to the user as reverse osmosis treated water when the system is
operated without a storage tank or when the storage tank is by passed.
Product
Model
Coway Water Filtration system
P-07FR P-07FRV
Reverse Osmosis(RO) RO&UV
gal/day gal/day ∙∙
∙∙
gal/min gal/min
UF UF&UV
240(W) X 410(D) X 400(H)mm <9.4(W) X 16.1(D) X 15.7(H)inch>
12(26.5 lb)
0.14-0.83MPa(20-120psi) 0.10-0.83MPa(15-120psi)
6.5(14.3 lb)
Dimension
Working Temperature
Net Weight
Working Pressure
P-07FU P-07FUV
Rated Service Flow
41-95℉(5-35)
Production Rate
Filtration method
Power Supply
Voltage rating that matches it on the rating plate.

28
Warranty Information
Other Cautions for Safety
29
WATER FLOW DIAGRAM
WARRANTY INFORMATION
Product Guarantee
Parts and components shall be replaced free of charge within the guarantee period if
the defects occur due to manufacturing defects in normal operation.
Contact us in case of breakdown.
In the following cases, repair work shall be charged even within the guarantee period.
▶Breakdown caused by careless operation or unreasonable repair and renovation.
▶Breakdown caused by nonperformance of the instructions specified in the manual.
Even after the expiration of guarantee period, it is possible to apply for charged repair.
Present this Letter of Guarantee whenever repair is needed.
This Letter of Guarantee is valid only in domestic where you buy this product.
Keep this Guarantee carefully as it is not re-issued.
Please contact our customer's service center in case you are not satisfied with our A/S service.
● Nationwide Periodical Inspection and Filter Replacement Call : 213-480-1600
● Nationwide A/S Call : 213-480-1600
● Customer Counseling Center Call : 213-480-1600 Fax :
In case any other filters or parts which are not genuine
products of we are used, we is not responsible for any
problems related to water quality.
☞
Model P-07FR/RV/U/UV
1 year
Guarantee Period
Serial No.
Date of Purchase
Guarantee Period From To
Customer’s Address
Customer’s Name Tel.
Coway Co., Ltd
658, Yugu-Ri, Yugu-Eub, Gongju-Si, Choongchungnam-Do, Korea
Tel : [phone] Fax : [phone]
www.coway.com
1.
2.
3.
4.
5.
6.
7.
▶P-07FRV
Neo-Sense
Post-Carbon
Membrane(UF)
LPS
Purified Water
Stem
Elbow
Bulk Head
(1/4)
Feed Water
Regulator
HPS
Reducer
(1/4+3/8)
Bulk Head(1/4)
UV Lamp
▶P-07FUV
Neo-Sense
Membrane(Ro)
Fine Post-carbon
Feed Water
Disposed Water
Purified Water
HPS_F
Booster
Pump
Feed V/V
Feed V/V
Check
Fitting(3/8)
LPS
Bulk Head(1/4)
HPS_E
Bulk Head(1/4)
Reducer
(1/4+3/8)
Bulk Head
(3/8)
Stem Elbow
UV Lamp

30
Other Cautions for Safety
31
MEMO
