User Manual /IBR1100/IBR1150 7/15/16
COR Series
Router
IBR1100 / IBR1150
User Manual
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 2
User Manual /IBR1100/IBR1150 7/15/16
TABLE OF CONTENTS
INTRODUCTION 4
WHAT’S IN THE BOX 4
KEY FEATURES 4
WAN 4
LAN 4
WIFI1
MANAGEMENT 4
VPN AND ROUTING 5
SECURITY 5
CLOUD OPTIMIZED IP COMMUNICATIONS 5
SPECIFICATIONS 6
ACCESSORIES 7
BUSINESS-GRADE MODEM SPECIFICATIONS 9
HARDWARE 11
POWER/GPIO CONNECTOR 12
RS-232 (SERIAL PORT) 12
DUAL MODEM DOCK INSTALLATION INSTRUCTIONS 13
DUAL MODEM DOCK HARDWARE AND DIMENSIONS 15
LEDS 16
SUPPORT AND WARRANTY 16
QUICK START 17
BASIC SETUP 17
ACCESSING THE ADMINISTRATION PAGES 18
FIRST TIME SETUP WIZARD 18
USING ENTERPRISE CLOUD MANAGER 19
ADMINISTRATION PAGES 20
QUICK LINKS 20
DASHBOARD 20
CONNECTION MANAGER 21
WAN INTERFACE PROFILES & PRIORITY 21
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 3
User Manual /IBR1100/IBR1150 7/15/16
STATUS 25
INTERNET 25
CLIENT LIST 30
TUNNELS 30
FIREWALL 31
ROUTING 32
ETHERNET 32
GPS 32
SYSTEM LOGS 32
NETWORKING 33
LOCAL NETWORKS 33
VLAN INTERFACES 44
TUNNELS 44
ROUTING 57
QOS 67
DNS SERVERS 70
WIFI AS WAN 72
WAN AFFINITY 74
CLIENT DATA USAGE 75
NHRP 76
SECURITY 78
IDENTITIES 78
ZONE FIREWALL 79
CONTENT FILTERING 84
CERTIFICATE MANAGEMENT 87
SYSTEM 90
ADMINISTRATION 90
ENTERPRISE CLOUD MANAGER 99
DEVICE ALERTS 100
SERIAL REDIRECTOR 101
GPIO CONFIGURATION 101
SNMP CONFIGURATION 102
SYSTEM CONTROL 104
DIAGNOSTICS 106
SETUP WIZARDS 107
APPENDIX 110
SAFETY, REGULATORY, AND WARRANTY GUIDE 110
ROUTER COMMUNICATION/DATA USAGE 112
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 4
User Manual /IBR1100/IBR1150 7/15/16
INTRODUCTION
WHAT’S IN THE BOX
KEY FEATURES
• Ruggedized router with integrated business-class 3G/4G modem; includes integrated mounting plate
• Two meter locking power and GPIO cable (direct wire)
• Quick Start Guide with warranty information
NOTE: Due to the diverse needs of customers, the COR IBR1100/IBR1150 package does not include a power adapter or
antennas. See the Accessories section below for several power and antenna options.
WAN
• Dual-modem capable with optional IBR1100/IBR1150 Dual-Modem Dock
• LP6: LTE Advanced LTE/HSPA+ (SIM-based Auto-Carrier Selection for all North American and European carriers)
• LPE: 4G LTE/HSPA+/EVDO (multi-carrier)
• LP3: 4G LTE/HSPA+ (Europe, EMEA, and Australia/New Zealand)
• WiFi as WAN¹, with WPA2 Enterprise Authentication for WiFi-as-WAN³
• Failover/Failback
• Load Balancing
• Advanced Modem Failure Check
• WAN Port Speed Control
•
• IP Passthrough
• Standby
LAN
• VLAN 802.1Q
• DHCP Server, Client, Relay
• DNS and DNS Proxy
• DynDNS
• UPnP
• DMZ
• Multicast/Multicast Proxy
• QoS (DSCP and Priority Queuing)
• MAC Address Filtering
WIFI1
• Dual-Band Dual-Concurrent
• 802.11 a/b/g/n/ac
• Up to 128 connected devices (64 per radio – 2.4 GHz and 5 GHz)
• Multiple SSIDs: 2 per radio (4 total)
• WPA2 Enterprise (WiFi)
• Hotspot/Captive Portal
• SSID-based Priority
•
MANAGEMENT
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 5
User Manual /IBR1100/IBR1150 7/15/16
• Cradlepoint Enterprise Cloud Manager²
• Web UI, API, CLI
• Active GPS support on all models
• Data Usage Alerts (router and per client)
• Advanced Troubleshooting (support)
• Device Alerts
• SNMP
• SMS control
• Serial Redirector
• Auto APN Recovery
VPN AND ROUTING
•
• L2TP³
• GRE Tunnel
• OSPF/BGP/RIP³
•
• Per-Interface Routing
• Routing Rules
• Policy-based Routing
• NAT-less Routing
• Virtual Server/Port Forwarding
• NEMO/DMNR³
• IPv6
• VRRP³
• STP³
• NHRP³
• VTI Tunnel support
• OpenVPN support
• CP Secure VPN compatible
• Serial PAD Mode
SECURITY
• RADIUS and TACACS+ support*
• 802.1x authentication for Ethernet
• Zscaler integration³
•
• ALGs
• MAC Address Filtering
• Advanced Security Mode (local user management only)
• Per-Client Web Filtering
• IP Filtering
• Content Filtering (basic)
• Website Filtering
• Zone-Based Object Firewall with host address (IP or FQDN), port, and mac address
*-Native support for authentication. Authorization and accounting support through hotspot/captive portal services.
CLOUD OPTIMIZED IP COMMUNICATIONS
• Automated WAN Failover/Failback support
•
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 6
User Manual /IBR1100/IBR1150 7/15/16
SPECIFICATIONS
WAN:
• Dual-modem capable with optional IBR1100/IBR1150 Dual-Modem Dock
• Integrated LP6 Category 6 LTE Advanced LTE modem (with DC-HSPA+ failover) or LPE 4G LTE modem (with HSPA+/
EVDO/3G and 2G failover) or LP3 4G LTE modem (with HSPA+ and 2G failover)
• Three LAN/WAN switchable 10/100 Ethernet ports – one default WAN (cable/DSL/T1/satellite/Metro Ethernet)
• WiFi as WAN, Metro WiFi; 2x2 MIMO “N” 2.4 GHz or 5 GHz; 802.11 a/b/g/n/ac (IBR1100 only)
LAN:
• Dual-band dual-concurrent WiFi; 802.11 a/b/g/n/ac (IBR1100 only)
• Three LAN/WAN switchable 10/100 Ethernet ports – two default LAN
• Serial console support for out-of-band management of a connected device
PORTS:
• Power
• 2-wire GPIO
• Add three more GPIO ports with optional Serial-to-GPIO cable (see Accessories section below)
• USB 2.0
• Three Ethernet LAN/WAN
• Two cellular antenna connectors (SMA)
• One active GPS antenna connector (SMA)
• Two WiFi antenna connectors (R-SMA)
• Serial DE-9 (commonly called “DB-9”) connector – RS-232 (out-of-band management of an external device
requires a null modem adapter/cable)
TEMPERATURE:
•
•
•
HUMIDITY (non-condensing):
• 5% to 95% operating
• 5% to 95% storage
POWER:
• DC input steady state voltage range: 9–36 VDC (requires inline fuse for vehicle installations)
• For 9–24 VDC installations, use a 3 A fuse
• For > 24 VDC installations, use a 2.5 A fuse
• Reverse polarity and transient voltage protection per ISO 7637-2
• Ignition sensing (automatic ON and time-delay OFF)
• Advanced VPN connectivity options to HQ
•
• MAC Address Filtering
• 802.1p/q for LAN QoS segmentation and treatment of VoIP on LAN
• Private Network support (wired and 4G WAN)
• Cloud-based management²
1 – WiFi-related functions are only supported on IBR1100 models
2 – Enterprise Cloud Manager requires a subscription
3 – Requires an Extended Enterprise License
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 7
User Manual /IBR1100/IBR1150 7/15/16
• Power consumption:
• Idle: typical=400mA@12VDC (4.8W); worst case=800mA@12VDC (9.6W)
• Tx/Rx: typical=650mA@12VDC (7.8W); worst case=1300mA@12VDC (15.6W)
• 12VDC 2A adapter recommended
WIFI POWER:
• 2.4 GHz band: 17 dBm conducted
• 5 GHz band: 15 dBm conducted
SIZE: 5.3 x 4.4 x 1.4 in (134 x 112 x 35 mm)
WEIGHT: 16.1 oz (457 g)
CERTIFICATIONS:
• FCC, CE, IC
•
• Safety: UL/CUL, CB Scheme, EN60950-1
• Hazardous Locations: Class I, Div. 2
• Shock/Vibration/Humidity: compliant with MIL STD 810G and SAEJ1455
• Ingress Protection: compliant with IP64 (includes protection from dust and splashing water)
• Materials: WEEE, RoHS, RoHS-2, California Prop 65
• Vehicle: E-Mark, compliant with ISO 7637-2
• Telecom: PTCRB/CTIA, GCF-CC
GPS
• GPS Protocols: TAIP and NMEA 0183 V3.0
• Satellite channels: Maximum 30 channels (16 GPS, 14 GLONASS), simultaneous tracking
• Concurrent standalone GPS, GLONASS, BeiDou and Galileo (LP6 models only)
• 1 Hz refresh rate
• Accuracy:
• < 2m: 50%
• < 5m: 90%
• Horizontal: < 2m (50%); < 5m (90%)
• Altitude: < 4m (50%); < 8m (90%)
• Velocity: < 0.2 m/s
• Acquisition (measured with signal strength = -135dBm):
• Hot start: 1 second
• Warm start: 29 seconds
• Cold start: 32 seconds
• Sensitivity
•
an in-view satellite 50% of the time when in sequential tracking mode)
•
device can still detect an in-view satellite 50% of the time)
• Operational limits: altitude < 6000 m or velocity < 100 m/s (either limit may be exceeded, but not both)
ACCESSORIES
Because of the diversity of customer needs, the COR IBR1100/IBR1150 does NOT include a power adapter or antennas
options for dual-modem capability, power and antennas:
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 8
User Manual /IBR1100/IBR1150 7/15/16
DUAL-MODEM DOCK
IBR1100/IBR1150 Dual-Modem Dock (Part # 170675-000), FirstNet/Band 14 ready
integrated 4G LTE modem:
• MC400LP6 (North America, Europe)
• MC400LPE-VZ (Verizon)
• MC400LPE-AT (AT&T)
• MC400LPE-SP (Sprint)
• MC400LPE-GN (generic – for use on T-Mobile in the U.S. and Rogers, Bell, & TELUS in Canada)
• MC400LP3-EU (Europe)
POWER
Wall options
•
line cord (Part # 170648-000)
• Line cord for North America (Part # 170623-001)
• Line cord for EU (Part # 170623-002)
• Line cord for UK (Part # 170623-003)
•
170584-002)
NOTE: Cradlepoint primarily recommends the extended temperature adapter because it covers the COR IBR1100/
IBR1150 full temperature range of −30 °C to 70 °C. Cost-sensitive customers that intend to use the IBR1100/IBR1150 in
temperature-controlled office environments can order the 170584-002 adapter, but it limits the operating temperature
range to 0 °C to 40 °C.
Vehicle options
• Vehicle locking power adapter for COR (Part # 170635-000)
• Two meter locking power and GPIO cable (direct wire) for replacement – included by default (Part # 170585-000)
Adapters
• Barrel to 4-pin power adapter (Part # 170665-000)
• Serial-to-GPIO cable (Part # 170676-000)
ANTENNAS – 3G/4G Modem, WiFi, & GPS
• 700 MHz – 2700 MHz Wide Band Directional Antenna (Yagi/Log- Periodic) Part #: 170588-000
• 12” Mag-Mount Antenna with SMA Male Connector Part #: 170605-000
• 4” Mini Mag-Mount Antenna with SMA Male Connector Part #: 170606-000
• 2.4/5 GHz Dual-band Dual-concurrent WiFi Antenna Part #: 170628-000 (WiFi models only)
• Universal 3G/4G/LTE Modem Antenna Part #: 170649-000
• GPS Screw-Mount Antenna Part #: 170651-000
• GPS Mag-Mount Antenna Part #: 170652-000
• Multi-Band Omni-Directional Antenna Part #: 170668-000
• Indoor/Outdoor Panel Patch Part #: 170669-000
Vehicle Antennas
• 3-in-1 GPS & Modem Screw-Mount Part #: 170653-000
• 3-in-1 Adhesive-Mount Antenna Part #: 170653-001
• 5-in-1 GPS, Modem & WiFi Screw-mount Part #: 170654-000
•
001
See the Cradlepoint antenna accessories page for more information about antennas. Also see the Antenna Ordering
and Installation Guide, available as a PDF in the Resources section of antenna and router product pages.
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 9
User Manual /IBR1100/IBR1150 7/15/16
BUSINESS-GRADE MODEM SPECIFICATIONS
COR IBR1100/IBR1150 LP6 models include an integrated LTE Advanced Category 6 4G LTE modem. The LP6 modems
support SIM-Based Auto-Carrier selection so there is only one model for all of North America. Simply insert the SIM
and wait for the router to automatically detect the SIM and establish a connection.
COR IBR1100LP6-NA, COR IBR1150LP6-NA, COR IBR1100LP6-EU
• Technology: LTE Advanced, HSPA+
• Downlink Rates: LTE 300 Mbps, HSPA+ 42.2 Mbps
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps
• Frequency Bands:
• LTE Bands 1-5, 7, 8, 12, 13, 17, 20, 25, 26, 29, 30, 41
• Verizon: 2, 4, 5, 13 (XLTE support w/carrier aggregation)
• AT&T: 2, 4, 5, 12/17, 29, 30
• Sprint: 25, 26, 41 (LTE Plus Support)
• T-Mobile: 2, 4, 12 (T-Mobile Wideband LTE Support)
• Carrier Aggregation:
• 1+ 8
• 2+ 2/5/12 (17 w/MFBI)/13/29
• 3+ 7/20
• 4+ 4/5/12 (17 w/MFBI)/13/29
• 5+ 2/4/30
• 7+ 3/7/20
• 8+ 1
• 12 (17 w/MFBI) + 2/4/30
• 13+ 2/4
• 20+ 3/7
• 30+ 5/12 (17 w/MFBI)
• 41+ 41
• Fallback: WCDMA/DC-HSPA+ (42/5.76 Mbps): Bands 1, 2, 3, 4, 5, 8
• Power:
• Antennas:
• GPS: active GPS support
• SMS: SMS support
• Industry Standards & Certs: CE, FCC, GCF-CC, IC, PTCRB, AT&T, Sprint, Verizon
COR IBR1100/IBR1150 LPE models
modem (e.g., the COR IBR1100LPE-VZ includes a Verizon LTE modem).
frequency bands in bold below are supported by the listed provider.
COR IBR1100LPE-VZ, COR IBR1150LPE-VZ – 4G LTE/HSPA+/EVDO for Verizon
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
• Antennas:
• GPS: active GPS support
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 10
User Manual /IBR1100/IBR1150 7/15/16
• Industry Standards & Certs: FCC, Verizon
COR IBR1100LPE-AT, COR IBR1150LPE-AT – 4G LTE/HSPA+/EVDO for AT&T
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
• Antennas:
• GPS: active GPS support
• Industry Standards & Certs: PTCRB, FCC, IC, AT&T
COR IBR1100LPE-SP, COR IBR1150LPE-SP – 4G LTE/HSPA+/EVDO for Sprint
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 – AWS (1700/2100 MHz), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700
MHz), Band 25 (1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
• Power:
• Antennas:
• GPS: active GPS support
• Industry Standards & Certs: FCC, Sprint
COR IBR1100LP3-EU, COR IBR1150LP3-EU – 4G LTE/HSPA+ for Europe
• Technology: LTE, HSPA+
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps (theoretical)
• Frequency Bands:
• LTE Band 1 (2100 MHz), Band 3 (1800 MHz), Band 7 (2600 MHz), Band 8 (900 MHz), Band 20 (800 MHz)
• HSPA+/UMTS (800/850/900/1900/2100 MHz)
• GSM/GPRS/EDGE Quad-Band (850/900/1800/1900 MHz)
• Power:
• Antennas:
• GPS: active GPS support
• Industry Standards & Certs: CE, GCF-CC
COR IBR1100LPE-GN, COR IBR1150LPE-GN – 4G LTE/HSPA+/EVDO (generic – for use on T-Mobile and U.S. Cellular in
the U.S. and Rogers, Bell, & TELUS in Canada)
• Technology: LTE, HSPA+, EVDO Rev A
• Downlink Rates: LTE 100 Mbps, HSPA+ 21.1 Mbps, EVDO 3.1 Mbps (theoretical)
• Uplink Rates: LTE 50 Mbps, HSPA+ 5.76 Mbps, EVDO 1.8 Mbps (theoretical)
• Frequency Bands:
• LTE Band 2 (1900 MHz), Band 4 (AWS), Band 5 (850 MHz), Band 13 (700 MHz), Band 17 (700 MHz), Band 25
(1900 MHz)
• HSPA+/UMTS (850/900/1900/2100 MHz, AWS)
• GSM/GPRS/EDGE (850/900/1800/1900 MHz)
• CDMA EVDO Rev A/1xRTT (800/1900 MHz)
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 11
User Manual /IBR1100/IBR1150 7/15/16
WiFi Antenna Connector*
(Reverse SMA)
USB 2.0
Port
LAN or WAN Default: WAN
10/100 Ethernet Ports
Default: LAN)
Power Port
WiFi Antenna Connector*
(Reverse SMA)
* - only on IBR1100
HARDWARE
3G/4G Antenna
Connector (SMA)
3G/4G Antenna Connector
(SMA)
RS-232 Port
(female)
Reset
Button
GPS Connector (SMA)
• Power:
• Antennas:
• GPS: active GPS support
• Industry Standards & Certs: PTCRB, FCC, IC
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 12
User Manual /IBR1100/IBR1150 7/15/16
POWER/GPIO CONNECTOR
This connector has four pin slots: power, ground, input, and output.
Connector pinout – view into router (rear view of cable connector):
Pin Denition Details Wire Color
1 Ground - Black
2Power 9-36V DC Red
3 Input 3V input high threshold (36V tolerant) Orange
4 Output capable of sinking 250 mA Blue
RS-232 (SERIAL PORT)
This is a serial DE-9 (commonly called “DB-9”), 9-pin female connector of a modem or DCE form. Normally, you use a
M-to-F straight through cable to a male DTE port, such as those commonly found on a computer or network device.
The pins are numbered from the top right as shown here:
Pin Name Direction (relative to IBR1100/IBR1150)
1 DCD out
2 TX out
3 RX in
4 DSR in
5 GND N/A
6DTR out
7 CTS in
8RTS out
9 RI out
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 13
User Manual /IBR1100/IBR1150 7/15/16
1. Remove modem door (D) from dock (A).
2. Insert activated SIM(s) into MC400 modem (B).
3. (Optional - for moisture/dust resistance) Place one o-ring (C) onto each antenna connector.
4. Slide MC400 modem (B) into modem dock (A).
5. Attach modem door (D) using M3 screws (E).
6.
of the router (F) into the guide rails(s) of the dock (A).
DUAL MODEM DOCK INSTALLATION INSTRUCTIONS
Router mounting flange
Dock guide rail
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 14
User Manual /IBR1100/IBR1150 7/15/16
7. Fully seat USB connectors and align router/dock holes.
8. For new installations: Secure router to dock using four M5x8 screws (G), then secure dock to mounting
surface using four mounting screws (H) (not supplied). Skip to step 10. For high-vibration environments,
Cradlepoint recommends using thread locker.
9. For existing installations: Secure router to dock and mounting surface using four M5x40 screws (I). For
high-vibration environments, Cradlepoint recommends using thread locker or nylon lock nut.
10. Attach included or accessory antennas.
NOTE: Do not place IBR1100/IBR1150 antennas and MC400 antennas immediately adjacent. Cradlepoint recommends
remotely attaching one or both sets of antennas.
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 15
User Manual /IBR1100/IBR1150 7/15/16
DUAL MODEM DOCK HARDWARE AND DIMENSIONS
Top view Bottom view
Rear view
Front view
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 16
User Manual /IBR1100/IBR1150 7/15/16
CradleCare Support available in the US and Canada with technical support, software upgrades, and advanced hardware
exchange – 1-, 3-, and 5-year options.
Three-year limited hardware warranty available world-wide on IBR1100/IBR1150 series products when purchased from
an approved Cradlepoint Partner or Distributor – extend warranty to 5 years.
SUPPORT AND WARRANTY
LEDS
SIGNAL STRENGTH Blue LED bars indicate the active modem’s signal strength.
• 4 Solid Bars = Strongest signal.
• 1 Blinking Bar = Weakest signal. (A blinking bar indicates half of a bar.)
POWER
The Cradlepoint IBR1100/IBR1150 must be powered using an approved 9-36 VDC power
source.
• Blue = Powered ON.
• No Light = Not receiving power. Check the power switch and the power source connection.
• Flashing Amber = Attention. Open the administration pages and check the router status.
WiFi BROADCAST These two LEDs indicate activity on the WiFi broadcast for both the 2.4
GHz and 5 GHz bands.
• 2.4GHz (green) = 2.4 GHz WiFi is on and operating normally.
• 5GHz (blue) = 5 GHz WiFi is on and operating normally.
EXTERNAL USB MODEM Indicates the status of external USB modem.
Both internal and external USB modems have the following LED indicators:
• Green = Modem has established an active connection.
• Blinking Green = Modem is connecting.
• Amber = Modem is not active.
• Blinking Amber = Data connection error. No modem connection possible.
• Blinking Red = Modem is in the process of resetting.
ADDITIONAL LED INDICATIONS
•
•
upgrade.
EC
2.4GHz
5GHz
INTEGRATED MODEM
Indicates information about the integrated modem.
• Green = Connected to integrated modem.
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 17
User Manual /IBR1100/IBR1150 7/15/16
QUICK START
BASIC SETUP
1. Insert an activated SIM
A wireless broadband data plan must be added to your Cradlepoint IBR1100. Wireless broadband data plans are
available from wireless carriers such as Verizon, AT&T, Sprint, EE, and Vodafone. The SIM must be provisioned
with the carrier. Contact your carrier for details about selecting a data plan and about the process for
provisioning your SIM.
Once you have an activated SIM, insert it into the integrated modem. Insert the SIM card into the slot marked
SIM 1 (use the other slot, SIM 2, for a secondary/backup SIM).
To insert or remove SIM card:
1. Remove bottom SIM cover.
2. Slide metal latch down to unlock.
3.
4. Insert SIM card with metal contacts down and notch out.
5. Press cartridge back into place.
6. Return metal latch to start (lock) position.
7. Replace bottom SIM cover.
Note: Device will not power on without cover in place.
2. Attach the WiFi and modem antennas
Attach the three WiFi antennas (included) and two modem antennas to the connectors. Antennas are jointed,
which enables you to position them for optimal signal. To attach, hold the antenna straight and twist the base
of the antenna to connect, folding the joint if needed. NOTE: Ensure that the router antennas are not near metal
or other RF reflective surfaces.
3. Connect to power source
Wire power cable to 9-36v power source. (AC power supply sold separately.)
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 18
User Manual /IBR1100/IBR1150 7/15/16
ACCESSING THE ADMINISTRATION PAGES
changes to your router.
1. Open a browser window and type “cp/” or “192.168.0.1” in the address bar. Press ENTER/RETURN.
2. When prompted for your password, type the eight character DEFAULT PASSWORD found on the product
label.
NOTE: The product label below is an example only: your DEFAULT PASSWORD and SSID will be unique.
Enterprise Cloud
Manager (ECM) without logging into the local administration pages. Set up a group of routers and set the
below for more information about ECM.
FIRST TIME SETUP WIZARD
FIRST TIME SETUP WIZARD, which
the following:
• Administrator Password
• Time Zone
• WiFi Network Name
• Security Mode
• Access Point Name (APN) for SIM-based modems
• Modem Authentication
• Failure Check
If you are currently using the router’s WiFi network, you will need to reconnect your devices to the network
using the newly established wireless network name and password.
NOTE: To return to the First Time Setup Wizard after your initial login, select SYSTEM from the navigation bar,
expand Setup Wizard,and select First Time Setup.
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 19
User Manual /IBR1100/IBR1150 7/15/16
USING ENTERPRISE CLOUD MANAGER
Rapidly deploy and dynamically manage networks at geographically distributed stores and branch locations with
Enterprise Cloud Manager, Cradlepoint’s next generation management and application platform. Enterprise Cloud
Manager (ECM) integrates cloud management with your Cradlepoint devices to improve productivity, increase
reliability, reduce costs, and enhance the intelligence of your network and business operations.
Click here to sign up for a free 30-day ECM trial.
Depending on your ordering process, your devices may have already been bulk-loaded into ECM. If so, simply
log in at cradlepointecm.com using your ECM credentials and begin managing your devices seamlessly from the
cloud.
If your device has not yet been loaded into your ECM account, you need to register. Log into the device
administration pages and select Enterprise Cloud Manager from the SYSTEM menu. Enter your ECM username
and password, and click on “Register”.
Once you have registered your device, go to cradlepointecm.com and log in using your ECM credentials.
For more information about how to use Cradlepoint Enterprise Cloud Manager, see the following:
• Getting Started
• ECM on the Knowledge Base
©2016 Cradlepoint. All Rights Reserved. |+1.855.813.3385 |cradlepoint.com 20
User Manual /IBR1100/IBR1150 7/15/16
ADMINISTRATION PAGES
Quick Links
Dashboard
Connection Manager
Status
Networking
Security
System
QUICK LINKS
DASHBOARD
The Dashboard is a centralized location
for basic information about the status of
your router. The areas include:
• Device Information
• Ethernet WAN*
• Modems*
• WWAN*
• Ethernet LAN*
• WiFi LAN*
*-To quickly edit settings for any of
these areas, click on the pencil icon ( ) in
the top-right of the desired dialog box.
You may return to the Dashboard at
any time by clicking on DASHBOARD
from the left menu or by clicking on the
Cradlepoint logo at the top-left of the
screen.
Quick Links allows you to bookmark your most commonly-used settings. Simply click on the bookmark icon ( )
to add an item to your Quick Links menu. To remove an item from your Quick Links menu, select the item and
click on the remove bookmark icon ( ).
Quick Links Menu Add Quick Link Delete Quick Link
Other manuals for COR IBR1100 series
3
This manual suits for next models
3
Table of contents
Other Cradlepoint Network Router manuals
Cradlepoint
Cradlepoint 5G Internet Kit User manual
Cradlepoint
Cradlepoint COR IBR600C Series User manual
Cradlepoint
Cradlepoint AER1600 Series User manual
Cradlepoint
Cradlepoint MBR1400 Series User manual
Cradlepoint
Cradlepoint AER1600 Series User manual
Cradlepoint
Cradlepoint R1900 Series User manual
Cradlepoint
Cradlepoint MBR1400 Series User manual
Cradlepoint
Cradlepoint AER3100 Series User manual
Cradlepoint
Cradlepoint CRADLEPOINT IBR650 User manual
Cradlepoint
Cradlepoint MBR900 User manual
Cradlepoint
Cradlepoint IBR600E User manual
Cradlepoint
Cradlepoint COR IBR350 User manual
Cradlepoint
Cradlepoint COR Series User manual
Cradlepoint
Cradlepoint CBR400 User manual
Cradlepoint
Cradlepoint ARC SERIES User manual
Cradlepoint
Cradlepoint COR IBR1700 Series User manual
Cradlepoint
Cradlepoint E102-C7C User manual
Cradlepoint
Cradlepoint E110 User manual
Cradlepoint
Cradlepoint CBR400 User manual
Cradlepoint
Cradlepoint S700 Series User manual
