Create WIND FOLD User manual

1ENGLISH
WIND FOLD
CEILING FAN WITH LIGHT
MANUAL ASSEMBLY

4
EN
To download this user guide in your language, visit our website:
www.create-store.com/uk
ES
Para descargar el manual en su idioma, visite nuestra web:
www.create-store.com/es
PT
Para baixar o manual no seu idiomas, visite nosso site:
www.create-store.com/pt
FR
Pour télécharger le manuel dans votre langue, visitez notre site Web:
www.create-store.com/fr
IT
Per scaricare il manuale nella sua lingua, visitare il nostro sito Web:
www.create-store.com/it
DE
Um das Handbuch in Ihrer Sprachen herunterzuladen, besuchen Sie unsere
Website:
www.create-store.com/de
NL
Bezoek onze website om de handleiding in uw taal te downloaden:
www.create-store.com/nl
PL
Aby pobrać instrukcję w swoim języku, odwiedź naszą stronę internetową:
www.create-store.com/pl
WIND FOLD

5
INDEX
Box contents 6
Step 1. Wood roof 7
Step 1. Concrete ceiling 8
Step 1. False ceiling 10
Choice of grab bar 11
Step 2. Blade assembly 13
Step 3. Assembly of the main body 15
Step 4. Driver connection 16
Step 5. Fitting the trim 19
Step 6. Led board connection 20
Step 7. Placement of la tulipa 21
Blade balancing kit 22
WIND FOLD

6ENGLISH
A B
E
I J K L
Q
F
C D
M N
G H
R
BOX CONTENTS
(1) EXPANSION SCREWS
FLOWER
EMBELLISHER
O
TERMINALS
SPLICE
P
BALANCING KIT SUPPORT
BLADES
EMBELLISHER
ENGINE
BLADE SCREWS
(x3) BLADES
SHANK EXTENSION POST MOUNTING BRACKET
TULIPA
DRIVER
ENGINE
REMOTE CONTROL LED PLATE
SCREWS FOR
TRIM + ENGINE
(2) WOOD SCREWS
ATTENTION! Before starting the as-
sembly, remember to disconnect the
light from the electrical panel so as
not to suffer an electric shock.

7ENGLISH
K
STEP 1. WOOD ROOF
+ +
(2) WOOD SCREWS
OPTIONAL
ACCORDING TO TYPE OF ROOF
M
x4
1
3
5 6
4
If necessary, depending on the type of
roof, you will need to use a drill to make the
hole in the wood.
Repeat this step on all 3 holes
remaining.
Place the washer and then the
screw M2.
With the help of the screwdriver tighten
the screws M2.
Make sure the part K It is perfectly hooked
to the ceiling and that no cable is trapped.
Mark with a pencil the 4 holes of the piece
Kin the roof.
K
PARTS AND TOOLS
M2
M2
MATERIAL NOT INCLUDED
2
K
SUPPORT OF
MOUNTING

8ENGLISH
STEP 1. CONCRETE CEILING
(1) EXPANSION SCREWS
With the help of a drill, make the two cor-
responding holes with a Ø8 mm drill bit.
Mark with a pencil the 2 central holes of
the piece K on the ceiling using the same
piece as a guide.
K
M1 M2
M1 M2 M3 M4
disassemble the part Mseparating it into pieces.
M
+ +
MK
PARTS AND TOOLS
MATERIAL NOT INCLUDED
Ø8mm
1
3
2
4
Only the thread part should protrude.place the pieces M1 in the holes in the ceil-
ing.
SUPPORT OF
MOUNTING

9ENGLISH
place the piece Kmatching their holes
with the screws M1. Make sure the ceiling
cables are on one side of the piece K.
M1 K
K
M4
5
7 8
6
Enter the part in order M2, M3 and then
the nut M4.
Tighten the part M4 with a No. 10 wrench,
until you feel it's ok
xed.
Make sure the part K It is perfectly hooked
to the ceiling and
no cable gets caught.
M2
M3
M4

10 ENGLISH
+ ++
PARTS AND TOOLS
STEP 1. FALSE CEILING
FIXING SCREWS
WITH SPRING LEVER
SUPPORT OF
MOUNTING
MATERIAL NOT INCLUDED
Make sure the part Kis perfectly attached
to the ceiling to be able to continue with
the assembly.
With the help of a drill, make the 2 corre-
sponding holes.
Insert the xing screws into the holes and
make sure that the lever opens.
place the piece K and screw the xing
screws to the false ceiling.
Mark the 2 central holes of the piece on
the ceiling with a pencil Kusing the same
piece as a guide.
K
X
3
5
4
2
K
K
1

11ENGLISH
CHOICE OF GRAB BAR
+
1
4
7 8 9
2
5
3
6
I
I
J
J
J
J
+
TILT SUPPORT
IBefore you start, choose the desired height.
(10cm+/-)
You will have to choose between the height of the
piece Iwave J.
· If you choose the height of the piece J, You must
follow the instructions below.
· If you choose the height of the piece I, go directly
to step 2 (page 12).
Using a screwdriver, remove the two screws on the bar tilt
bracket I.
Slide the tilt stand down.
Remove the pin from the tilt
bracket.
Carefully pull the pin out of
the bar I.
Attach the tilt bracket to
the bar J.
Place the pin of the tilt sup-
port on the bar J.
Pull out the bracket
bar tilt I.
Pull out the bar pin locking
piece I.

12 ENGLISH
10
13 14
11 12
J
J
J
J
I
Snap the tilt bracket onto
the pin.
Tighten the two screws on
the tilt bracket with the
screwdriver.
Put the pin back in the piece
J.
Secure the pin with the
locking piece so that it does
not come out.
The piece is already J ready
to use.

13ENGLISH
STEP 2. BLADE ASSEMBLY
+ + + +
E Q R
(x3)
BLADES
1
4
7
2
5
8
3
6
9
H
Start by removing the engine bolts. H, if your screws Qare in a plastic bag, go to step 4.
Q
Remove the blade support bolts. Rand save them for the next step.
Start placing the blades Escrewing the screws Q from the bottom of the engine H, as shown
in the images. Remember to tighten the screws gradually.
(x7) SCREWS
BLADES
BLADE SUPPORT
H
ENGINE

14 ENGLISH
10
16
13
19
11
17
14
20
12
18
15
21
Once the rst blade is located Eand fasten the screws Qto the engine H, rotate the center
piece so that the driver cables are facing up.
Place the blade support Ron top of engine Hand below the blades E.
tighten the blade Ewith the screws you removed from the blade holder R.
Keep screwing the rest of the blades E just like the rst one did.

15ENGLISH
1
4
2
5
3
6
A
L
A
H
H
Remove the pin from the
part I/J, depending on the
chosen height.
Insert the seatpost I/J,through the hole in the part A.
Insert the seatpost I/J,
through the hole in the part
L.
Once the piece is inserted
AY L, you must insert the
cables of the part H inside
the bar. If you want, you can
secure the wires with elec-
trical tape to make it easier
to pass them through.
STEP 3. ASSEMBLY OF THE MAIN BODY
+ ++ O +
CHOOSE THE HEIGHT YOU NEEDFLOWER ENGINE
A I JH L
EMBELLISHER
ENGINE

16 ENGLISH
STEP 4. DRIVER CONNECTION
+ +
B
DRIVER
O
SPLICING TERMINALS
10 11
H
Put the locking piece on the
pin so that it does not come
out.
Then replace the two
screws so that the post is
fully attached.
Once the stem is well an-
chored to the piece H, the
main body of the fan motor
will be assembled.
12
H
7 8 9
H
Insert the seatpost into the
top of the piece H. Make
sure no wires get pinched.
Once the seatpost has been
inserted, place the pin of the
piece I/Jso that it matches
the hole in the seatpost.
With the help of a screw-
driver, remove the 2 screws
from the top of the piece H.

17ENGLISH
O
4
7
5
8 9
6
Join the part connections Bwith the connections of
engine, each with its corresponding color.
Once the cables are con-
nected, insert the part Bin-
side the piece K, As shown
in the picture.
Select and connect all
ground wires, including your
installation.
You will need to attach the
remaining wires from the
piece B. and the phase and
neutral cables of its instal-
lation in the strip of the
piece K, as it's shown in the
following.
Once connected, place the
part Oscrewing it on until it
is secure.
K
1 2 3
Put the tilt bracket into the
slot on the part K.
Remember to set the notch
on the tilt bracket back so
that the piece ts snugly.
Before continuing, check
that the central structure is
well placed so that it does
not fall.

18 ENGLISH
10 11 12
Connect the L cable of the
driver to the PHASE cable
of your installation.
Connect the N wire of the
driver to the NEUTRAL wire
of your installation.
Make sure everything is at-
tached correctly.
13 14 15
slide piece A upwards to t it on the protruding screws of
the piece K.
Once tted, turn the piece
Atoward the left. Make sure
no wires get pinched.
Finally, with the help of a screwdriver, tighten the screws so that the piece is well xed.
16 17 18
AK

19ENGLISH
STEP 5. FITTING THE TRIM
++
G N
Using a screwdriver, remove the 3 center screws from the
motor for later use. If these screws come in a sealed bag,
use them for this step.
Pass the fan cables through
the center hole of the piece
G.
Then rmly tighten the
screws used in step 1 so
that the part Gis properly
fastened.
1
4
2
5
7
6
3
G
G
place the piece Galigning
the holes with the holes in
the motor. Leave the blue
and white wires coming out
of the hole,
EMBELLISHER SCREWS FOR
EMBELLISHER

20 ENGLISH
D
Connect the part wires Dto those of the fan joining the connections, each cable with its
same color.
Then attach the part Dto the fan with the help of the magnets so that it stays in place.
1
4
2
5
3
6
D
D
DD
STEP 6. LED BOARD CONNECTION
LED PLATE
