Crestron UC-M70-U User manual

The UC-M70-U Crestron Flex tabletop conferencing system provides a
large room video conference solution for open-platform UC applications.
It supports a single video display and features a Crestron Flex tabletop
conference device and an AI collaboration camera.
In the Box
Tabletop Conference Device
1 Tabletop Conference Device (6508083)
1 Cable, CAT5e, RJ-45 - RJ-45, 12 ft (3.7 m) (2033988)
1 Cable Retention Plate (2047908)
3 Tie Wrap (2047935)
Additional Items
1 AI collaboration camera (6512296)
1 Microphone pod (6508084)
1 Cable, thin HDMI®, 6 ft (1.8 m) (6510946)
1 Cable, HDMI, 20 ft (6.1 m) (6503567)
1 Cable, USB 2.0, A - Micro-B, 6 ft (1.8 m) (6510947)
1 Cable, USB Extension, USB Type A Male-to-Female, 15 ft
(4.6m) (6508260)
1 IR Emitter Probe (6500940)
1 Power supply (6500187)
Install the Cable Retention Plate
The included cable retention plate provides tie-down points for cables
that connect to the Crestron® conference device.
Remove the adhesive backing from the cable retention plate and install
it on the underside of the conference device as shown in the following
diagram. Ensure the cable retention plate is firmly attached before
securing cables.
CAUTION: When turning over the device, place the device on a soft
surface to avoid damage.
NOTE: If a swivel mount kit (CCS-UCA-SMK) is to be used, use the
cable retention bracket included with the swivel mount kit as described
in the CCS-UCA-SMK DO Guide (Doc. 7882).
1
UC-M70-U QuickStart
Crestron Flex Tabletop Large Room Video Conference System

UC-M70-U QuickStart
Crestron Flex Tabletop Large Room Video Conference System
Connect
Make system connections as shown below.
2

Bundle Cables
Bundle the cables together and use a provided tie wrap to secure the
bundle to one of the positions on the cable retention plate at the rear of
the device. Avoid bundling power and data cables together.
Insert the included USB and HDMI cables into their respective cable
channels as labeled on the underside of the conference device and as
shown in the following image.
NOTES:
lWhen routing the USB and HDMI cables through the channels out
of the front of the device, the cables donot need to be bundled. If
the system design requires routing the USB and HDMI cables
through the rear of the device, the cables should be bundled and
secured to the cable retention plate.
lWhen using a swivel mount kit, do not route the USB and HDMI
cables through the swivel tube.
Configure
Configure the device using the web interface. To access the web
interface, enter the device's IP address into a web browser. Select the
gear icon in the upper right-hand corner of the screen and enter the
username ("admin") and password ("admin") when prompted.
NOTE: To find the device's IP address, tap the information icon on the
device's home screen.
For detailed configuration information, refer to the CCS-UC-1 Product
Manual (Doc. 7844).
UC-M70-U QuickStart
Crestron Flex Tabletop Large Room Video Conference System
3

Visit the Product Page
Scan the QR code to visit the product page.
UC-M70-U
www.crestron.com/model/6511603
