Crestron UC-C140-T User manual

The Crestron Flex UC Video Conference System Integrator Solution for
Microsoft Teams Rooms (UC-C140-T) delivers a powerful, professional
solution for knowledge workers who want the Microsoft Teams software
experience in small to midsize meeting and conference rooms.
The UC-C140-T allows the installer to select audio and camera hardware
dictated by the room while offering optional direct or network connection
methods between the included system components.
MinimumRequirements
lA video display, connected to the UC-ENGINE-SD
lA Microsoft Teams or Skype® for Business software account
NOTE: The account should be prepared two to three weeks in
advance of hardware installation.
lAn environment running Microsoft Exchange Server® software (2013
SP1 or later for on-premises installation or Microsoft 365™ software
for Cloud) for scheduling and/or Skype for Business 2015
(on-premises installation or Microsoft 365 software for Cloud)
lUSBCamera
lAEC-enabled USB speakerphone or DSP device
View the Crestron Flex Pre-Deployment Checklist to help plan your
Crestron Flex installation.
In the Box
UC Engine Bracket Assembly
1 UC-BRKT-100-SD-ASSY (6511033)
1 Power cord
Mounting Hardware
Touch Screen, 10.1 in., Black
1 TSW-1060-B-S (6507651)
1 Security Latch (4525305)
Mounting Hardware
Tabletop Kit for Touch Screen, Black
1 TSW-1060-TTK-B-S (6507729)
1 Template
Mounting Hardware
Accessories
1 PWE-4803RU, PoEInjector (6502429)
2 CBL-CAT5E-7, CAT5e cable, RJ-45-to-RJ-45, Black,
7 ft (2.1 m) (6509924)
1 CBL-HD-20, HDMI® cable 20 ft (6.1 m) (6503567)
1 CBL-USBC-HD-9, USB 3.0 to HDMI Converter cable,
9 ft (2.7 m) (6510718)
1
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

Overview
The following diagram illustrates standard system connections. Two optional connection methods are available — direct or network connection. Both
the direct connection and network connection methods are shown below to help determine the appropriate method for your solution. The room display,
camera, audio devices, and laptop are not included with this solution. See pages 4and 5for more information.
2
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

Connect
1. Remove the connector covers prior to making UC-ENGINE-SD
connections on the UC-BRKT-100-SD-ASSY bracket assembly.
2. Make connections to the TSW-1060-B-S touch screen and
UC-BRKT-100-SD-ASSY bracket assembly as shown in the following
illustrations.
The TSW-1060-B-S touch screen can communicate with the
UC-ENGINE-SD over a direct connection or a network connection.
Choose a direct connection to the UC-ENGINE-SD for simple
installation and setup, or a network connection if the TSW-1060-B-S
must be installed on the network and managed by the Crestron XiO
Cloud™ service.
3
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

Direct Connection
For simplified installation and configuration, use a direct Ethernet connection between the TSW-1060-B-S touch screen's PWE-4803-RU PoE
injector and the USB-to-RJ-45 Ethernet Adapter on the bottom of the UC-ENGINE-SD.
NOTE:Direct Connection does not allow Crestron XiO Cloud management of the TSW-1060-B-S. A network connection must be made as
shown on the following page.
4
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

Network Connection
Use the network connection for full network control of the TSW-1060-B-S touch screen with the Crestron XiOCloud service. The LAN port on the
TSW-1060-B-S touch screen's PoE injector connects to the UC-ENGINE-SD over the VLAN.
5
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

3. Connect the display device and camera to the UC-ENGINE-SD as shown below.
6
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

4. Bundle the cables with the integrated cable tie wraps. The cable tie
wraps are reusable.
Complete the Installation
After completing UC-ENGINE-SD connections, secure the connector
covers using a #1 Phillips head screwdriver to replace the screws.
NOTE: For additional security, replace the screws with the spanner
screws included with the bracket assembly. A 1/4 in. bit is also supplied
with the bracket assembly to install the spanner screws.
7
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

Configure
Apply Power
Press the power button on the bottom of the UC-ENGINE-SD and apply
power to all of the other devices in the system.
Configure the TouchScreen
NOTE:If the TSW-1060-B-S touch screen is directly connected to the
UC-ENGINE-SD via the PWE-4803-RU, perform steps 1 and 2 below,
and skip to "Configure the System."Otherwise, continue below.
1. Tap Touch Here to Enable a Specific Application on the bottom of the
TSW-1060-B-S touch screen. A list of applications is displayed.
2. Tap Teams Video, and then tap Confirm. The TSW-1060-B-S touch
screen will reboot.
3. On a computer, open a web browser to the IP address of the
TSW-1060-B-S touch screen. Log in and navigate to Settings >
Applications.
NOTES:
lThe TSW-1060-B-S touch screen (via the PW-4803RU) and
computer must be on the same network switch and VLAN.
lA login with administrative rights for the TSW-1060-B-S
touch screen is required.
4. Enter the following information in the appropriate fields:
lTeams Video PC Address: Enter the IP address or hostname of
the UC-ENGINE-SD.
NOTE: The hostname is printed on a label affixed to the
UC-ENGINE-SD (mounted on the UC-BRKT-100-SD-ASSY
bracket assembly).
lTeams Video PC Port: By default, port number 49500 is used. If
a different port number has been configured on the
UC-ENGINE-SD, enter that port number instead.
lTeams Video Username: Enter the login username for the
UC-ENGINE-SD. (The default username is “admin”.)
lTeams Video Password: Enter the login password for the
UC-ENGINE-SD. (The default password is “sfb”.)
5. Click Save Changes.
For more information, refer to the TSW-560/TSW-760/TSW-1060
Supplemental Guide (Doc. 7927).
Configure the System
Use the TSW-1060-B-S and your Microsoft Teams or Skype account
credentials to configure the UC-ENGINE. Refer to the Crestron Flex UC
Video Conference Systems Supplemental Guide (Doc. 8360).
8
UC-C140-T QuickStart
Crestron Flex UC Video Conference System Integrator Solution for Microsoft Teams® Rooms

Visit the Product Page
Scan the QR code to visit the product page.
UC-C140-T
www.crestron.com/model/6511499
