Crestron APAD User manual

Crestron APAD
WallMountLCDController
Operations & Installation Guide

This document was prepared and written by the Technical Documentation department at:
Crestron Electronics, Inc.
15 Volvo Drive
Rockleigh, NJ 07647
1-888-CRESTRON
All brand names, product names and trademarks are the property of their respective owners.
©2006 Crestron Electronics, Inc.

Crestron APAD Wall Mount LCD Controller
Contents
Wall Mount LCD Controller: APAD 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Specifications ..............................................................................................................2
Physical Description....................................................................................................3
Industry Compliance ...................................................................................................6
Setup..........................................................................................................................................7
Network Wiring...........................................................................................................7
Identity Code...............................................................................................................7
Installation...................................................................................................................7
Hardware Hookup .....................................................................................................11
Configuring the APAD..............................................................................................12
Setup Mode................................................................................................................12
Programming Software............................................................................................................14
Earliest Version Software Requirements for the PC .................................................14
Programming with Crestron SystemBuilder..............................................................14
Programming with SIMPL Windows........................................................................14
Programming with VisionTools Pro-e.......................................................................16
Example Program......................................................................................................16
Uploading and Upgrading........................................................................................................17
Establishing Communication.....................................................................................17
Programs, Projects, and Firmware.............................................................................17
Operation.................................................................................................................................18
Problem Solving ......................................................................................................................19
Troubleshooting.........................................................................................................19
Check Network Wiring..............................................................................................19
Reference Documents................................................................................................20
Further Inquiries........................................................................................................20
Future Updates ..........................................................................................................21
Return and Warranty Policies..................................................................................................22
Merchandise Returns / Repair Service ......................................................................22
CRESTRON Limited Warranty.................................................................................22
Operations & Installation Guide – DOC. 6455 Contents •i

Crestron APAD Wall Mount LCD Controller
Wall Mount LCD Controller: APAD
Introduction
Features and Functions
• Stylish, affordable wall mount controller
• Pleasing white-on-black LCD graphic display
• Translucent white backlit “softkey” pushbuttons
• Intuitive navigation wheel with “key click” audible feedback
• Cresnet®communications — 2-Series compatible
Graphic Display
The white-on-black LCD display presents the user with a large amount of
information in a small space. With graphical support for scrolling text, icons, and
bargraphs, the APAD delivers an ideal user interface for controlling audio and a
range of other possible functions throughout the home or office. Four "softkey"
buttons beneath the display permit intuitive menu navigation and function selection.
Nav Wheel
The APAD's navigation wheel (Nav Wheel) enables easy navigation of menus,
scrolling through lists of items and/or functions, and adjusting values that appear on
the display. The built-in "key click" feature audibly enhances the Nav Wheel's
natural feel, and the “soft” button to the right quickly executes the desired selection
set by the Nav Wheel. A dedicated, programmable power button is also included for
fast, easy power on/off control of system devices.
Backlit Buttons
The buttons on the APAD are translucent with adjustable white LED backlighting
for a luxurious, luminous appearance and easy operation under low lighting
conditions.
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •1

Wall Mount LCD Controller Crestron APAD
True-Feedback
Simplified connectivity using the Crestron®4-wire Cresnet control bus makes
installation a breeze. Fully bidirectional communications enables true-feedback for
display of current status of audio, lighting, or climate control settings.
Versatile Mounting Options
Several mounting options are available for the APAD to facilitate a clean, attractive
installation in any wall or similar flat surface.
Specifications
Specifications for the APAD are listed in the following table.
APAD Specifications
SPECIFICATION DETAILS
LCD Display
Display Type
Size
Resolution
Color
Illumination
Transmissive LCD dot matrix
2.72 in (6.9 cm) wide x 1.44 in (3.7 cm) high
128 x 64 pixels
Monochrome, white on black, invertible
White LED backlit
Controls
Nav Wheel
Functions
Power
(1) Continuous turn rotary encoder; used to
navigate menu, scroll through lists and adjust
values.
(5) “softkey” pushbuttons, programmable, normally
used to select menu functions. The pushbutton to
the right of the nav wheel is normally used to
execute a selected command.*
(1) pushbutton, programmable, normally used to
execute a power command*
* All pushbuttons translucent, white backlit,
dimmable
Graphics Monochrome, white on black (invertible), supports
dynamic text and icon graphics
Audio Built-in speaker (rear) for key click sound
Power Requirements
Cresnet Power Usage
3 Watts (0.125 Amps @ 24 Volts DC)
Default NET ID 2E
Minimum 2-Series
Control System Update
File
3.155.0 or later
Environmental
Temperature
Humidity
32 to 104° F (0 to 40° C)
10% to 90% RH (non-condensing)
Enclosure
Construction
Faceplate
Injection-molded plastic, flush wall-mountable
Injection-molded plastic, white
(Continued on next page)
2 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
APAD Specifications (continued)
SPECIFICATION DETAILS
Dimensions
Height
Width
Depth
4.8 in (12.2 cm)
4.9 in (12.5 cm)
1.94 in (4.93 cm)
Weight 9.2 oz (257.6 gm)
AVAILABLE ACCESSORIES
BB-1000L
PMK-1000L
TMK-1000L
MMK-1000L
WMKT-1000L
WMKM-1000L
WMKB-1000L
Pre-Construction Wall Mount Back Box
Pre-Construction Wall Mount Kit
Trim Ring
Mud Ring
Lectern or Post-Construction Wall Mount Kit
with Trim Ring
Post-Construction Wall Mount Kit with Mud Ring
Post Construction Wall Mount Kit - Bracket
Physical Description
This section provides information on the connections, controls, and indicators
available on your APAD.
APAD Physical View
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •3

Wall Mount LCD Controller Crestron APAD
APAD Overall Dimensions
4.9 in
(12.5 cm)
4.8 in
(12.2 cm)
3.74 in
(9.50 cm)
0.59 in
(1.50 cm)
0.43 in
(1.09 cm)
3.95 in
(10.03 cm) 4.16 in
(10.56 cm)
3.58 in
(9.08 cm)
0.62 in
(1.57 cm)
0.33 in
(0.83 cm)
4.06 in
(10.30 cm)
3.36 in
(8.53 cm)
0.78 in
(1.96 cm)
0.43 in
(1.09 cm)
1.67 in
(4.27 cm)
1.94 in
(4.93 cm)
4 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
APAD Front and Rear Face (Bezel Removed)
APAD Controls, Connectors, & Indicators
# CONNECTORS,
CONTROLS, &
INDICATORS
DESCRIPTION
1 Display Screen
Programmable display shows pages, menus,
and soft button functions of a project used to
control one or more devices in a Cresnet
system.
2 Reset Button Used alone to reset system defaults. When
pressed while another soft button is pressed,
APAD immediately goes into Setup mode.
3 Power Button
Used to execute a power command to one or more devices in the system.
4 Nav Wheel Used to navigate menus, scroll through lists
and adjust values shown on the display.
5 Soft Buttons
Five programmable buttons used with the
Nav Wheel to select the functions and
parameters used to control devices in the
system. Each button can be programmed to
provide a different function on every page of
a given project.
6
NET
24 Y Z G
Four-position terminal block connector for
data and power. Connects to Cresnet control
network. An interface connector is provided.
Pin 1 (24) Power
Pin 2 (Y) Data
Pin 3 (Z) Data
Pin 4 (G) Ground
7 Speaker Built-in transducer for key click sound.
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •5

Wall Mount LCD Controller Crestron APAD
Industry Compliance
As of the date of manufacture, the APAD has been tested and found to comply with
specifications for CE marking and standards per EMC and Radiocommunications
Compliance Labelling.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
 Reorient or relocate the receiving antenna.
 Increase the separation between the equipment and receiver.
 Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
 Consult the dealer or an experienced radio/TV technician for help.
6 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
Setup
Network Wiring
When wiring the network, consider the following:
• Use Crestron Certified Wire.
• Use Crestron power supplies for Crestron equipment.
• Provide sufficient power to the system.
CAUTION: Insufficient power can lead to unpredictable results or damage
to the equipment. Please use the Crestron Power Calculator to help calculate
how much power is needed for the system
(http://www.crestron.com/calculators).
• For larger networks, use a Cresnet Hub/Repeater (CNXHUB) to maintain
signal quality.
For more details, refer to “Check Network Wiring” on page 19.
Identity Code
The Net ID of the APAD has been factory set to 2E. The Net IDs of multiple APAD
devices in the same system must be unique. Net IDs can be changed from the “Setup
Mode” on page 12 or from a personal computer (PC) via the Crestron Toolbox.
When setting the Net ID, consider the following:
• The Net ID of each unit must match an ID code specified in the SIMPL
Windows program.
• Each network device must have a unique Net ID.
For more details, refer to the Crestron Toolbox help file.
Installation
The APAD installs simply and cleanly into existing or newly constructed walls, with
an assortment of pre- and post-construction mounting options. All listed mounting
options are provided separately from the actual APAD. Refer to the table after this
paragraph for a complete list of mounting options and respective Installation Guides
for the APAD LCD Controller.
Mounting Options for the APAD
PRE-
CONSTRUCTION
OPTION
POST-
CONSTRUCTION
OPTION
MODEL
NUMBER DOCUMENT NUMBER
Back Box Kit BB-1000L 6060
Pre-Construction
Mount Kit PMK-1000L 6061
Mud Mount Kit
(accessory) MMK-1000L 6062
(Continued on next page)
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •7

Wall Mount LCD Controller Crestron APAD
Mounting Options for the APAD (continued)
PRE-
CONSTRUCTION
OPTION
POST-
CONSTRUCTION
OPTION
MODEL
NUMBER DOCUMENT NUMBER
Trim Mount Kit
(accessory) TMK-1000L 6063
Wall Mount Kit – Mud WMKM-1000L 6062
Wall Mount Kit – Trim WMKT-1000L 6063
Wall Mount Kit – Bracket * WMKB-1000L 6283
*One set of brackets is supplied with the APAD
NOTE: Pre-construction refers to framed walls prior to hanging drywall.
Post-construction refers to framed walls with drywall hung.
The only tools required for the procedures presented here are masking tape (or
equivalent), a gypsum board saw (or equivalent), and a #1 Phillips tip screwdriver.
The following procedures are based on the use of the supplied screws and brackets
for post-construction installation.
Mounting the APAD
The APAD is designed for mounting in a wall or lectern. Two overlay cutout
templates (0V40087) are supplied. One is in the shape of the required opening; the
other is similar to a frame, with the inner area of the frame the shape of the required
opening. (Refer to the following diagrams.) Use the most convenient template.
Mounting Parts Supplied with the APAD
PART DESCRIPTION QUANTITY
Screw #4-40 x 1-½”, Pan Head 4
Mounting Bracket 2
Overlay Template Cutout 1
Four-pin Connector Plug 1
NOTE: The following drawings are not to scale. Do not attempt to use them to
prepare the hole in the mounting surface.
8 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
APAD Cutout Dimensions (1 of 2)
CUT ALONG THIS EDGE
TEMPLATE - 0V40087
FOR LC–1000, CT–1000
OR APAD ( 1 OF 2 )
4.17 in
(10.60 cm)
4.27 in
(10.85 cm)
APAD Cutout Dimensions (2 of 2)
TEMPLATE - 0V40087
FOR LC–1000, CT–1000
OR APAD ( 2 OF 2 )
CUT ALONG THIS EDGE
4.17 in
(10.60 cm)
4.27 in
(10.85 cm)
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •9

Wall Mount LCD Controller Crestron APAD
1. Locate an area on the wall that is free of studs and miscellaneous wiring.
2. Make a small hole near the middle of the designated site, and verify that the
location is suitable.
3. Using masking tape (or equivalent), fasten the template to the wall; verify
that the template is level, and trace the opening shape on the wall.
4. Remove the template, and then cut out and remove the traced shape to
produce the required opening.
APAD Mounting Example (Mounting Surface Not Shown)
Mounting
Screws
Mounting
Brackets
5. Connect the Cresnet cable, using the supplied mating connector, to the
Cresnet port as described in “Hardware Hookup” on page 11.
6. Insert the mounting screws through the APAD front plate as shown and
thread into the mounting brackets a few turns.
7. Insert the APAD into the mounting hole and tighten the screws evenly to
bring the mounting brackets into contact with the back of the drywall.
8. Make sure the APAD is positioned squarely in the mounting hole, and then,
using a #1 Phillips screwdriver, tighten the mounting screws slightly, about
an additional 1/2 turn, to hold the unit securely in position. Do not
overtighten screws.
9. Place the bezel in position over the unit. The bezel is held firmly in place by
magnets.
Removal from the Mounting Surface
If it is necessary to remove the APAD after it has been installed, complete the
following steps in the order provided. The only tool required is a #1 Phillips
screwdriver.
10 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
NOTE: If it becomes necessary to remove the APAD from the mounting surface,
the original mounting brackets may fall into the wall and will have to be replaced.
Additional brackets are available in the optional Wall Mount Kit – Bracket, Model
Number WMKB-1000L.
1. Pull the bezel away from the APAD.
2. Loosen and remove the two screws that secure the top of the APAD to the
mounting surface.
3. Loosen but do not remove the two screws that secure the bottom of the
APAD to the mounting surface, and shift the APAD in the hole so the
brackets will fall away from their top position on the mounting surface.
4. Pull the top portion of the APAD away from the mounting surface first and
attempt to remove the unit from the opening with the brackets hanging from
the bottom mounting screws.
5. If necessary, secure the attached cable before disconnecting it from the back
of the APAD, to keep it from falling into the wall.
Hardware Hookup
NOTE: To prevent overheating, do not operate this product in an area that exceeds
the environmental temperature range listed in the specifications table. Consideration
must be given if installed in a closed or multi-unit rack assembly, inside a closed
desk, or in a closed podium since the operating ambient temperature of these
environments may be greater than the room ambient. Contact with thermal insulating
materials should be avoided on all sides of the unit.
Connecting the Device Make the necessary connections as called out in the illustration that follows this
paragraph. Refer to “Network Wiring” on page 7 before attaching the 4-position
terminal block connector (supplied). Apply power to the network after all
connections have been made.
Hardware Connections for the APAD
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •11

Wall Mount LCD Controller Crestron APAD
Configuring the APAD
Project not Found Screen
MAIN MENU
ABOUT Screen
Load in Progress Screen
Prior to normal operation, it is necessary to configure the unit using a series of setup
screens. If the project for the APAD has not been loaded prior to configuring the
APAD, the screen shown to the left is displayed instead of the MAIN MENU. You
can choose to load the project at this time (refer to “Uploading and Upgrading” on
page 17), or follow the screen instruction and press any button to enter the Setup
Mode.
If the APAD project has already been loaded, the MAIN MENU for configuring the
APAD, shown to the left, appears when any button is pressed and held
(approximately five seconds) when power is applied.
Note that holding any of the soft buttons for more than 10 seconds while going into
setup mode will reset the brightness and contrast to their default levels.
The MAIN MENU displays three soft button choices: About, Setup, and Save and
Exit.
Selecting About displays an information screen that shows the firmware, project
name, and version number. Selecting Setup displays the Setup screen (Refer to
“Setup Mode,” below) that provides all the parameters that are used to configure the
APAD. The Save and Exit selection is used after performing all setup functions to
save the configuration and exit to normal operation.
If you choose to load the project at this time, the screen displays a progress bar as
the project is loaded (shown to the left).
Setup Mode Screen
Setup Mode
Setup Mode can be entered from the Main Menu, as stated above, or, if the APAD
has not yet been installed, by pressing and holding any button when power is
applied. If the unit is installed and power is already applied, the easiest method is to
remove the bezel, press and hold any button, and press the Reset button; the unit
immediately enters Setup Mode.
In the Setup Mode, use the Nav Wheel to scroll through the menu options, and then
press the soft button to the right to select the option. Press the Back soft button to
return to the Main Menu.
The following paragraphs describe each of the setup options in the order listed in the
menu.
Cresnet ID Screen
Cresnet ID
Use the Nav Wheel to select the desired ID number, from 03 to FE, in least significant
digit steps (e.g., 03, 04, 05), or use the << and >> soft buttons to change the number
in most significant digit steps (e.g., 03, 13, 23).
Press the Default soft button to select the default ID value (2E), press the Ok soft
button to accept the selection and return to the Setup Mode screen.
12 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
LCD Brightness
LCD Brightness
Use the Nav Wheel to select the desired brightness percentage value, from 01 to 99,
in single digit steps (01, 02, 03, etc.), or use the << and >> soft buttons to change the
number in most significant digit steps (10, 20, 30, etc.).
Note that holding any of the soft buttons for more than 10 seconds while going into
setup mode will reset the brightness to the default (22%).
Press the Default soft button to return to the default setting; press Ok to accept the
new setting and return to the Setup Mode screen.
Screen Invert
Screen Invert
Use the soft buttons to turn screen inversion on or off. (“Off” is normal appearance –
white text on black screen. “On” is inverted appearance – black text on white screen.)
Press the Default soft button to return to the default setting; press Ok to accept the
new setting and return to the Setup Mode screen.
LCD Contrast
LCD Contrast
Use the Nav Wheel to select the desired LCD contrast percentage value, from 01 to
99, in single-digit steps (01, 02, 03, etc.), or use the << and >> soft buttons to change
the number in most significant digit steps (10, 20, 30, etc.). Note that two contrast
settings are required: one for invert on, and one for invert off.
Note that holding any of the soft buttons for more than 10 seconds while going into
setup mode will reset the contrast to the defaults (non-inverted contrast 72%; inverted
contrast 66%).
Press the Default soft button to return to the default setting; press Ok to accept the
new setting and return to the Setup Mode screen.
Key Backlight
Key Backlight
Use the Nav Wheel to select the desired key backlight percentage value, from 01 to
99, in single-digit steps (01, 02, 03, etc.), or use the << and >> soft buttons to change
the number in most significant digit steps (10, 20, 30, etc.).
Press the Default soft button to return to the default setting (30%); press Ok to accept
the new setting and return to the Setup Mode screen.
Standby
Standby
Use the Nav Wheel to select the desired standby minutes, from 0 to 120, in single-
minute increments, or use the << and >> soft buttons to change the number in ten-
minute increments (10, 20, 30, etc.).
Press the Default soft button to return to the default setting (10 minutes); press Ok to
accept the new setting and return to the Setup Mode screen.
Key Click
Key Click
Use the ON and OFF soft buttons to turn the Key Click feature on and off (default is
off).
Press the Default soft button to return to the default setting; press Ok to accept the
new setting and return to the Setup Mode screen.
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •13

Wall Mount LCD Controller Crestron APAD
Programming Software
Have a question or comment about Crestron software?
Answers to frequently asked questions (FAQs) can be viewed in the Online Help
section of the Crestron website. To post a question or view questions you have
submitted to Crestron’s True Blue Support, log in at http://support.crestron.com.
First-time users will need to establish a user account.
Earliest Version Software Requirements for the PC
NOTE: Crestron recommends that you use the latest software to take advantage of
the most recently released features. The latest software is available from the Crestron
website.
Crestron has developed an assortment of Windows-based software tools to develop
a Cresnet system. The following are the minimum recommended software versions
for the PC:
Software
TASK REQUIRED SOFTWARE VERSION
Simplify programming with
wizards
(optional but recommended)
Crestron SystemBuilder™ version 3.0 or
later with SystemBuilder Templates version
3.0 or later; Refer to software release notes
or Crestron website for other required
Crestron software packages
Program SIMPL Windows 2.07.17 or later, with
Library Update 377 or later
Upload program and firmware Crestron Toolbox 1.02.17 or later
Create custom LCD screens and
page flips for custom programs Vision Tools®Pro-e version 3.5 or later; Requires Crestron Database version 18.0
or later
Programming with Crestron SystemBuilder
Crestron SystemBuilder is the easiest method of programming a Crestron system.
For additional details, download SystemBuilder from the Crestron website and
examine the extensive help file.
For lower level control and additional programming flexibility, use SIMPL
Windows.
Programming with SIMPL Windows
NOTE: While SIMPL Windows can be used to program the APAD, it is
recommended to use SystemBuilder for configuring a system that contains the
APAD.
SIMPL Windows is Crestron’s premier software for programming Crestron control
systems. It is organized into two separate, but equally important “Managers.”
14 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455

Crestron APAD Wall Mount LCD Controller
Configuration Manager Configuration Manager is the view where programmers “build” a Crestron control
system by selecting hardware from the Device Library.
• To incorporate the APAD into the system, drag the APAD from the Wired
Keypads folder of the Device Library and drop it in the System Views.
Locating the APAD in the Device Library
• The system tree of the control system displays the device in the appropriate
slot with a default Net ID as shown in the following illustration.
C2Net Device, Slot 9
• Additional APAD devices are assigned different Net ID numbers as they are
added.
• If necessary, double click a device to open the “Device Settings” window
and change the Net ID, as shown in the following figure.
Operations & Installation Guide – DOC. 6455 Wall Mount LCD Controller: APAD •15

Wall Mount LCD Controller Crestron APAD
“APAD Device Settings” Window
• The ID code specified in the SIMPL Windows program must match the Net
ID of each unit.
Programming Manager Programming Manager is the view where programmers "program" a Crestron control
system by assigning signals to symbols. The symbol can be viewed by double
clicking on the icon or dragging it into Detail View. A description for each signal in
the symbol is described in the SIMPL Windows help file (F1).
Programming with VisionTools Pro-e
The APAD LCD screens should be created in VisionTools Pro-e to allow selection
of functions, and control of system devices. Note that the APAD design permits the
six buttons to be programmed individually per project or for each page in a project.
The result is almost limitless functionality, with real time feedback of commands.
Example Program
An example program for the APAD is available from the Crestron website
(http://www.crestron.com/exampleprograms).
16 •Wall Mount LCD Controller: APAD Operations & Installation Guide – DOC. 6455
