Crestron 4K DigitalMedia 3-Series User manual

CrestronDMPS3-300-C/DMPS3-200-C
3-Series®DigitalMedia™PresentationSystem300
Operations Guide

Important Safety Instructions
•Read these instructions.
•Keep these instructions.
•Heed all warnings.
•Follow all instructions.
•Do not use this apparatus near water.
•Clean only with dry cloth.
•
Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
•Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers)
that produce heat.
•Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades with
one wider than the other. A grounding-type plug has two
blades and a third grounding prong. The wide blade or the
third prong are provided for yo
ur safety. If the provided plug
does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
•Protect the power cord from being walked on or pinched
particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus.
•Only use attachments/accessories specified by the
manufacturer.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPARATUS TO RAIN OR
MOISTURE. THE APPARATUS SHALL NOT BE EXPOSED
TO DRIPPING OR SPLASHING. OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED
ON THE APPARATUS.
WARNING:
TO PREVENT ELECTRIC SHOCK, DO NOT REMOVE
COVER. THERE ARE NO USER SERVICEABLE PARTS
INSIDE. ONLY QUALIFIED SERVICE PERSONNEL
SHOULD PERFORM SERVICE.
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated “dangerous voltage” within the
product's enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
•Use only with the cart, stand, tripod, bracket or
table specified by the manufacturer or sold with
the apparatus. When a cart is used, use caution
when moving the cart/apparatus combination to
avoid injury from tip-over.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in
the literature accompanying the appliance.
WARNING:
THIS IS AN APPARATUS WITH CLASS I
CONSTRUCTION. IT SHALL BE CONNECTED TO AN
ELECTRICAL OUTLET WITH AN EARTHING GROUND
TERMINAL.
IMPORTANT:
This device can be used with Class 2 output wiring.
•Unplug this apparatus during lightning storms or when
unused for long periods of time.
•Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any
way, such as power-supply cord or plug is damaged, liquid
has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture, does not
operate normally, or has been dropped.
•Disconnect power prior to connecting or disconnecting
equipment.
•Do not install in direct sunlight.
•
The apparatus must be installed in a way that the power cord
can be removed either from the wall outlet or from the
device itself in order to disconnect the main power.
•Prevent foreign objects from entering the device.

Regulatory Compliance
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.
As of the date of manufacture, the DMPS3-300-C and DMPS3-200-C have been tested and found to comply
with specifications for CE marking.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following conditions:
(1) This device may not cause harmful interference and (2) this device must accept any interference received,
including interference that may cause undesired operation.
CAUTION: Changes or modifications not expressly approved by the manufacturer responsible for
compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
•Reorient or relocate the receiving antenna
•Increase the separation between the equipment and receiver
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
•Consult the dealer or an experienced radio/TV technician for help
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)
The specific patents that cover Crestron products are listed at patents.crestron.com.
Crestron, the Crestron logo, 3-Series, AirMedia, Auto-Locking, Cresnet, Crestron Control, Crestron e-Control, Crestron Fusion, Crestron Toolbox,
DigitalMedia, DigitalMedia 8G, DigitalMedia 8G+, DM, DM 8G+, Fusion EM, Fusion RV, Mobile Pro, QuickSwitch HD, RoomView, and Smart
Graphics are either trademarks or registered trademarks of Crestron Electronics, Inc. in the United States and/or other countries. Apple, iPhone, and
iPad are either trademarks or registered trademarks of Apple, Inc. in the United States and/or other countries. BACnet is either a trademark or
registered trademark of BACnet International in the United States and/or other countries. Blu-ray Disc is either a trademark or registered trademark of
Blu-ray Disc Association (BDA), in the United States and/or other countries. IOS is a either a trademark or registered trademark of Cisco Technology,
Inc. in the United States and/or other countries. Dolby and Dolby Digital are either trademarks or registered trademarks of Dolby Laboratories, Inc. in
the United States and/or other countries. DTS, DTS-ES, and DTS 96/24 are either trademarks or registered trademarks of DTS, Inc. in the United States
and/or other countries. Android is either a trademark or registered trademark of Google, Inc. in the United States and/or other countries. HDMI and the
HDMI logo are either trademarks or registered trademarks of HDMI Licensing, LLC. in the United States and/or other countries. HDBaseT and the
HDBaseT Alliance logo are either trademarks or registered trademarks of HDBaseT Alliance in the United States and/or other countries. Internet
Explorer, Microsoft, and Windows are either trademarks or registered trademarks of Microsoft Corporation in the United States and/or other countries.
Other trademarks, registered trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or
their products. Crestron disclaims any proprietary interest in the marks and names of others. Crestron is not responsible for errors in typography or
photography.
This document was written by the Technical Publications department at Crestron.
©2014 Crestron Electronics, Inc.

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
Contents
3-Series DigitalMedia Presentation System 300: DMPS3-300-C and
DMPS3-200-C 1
Introduction ...............................................................................................................................1
Features and Functions................................................................................................1
Internal Block Diagrams............................................................................................10
Specifications ............................................................................................................11
Physical Description..................................................................................................20
Setup........................................................................................................................................29
Network Wiring.........................................................................................................29
Installation.................................................................................................................29
Hardware Hookup .....................................................................................................32
Uploading and Upgrading........................................................................................................35
Establishing Communication.....................................................................................35
Firmware ...................................................................................................................36
IP Configuration........................................................................................................36
DMPS Tool................................................................................................................37
Configuration and Operation...................................................................................................38
Configuration.............................................................................................................38
Default System Operation .........................................................................................49
Problem Solving ......................................................................................................................50
Troubleshooting.........................................................................................................50
Check Cresnet Network Wiring ................................................................................52
Reference Documents................................................................................................53
Further Inquiries........................................................................................................53
Future Updates ..........................................................................................................54
Return and Warranty Policies..................................................................................................55
Merchandise Returns / Repair Service ......................................................................55
Crestron Limited Warranty........................................................................................55
Operations Guide – DOC. 7591A Contents •i

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
•High definition multimedia system switcher, mic mixer, audio DSP,
amplifier, and control system
•Integrated DigitalMedia switcher featuring DM 8G+™ technology
•HDBaseT Certified—enables direct connection to other HDBaseT certified
displays and sources
•Matrix signal routing for up to seven simultaneous sources and four
displays (DMPS3-300-C) or six sources and two displays
(DMPS3-200-C)
•Handles HDMI®, DVI, DisplayPort Multimode,* and S/PDIF digital
sources
•Handles RGB, composite, S-video, component, and stereo audio analog
sources
•Features auto-detecting, auto-switching inputs for all types of video and
audio sources
3-Series DigitalMedia Presentation System 300:
DMPS3-300-C and DMPS3-200-C
Introduction
The DMPS3-300-C and DMPS3-200-C systems from Crestron®are complete,
high-definition presentation control and signal routing solutions for classrooms,
boardrooms, lecture halls, and videoconference rooms. Integrating the control system,
multimedia matrix switcher, audio DSP, and amplifier all into one 3-space rack mount
package, the systems afford extensive signal routing flexibility and
high-performance signal processing without the need for separate components.
Auto-configuring inputs enable plug-and-play compatibility with a wide range of
digital and analog sources. Built-in DigitalMedia™ and HDBaseT®connectivity
affords a streamlined wiring solution for interfacing with remote AV sources,
computers, and display devices.
For simplicity within this guide, the term “DMPS3-300/200-C” is used except where
noted.
Features and Functions
(Continued on following page)
* HDMI requires an appropriate adapter or interface cable to accommodate a DVI or DisplayPort
Multimode signal. CBL-HD-DVI interface cables available separately.
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •1

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
•Includes built-in 4-channel (DMPS3-200-C), or 6-channel
(DMPS3-300-C) gated microphone mixing with DSP
•Affords versatile audio signal mixing and routing to seven
(DMPS3-300-C) or five (DMPS3-200-C) separate outputs
•Allows audio-follow-video or breakaway switching for all inputs
•Enables HDMI audio signal extraction and embedding
•Provides three stereo analog outputs, each with independent DSP per
output
•Features built-in amplifier, selectable for 20 W per channel @ 8 ohms
and 4 ohms stereo or 40 W @ 70/100 volt mono
•Multichannel PCM, Dolby®, and DTS®audio signals can be routed to the
HDMI and DM 8G+ outputs
•DigitalMedia 8G+™ connectivity affords single-wire CAT5e interface
for remote sources and displays1
•Furnishes Power over DM®or HDBaseT for PoDM/PoH-powered
devices2
•QuickSwitch HD®technology manages HDCP keys for fast, reliable
switching
•Auto-Locking™ technology achieves rapid switching between disparate
sources
•Performs automatic AV signal format management via EDID
•Scaler options provide discrete image optimization for each display
device3
•Integrated Ethernet switch provides a single-point LAN connection
•Private Network mode requires just one IP address for the complete
system
•Distributes USB HID mouse and keyboard signals via DigitalMedia
•Expanded USB device support available using routable USB-EXT-DM
USB Extenders3
•3-Series®control system provides fully-programmable device control
•Supports Crestron touch screens, keypads, and wireless remotes
•XPanel with Smart Graphics™ computer and web based control
•iPhone®, iPad®, and Android™ control app support
•Crestron Fusion®Enterprise Management Software support
•SNMP support
•Provides easy setup and diagnostics via front panel or software
•Internal universal power supply for worldwide compatibility
•3-space 19-inch rack-mountable
Features and Functions
(Continued)
1. For DM 8G+ wiring, use Crestron DM-CBL-8G DigitalMedia 8G™ cable, Crestron DM-CBL
DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or generic CAT5e (or better) UTP or
STP. Maximum wire length for DM 8G+ is 330 ft (100 m) between devices. Shielded cable and
connectors are recommended to safeguard against unpredictable environmental electrical noise, which
may impact performance at resolutions above 1080p. For complete system design guidelines, refer to
the Crestron DigitalMedia Design Guide (Doc. 4546) at www.crestron.com/manuals. All wire and
cables sold separately.
2. Supplying Power over DM (PoDM) or Power over HDBaseT (PoH)requires external power pack,
model PW-4818DU, sold separately.
3. Item(s) sold separately.
2•3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
No Programming Required
Installing the DMPS3-300/200-C is easy, fast, and affordable. There is no
programming required to deliver a fully-functional presentation system–just select the
input sources and display device, add lighting control and other features, and the job
is done. Configuring and controlling the complete system is enabled using the
TSW-750-B PAK 7” tabletop touch screen.1
HD System Switcher
The DMPS3-300/200-C provides high-performance routing of numerous digital and
analog sources to up to four separate projectors, flat panel displays, codecs, touch
screens, and other devices. Connectivity is provided for multiple HDMI sources2 or
other combinations of HDMI, RGB, S/PDIF, analog audio, and analog video
sources(plus additional remote sources via DM 8G+). Input auto-detection and
auto-switching eliminates the need to configure the inputs—simply connect the source
and the DMPS3-300/200-C selects the right audio and video combination.
Depending on the DMPS3 device being used, built-in matrix switching allows routing
of up to seven simultaneous sources to up to four HDMI or DVI display devices, plus
up to three additional analog audio components.
Flexible Audio Routing
The HDMI, S/PDIF, and analog audio inputs may be configured to follow their
associated video inputs or switched independently. In fact, the audio from any HDMI
source can be extracted from the digital stream and converted to analog to feed an
outboard processor, mixer, or codec, with the return signal feeding back through any
analog input, which can be embedded with any video source to form a new HDMI
output. Routing of multichannel PCM, Dolby, and DTS audio sources is supported
through the HDMI and DM 8G+ outputs. All analog audio, HDMI, DM, and S/PDIF
inputs include adjustable input compensation to accommodate a wide range of signals
and maintain consistent volume levels when switching between sources.
DigitalMedia 8G+
Integrated DigitalMedia DM 8G+ inputs and outputs afford the ultimate in simplicity,
providing a true one-wire interface for remote sources and display devices. Easily add
up to two DM 8G+ transmitters to provide connectivity for HD AV sources and
computers at a table or lectern. Connect two DM 8G+ receivers (with the
DMPS3-300-C) to provide independent signal routing and control for two separate
projectors or flat panel displays.
Supporting wire lengths up to 330 feet (100 meters), DM 8G+ can also provide an
ideal interface to a central DigitalMedia switcher as part of a larger multiroom or
room-combining system.
DM 8G+ requires just one CAT5e wire run to each location, transporting
high-definition video, audio, and Ethernet for each device without compromise.3
1. Item(s) sold separately
2. HDMI requires an appropriate adapter or interface cable to accommodate a DVI or DisplayPort
Multimode signal. CBL-HD-DVI interface cables available separately.
3. For DM 8G+ wiring up to 330 ft (100 m) between devices, use Crestron DM-CBL-8G DigitalMedia 8G
cable, Crestron DM-CBL DigitalMedia cable, Crestron DM-CBL-D DigitalMedia D cable, or generic
CAT5e (or better) UTP or STP. Shielded cable and connectors are recommended to safeguard against
unpredictable environmental electrical noise, which may impact performance at resolutions above
1080p. Refer to the Crestron DigitalMedia Design Guide (Doc. 4546) for complete system design
guidelines. All cable sold separately.
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •3

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
Power over DM (PoDM) is supplied over the same CAT5e connection, providing a
centralized power source for all compatible transmitters and receivers.*
HDBaseT Certified
Crestron DigitalMedia 8G+ technology is designed using HDBaseT Alliance
specifications, ensuring interoperability with other HDBaseT certified products. Via
DM 8G+, the DMPS3-300/200-C can be connected directly to any HDBaseT
compliant source or display device without requiring a DM transmitter or receiver.
The DMPS3-300/200-C supports the feature set of HDBaseT that converges
uncompressed full HD digital video, audio, Ethernet, power,* and control signals
through a single CAT5e or CAT6 cable over distances up to 330 ft (100 m).
Multichannel Microphone Mixer
For a complete presentation or conferencing solution, the DMPS3-300/200-C includes
built-in mixing and processing for multiple microphones (six for DMPS3-300-C, four
for DMPS3-200-C). Each mic input provides 60 dB of gain adjustment, switchable 48
V phantom power, fully-adjustable gating, compression, limiting, and 4-band EQ.
Sophisticated matrix mixing allows for a completely different stereo mix of all
microphones at each of the DMPS3-300/200-C system’s outputs.
Professional Audio DSP
Each analog audio output on the DMPS3-300/200-C includes its own digital signal
processor, allowing each output to be optimized to feed a power amplifier, codec,
recorder, or assistive listening system. In addition to real-time adjustable volume,
bass, treble, and mute controls, each DSP provides 10-band graphic equalization,
4-band parametric equalization, and 85 ms speaker delay adjustment. Hardware relay
muting on each output helps prevent “thumping” on power up.
Codec Mixing
For video or audio teleconferencing applications, the DMPS3-300/200-C allows one
or two codecs to be connected to any of the seven source inputs. Audio from both
codecs can be mixed with the local presentation source and routed to the room
speakers via the Program output. The presentation source audio can also be routed to
the codecs via the Aux outputs, allowing far end participants to experience the full
presentation. Both codecs can even be used simultaneously, allowing the signal from
one codec to be fed to the other for a fully inclusive teleconferencing experience.
Built-in Power Amplifier
Its built-in power amplifier allows the DMPS3-300/200-C to directly drive a pair of
stereo speakers (20 watts per channel @ 4 ohms or 8 ohms), or a string of distributed
ceiling speakers (40 watts mono @ 70 or 100 volts). Fed by the main program output,
the internal amplifier benefits fully from the onboard DSP. For larger applications,
Crestron AMP-series power amplifiers may be added, providing a complete solution
for driving separate program and speech speakers, or any multizone speaker system.
* Supplying Power over DM (PoDM) or Power over HDBaseT (PoH) requires an external power pack,
sold separately.
4•3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
EDID Format Management
The DMPS3-300/200-C allows for management of the EDID (Extended Display
Identification Data) information that passes between the display devices and input
sources in the system. Using Crestron Toolbox™ software, the format and resolution
capabilities of each device can be assessed, allowing the installer to configure EDID
signals appropriately for the most desirable and predictable behavior.
A Scaler for Every Display
Through a distributed scaler approach, the DMPS3-300/200-C affords a very
flexible and user-friendly solution for handling multiple disparate display devices
and video codecs. Employing discrete outboard scalers like the HD-SCALER and
DM-RMC-SCALER-C (both sold separately), the DMPS3-300/200-C allows an
independent high-performance scaler to be installed at each display device, ensuring
an optimal image on every screen no matter what sources are selected.
QuickSwitch HD Technology
Handling high definition digital media means handling HDCP (High-bandwidth
Digital Content Protection), the encryption scheme used by content providers to
protect DVD and Blu-ray Disc™ releases and broadcast signals against unauthorized
copying. Viewing HDCP encrypted content requires a source device to authenticate
each display and signal processor in the system and issue it a key before delivering an
output signal. When using a conventional HDMI or DVI switcher, it is common to
experience a complete loss of signal for up to 15 seconds during the authentication
process each time a new source or display is selected anywhere in the system. Also,
every source device has a limited number of keys available, so if it is connected to too
many displays, the source simply stops outputting a signal without warning.
Crestron QuickSwitch HD manages the keys for every HDCP-compliant device in the
system, maintaining continuous authentication for each device to ensure fast, reliable
routing of any source to any number of display devices.
Auto-Locking Technology
Crestron Auto-Locking technology enables super-fast signal switching by
instantaneously configuring every device in the signal path, including DM
transmitters, DM receivers, and scalers, as soon as the signal hits the first device.
Whether switching between sources or TV channels, Auto-Locking significantly
reduces the time it takes each device to sense the new signal and configure itself to
handle the changes, virtually eliminating any noticeable gap while switching.
Built-in Ethernet Switch
In addition to transporting digital video and audio, the DigitalMedia 8G+ ports on the
DMPS3-300/200-C can also extend Ethernet out to each display and source device,
providing high-speed connectivity for each room device that requires a LAN
connection. Ethernet is also utilized internally by the Crestron control bus to manage
each transmitter and receiver and provide device control.
Private Network Mode
To streamline its implementation on a corporate or university LAN, the
DMPS3-300/200-C employs Private Network mode to provide a single-point
connection for the complete system. Using Private Network mode, the
DMPS3-300/200-C requires just one IP address for the complete DM network,
including all connected DM transmitters and receivers.
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •5

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
USB Switch
Along with video, audio, and Ethernet, the DigitalMedia 8G+ ports on the
DMPS3-300/200-C can also provide for the routing of USB HID (Human Interface
Device) signals, allowing a USB HID compliant keyboard, mouse, or both at one
location to control a computer or media server at another location. USB HID
connectivity is provided through select DM receivers and transmitters. Crestron also
offers USB Extenders (USB-EXT-DM) (sold separately) to enable the routing of
multiple USB devices of virtually any type, all seamlessly managed through the
DMPS3-300/200-C.
Integrated 3-Series Control System
Its built-in 3-Series control system enables the DMPS3-300/200-C to provide
complete, customizable control of every AV device, as well as room lighting, window
shades, and projection screens, without requiring a separate control processor. The
DMPS3-300/200-C supports the full line of Crestron touch screens, keypads, and
wireless remotes for a user experience custom tailored to the specific requirements of
each end-user. Support for Crestron control apps and Crestron Fusion Enterprise
Management Software delivers the industry’s most powerful platform for remotely
controlling and managing multiple rooms using computers and mobile devices.
CEC Embedded Device Control
The primary objective of every Crestron system is to enable precisely the control
desired for a seamless user experience. In addition to conventional IR, RS-232, and
Ethernet device control, the DMPS3-300/200-C can provide an alternative by
harnessing the CEC (Consumer Electronics Control) signal embedded in HDMI. The
DMPS3-300/200-C provides a gateway for controlling many devices right through
their HDMI connections, potentially eliminating the need for any dedicated control
wires or IR emitters. Through proper CEC signal management, the
DMPS3-300/200-C permits control of each device as desired.
Easy Setup
Every step of the DMPS3-300/200-C setup process is designed to be quick and easy
using its front panel or Crestron Toolbox software, configuring inputs and outputs
automatically while letting the installer make intelligent design decisions along the
way. Out of the box, the DMPS3-300/200-C’s front panel supports basic signal
routing for easy testing and troubleshooting during installation. The front panel label
strips can be customized using Crestron Engraver software or standard 3/8 in
(~10 mm) tape labels, allowing for the clear designation of each input and output.
Inputs and outputs may also be designated by name through the software to appear on
the LCD display.
6•3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
Applications
The following diagram shows a DMPS3-300-C in a presentation room application.
DMPS3-300-C in a Presentation Room Application
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •7

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
The following diagram shows a DMPS3-300-C in a video conferencing application.
DMPS3-300-C in a Video Conferencing Application
8•3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
The following diagram shows the audio controls in the microphone input stage.
Labels M1 through M6 correspond to the labels in the mixer stage portion of the
Audio Flow Diagram below.
DMPS3-300-C Mic Audio Controls Diagram
The following audio flow diagram shows the audio controls in the DMPS3-300-C
mixer stage. Labels M1 through M6 correspond to the labels in the microphone input
stage diagram above.
DMPS3-300-C Audio Flow Diagram
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •9

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
Internal Block Diagrams
The following diagrams represent the audio and video switching functions and signal
flow of the DMPS3-300-C.
DMPS3-300-C Audio Block Diagram
10 •3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
DMPS3-300-C Video Block Diagram
Specifications
Specifications for the DMPS3-300/200-C are listed in the following table.
DMPS3-300/200-C Specifications
SPECIFICATION DETAILS
Operating System Crestron 3-Series;
Real time, preemptive,
multithreaded/multitasking kernel;
Transaction-Safe Extended FAT file system;
Supports up to 10 simultaneously running
programs
Memory
SDRAM 512 MB
Flash 4 GB
(Continued on following page)
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •11

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
DMPS3-300/200-C Specifications (Continued)
SPECIFICATION DETAILS
Communications
Ethernet 10/100/1000 Mbps, auto-switching,
auto-negotiating, auto-discovery, full/half duplex,
industry-standard TCP/IP stack, UDP/IP, CIP,
DHCP, Private Network Mode, SSL, IEEE
802.1X, SNMP, BACnet™/IP,1IPv4 or IPv6,
active directory authentification, RSTP, SMTP
e-mail client, IIS v.6.0 web server;
Installer setup via Crestron Toolbox or MSIE2
Cresnet
®
Cresnet master mode
DigitalMedia DM 8G+, HDCP, EDID, CEC, PoDM, HDBaseT
compliant
HDMI HDMI, HDCP, EDID, CEC
USB USB signal routing via select transmitters,
receivers, and extenders; USB service port for
computer console
RS-232 2-way device control and monitoring up to
115.2 kBd with hardware and software
handshaking
IR/Serial 1-way device control via infrared up to 1.2 MHz,
or serial TTL/RS-232 (0 – 5 volts) up to
115.2 kBd;
Supports CNXRMIRD IR Receiver3
Ethernet Switch
8-port switch with Private Network mode;
Provides (1) rear panel 10Base-T/100Base-
TX/1000Base-T Gigabit LAN port and (7) internal
100 Mbps ports for the control processor,
switcher, audio DSP, and DM ports
Video
Switcher Auto-detecting multiformat digital/analog source
inputs, 7x4 matrix switcher, HDMI, and DM 8G+
outputs, QuickSwitch HD technology
Input Signal Types
(DMPS3-300-C) HDMI (Inputs 1 – 5), RGB
4
(Inputs 3 – 5),
composite/S-video/component (Input 5),
DM 8G+ and HDBaseT (Inputs 6 and 7)
Input Signal Types
(DMPS3-200-C) HDMI (Inputs 1 – 5), RGB
4
(Inputs 3 – 5),
composite/S-video/component (Input 5),
DM 8G+ and HDBaseT (Input 6)
Output Signal Types
(DMPS3-300-C)
HDMI (Outputs 1 and 2), DM 8G+ and HDBaseT
(Outputs 3 and 4)
Output Signal Types
(DMPS3-200-C) HDMI (Output 1), DM 8G+ (Output 2)
Formats HDMI with Deep Color and 3D,
5
DVI,
6
DisplayPort Multimode,6HDCP content
protection support, HD up to 1080i/1080p,
computer up to UXGA/WUXGA, RGBHV,
RGBS, RGsB, YPbPr, Y/C, NTSC, PAL
(Continued on following page)
12 •3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A

Crestron DMPS3-300-C/DMPS3-200-C 3-Series DigitalMedia Presentation System 300
DMPS3-300/200-C Specifications (Continued)
SPECIFICATION DETAILS
Video (Continued)
Input Resolutions
HDMI and HDBaseT,
Progressive
640 x 480 @ 60 Hz
720 x 480 @ 60 Hz (480p)
720 x 576 @ 50 Hz (576p)
800 x 600 @ 60 Hz
848 x 480 @ 60 Hz
852 x 480 @ 60 Hz
854 x 480 @ 60 Hz
1024 x 768 @ 60 Hz
1024 x 852 @ 60 Hz
1024 x 1024 @ 60 Hz
1280 x 720 @ 50 Hz (720p50)
1280 x 720 @ 60 Hz (720p60)
1280 x 768 @ 60 Hz
1280 x 800 @ 60 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 Hz
1360 x 768 @ 60 Hz
1365 x 1024 @ 60 Hz
1366 x 768 @ 60 Hz
1400 x 1050 @ 60 Hz
1440 x 900 @ 60 Hz
1600 x 900 @ 60 Hz
1600 x 1200 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 24 Hz (1080p24)
1920 x 1080 @ 25 Hz (1080p25)
1920 x 1080 @ 50 Hz (1080p50)
1920 x 1080 @ 60 Hz (1080p60)
1920 x 1200 @ 60 Hz
2048 x 1080 @ 24 Hz
2048 x 1152 @ 60 Hz
plus any other resolution allowed by HDMI up to
165 MHz pixel clock
Input Resolutions
HDMI and HDBaseT,
Interlaced
720 x 480 @ 30 Hz (480i)
720 x 576 @ 25 Hz (576i)
1920 x 1080 @ 25 Hz (1080i25)
1920 x 1080 @ 30 Hz (1080i30)
plus any other resolution allowed by HDMI up to
165 MHz pixel clock
Input Resolutions
RGB 640 x 480 @ 60 Hz
720 x 480 @ 60 Hz (480p)
720 x 576 @ 50 Hz (576p)
800 x 600 @ 60 Hz
848 x 480 @ 60 Hz
1024 x 768 @ 60 Hz
1280 x 720 @ 50 Hz (720p50)
1280 x 720 @ 60 Hz (720p60)
1280 x 768 @ 60 Hz
1280 x 800 @ 60 Hz
1280 x 960 @ 60 Hz
1280 x 1024 @ 60 Hz
1360 x 768 @ 60 Hz
1366 x 768 @ 60 Hz
(Continued on following page)
Operations Guide – DOC. 7591A 3-Series DigitalMedia Presentation System 300: DMPS3-300/200-C •13

3-Series DigitalMedia Presentation System 300 Crestron DMPS3-300-C/DMPS3-200-C
DMPS3-300/200-C Specifications (Continued)
SPECIFICATION DETAILS
Video
Input Resolutions
RGB (Continued) 1400 x 1050 @ 60 H
1440 x 900 @ 60 Hz
1600 x 1200 @ 60 Hz
1680 x 1050 @ 60 Hz
1920 x 1080 @ 50 Hz (1080p50)
1920 x 1080 @ 60 Hz (1080p60)
1920 x 1200 @ 60 Hz
2048 x 1152 @ 60 Hz
Input Resolutions
Component 480i, 576i, 480p, 576p, 720p50, 720p60,
1080p24,1080i25 (1125 lines), 1080i30,
1080p30, 1080p50 (1125 lines), 1080p60
Input Resolutions
Composite and S-video 480i, 576i
Output Resolutions Matched to inputs
Analog-To-Digital Conversion 10-bit 165 MHz per each of 3 channels
RGB Source Image
Adjustments
Brightness 0% to 50%
Contrast -50% to +50%
Fine Phase -16 to +15
X Position -100 to +100
Y Position -10 to +10
RGB Gains -50 to +50, separately adjustable for red,
green, and blue
YPbPr, Y/C, or Composite
Source Image Adjustments
Brightness 0% to 50%
Contrast -50% to +50%
Saturation -50% to +50%
Hue -50% to +50%
Audio
Switcher/Mixer
(DMPS3-300-C) 6-channel gated mic mixer with DSP,
auto-detecting multiformat digital/analog
source inputs, DigitalMedia 8G+ inputs,
7 x 7 stereo source switcher, 7 x 4
multichannel source switcher, analog, and
HDMI outputs, DM 8G+ outputs,
independent 6-channel mic plus source mixer
per output, independent stereo DSP per
analog output, integrated power amplifier,
digital audio pass-through mode
Switcher/Mixer
(DMPS3-200-C) 4-channel gated mic mixer with DSP,
auto-detecting multiformat digital/analog
source inputs, DigitalMedia 8G+ inputs,
6 x 5 stereo source switcher, 6 x 2
multichannel source switcher, analog, and
HDMI outputs, DM 8G+ outputs,
(Continued on following page)
14 •3-Series DigitalMedia Presentation Systems: DMPS3-300/200-C Operations Guide – DOC. 7591A
