GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Introduction
CRESTRON GREEN LIGHT EXPRESS power switching cabinets come pre-configured with GLXX switching
modules already installed. The cabinets only require installation and wiring of feed and load circuits.
Regulatory Compliance
The cabinet and modules are Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.
Application
The following diagram shows CRESTRON GREEN LIGHT EXPRESS power switching cabinets in a lighting
application that is controlled by an IPAC system.
CRESTRON GREEN LIGHT EXPRESS Power Switching Cabinets in a Typical Lighting Application
Crestron Electronics, Inc. Installation Guide – DOC. 6887A
15 Volvo Drive Rockleigh, NJ 07647 (2025418)
Tel: 888.CRESTRON 04.10
Fax: [phone] Specifications subject to
www.crestron.com change without notice.

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Physical Description
This section shows the dimensions of the CRESTRON GREEN LIGHT EXPRESS power switching cabinets.
Dimensions of GLPS-HDSW-FT-8 ,-12, -16, -20, -24 Power Switching Cabinets (Front, Side and Bottom View)
24 1/4"
(616 mm)
16 1/8”
(409 mm)
3 1/16”
(78 mm)
KNOCKOUT FOR 3/4”
(20 mm) CONDUIT
(TYPICAL BOTH
SIDES)
4 7/16”
(113 mm)
1/4” (7 mm)
3 1/4”
(83 mm)
2 1/2” (64 mm)
14 3/8"
(365 mm)
1 1/4” (32 mm)
2 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Dimensions of GLPS-HDSW-FT-8, -12, -16, -20, -24 (shown below) Power Switching Cabinets (Internal View)
23 1/2"
(597 mm) 18 15/16”
(481 mm)
(2X) Ø 7/16 ( 12 )
MOUNTING HOLE
S
Ømm
(2x) 11/16”
(19 mm)
2 1/8” (55 mm)
(2x) Ø 5/8”
(Ø 16 mm)
(2X) Ø 5/16”
(Ø 8 mm)
MOUNTING HOLES
2 1/4”
(58 mm) 10 7/8”
(276 mm)
* TIE WRAP
HOLDERS (MAY
BE MOVED TO
OTHER HOLES
AS REQUIRED)
SERVICE
SCREWDRIVER
* Installed GLXX modules come with additional tie wrap holders.
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •3

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Dimensions of GLPS-HDSW-FT-28, -32, -36, -40, -48, -52, -56 Power Switching Cabinets (Front, Side and Bottom View)
16 1/8”
(409 mm)
39 5/8”
(1 m)
3 1/16”
(78 mm)
KNOCKOUT FOR 3/4”
(20 mm) CONDUIT
(TYPICAL BOTH
SIDES)
4 7/16”
(113 mm)
1/4” (7 mm)
3 1/4”
(83 mm)
2 1/2” (64 mm)
14 3/8"
(365 mm)
1 1/4” (32 mm)
4 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Dimensions of GLPS-HDSW-FT–28, -32, -36, -40, -48,-52, -56 (shown below) Power Switching Cabinets (Internal View)
2 1/8” (55 mm)
(2X) Ø 5/16”
(Ø 8 mm)
MOUNTING HOLES
(2x) 11/16”
(19 mm)
10 7/8”
(276 mm)
2 1/4”
(58 mm)
GROUND
LUG
38 7/8”
(998 mm) 34 3/8”
(873 mm)
(2X) Ø 7/16
(Ø 12 mm)
MOUNTING HOLES
(2x) Ø 5/8”
(Ø 16 mm) * TIE WRAP
HOLDERS (MAY
BE MOVED TO
OTHER HOLES
AS REQUIRED)
SERVICE
SCREWDRIVER
* Installed GLXX modules come with additional tie wrap holders.
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •5

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Installation
Observe the following when installing the cabinet:
• The cabinet must be mounted by a licensed electrician in accordance with all national and local codes.
Refer to the diagram below for specific requirements.
• The cabinet is designed for surface mounting on a wall.
• Cabinets are intended for indoor use only.
• The ambient temperature range should be 32°F to 104°F (0°C to 40°C). The relative humidity should range
from 10% to 90% (non-condensing). Allow adequate clearance in front of the cover for servicing.
Mounting Location
3 ft
(0.9 m)
Minimum
Required
Clearance
Wall
6 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Wiring
NOTE: All wiring must be installed in accordance with all local and national electrical codes.
NOTE: Refer to the torque settings specified on pages 8 and 9.
CRESTRON GREEN LIGHT EXPRESS power switching cabinets come pre-configured with GLXX-HDSW
switching modules already installed. The cabinets only require installation and wiring of feed and load circuits.
The following must be performed after mounting the cabinet:
• Connect incoming feed conductors to the input terminals and connect loads to contact terminals (section A
of the following diagram)`
• Connect control wiring (section Bof the following diagram)
Feed-Through and Load Wiring
SERVICE
SCREWDRIVER
A
B
CLASS 2
WIRING ONLY
FEEDS
FROM
BREAKER
PANEL TO
LOADS
FEEDS
FROM
BREAKER
PANEL TO
LOADS
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •7

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Feed-Through and Load Wiring (Section A)
NOTE: Use copper conductors only – rated 75°C.
Wire Gauge and Torque Values
TERMINAL CONNECTOR MAX
WIRE RANGE TORQUE STRIP LENGTH
INPUT 26-10 AWG 5.31 lb-in (0.6 Nm) to
7.08 lb-in (0.8 Nm) max 3/8” (9 mm)
OUTPUT/CONTACT 26-10 AWG 5.31 lb-in (0.6 Nm) to
7.08 lb-in (0.8 Nm) max 3/8” (9 mm)
GROUND LUG 14-4 AWG 25-45 lb-in
(2.8-5.1 Nm) 3/4" (19 mm)
Load Wiring for GLXX -HDSW8 and GLXX- HDSW16
SERVICE
SCREWDRIVER
LINE 1*
TO LOAD
LINE 2*
TO LOAD
L
SINGLE-POLE
DOUBLE-POLE
LINE
TO LOAD
* Lines 1 and 2 must be on different phases.
NOTE: All GLXX-HDSW8 or GLXX-HDSW16 modules must be connected together in series to the
GLXX-CNTRL Express Controller using the quick-connect jumper wires provided.
8 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Control Wiring (Section B)
The bottom of the cabinet contains Cresnet®connections for interfacing to the rest of the Crestron®control system.
It also provides overrides input which can be tied to devices such as the GLS-PLS-120/277 phase-loss sensor, or
other devices that provide a dry contact closure (manual switch, fire alarm relay, etc.).
To ensure optimum performance over the full range of your installation topology, use Crestron certified wire.
Failure to do so may incur additional charges if support is required to identify performance deficiencies because of
using improper wire.
NOTE: Interface connectors for NET (x2), and OVERRIDE (x3) ports are provided.
Wire Gauge and Torque Values
TERMINAL CONNECTOR MAX
WIRE RANGE TORQUE STRIP LENGTH
NET 26-12 AWG 4.43 lb-in
(0.5 Nm) 1/4” (6 mm)
OVERRIDE 26-12 AWG 4.43 lb-in
(0.5 Nm) 1/4” (6 mm)
Connector Wiring
NET:
TO CONTROL SYSTEM AND
OTHER CRESNET DEVICES
OVERRIDE:
FROM GLS-PLS-120/277, FROM
OTHER CABINET,
FROM ALARM, ETC.
(OPTIONAL); TO OTHER
CABINET(S) IF NECESSARY
RED
WHITE
BLUE
BLACK
RED
WHITE
BLUE
BLACK
MODULES:
TO HDSW MODULES
NOTE: For instructions on network wiring, refer to “Appendix C: Network Wiring” on page 18.
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •9

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
NET Port Wiring
When wiring the supplied NET connectors for connection to a Crestron control system or other device on the
Cresnet network, use Crestron certified wire such as CRESNET-NP or CRESNET-P. For instructions on
network wiring, refer to “Appendix C: Network Wiring” on page 18.
When daisy-chaining connections between NET ports, strip the ends of the wires carefully to avoid nicking the
conductors. Twist together the ends of the wires that share a pin on the network connector, insert the connection
into the Cresnet connector, tighten the retaining screw. Repeat the procedure for the other three conductors.
OVERRIDE Port Wiring
When a connection is applied between the override terminals, the modules will enter Override mode. The
Crestron GLS-PLS-120/277 phase-loss sensor or any device that provides a dry contact closure can be
connected to the supplied OVERRIDE connector on the bottom of the cabinet.
Mechanical Override
1. Locate the mechanical override rocker switch labeled STATUS on the top of the relay.
Mechanical Override Switch
MECHANICAL
OVERRIDE
2. Place the tip of a screwdriver on the switch and push against the indentation.
3. The rocker switch will toggle into either an “ON or OFF” position, overriding the current state.
10 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Relays
The GLXX-CTRL identifies relays in the sequential order in which they are introduced to the GLXX-HDSW.
Relays come pre-installed from the factory. Install additional relays from left to right, starting the top of the cabinet
and moving down. Refer to the illustration below.
Relay Installation Sequence
SERVICE
SCREWDRIVER
1 2
3 4
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •11

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Relay Installation Procedure
1. Insert the output side of the relay into the tab(s) on the mounting strap.
2. Push down on the relay to lock the spring clips into the relay. Refer to the illustration below.
Inserting the relay into the mounting strap (Double Pole Relay Shown)
Tabs
Push
Spring
Clips
3. Attach the wiring connector on the relay to the GLXX-HDSW.
Connecting the Relay to the GLXX-HDSW (Single Pole Relay Shown)
12 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Relay Removal Procedure
1. Disconnect the wiring connector on the relay from the GLXX-HDSW.
Disconnecting the Relay from the GLXX-HDSW (Single Pole Relay Shown)
2. To release the relay from the mounting strap, press firmly on the spring clip(s).
3. Pull the relay away from the tabs and lift it out of the mounting strap
Removing the relay from the mounting strap (Double Pole Relay Shown)
Press Down
Tabs
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •13

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Testing
Manual Control
Lighting loads can be manually controlled from the front panel.
TOGGLES LOCAL
CONTROL ON/OFF
TOGGLES SELECTED
RELAY ON/OFF
USE UP/DOWN ARROWS
TO SELECT RELAY TO
CONTROL
(NET ID WILL DISPLAY
RELAY NUMBER)
RED LED ILLUMINATES
WHEN LOCAL
CONTROL IS ENABLED
NOTE: To disable local control, press the ENABLE button again or wait for two minutes. The red LED beside the
button will deactivate.
NOTE: The control system program may change the settings if the Override mode is not enabled.
Override Mode
The Override mode overrides the control system program and sets all of the output states to the stored override
values. For instructions on saving override settings, refer to “Save Override Settings” below.
To enable Override mode, press and release the OVR button. The OVR LED flashes slowly.
NOTE: If the Override mode was enabled from an external device (i.e. a contact closure is present on the
OVERRIDE terminals), the OVR LED will flash quickly. Pressing the OVR button has no effect.
To disable Override mode, press the OVR button again. The OVR LED extinguishes and the outputs return to the
states set by the control system program.
NOTE: If override states have not been stored, the factory default override state is all loads on.
Save Override Settings
The state of each output can be saved as an override setting, which can be automatically recalled when the Override
mode is enabled.
NOTE: The control system program has a setting that can prevent locally saving the override state. If this setting is
enabled, the display shows “Er” when trying to save override states. For more information, refer to the SIMPL
Windows help file.
To save the states of all outputs as the override setting, press and hold the OVR button for three seconds until the
OVR LED blinks once.
System Operation and Commissioning
This cabinet has been designed as a component of a programmed Crestron system. System commissioning by an
authorized Crestron representative must be performed to ensure system operation.
Once the cabinet has been wired and the modules have been tested, contact Crestron at 1-888-CRESTRON
[1-888-273-7876] to schedule commissioning.
14 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Problem Solving
Troubleshooting
The following table provides corrective action for possible trouble situations. If further assistance is required, please
contact a Crestron customer service representative.
Troubleshooting
TROUBLE POSSIBLE CAUSE(S) CORRECTIVE ACTION
Device is not receiving
power from a Crestron
power source.
Verify connections.
Device is not receiving
sufficient power via
Cresnet link.
Use the Crestron Power Calculator to help
calculate how much power is needed for
the system.
Module(s) does not
function.
System commissioning
not complete. Arrange for system commissioning.
Unit cannot be taken out
of Override mode Short (contact closure)
exists between Gand OVR
terminals on any of the
OVERRIDE terminals
present at bottom of the
cabinet.
Determine the reason for the short.
Remove or remedy the short
(e.g. GLS-PLS-120/277 phase-loss sensor
may not have been installed properly, or
actual phase-loss has been detected).
Further Inquiries
If you cannot locate specific information or have questions after reviewing this guide, please take advantage of
Crestron's award winning customer service team by calling Crestron at 1-888-CRESTRON [1-888-273-7876].
You can also log onto the online help section of the Crestron website (www.crestron.com/onlinehelp) to ask
questions about Crestron products. First-time users will need to establish a user account to fully benefit from all
available features.
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •15

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Appendix A: Setting Module Net IDs
The following procedure will normally be performed by an authorized Crestron representative as part of the System
Commissioning phase. For system wiring and basic testing as described on pages 7 and 14, it is not necessary to
perform this step. Only perform this step if instructed by an authorized Crestron representative, or when replacing
modules on a system that have already been commissioned (in the latter case the Net ID should be set to match the
Net ID of the module being replaced).
The Net ID of each module in the cabinet can be changed from the front panel of each module. The Net IDs of each
module in the system must be unique.
To set the Net ID using the front panel:
1. Press the recessed SETUP button to enter the Setup mode. The SETUP LED illuminates.
2. As shown in the following diagram, press the left button under the NET ID display to change the left digit
of the Net ID or press the right button under the NET ID display to change the right digit of the Net ID
number.
Changing the Net ID
CHANGES
LEFT DIGIT CHANGES RIGHT DIGIT
LABEL FOR
NET ID
SETUP
BUTTON & LED
RIGHT DIGITLEFT DIGIT
3. When the desired Net ID is displayed, press the SETUP button to exit the Setup mode. The SETUP LED
extinguishes.
If the SETUP button is not pressed, the Setup mode will time out after one minute activity and the Net ID
will revert back to its original value.
16 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Appendix B: Specifications
Specifications for the GLXX-HDSW modules are listed in the following table.
GLXX-HDSW Module Specifications
SPECIFICATION DETAILS
Input Voltage 100 – 347 VAC 50/60 Hz
Supported Load Types Incandescent, HID, magnetic low voltage (MLV),
electronic low voltage (ELV), neon/cold cathode, and
fluorescent ballasts, motor
Maximum Load
General Use / Electric Discharge Lamp
GLR-HD-1P 20 Amps, 347 Volts AC
GLR-HD-2P 20 Amps, 480 Volts AC
Motor 0.5 HP at 110-125 Volts AC
1.5 HP at 220-277 Volts AC
Environmental
Temperature 32º to 104º F (0º to 40º C)
Humidity 10% to 90% RH (non-condensing)
Heat Dissipation 10 BTU/Hr
Cresnet Power Usage 5W (Entire Cabinet)
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •17

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Appendix C: Network Wiring
Check Network Wiring
Use the Right Wire
In order to ensure optimum performance over the full range of your installation topology, Crestron Certified Wire
and only Crestron Certified Wire may be used. Failure to do so may incur additional charges if support is required to
identify performance deficiencies because of using improper wire.
Calculate Power
CAUTION: Use only Crestron power supplies for Crestron equipment. Failure to do so could cause equipment
damage or void the Crestron warranty.
CAUTION: Provide sufficient power to the system. Insufficient power can lead to unpredictable results or damage
to the equipment. Please use the Crestron Power Calculator to help calculate how much power is needed for the
system (www.crestron.com/calculators).
When calculating the length of wire for a particular Cresnet run, the wire gauge and the Cresnet power usage of each
network unit to be connected must be taken into consideration. Use Crestron Certified Wire only. If Cresnet units
are to be daisy-chained on the run, the Cresnet power usage of each network unit to be daisy-chained must be added
together to determine the Cresnet power usage of the entire chain. If the unit is home-run from a Crestron system
power supply network port, the Cresnet power usage of that unit is the Cresnet power usage of the entire run. The
wire gauge and the Cresnet power usage of the run should be used in the following equation to calculate the cable
length value on the equation’s left side.
Cable Length Equation
L = Length of run (or chain) in feet
R = 6 Ohms (Crestron Certified Wire: 18 AWG (0.75 MM ))
or 1.6 Ohms (Cresnet HP: 12 AWG (4 MM ))
P = Cresnet power usage of entire run (or chain)
2
2
L < 40,000
R x P
Where:
Make sure the cable length value is less than the value calculated on the right side of the equation. For example, a
Cresnet run using 18 AWG Crestron Certified Wire and drawing 20 watts should not have a length of run more than
333 feet (101 meters). If Cresnet HP is used for the same run, its length could extend to 1250 feet (381 meters).
NOTE: All Crestron certified Cresnet wiring must consist of two twisted pairs. One twisted pair is the +24V
conductor and the GND conductor and the other twisted pair is the Y conductor and the Z conductor.
Strip and Tin Wire
When daisy-chaining Cresnet units, strip the ends of the wires carefully to avoid nicking the conductors. Twist
together the ends of the wires that share a pin on the network connector and tin the twisted connection. Apply solder
only to the ends of the twisted wires. Avoid tinning too far up the wires or the end becomes brittle. Insert the tinned
connection into the Cresnet connector and tighten the retaining screw. Repeat the procedure for the other three
conductors.
Add Hubs
Use of a Cresnet Hub/Repeater (CNXHUB) is advised whenever the number of Cresnet devices on a network
exceeds 20 or when the combined total length of Cresnet cable exceeds 3000 feet (914 meters).
18 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A

CRESTRON GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT
Crestron Network Interconnect Diagram
CAUTION: Possible Equipment Damage if Miswired
To Control System
G
Z
Y
24 Front
View
To Network Device
24
Y
Z
G
Front
View
To Network Device
24
Y
Z
G
Front
View
Pair A
22 AWG Twisted
Blue = Z
White = Y
Pair B
18 AWG Parallel
Black = Ground
Red = 24 VDC
Shield
Do not power up system until all wiring is verified. Care should
be taken to ensure Data (Y & Z), and Power (24 & G)
connections are not crossed.
Ground Shield at the Control System end only.
Model CNTBLOCK network terminal expander and diagnostic
tool for the Cresnet system is recommended for testing purposes
and wiring convenience.
Crestron recommends the use of C2N-HBLOCK or CNTBLOCK as the
preferred method to daisy chain or expand the Cresnet network. If the blocks
are not available, use the method as shown.
NOTE:
Green
Green
Green
Installation Guide – DOC. 6887A GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT •19

Power Switching Cabinet GLPS-HDSW-FT CRESTRON GREEN LIGHT®EXPRESS
Crestron Network to Mini Network Interconnect Diagram
24
Y
Z
G
To Mini Network Device
Front
View
Front
View
To Network Device
24
Y
Z
G
Black
Blue
White
Red
Shield*
Red
White
Blue
Black
Wire Nuts &
Jumper Wires
CAUTION: Possible Equipment Damage if Miswired
Pair A
22 AWG Twisted
Blue = Z
White = Y
Pair B
18 AWG Parallel
Black = Ground
Red = 24 VDC
Do not power up system until all wiring is verified. Care should
be taken to ensure Data (Y & Z), and Power (24 & G)
connections are not crossed.
Ground Shield at the Control System end only.
Model CNTBLOCK network terminal expander and diagnostic
tool for the Cresnet system is recommended for testing purposes
and wiring convenience.
Jumper wires: Use #18 AWG. Use a wire nut that accomodates
all three wires.
To Control System
G
Z
Y
24 Front
View
Black
Green
Green
restron recommends the use of C2N-HBLOCK or CNTBLOCK as the
preferred method to daisy chain or expand the Cresnet network. If the blocks
are not available, use the method as shown.
NOTE: C
20 •GREEN LIGHT®EXPRESS Power Switching Cabinet GLPS-HDSW-FT Installation Guide – DOC. 6887A
