DO GUIDE
DO Connect the Device
Make connections to the CEN-SWPOE-16 using Crestron power supplies for Crestron
equipment.
CEN-SWPOE-16 Front Panel Connections
CEN-SWPOE-16 Rear Panel Connections
NOTE: Ensure that the unit is properly grounded by connecting the chassis ground lug to an
earth ground (building steel).
NOTE: To prevent overheating, do not operate this product in an area that exceeds the
environmental temperature range listed in the device’s table of specications on the Crestron
website.
DO Congure the Device
The CEN-SWPOE-16 provides a web-based conguration utility. For more information about
conguring the CEN-SWPOE-16, refer to the CEN-SWPOE-16 Supplemental Guide (Doc. 7408)
at www.crestron.com/manuals.
CEN-SWPOE-16
16-Port Managed PoE Switch
DO Install the Device
The Crestron®CEN-SWPOE-16 can be mounted into a rack or placed onto a at surface.
Mounting into a Rack
The CEN-SWPOE-16 occupies 1U of rack space. Using a #1 or #2 Phillips screwdriver, attach
the two included rack ears to the device and then mount the device into the rack using four
mounting screws (not included).
Placing onto a Flat Surface
When placing the device onto a at surface or stacking it with other equipment, attach the
included feet near the corners on the underside of the device.
DO Check the Box
QTY PRODUCT COLOR PART NUM.
2Bracket, Rack Ear, 1U 2032122
1 Power Cord, 6'7" (2 m) 4505164
4 Foot, 0.5" x 0.5" x 0.23", Adhesive Black 2002389
1 Cable, USB 2.0, A - B, 6' (1.83m) 2014966
COMPUTER:
To computer console
1-16:
To PoE or non-PoE
network devices
100–240 V, 50/60 Hz:
Power from line voltage
Ground

DO GUIDE DOC. 7941A (2047376) 09.16
Specications subject to change without notice.
DO Learn More
Visit the website for additional information and the latest rmware updates. To learn
more about this product, use a QR reader application on your mobile device to scan
the QR image.
Crestron Electronics
15 Volvo Drive, Rockleigh, NJ 07647
888.CRESTRON | www.crestron.com
As of the date of manufacture, the product has been tested and found to comply with specications for CE marking.
This product is Listed to applicable UL Standards and requirements by Underwriters Laboratories Inc.
Ce produit est homologué selon les normes et les exigences UL applicables par Underwriters Laboratories Inc.
Federal Communications Commission (FCC) Compliance Statement
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference
that may cause undesired operation.
CAUTION:Changes or modications not expressly approved by the manufacturer responsible for compliance could void the
user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not
occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
Industry Canada (IC) Compliance Statement
CAN ICES-3(B)/NMB-3(B)
Rack Mounting Safety Precautions
• Elevated Operating Ambient Temperature: If installed in a closed or multi-unit rack assembly, the operating ambient
temperature of the rack environment may be greater than room ambient temperature. Therefore, consideration should be
given to installing the equipment in an environment compatible with the maximum ambient temperature (Tma) specied by the
manufacturer.
• Reduced Airow: Installation of the equipment in a rack should be such that the amount of airow required for safe operation
of the equipment is not compromised.
• Mechanical Loading: Mounting of the equipment in the rack should be such that a hazardous condition is not achieved due to
uneven mechanical loading.
• Circuit Overloading: Consideration should be given to the connection of the equipment to the supply circuit and the effect that
overloading of the circuits might have on overcurrent protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
• Reliable Earthing: Reliable earthing of rack-mounted equipment should be maintained. Particular attention should be given to
supply connections other than direct connections to the branch circuit (e.g., use of power strips).
Electrical Connection
“This product must be connected to an earthed mains socket-outlet.”
• Finland: “Laite on liitettävä suojamaadoituskoskettimilla varustettuun pistorasiaan.”
• Norway: “Apparatet må tilkoples jordet stikkontakt.”
• Sweden: “Apparaten skall anslutas till jordat uttag.”
