Operations Guide - DOC. 6160 12 Inch Tilt/Lectern Touchpanels with Video: TPS-4500V & TPS-4500LV •1
12 Inch Tilt/Lectern
Touchpanels with Video:
TPS-4500V & TPS-4500LV
Introduction
Features and Functions
The TPS-4500V and TPS-4500LV (known collectively as the TPS-4500V/LV) series
packs all the power and performance of a Crestron Isys™ touchpanel in a stylish tilt
or lectern model. Its size and capabilities make it perfect for the conference room and
home theater.
TPS-4500V/LV Functional Summary
• 12" (30.5 cm) diagonal active matrix color display
• 800 x 600 native screen resolution
• 16 Bit non-palette graphics, over 64,000 colors
• 4 Mb of Flash, expandable to 32 Mb with Crestron®plug-in memory
modules & 8 Mb of DRAM memory
• Displays one NTSC/PAL/S-video/composite video source with 262,142
colors with the built-in TPS-VID/L-1 video card
• Up to 4,000 digital and analog signal joins; Up to 999 serial signal joins
• Local RS-232 port for console control
• Pop-up sub panels to reduce memory requirements, providing optimal
speed and performance
• Multiple button, slider control, and icon configurations, including
multi-mode objects
• Fast graphics performance: imported photographs, drawings, and icons
• Support for downloadable fonts – proportional and non-proportional
• Foreign language text
• Position Lock feature provides durable support of panel at any angle of
inclination between 30 and 80 degrees (TPS-4500V only)
The TPS-4500LV is available in two different colors: black, or white. The suffixes
‘B’ or ‘W’ respectively denotes color; i.e. TPS-4500LVB is a touchpanel with a
black faceplate. For simplicity within this guide, color suffix is omitted. The TPS-
4500 is black.

12 Inch Tilt/Lectern Touchpanels Crestron TPS-4500V & TPS-4500LV
Featuring a 12-inch (30.5 cm) active matrix display the TPS-4500V/LV uses the
65,536-color Isys engine, which allows all graphics to be displayed with incredible
brightness and depth.
Multiple graphics can be displayed on the TPS-4500V/LV without any shift in color
depth or quality. The touchpanel supports real-time video with the built-in
TPS-VID-1 (VIDL-1 for the 4500LV) video digitizer card.
The purpose of the TPS-4500V/LV touchpanel is to replace large, complicated hard-
wired panels in either a Cresnet®system or an RS-232 system with a series of
simpler screens each specific to the control problem at hand. Thus, a very large
number of functions can be made available to the user without the confusion
associated with hardware panels of that complexity. Icons, graphics, and text can
dramatically increase any user's comprehension of the control environment. Devices,
functions, and control zones are quickly organized and more easily accessed.
The TPS-4500V/LV has the ability to transmit touch coordinates when “RS-232 Port
for Touch Output” is selected. Currently Telestrator devices are supported on the
TPS-4500V/LV. Refer to the “RS-232 Menu” section of “Configuring the
Touchpanel” on page 13 and “Appendix C: Configuring the RS-232 Port for Use”
on page 45 for instructions on selecting this feature.
Specifications
The following provides a summary of specifications for the TPS-4500V/LV
touchpanel.
Specifications for the TPS-4500V/LV Touchpanel
SPECIFICATION DETAILS
Power Requirements 27 Watts (1.13 Amp @ 24 VDC)
Default Net ID 03
Timeout Adjustable from 0 to 120 minutes (Default = 15
min.)
Signal Join Maximums 4000 Digital and Analog, 999 Serial
Video Types NTSC or PAL
Video Formats Composite or S-video
Video Format Detection Within 2 seconds
Control System Update
Files,1,2,3
2-Series Control System Version C2-2004.CUZ or later2
CEN/CN-TVAV Version 51130V.UPZ or later4
CNMSX-AV/PRO Version 51125X.UPZ or later4
CNRACKX/-DP Version 51125W.UPZ or later4
ST-CP Version 4.00.49S.UPZ or later5
Touchpanel Firmware TPS.V.2.000.0.csf or later
Memory 4MB internal flash memory (upgradeable to
32MB), 8MB of DRAM6
Screen Dimensions 12"/30.1 cm diagonal
Screen Viewing Angles: Y Dir. (X=0o): +45o(from top), -55o(from bottom)
X Dir. (Y=0o): +60o(from right), -60o(from left)
(continued on next page)
2 •12 Inch Tilt/Lectern Touchpanels with Video: TPS-4500V & TPS-4500LV Operations Guide - DOC. 6160

Crestron TPS-4500V & TPS-4500LV 12 Inch Tilt/Lectern Touchpanels
Specifications for the TPS-4500V/LV Touchpanel (continued)
SPECIFICATION DETAILS
Screen Resolution 800 x 600 pixels
Color 16 Bit non-palette graphics with color key video
window capability, 65,536 colors
Display Type Touch-sensitive active matrix color LCD
Enclosure TPS-4500LV: Black metal enclosure with injection-
molded plastic faceplate in black or white
TPS-4500V: high impact, black molded plastic
enclosure
CPU 63MIPs Coldfire processor running Isys generation
firmware
Cresnet Via 4-pin Cresnet connector
RS-232 RJ-11 connector for console, telestrator, etc.
Default settings: 115200, 8 bit, parity none, stop
bit 1.
Operating Temperature
and Humidity
50º to 113º F (10º to 45º C),
10 to 90% Relative Humidity (non-condensing)
Dimensions and Weight
TPS-4500LV
(with faceplate)
Height: 11.04 in (28.05 cm)
Width: 13.43 in (34.11 cm)
Depth: 2.70 in (6.85 cm)
Weight: 6.0 lbs (2.75 kg)
TPS-4500V Height: 11.86 in (30.12 cm)
Width: 13.26 in (33.69 cm)
Depth: 11.17 in (28.36 cm)
Weight: 7.7 lbs (3.53 kg)
1 The latest versions can be obtained from the Downloads | Software Updates section of the Crestron
website (www.crestron.com). Refer to NOTE after last footnote.
2 Crestron 2-Series control systems include the AV2, CP2, CP2E, MP2, MP2E, PAC2, PRO2, and
RACK2.
3 CNX update files are required for either CNMSX-AV/PRO or CNRACKX/-DP. Filenames for CNX
update files have a UPZ extension and ST-CP files are in one EXE or zipped UPZ file. To avoid
program problems, make certain you are using the update file with the correct suffix letter (e.g., S,
V, W, X).
4 When loading VT Pro-e files or firmware through the RS-232 port of the control system, be sure that
the baud rate is at 38400 (Cresnet speed) or lower. Otherwise, the Viewport may post the "Transfer
Failed" message.
5 These control systems do not support loading of firmware or VT Pro-e files to the TPS-series panels
through the RS-232 port of the control system. In order to load these files to the touchpanel when
using these control systems use the RS-232 port on the TPS-4500V/LV.
6 Additional Flash memory can be purchased, refer to “Memory” on page 7. The complexity of the
control screens and the sampling of the WAV files influence memory usage.
NOTE: Crestron software and any files on the website are for Authorized Crestron
dealers and Crestron Authorized Independent Programmers (CAIP) only. New users
may be required to register to obtain access to certain areas of the site (including the
FTP site).
Operations Guide - DOC. 6160 12 Inch Tilt/Lectern Touchpanels with Video: TPS-4500V & TPS-4500LV •3

12 Inch Tilt/Lectern Touchpanels Crestron TPS-4500V & TPS-4500LV
Physical Description
The TPS-4500LV’s 12-inch (30.5-cm) touch sensitive viewing screen is located on
the front of the TPS-4500LV touchpanel, shown below and on the next page. The
electronic hardware is housed in a black metal enclosure. All video, RS-232, and
network connections are made at the rear of the unit. Two color bezels are available:
black (TPS-4500LVB) and white (TPS-4500LVW).
Physical Views of the TPS-4500LV Touchpanel (Front & Side)
2.70 in
(6.85 cm)
13.43 in
(34.11 cm)
7.26 in
(18.44 cm)
11.04 in
(28.05 cm)
9.68 in
(24.59 cm)
NOTE: For cutout dimensions, refer to “Appendix B: Cutout Detail of Supplied
Template” on page 44.
4 •12 Inch Tilt/Lectern Touchpanels with Video: TPS-4500V & TPS-4500LV Operations Guide - DOC. 6160

Crestron TPS-4500V & TPS-4500LV 12 Inch Tilt/Lectern Touchpanels
Physical Views of the TPS-4500LV Touchpanel (Rear and Bottom)
ROCKLEIGH, NJ 07647 USA
ELECTRONICS, INC.
3.25 in
(8.26 cm)
4.45 in
(11.31 cm)
3.25 in
(8.26 cm)
10.22 in
(25.97 cm)
The TPS-4500V’s 12-inch (30.5-cm) touch sensitive viewing screen is located on the
front of the TPS-4500V touchpanel. The electronic hardware is housed in a high
impact, black molded plastic enclosure, shown in the following diagram. This
touchpanel is designed for placement on a counter. It possesses a hinged base, which
can tilt from 30 to 80 degrees. Refer to “Position Lock Buttons (TPS-4500V only)”
on page 7 for tilting details. All RS-232, video, network, and power connections are
made at the rear panel on the base of the unit.
NOTE: Video and network signals are connected to either the TPS-4500IMPC or
TPS-4500IMW touchpanel interface modules. For more information on video
connections, refer to “Video” on page 18.
Operations Guide - DOC. 6160 12 Inch Tilt/Lectern Touchpanels with Video: TPS-4500V & TPS-4500LV •5

12 Inch Tilt/Lectern Touchpanels Crestron TPS-4500V & TPS-4500LV
Physical Views of the TPS-4500V Touchpanel (Front and Back)
11.86 in
(30.12 cm)
9.84 in
(25.00 cm)
13.26 in
(33.69 cm)
RS-232
NET/VIDEO
24VDC 2.0A
Physical Views of the TPS-4500V Touchpanel (Top and Bottom)
6.25 in
(15.86 cm)
0.95 in
(2.43 cm)
8.48 in
(21.53 cm)
10.56 in
(26.81 cm)
6.50 in
(16.51 cm)
Physical Views of the TPS-4500V Touchpanel (Side with Min. and Max. Angle)
11.17 in
(28.36 cm)
11.86 in
(30.12 cm)
8.26 in
(20.97 cm)
10.28 in
(26.12 cm)
1.80 in
(4.58 cm)
1.60 in
(4.07 cm)
TILT ANGLE
30 TO 80
DEGREES
6 •12 Inch Tilt/Lectern Touchpanels with Video: TPS-4500V & TPS-4500LV Operations Guide - DOC. 6160
