Introduction
Features and Functions
• Separate interface panel for use IM-WCVP iMedia Wall Plate Computer
Center with Video Control Panel1
• Connects to IM-WCVP to create IM-WCCV-S Wall Plate Computer
Center with Video using CresCAT™-IM iMedia cable or other high
quality CAT5 cable (up to 40 feet)2
• Connects PC and composite video (with audio) sources to iMedia systems
• Mounts in a standard, 2½ inch deep, double-gang electrical box
1. The IM-WCVI is part of the IM-WCCV-S. It must be used with the IM-WCVP.
2. For more information on CresCAT-IM cable, refer to “IM Wiring” on page 7.
The iMedia Transport
The iMedia transport utilizes a single CAT5e* type cable to transmit computer RGB,
video, and stereo audio signals to a single projector or plasma display. A typical
XGA signal (1024 X 768 pixels at 60Hz) can be transmitted up to 84 feet using
iMedia, while higher resolutions up to 1600 x 1200 can be handled over shorter
distances. Composite video signals can be transmitted up to 218 feet. Audio is
transmitted digitally at 20-bit, 48 kHz resolution. Control and power signals are also
contained on the same wire, eliminating the need for separate control or power
cables.
* For iMedia use CresCAT-IM cable, or quality CAT5e/CAT6 cable having a maximum delay skew
of 15ns per 100m.
2-Piece Wall Plate Multimedia Interface
The IM-WCCV-S is an iMedia (IM) transmitter featuring separate wall plates for
interface and control. The interface panel (IM-WCVI) is designed to install in a
Operations & Installation Guide – DOC. 6488 iMedia Wall Plate Interface: IM-WCVI •1

iMedia Wall Plate Computer Center with Video Interface Crestron IM-WCVI
standard 2-gang electrical box, providing video, RGB, and stereo audio inputs for
connection to the output of a computer or AV source. The control panel (IM-WCVP)
is a separate 1-gang wall plate, which may be installed up to 40 feet from the
interface panel.
Installing wiring for the IM-WCCV-S is extremely simple using CRESCAT-IM
cable. Up to three IM-WCCV-S's, or other IM transmitters, may be installed as part
of a complete system to provide multiple input locations within the room.
Foolproof Operation
Every iMedia system is easy and intuitive to use. A simple press of the VIDEO or
PC buttons on the control panel selects the appropriate input, turns on the projector
(or plasma, etc.), lowers the screen or lift, and routes all the signals where they need
to go. The volume control affords easy adjustment of the audio level, and the entire
system can be turned off at any time by simply holding down either button for five
seconds.
For systems having more than one IM transmitter, selecting an input at a given input
location overrides the previously selected input at any other location. The audio level
for each input location is controlled individually by its respective volume control.
Application
The IM-WCVI is part of the IM-WCCV-S iMedia transmitter. As shown in the
following diagram, iMedia transmitters provide input points for video and PC
sources on an iMedia receiver.
iMedia System Diagram
iMedia Receiver Display Device
iMedia
Transmitter
IM-TCC
IM-WCC
IM-FTCC-B
IM-RXV1
IM-RXV3
CresCAT-IM
Screen/Lift
Room Sensor
IR
Audio Amplifier
or Speakers
LAN
Control
RS-232 Control
IM-TCCV
IM-WCCV
IM-WCCV-S
IM-FTCCV*
Computer
Video
*IM-FTCCV available 3Q 2006
2 •iMedia Wall Plate Interface: IM-WCVI Operations & Installation Guide – DOC. 6488

Crestron IM-WCVI iMedia Wall Plate Computer Center with Video Interface
Specifications
Specifications for the IM-WCVI are listed in the following table.
IM-WCVI Specifications
SPECIFICATION DETAILS
Video Formats
RGB Video
Gain
Max. Input Voltage
Input Impedance
Resolutions
RGBHV (VGA), RGBS, RGsB, composite
R/G/B: 0 dB (unity gain, 75 ohm termination)
R/G/B: 1.0 VPP
H/V: 5 VPP
R/G/B: 75 Ohms
H/V: 1k Ohms
Supports videos up to XGA @ 60 Hz vertical
rate with maximum cable length of 84 feet and
maximum compensation at receiver. For
higher pixel resolutions (up to 1600 X 1200
pixels at 60 Hz vertical rate) refer to the chart
on page 8.
Composite Video
Gain
Max. Input Voltage
Input Impedance
Bandwidth
Composite: 0 dB (unity gain, 75 ohm
termination)
1.0 VPP
75 Ohms
> 100 MHz (-3 dB) at unity gain
Audio
Max. Input Level
Input Impedance
Audio Analog /
Digital conversion
Frequency Response
2 VRMS
10k Ohms
20-bit, 48 kHz
20 Hz to 20 kHz
Power Requirements Power is provided by the iMedia receiver
via the IM transport
Environmental
Temperature
Humidity
41° to 104°F (5° to 40°C)
10% to 90% RH (non-condensing)
Enclosure Requires 2.5 inch deep double-gang
electrical box
Dimensions
Height
Width
Depth
4.50 in. (11.43 cm)
4.56 in. (11.58 cm)
2.64 in. (6.71 cm)
Weight 14.7 oz. (417 g)
Operations & Installation Guide – DOC. 6488 iMedia Wall Plate Interface: IM-WCVI •3

iMedia Wall Plate Computer Center with Video Interface Crestron IM-WCVI
Physical Description
This section provides information on the connections, controls, and indicators
available on your IM-WCVI.
IM-WCVI Physical View
IM-WCVI Overall Dimensions
4.56 in.
(11.58 cm)
2.64 in.
(6.71 cm)
2.28 in.
(5.79 cm)
4.50 in.
(11.43 cm)
1
2
5
3
7
6
4
4 •iMedia Wall Plate Interface: IM-WCVI Operations & Installation Guide – DOC. 6488

Crestron IM-WCVI iMedia Wall Plate Computer Center with Video Interface
Connectors, Controls, & Indicators
# CONNECTORS,
CONTROLS, &
INDICATORS
DESCRIPTION
1 VIDEO
(1) RCA-type female connector for
composite video input.
2 AUDIO (R-L)
(1) Pair of RCA-type female connectors
for audio feed of composite video input.
3 TO IM-RXV
RECEIVER
(1) Female RJ-45 connector for iMedia
connection to IM-RXV1 or
IM-RXV3 receiver over CresCAT-IM
cable or other high-quality CAT5 wire.
For iMedia pin assignments, refer to the
chart on page 8.
4 TO IM-WCVP
CONTROL CENTER
Female RJ-45 port to connect to
IM-WCVP over CresCAT-IM wire or
other high-quality CAT5 wire (40 feet
maximum).
5 PC
(1) Female DB15HD connector is used
for connecting a computer’s RGB video
output to the display device.
The following table lists pin
assignments:
PIN FUNCTION PIN FUNCTION
1 Red Video 9 No Connect
2 Green Video 10 Ground
3 Blue Video 11 No Connect
4 Reserved 12 Monitor Sense
1
5 Ground 13 Horizontal Sync
6 Red Ground 14 Vertical Sync
7 Green Ground
8 Blue Ground
15 Monitor Sense
2
6 AUDIO (PC)
(1) 3.5mm female mini-jack connects to
audio output of PC.
7 GROUND WIRE Connect the flying lead to earth ground.
Operations & Installation Guide – DOC. 6488 iMedia Wall Plate Interface: IM-WCVI •5

iMedia Wall Plate Computer Center with Video Interface Crestron IM-WCVI
Industry Compliance
As of the date of manufacture, the IM-WCVI has been tested and found to comply
with specifications for CE marking and standards per EMC and
Radiocommunications Compliance Labelling.
NOTE: This device complies with part 15 of the FCC rules. Operation is subject to
the following two conditions: (1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may
cause undesired operation.
6 •iMedia Wall Plate Interface: IM-WCVI Operations & Installation Guide – DOC. 6488
