Crosley CF4503 User manual

Corner Credenza Pet Crate
CF4503

2
PART LIST
A B CD E
FG
Top
1 PC
Bottom Left Panel Door FrameRight Panel
1 PC 1 PC 1 PC 1 PC
Back Center Panel Back Panel
1 PC 2 PCS
HARDWARE LIST
#1 #2 #3 #4 #5
#6 #7
18 PCS (Extra 1) 6 PCS (Extra 1) 6 PCS (Extra 1) 6 PCS (Extra 1) 24 PCS (Extra 1)
1 PC 1 SET
Wood Dowel Bolt Spring Washer Flat Washer Screw
Allen Wrench Safety Strap Kit
Ø8 x 30mm Ø1/4" x 38mm Ø3 x 15mm
ADDITIONAL TOOLS (Not Provided)
Note: It is not recommended to use power tools during assembly.
Phillips Head Screwdriver
Note: Wood dowels are intended for alignment. Additional clearance
between wood dowel and pre-drilled hole is intentional for ease
of assembly.

3
Please do not use tools to assemble this unit unless specifically indicated.
Unlocked Locked
Step 1. Carefully lay top (part A) on a soft surface, such as carpet. Attach door frame
(part E) to top (part A) using wood dowels (part #1) and lock the hardware.
E
#1
A
E
#1 #1 #1 #1
A
#1 x 4
Reference the images above any time the instructions state "lock the hardware".
Note: Be sure to check all hardware is locked when completed.

4
Step 2. Attach left panel (part C) and right panel (part D) to top (part A) using wood
dowels (part #1) and lock the hardware.
A
#1
#1
D
C
#1 #1 #1
#1
#1 x 4
Step 3. Attach back center panel (part F) to top (part A) using wood dowel (part #1)
and lock the hardware.
A
F
F
A
#1
#1 x 1

5
Step 4. Attach bottom (part B) to assembled unit (parts C, D, E & F ) using wood
dowels (part #1), spring washers (part #3), flat washers (part #4), bolts (part #2)
and allen wrench (part #6).
#2
#3
#4
#2
#3
#4
#2
#3
#4
#2
#3
#4
#2
#3
#4
#2
#3
#4
#1
#1 #1 #1
#1
#1 #1 #1
#1
E
#2
#3
#4
#6
B
D
C
F
#1 x 9
#2 x 6
#3 x 6
#4 x 6
#6 x 1
Important: Safety strap kit (part #7) must be installed to prevent tipping, damage
Step 5. Carefully turn unit upright. Attach back panels (part G) to assembled unit
(parts A, B, C, D, & F) using screws (part #5) and phillips head screwdriver.
and / or injury.
Keep the hole
for safety strap
hardware
#5 x 24
#5
#5
A
F
B
G
C
G
D
A
F
G
A

6
Note: It is important to adjust levelers once fully assembled and upright. Extend
adjustable leveler until it's firmly in contact with the floor. If relocating, adjust
leveler as needed until it's firmly in contact with the floor in new location.

7
#7
1 SET
Safety Strap Kit
A B CD E
Washer Short Screw Long Screw
1 PC 2 PCS 1 PC 1 PC 1 PC
Wall Anchor Safety Wall
Strap
SAFETY WALL STRAP INSTALLATION
Note: It is highly recommended to install this safety strap kit to prevent tipping, damage
and/or injury
1.Insert short screw (C) through washer (B) and safety wall strap (E) and attach to top
(part A) using phillips head screwdriver.
2.Drill a 11/32" hole where you want to secure the unit. The drilled hole will be at the
same height as the hole in top (part A) where the safety wall strap (E) is attached.
Tap wall anchor (A) into the hole.
3.Insert long screw (D) through washer (B) and safety wall strap (E) into wall anchor
(A) using phillips head screwdriver.
Note: This item is not intended for clothing storage use.
WALL
WARNING
T V
!
Children have died from furniture
tipover.To reduce the risk of
furniture tipover:
. ALWAYS install tipover restraint
provided.
. NEVER put a TV on this product.
. NEVER allow children to stand,
climb or hang on drawers,doors,
or shelves.
. NEVER open more than one
drawer at a time.
. Place heaviest items in the
lowest drawers.
This is a permanent label.
Do not remove!
A
A
B
D
E
A
C
B
Ø8*3/4" Ø8*1-1/2"
