Crosley CF2002 User manual

F U R N I T U R E
Dining Table
CF2002

HARDWARE LIST
PART LIST
ABC
Table Top
1 PC Table Leaf
1 PC
Leg
4 PCS
#1 #2 #3
#4
1/4" 1/4"
Flat Washer
8 PCS([WUD
Spring Washer
8 PCS([WUD
M8 x 60mm
Bolt
8 PCS([WUD
M5
Allen Wrench
1 PC
ADDITIONAL TOOLS (Not Provided)
Note: It is not recommended to use power tools during assembly.
Phillips Head ScrewGriver
2

underneath table top (part A) and pull on opposite ends to separate.
using phillips head screwdriver.
Carefully turn table top (part A) upside down on a soft flat surface, such as carpet. Attach
legs (part C) to table top (part A) using flat washers (part #1), spring washers (part #2),
bolts (part #3) and allen wrench (part #4).
Note: Please fully tighten all bolts.
Figure 1#1
#3
#4
#2
#1 x 8
x 8
x 8
x 1
C
C
C
C
A
#2#3
#4
Step 2. Carefully turn unit upright. To insert table leaf (part B), unlock the clamp locks
Step 1. Before assembly remove two corner connectors (See Figure 1)

Note: Ensure clamp locks line up correctly when inserting table leaf (part B).
Step 3. Place table leaf (part B) in position and push table top (part A)
from both ends to close.
B
Step 4. Lock clamp locks underneath table top (part A) to secure.
