Crosswater LIBRA LB6117C Series User manual

1
LIBRA
IMPORTANT INFORMATION BEFORE YOU START
Please read carefully and keep this information for further reference.
Sanitaryware
i
PRODUCT CODES:
LB6117Cx - 35kg
LB6115Cx - 25kg
LB6105Cx - 2.5kg
Thank you for buying a Crosswater Product. To ensure that it
works to its full potential, it needs to be tted correctly.
Check the contents of the pack carefully before installation.
Crosswater will not be held responsible for any de-t/re-t
costs where faulty product has been tted. If any fault is
found with materials or workmanship, it must be reported
immediately to the manufacturer. Remedial action will be
taken, based on information received, on condition that:
1. Full details are supplied to the manufacturer.
2. The product has not been modied or tampered with;
3. The manufacturer is informed of any damage/shortages
prior to installation.
4. The product has not been installed, or attempts have been
made to install.
We do not accept responsibility for any problems that may
occur through incorrect installation. This product should
only be installed by a suitably qualied plumber/installer.
Should the installation be completed by a non-qualied
person any product guarantee maybe considered invalid. For
a claim made under our warranty, written certication of your
installer’s qualications may be required.
V1.05.2023

2
IMPORTANT INFORMATION
Please read carefully and keep this information for further reference.
i
Please check for any hidden pipes or electrical cables before drilling holes in the oor or walls. When using power tools always
follow the manufacturer’s user instructions. This installation guide details tting to a solid wall. If your bathroom has studded/
plasterboard walls, please use appropriate plasterboard xings.
Make sure that the wall can take the weight of the products before undertaking the installation.
Fittings, when over tightened can create stress within the basin material which may in time cause the failure of the product.
Care should also be taken when tting a tap and waste to the basin in order to prevent similar stress related failures. Waste
ttings should be carefully bedded in silicone and the back nut hand tightened; an additional quarter turn using a suitable
spanner is suicient to create the required watertight seal.
If any maintenance is required then it must be carried out by a qualied Plumber. The manufacturer reserves the right to make
technical modications without prior notice.
Drill + 8mm Drill Bit Pencil
Screw Driver
Tape Measure
Spirit Level
Adjustable Spanner
Safety Goggles
Tools Required (not supplied):
Water Based
Silicone Sealant

3
180mm
A
A-5mm
v
C
C
AB
C
INSTALLATION - WALL HUNG
12
3 4
Follow the manufacturer’s instructions for the installation
of the concealed cistern selected, ensuring the xing points
match the width of the wall hung toilet.
Measure distance A and reduce the depth of the bullets by
5mm to ensure a tight grip against the wall surface. Make sure
the bullet xings are facing up.
Push the inlet as far as possible into the toilet and mark the
distance on the pipe. Measurement A.
Then push the inlet into the concealed cistern as far as
possible and mark the distance on the pipe. Measurement B.
Measure the distance between both marks. Measurement C.
Finally, cut measurement C o the end of the inlet pipe before
securing the toilet to the wall. Follow the manufacturer’s
guidelines for applying grease to the seals
Place the toilet upside down and assemble the xing kit
on the toilet installation holes ensuring a tight t. The grub
screws should be facing up, so they can be accessed through
the toilet seat holes.
Place the toilet on the xings.
Secure the toilet to the concealed cistern and wall by
tightening the grub screws to the bullet xings.
Apply a exible sealant around the top and rear of the toilet
as shown, leave to dry for 24 hours before use.

4
B
B
A
A
AB
B
B
A
A
B
INSTALLATION - BACK TO WALL
Follow the manufacturer’s instructions for the installation of
the concealed cistern selected, ensuring the inlet and outlet
wastes match the measurements of the back to wall toilet.
Oer the toilet to its position and mark the location of the
side holes on the oor. Then remove the toilet and measure
the thickness of the ceramic at distance A. Install the toilet
oor xings.
Place the toilet back in position and secure to the oor xings
using the screws, washers and cover caps provided.
Apply a exible sealant around the base and rear of the toilet
as shown, leave to dry for 24 hours before use.
12
3

5
1 2 3
INSTALLATION - TOILET SEAT
Locate the xings on the toilet seat and tighten in the order
shown, using a screw driver. Do not over-tighten at this stage.
Insert the toilet seat into the xings and allow to so-close.
Move the seat into position, ensuring the sides and front are
ush with the toilet.
Once the position of the toilet seat is achieved, carefully
remove the toilet seat by pressing the central release button.
Avoid moving the xings whilst releasing the seat and tighten
the xings using a screw driver and moderate force. The
Cover caps can now be applied before returning the seat to its
position.
Do not force the toilet seat shut as this may damage the so-
close mechanism over time. Do not stand on the seat. When
cleaning the toilet, always leave the toilet seat open to allow
chemical gases to release. Do not leave harsh chemicals in the
toilet bowl with the seat lid closed.
12
4
3

6
Part of the
Bathroom Brands Group
Lake View House
Rennie Drive, Dartford
Kent DA1 5FU
United Kingdom
0345 873 8840
www.crosswater.co.uk
We reserve the right to make technical modications without prior notice.
Clean regularly using with warm soapy water and polish with only a so cloth.
Any residues from soap, toiletries etc. should be rinsed o straight aer use.
Household bleaches and cleaners containing harsh chemicals may damage the surface nish.
Avoid using abrasive cloths, scouring pads, scrub sponges, steel wool or anything similar.
Lime-scale marks can be cleaned using a diluted lime-scale remover used in accordance with manufacturers instructions.
CARE & MAINTENANCE
