Crosswater Fenmore 28-20-T User manual

Before beginning installation, check for any damage
that may have occurred during transport.
Note: Damage claims cannot be made during or
after installation.
For ease of installation you will need:
● To read the installation instructions completely before beginning.
● To read all warnings, care, and maintenance information.
● To complete the valve rough-in prior to installing this trim kit.
Installation Instructions
Fenmore
Dual Handle Thermostatic Trim With
Volume Control and Diverter
28-20-T
15125627
Adjustable PliersAdjustable Wrench
Tools You Will Need
Screwdriver

28-20-T
Installation Instructions
15125627 2
6
1
5
Slide on top plate on the finished
sleeve. If the top plate does not
engage the finished sleeve an
extension kit is necessary. Please
contact your Ammara Designs
distributor.
Ensure that the valve installed
correctly.
Turn off the water supply and remove
the mud guard.
Install escutcheon with 2 screws.
Do not overtighten the screws.
Thread on finished sleeve.
Slide on temperature control
escutcheon engaging the stem
making sure the temperature
override button facing straight up.
Secure with screw.
Set the volume control/diverter
handle and escutcheon at 12 o'clock
and place on the top stem and
nipple. Rotate the escutcheon
clockwise to secure the assembly to
the plate.
7
Align the handle at 6 o' clock position
and slide handle into escutcheon
and secure with set screw.
89
2 3
NOTE: Make sure the hole in the
stem is facing straight up. (This sets
the valve at 100ºF).
4

10
Turn on the water supply. Remove all
shower heads and/or hand showers.
Turn the volume control/diverter
handle to each function to flush the
system.
151256273
Rotate the cartridge stem to adjust
safety temperature. Rotate clockwise
to reduce temperature while rotate
anticlockwise to increase
temperature. Once the temperature
is 100ºF go to step #14.
Turn off the water supply. Remove
temperature control handle and
escutcheon.
100o
F
Safety
Temperature
11
Turn on the water supply, with the
temperature control handle in the
default position, measure the
temperature of the water. If the
temperature is 100ºF, go to step #15,
if not go to step #12.
100o F
Safety
Temperature
13
Reinstall the temperature control
handle and escutcheon making sure
the temperature override button is on
top and the handle is set at 6 o'clock.
Turn off the water supply. Remove
handle, escutcheon.
The valve maximum temperature is
set at 107ºF. Should your customer
like to change this go to step #16.
If not go to step #21.
107o F
Hottest
Temperature
15
Rotate the inner white temperature
range control ring to adjust
temperature. Rotate clockwise to
reduce temperature while rotate
counterclockwise to increase
temperature.
18
Remove the inner white temperature
range control ring.
17
12
14
16

Cleaning Instructions
Rinse away any traces of soap and gently dry with a clean, soft cloth after each use.
Rinse completely with water and dry any overspray. This will maintain the finish and avoid
water spotting.
To remove mineral deposits, use a 50/50 solution of white vinegar and water. Do not allow
the solution to soak on the product.
Simichrome Polish® contains a protective film to enhance maintenance and is helpful in
preventing water spot buildup. Follow instructions to ensure optimum results.
Never use an abrasive material such as a brush or scouring pad to clean the surface. The
use of abrasive cleaners, cleansers or disinfectants will alter the surface finish and void the
warranty.
Do not allow certain materials such as toothpaste, cologne, shaving cream, nail polish
remover, vinegar, wine, drain and glass cleaners to remain on the surface. Prolonged contact
will alter surface finishes and void the warranty.
We DO NOT recommend using any household cleaners as many can cause damage to
the finish.
Please see the website for care instructions for specific finishes.
Reinstall the inner white temperature
range control ring.
19
15125627 4
Installation completed.
21
Reinstall handle, escutcheon.
20

28-20-T
151256275
Replacement Parts
NO. Description Part NO.
4 Escutcheon 5L0073600
1
Handle Assembly 5Y0342300
2 O Ring 5R0R0294PL
Spring＆Button＆Pin 9Q11123
6 Handle Assembly 5Y0342200
Washer 5R4003700PL05
Hex Set Screw 9Q1356NT7
10 Screw M4X80 5T0F0266NT
8 Dome 5L0C0865
Washer 5R4Q0036PL9
12 Extension kit 9Q242000
13 Temperature Range Control Ring 5K202720PL
Escutcheon Assembly 5Y034470011
Washer 5R4004600PL0 14
12 13
Ordered Separately if needed
3
1
6
8
14
9
2
45
7
10 11

Issue date:02112022
Warranty - This Crosswater London product is covered by a limited lifetime warranty. For full details, terms and conditions please visit our website.
For further information contact:
Crosswater London, 393 Fortune Blvd., Milford, MA 01757
Toll free number: 844-XWATER-1 (844-992-8371) tel: [phone] fax: [phone]
www.crosswaterlondon.com
email: [email protected]
28-20-T
Applicable Standards/Codes
Installation Dimensions
IAPMO certified to meet or exceed the following:
• ASME A112.18.1/CSA B125.1
• Uniform Plumbing Code
• National Plumbing Code of Canada
• ADA Compliant
2-1/8 ＂ -2-5/8 ＂
2-3/4 ＂ -3-1/4 ＂
5 1/2 ＂- 6 5/16 ＂
2 3/4 ＂
8 11/16 ＂
7 5/16 ＂
4 5/16 ＂
3/4 ＂
15125627 6
2 15/16 ＂
2 3/16＂
1 3/4＂
